Circutor Master-Slave User manual

Master-Slave
INSTRUCTION MANUAL
(M247B01-03-22A)

URBAN MASTER - SLAVE
2Instruction Manual
Date Revision Description
02/19 M247B01-03-19A Initial Version
07/19 M247B01-03-19B Change of Logo and corporate colors
07/22 M247B01-03-22A Change in the following sections:
1.- 2.- 3.- 4.C.- 5.- 6.- 7.- 8.- 10.
Disclaimer
CIRCUTOR S.A.U. reserves the right to make modifications to the device or the unit specifications set
out in this instruction manual without prior notice.
CIRCUTOR S.A.U. on its web site, supplies its customers with the latest versions of the device speci-
fications and the most updated manuals.
www.circutor.com
Disclaimer
Revision log

URBAN MASTER - SLAVE
3Instruction Manual
Master-Slave
Instruction Manual
COPYRIGHT INFORMATION
This document is copyrighted, 2022 by CIRCUTOR S.A.U.. All rights are reserved. CIRCUTOR S.A.U. reserves the
right to make improvements to the products described in this manual at any time without notice.
No part of this manual can be reproduced, copied, translated or transmitted in any form or by any means without
the prior written permission of the original manufacturer. Information provided in this manual is intended to
be accurate and reliable. However, the original manufacturer assumes no responsibility for its use, or for any
infringements upon the rights of third parties that may result from its use.
All other product names or trademarks are properties of their respective owners.

URBAN MASTER - SLAVE
4Instruction Manual
Contents
Disclaimer ......................................................................................................................................2
Revision log....................................................................................................................................2
Contents.........................................................................................................................................4
1. So, hello! ................................................................................................................................................ 6
2. Features................................................................................................................................................. 8
3. How to use it? ......................................................................................................................................12
A. General............................................................................................................................... 12
B. Language ........................................................................................................................... 14
C. Starting a charging session............................................................................................... 15
D. Special events starting a charge.......................................................................................18
E. Stopping a charging session ............................................................................................ 20
F. Charge information ............................................................................................................ 21
G. Charge summary................................................................................................................22
H. Emergency button.............................................................................................................23
I. Connector status.................................................................................................................24
J. Errors ..................................................................................................................................25
4. How to connect it?.............................................................................................................................. 28
A. Network topology ............................................................................................................. 28
B. Introduction .......................................................................................................................29
C. IPSetup.............................................................................................................................. 30
5. Communications................................................................................................................................. 34
A. Introduction .......................................................................................................................34
B. Modem configuration ........................................................................................................35
6. Setup Webpage...................................................................................................................................50
A. Dashboard......................................................................................................................... 50
B. Monitor...............................................................................................................................52
C. Historic ...............................................................................................................................53
D. Integrations .......................................................................................................................54
E. Configuration .................................................................................................................... 55
F. Maintenance...................................................................................................................... 68
7. OCPP 1.5 ............................................................................................................................................... 72
A. Introduction .......................................................................................................................72
B. Before starting...................................................................................................................73
C. Configuration .....................................................................................................................75
8. OCPP 1.6 .............................................................................................................................................. 84
A. Introduction ...................................................................................................................... 84
B. Before starting.................................................................................................................. 85
C. Configuration .................................................................................................................... 86
9. Monitoring........................................................................................................................................... 96
10. Technical Data ................................................................................................................................... 98
A. AC Charge.......................................................................................................................... 98
B. DC Charge ........................................................................................................................100
Need help?.................................................................................................................................103
Guarantee...................................................................................................................................103

URBAN MASTER - SLAVE
5Instruction Manual

URBAN MASTER - SLAVE
6Instruction Manual
This manual provides information about the usability and configuration of the Master-Slave solution,
which has been designed and tested to allow electric vehicle charging, specified in IEC 61851.
It contains all the necessary information for safe use and help to get the best performance from it
with step-by-step configuration instructions.
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
SAFETY INFORMATION IN THIS DOCUMENT
ATTENTION!
Indicates that the damage to property can occur if appropiate
precautions are not taken.
ELECTRICAL RISK
Necessary precautions shall be taken to prevent any electrical risk
while the operations are carried out within the device.
Device must be disconnected from any power source during
commissioning.
1So, hello!

URBAN MASTER - SLAVE
7Instruction Manual
IMPORTANT SAFETY INFORMATION
Read carefully all the instructions before starting in order to ensure
properly installation of the Charge Point.
• Do not use the Charge Point for anything
other than electric vehicle charging modes
which are defined in IEC 61851-23.
• Do not modify the Charge Point. If modified,
CIRCUTOR will reject all responsibility and
the warranty will be void.
• Comply strictly with electrical safety
regulations according to your country.
• Do not make repairs or manipulations with
the unit energised.
• Only trained and qualified personnel
should have access to electrical parts
inside the Charge Point.
• Check the installation annually by a
qualified technician.
• Remove from service any item that has
a fault that could be dangerous for users
(broken connectors, caps that don’t
close...).
• Use only CIRCUTOR supplied spare parts.
• Do not use this product if the enclosure or
the EV connector is broken, cracked, open,
or shows any other indication of damage.
• Adaptors or conversion adapters and cord
extensions set are NOT allowed to be
used.
• The device does not emit noise,
ultrasounds, electromagnetic fields and
does not produce harmful substances,
thanks to which it can be operated in the
environment.
• Pay attention to traffic in busy streets.
• Waste generated after the disassembly
of a waste device or a device taken out
of service is handed over to a person
conducting activity in the field of recycling
or conducting activity in the field of
recovery processes.
Refer to TECHNICAL DATA section for more information about environmental installation conditions.
1So, hello!

URBAN MASTER - SLAVE
8Instruction Manual
Master
Able to be configured for multi-point solutions.
• HMI: 8’’ colour touch screen as the interface between the Charge Point and the user. Provides
detailed information about ongoing charge transactions and the instructions of how to interact
with the Charge Point.
• Connector Lock: To avoid disconnection of EV meanwhile is charging.
• Light beacon: Three LED colour indicate all connector status (free, error, charging or completed)
at a glance.
• RFID: User authentication.
• Ethernet: TCP/IP communication for remote supervision and configuration.
• 4G Modem (optional): For those places where wired communications are not enough.
• Energy metering: Integrated meter built is measuring power and energy consumed by the EV
during a charge transaction.
• Remote access: For supervision and control from everywhere.
• Charge transaction historics: Charge Point is capable of storing information about the charge
transactions.
• OCPP: Open standard communication protocol, allows communication between the Charge Point
and the Central System.
• Key lock access: Security that does not enable access to the inside of the charger.
• Built-in courtesy light(1):Facilitates locating the charge point in dark areas and reading the
operator instructions.
• Integrated payment system (optional): Availability for contactless card payment.
(1) Availability depending on the model.
2Features

URBAN MASTER - SLAVE
9Instruction Manual
Slave
• Connector Lock: Available lock system to avoid disconnection of EV meanwhile is charging.
• Light beacon: Three LED colour indicate all connector status (free, error, charging or completed)
at a glance.
• Energy metering: Integrated meter built is measuring power and energy consumed by the EV
during a charge transaction.
• Remote access: For supervision and control from everywhere.
• Charge transaction historics: Charge Point is capable of storing information about the charge
transactions.
• Key lock access: Security that does not enable access to the inside of the charger.
2Features

URBAN MASTER - SLAVE
10 Instruction Manual
Master-Slave combination
The following table shows the possible combinations of Charge Point that can work as Masters or
as Slaves:
MASTERS SLAVE TYPE OF CHARGE
URBAN Slave M2 AC
URBAN Slave T2 AC
URBANWB Slave M2 AC
URBANWB Slave T2 AC
URBAN Master M2 AC
URBAN Master T2 AC
URBANWB Master M2 AC
URBANWB Master T2 AC
Raption 50 DC
Raption 50 HV DC
Raption 50 EVO DC
Raption 100 DC
Raption 150 DC
Raption 150 C DC
URBAN Master CCS2 DC
URBAN Slave CCS2 DC
URBAN-WB Slave CCS2 DC

URBAN MASTER - SLAVE
11Instruction Manual
Outlets for each Master
We have different possibilities to be part of the Master-Slave solution, with a maximum of 18 outlets,
taking into account that 1 DC outlet equals to a 3 AC outlets.
The following picture shows some of the many possible combinations that can be part of the Mas-
ter-Slave solution(2):
(2) Number of Slaves outlets up to 18 AC.

URBAN MASTER - SLAVE
12 Instruction Manual
A General
The first time the Charge Point is powered on, the system will take around 10 seconds to start up,
the screen will show next image:
In the lower right corner, the firmware version is shown. After 10 seconds, the first screen that
appears is the screensaver.
3How to use it?

URBAN MASTER - SLAVE
13Instruction Manual
When tapping on the screen, the HMI will skip to the next one(3):
At this new screen, the Charge Point is asking for showing the identification method the user is going
to use in order to start a charge transaction, as you can see there are four possible options.
- Choosing RFID, Code Reader or keyboard options, are the options that will let to initiate a ‘Charging
session’to the user that has the identification card, has been registered in advance or a code has
been given to type it manually in the screen.
- Paying by a debit or credit card, that will let to initiate a ‘Charging session’ to the user without
been registered in advance.
In the lower right corner, it shows the connectors status and the charging process so as to know the
Charge Point availability.
(3) Depending on the optionals chosen, the identification methods available can vary.
iIf some Charge Point do not have the latest firmware update, the term
‘slave’ may appear instead of ‘satellite’.
3How to use it?

URBAN MASTER - SLAVE
14 Instruction Manual
B Language
During all the process is possible to change language, pressing on the top of the screen over the
‘Flag’ touch symbol:
The language can be chosen by tapping on the corresponding flag.
This option will allow user to change the language ONLY for the current Charge Transaction. When
Charge Point returns to main or standby screen, it will return the default language,which is configured
in the Setup Webpage.
iThe availability of the different languages is subject to the firmware
version.
In case of doubt, please consult your local supplier.

URBAN MASTER - SLAVE
15Instruction Manual
C Starting a charging session
Once the identification card is shown, it may take a few seconds to authorise the access.
The HMI informs if the access is granted or not.

URBAN MASTER - SLAVE
16 Instruction Manual
If the user is authorised, the connector can be chosen.
At any time it is possible to tap this button in order to go back
to the ‘identification screen’.
Once the connector is chosen, instruction screens will appear successively.
1- Connect your vehicle and press the ‘Start’ button
At any time is possible to tap this button in order to go back
to the previous screen.

URBAN MASTER - SLAVE
17Instruction Manual
2- Checking vehicle connection… Please wait
In a few seconds, the charging session will start and the HMI will show the charging process.
Tap this button in order to go back to the ‘identification
screen’.

URBAN MASTER - SLAVE
18 Instruction Manual
D Special events starting a charge
‘Not authorized’: some Charge Points could be working under the supervision of a main management
system. If the user is not authorized, the HMI will show the following message:
‘Authorization failed’: the authorization could not be completed due to some communication
problem with the Back Office.

URBAN MASTER - SLAVE
19Instruction Manual
It is possible that the Charge Session could not be started due to some unexpected reason. The HMI
will show next screen, press ‘Retry’ button and try again.

URBAN MASTER - SLAVE
20 Instruction Manual
E Stopping a charging session
After showing the same identification card that started the Charging Session, the Charge Point will
automatically allow to stop the charging session, press over the ‘Stop’ button:
Once the charging session is stopped, the HMI shows the summary screen.
