Cisco DPC2434 Operating instructions

78-4011351-01 Rev B
Model DPC2434 and EPC2434 VoIP Wireless
Home Gateways
Installation and Operation Guide

Please Read
Important
Please read this entire guide. If this guide provides installation or operation
instructions, give particular attention to all safety statements included in this guide.

Notices
TrademarkAcknowledgements
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco
and/or its affiliates in the U.S. and other countries. A listing of Cisco's
trademarks can be found at www.cisco.com/go/trademarks.
CableHome, DOCSIS, EuroDOCSIS, EuroPacketCable, and PacketCable are
trademarks or registered trademarks of Cable Television Laboratories, Inc.
Other third party trademarks mentioned are the property of their respective
owners.
The use of the word partner does not imply a partnership relationship between
Cisco and any other company. (1110R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Copyright
© 2007, 2013 Cisco and/or its affiliates. All rights reserved. Printed in the United States of
America.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.

IMPORTANT SAFETY INSTRUCTIONS
78-4011351-01 Rev B v
IMPORTANT SAFETY INSTRUCTIONS
Notice to Installers
The servicing instructions in this notice are for use by qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing other than that contained in the operating
instructions, unless you are qualified to do so.
20070112 SysInstaller 820 English
Notice à l’attention des installateurs de réseaux câblés
Les instructions relatives aux interventions d’entretien, fournies dans la présente notice, s’adressent
exclusivement au personnel technique qualifié. Pour réduire les risques de chocs électriques, n’effectuer
aucune intervention autre que celles décrites dans le mode d'emploi et les instructions relatives au
fonctionnement, à moins que vous ne soyez qualifié pour ce faire.
20070112 SysInstaller 820 French

IMPORTANT SAFETY INSTRUCTIONS
vi 78-4011351-01 Rev B
Mitteilung für CATV-Techniker
Die in dieser Mitteilung aufgeführten Wartungsanweisungen sind ausschließlich für qualifiziertes
Fachpersonal bestimmt. Um die Gefahr eines elektrischen Schlags zu reduzieren, sollten Sie keine
Wartungsarbeiten durchführen, die nicht ausdrücklich in der Bedienungsanleitung aufgeführt sind,
außer Sie sind zur Durchführung solcher Arbeiten qualifiziert.
20070112 SysInstaller 820 German
Aviso a los instaladores de sistemas CATV
Las instrucciones de reparación contenidas en el presente aviso son para uso exclusivo por parte de
personal de mantenimiento cualificado. Con el fin de reducir el riesgo de descarga eléctrica, no realice
ninguna otra operación de reparación distinta a las contenidas en las instrucciones de funcionamiento, a
menos que posea la cualificación necesaria para hacerlo.
20070112 SysInstaller 820 Spanish

IMPORTANT SAFETY INSTRUCTIONS
78-4011351-01 Rev B vii
Read These Instructions
Keep These Instructions
HeedAll Warnings
FollowAllInstructions
PowerSourceWarning
A label on this product indicates the correct power source for this product. Operate this product only
from an electrical outlet with the voltage and frequency indicated on the product label. If you are
uncertain of the type of power supply to your home or business, consult your service provider or your
local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING:
Avoid electric shock and fire hazard! Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
If this product connects to coaxial cable wiring, be sure the cable system is grounded (earthed). Grounding provides
some protection against voltage surges and built-up static charges.
Protect the Product from Lightning
For added protection, unplug this apparatus during lightning storms or when unused for long periods
of time. In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the Power Source from the On/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the power
source. The light goes out when the apparatus is turned off, regardless of whether it is still plugged into
an AC power source.
EliminateAC MainsOverloads
WARNING:
Avoid electric shock and fire hazard! Do not overload AC mains, outlets, extension
cords, or integral convenience receptacles. For products that require battery power or
other power sources to operate them, refer to the operating instructions for those
products.

IMPORTANT SAFETY INSTRUCTIONS
viii 78-4011351-01 Rev B
Prevent Power Cord Damage
Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where the cord exits from the apparatus.
Handling Optional, Rechargeable Battery
This product may contain a rechargeable Lithium-Ion battery to provide stand-by operation in the
event of an AC power failure. Heed the following warning and see the instructions later in this guide
for handling, replacing, and disposing of the battery.
WARNING:
There is danger of explosion if the battery is mishandled or incorrectly replaced.
Replace only with the same type of battery. Do not disassemble it or attempt to
recharge it outside the system. Do not crush, puncture, dispose of in fire, short the
external contacts, or expose to water or other liquids. Dispose of the battery in
accordance with local regulations and instructions from your service provider.
Provide Ventilation and Select a Location
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
Do not place this apparatus on a bed, sofa, rug, or similar surface.
Do not place this apparatus on an unstable surface.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the installation
provides proper ventilation.
Do not place entertainment devices (such as VCRs or DVDs), lamps, books, vases with liquids, or
other objects on top of this product.
Protect from Exposure to Moisture and Foreign Objects
Do not use this apparatus near water.
WARNING:
Avoid electric shock and fire hazard! Do not expose this product to liquids, rain, or
moisture.
WARNING:
Avoid electric shock and fire hazard! Unplug this product before cleaning. Clean only
with a dry cloth. Do not use a liquid cleaner or an aerosol cleaner. Do not use a
magnetic/static cleaning device (dust remover) to clean this product.
WARNING:
Avoid electric shock and fire hazard! Never push objects through the openings in this
product. Foreign objects can cause electrical shorts that can result in electric shock or
fire.

IMPORTANT SAFETY INSTRUCTIONS
78-4011351-01 Rev B ix
Accessories Warning
WARNING:
Avoid electric shock and fire hazard! Only use attachments/accessories specified by
your service provider or the manufacturer.
Service Warnings
WARNING:
Avoid electric shock! Do not open the cover of this product. Opening or removing the
cover may expose you to dangerous voltages. If you open the cover, your warranty will
be void. This product contains no user-serviceable parts. Refer all servicing to
qualified service personnel.
Servicing is required when the apparatus has been damaged in any way, such as a power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
Check Product Safety
Upon completion of any service or repairs to this product, the service technician must perform safety
checks to determine that this product is in proper operating condition.
Protect the Product when Moving It
Always disconnect the power source when moving the apparatus or connecting or disconnecting
cables.
WARNING:
Avoid personal injury and damage to this product! Use only with the cart, stand,
tripod, bracket, or table specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart / apparatus combination to
avoid injury from tip-over.
20070320 Modem Cable with Recharge Battery

FCC Compliance
78-4011351-01 Rev B xi
FCC Compliance
United States FCC Compliance
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against such interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the cable company or an experienced radio/television technician for help.
Any changes or modifications not expressly approved by Cisco Systems, Inc., could void the
user's authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph below is a
requirement of the FCC and is intended to supply you with information regarding the FCC
approval of this device. The phone numbers listed are for FCC-related questions only and not
intended for questions regarding the connection or operation for this device. Please contact your cable
service provider for any questions you may have regarding the operation or installation of this device.
DeclarationofConformity
This device complies with Part 15 of FCC
Rules. Operation is subject to the following two
conditions: 1) the device may not cause
harmful interference, and 2) the device must
accept any interference received, including
interference that may cause undesired
operation.
VoIP Wireless Home Gateway
Model: DPC2434 and EPC2434
Manufactured by:
Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: [phone]
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme NMB-003 du Canada.

FCC Compliance
xii 78-4011351-01 Rev B
FCCPart68
The Federal Communications Commission (FCC) of the United States restricts specific uses of
modems, and places registration responsibilities on both the manufacturer and the individual
user.
1The modem may not be connected to a party line or to a coin-operated telephone.
2Notification to the telephone company is no longer required prior to connecting
registered equipment, but upon request from the telephone company, the user shall tell
the telephone company which line the equipment is connected to as well as the
registration number and ringer equivalence number of the registered protective circuitry.
FCC information is printed on a label on the bottom of the modem.
IC (Industry Canada) Notice
Notice: The Industry Canada (formerly Canadian Department of Communications) label
identifies certified equipment. This certification means that the equipment meets certain
telecommunications network protective, operational, and safety requirements. The
department does not guarantee the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to
the facilities of the local telecommunications company. The equipment must also be installed
using an acceptable method of connection. In some cases, the company's inside wiring
associated with a single-line individual service may be extended by means of a certified
connector assembly (telephone extension cord). The customer should be aware that
compliance with the above conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance
facility designated by the supplier. Any repairs or alterations made by the user may give the
telecommunications company cause to request the user to disconnect the equipment. Users
should ensure for their own protection that the electrical ground connections of the power
utility, telephone lines and internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural areas.
CAUTION:
Users should not attempt to make such connections themselves, but should
contact the appropriate electric inspection authority, or electrician, as
appropriate.
20060319 FCC DSL

FCC Compliance
78-4011351-01 Rev B xiii
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. To maintain compliance with the FCC RF exposure
guidelines, this equipment should be installed and operated with minimum distance
of at least 7.8 in. (20cm) from all persons.

78-4011351-01 Rev B iii
Contents
IMPORTANT SAFETY INSTRUCTIONS v
FCC Compliance xi
FCC Radiation Exposure Statement...................................................................................xiii
About This Guide v
Chapter 1 Introducing the Model DPC2434 and EPC2434 VoIP
Wireless Home Gateways 1
DPC2434 and EPC2434 Features............................................................................................ 2
DPC2434 and EPC2434 Components.................................................................................... 4
Theory of Operation ................................................................................................................ 9
Chapter 2 Installing the DPC2434 and EPC2434 for Internet
Service 15
Before You Begin.................................................................................................................... 16
Install the Wireless Home Gateway.................................................................................... 20
Configure TCP/IP.................................................................................................................. 22
Install USB Drivers ................................................................................................................ 25
Chapter 3 Installing the DPC2434 and EPC2434 for Telephone
Service 27
Telephone Requirements ...................................................................................................... 28
About the Battery................................................................................................................... 29
Mount the Cable Modem on a Wall (Optional)................................................................. 31
Install the Cable Modem to Provide Telephone Service .................................................. 33
Chapter 4 Troubleshooting the Installation 37
Functions of Front Panel LED Status Indicators................................................................ 39
Powering Options .................................................................................................................. 42
No Downstream Signal Lock ............................................................................................... 44
Ranging Not Complete ......................................................................................................... 46
IP Connectivity Not Complete............................................................................................. 48
Registration Not Complete................................................................................................... 50

Contents
iv 78-4011351-01 Rev B
Having Difficulty? ................................................................................................................. 52
Troubleshooting for Telephony Installations..................................................................... 56
Chapter 5 Operating the DPC2434 and EPC2434 59
WebWizard ............................................................................................................................. 60
Display Basic Wireless Home Gateway Information........................................................ 63
Display Network Communication Status .......................................................................... 67
Display Cable Modem Operational Status......................................................................... 68
Display the Cable Modem Log ............................................................................................ 69
Display the EMTA State........................................................................................................ 70
Display the Default Web Page ............................................................................................. 71
Display the Scan Page (Frequency Values) ........................................................................ 72
Appendix A Specifications 73
Technical Specifications ........................................................................................................ 74
Appendix B Cable Modem Warranty and RMA Information 87
Warranty and RMA Information......................................................................................... 88

About This Guide
78-4011351-01 Rev B v
About This Guide
Introduction
This installation and operation guide applies to the Model DPC2434 and the Model
EPC2434 Voice over Internet Protocol (VoIP) Wireless Home Gateways. The
DPC2434 and EPC2434 are equipped with an embedded multimedia terminal
adapter (EMTA) that includes two RJ-11 telephone ports supporting two-line voice
services, a 10/100BaseT Ethernet port, and a USB 2.0 port for high-speed data
connectivity.
The DPC2434 is compatible with the following specifications:
Data Over Cable System Interface Specifications (DOCSIS) 2.0, 1.1, 1.0
PacketCable 1.5 and 1.0
CableHome 1.1
The EPC2434 is designed for the following specifications:
EuroDOCSIS 2.0, 1.1
EuroPacketCable 1.0
CableHome 1.1
Scope
This guide provides the following design, performance, and technical information
for understanding basic VoIP and cable modem operation and function to
familiarize you with the DPC2434 and EPC2434:
Design and performance features
Theory of operation for cable modems
Procedures for installing, operating, maintaining, and troubleshooting the
DPC2434 and EPC2434 using the Cable Modem Access Protection and
WebWizard features
Appendixes that include technical specifications
Note: This guide does not contain installation procedures for cable modem headend
equipment. Consult the documentation supplied with your equipment for the
correct installation procedures.

About This Guide
vi 78-4011351-01 Rev B
Purpose
After reading this guide, you will be able to install, operate, maintain, and
troubleshoot the DPC2434 and EPC2434.
Audience
This guide is written for cable service providers, system operators, cable modem
installers, system engineers, customer service representatives, cable modem
marketing personnel, and Cisco Service engineers.
Related Documents (for Cable Service Providers Only)
You can access other cable modem documents at the following Web site:
https://www.cisco.com
Document Version
This is the second release of this document.

78-4011351-01 Rev B 1
Introduction
The Model DPC2434 and EPC2434 Wireless Home Gateways provide
broadband network operators with a cost-effective way to offer
standard telephone service along with high-speed data services to
subscribers. The DPC2434 and EPC2434 feature a highly integrated
embedded multimedia terminal adapter (EMTA) with two RJ-11
telephony ports for conventional telephones or fax machines. In
addition, the DPC2434 and EPC2434 contain both a 10/100BaseT
Ethernet port and a USB 2.0 port to provide connectivity for high-
speed data services or other Internet appliances. An optional model of
the DPC2434 includes an internal Lithium-Ion cartridge-style battery
for convenient backup power.
This chapter provides an overview of the outstanding design and
performance features of the DPC2434 and EPC2434, the front and back
panel components, and a theory of operation for cable modems for
successful installation and operation. This chapter also provides the
requirements for the cable system and the subscriber’s site.
1Chapter 1
Introducing the Model
DPC2434 and EPC2434 VoIP
Wireless Home Gateways
In This Chapter
DPC2434 and EPC2434 Features........................................................... 2
DPC2434 and EPC2434 Components................................................... 4

Theory of Operation ............................................................................... 9

Chapter 1 Introducing the Model DPC2434 and EPC2434 VoIP Wireless Home Gateways
2 78-4011351-01 Rev B
DPC2434 and EPC2434 Features
This section contains an overview of some of the design and performance features of
the DPC2434 and EPC2434.
Design and Performance Features
The DPC2434 is designed to meet DOCSIS 2.0, 1.1, and 1.0 specifications along with
PacketCable 1.5, PacketCable 1.0, and CableHome 1.1 specifications.
The EPC2434 is designed for compatibility with EuroDOCSIS 2.0 and 1.1 along with
EuroPacketCable 1.0 and CableHome 1.1.
The following list provides some of the outstanding design and performance
features of the DPC2434 and EPC2434:
Attractive compact design
EMTA that provides two lines of voice services
One or two internal cartridge-style Lithium-Ion batteries provide backup power
for operation in the event of an AC power failure (optional models only)
802.11g Wireless Access Point
Integrated router featuring NAT, DHCP server, and parental control technology
Standard VoIP call signaling, compliant with MGCP/NCS specifications
Software upgrades available to support session initiation protocol (SIP) call
signaling
G.711 and G.728 codecs (other codecs are available upon request)
Echo cancellation
Voice activation detection (VAD)
Comfort noise generation (CNG)
WebWizard browser-based graphical user interface for simple setup
Front-panel LED status indicators provide an easy-to-understand display that
shows cable modem status and real-time data transmission activity
Lockdown mode prevents unauthorized or accidental reset of gateway settings
Internet Protocol Security (IPSec) and AES-128 encryption options
IPsec VPN termination
Downloadable software for future upgrades
Bridged 10/100BaseT auto-sensing/auto-MDIX 4-port Ethernet switch
