Installing the Cisco RPS Adapter Plate

in Cisco 2600 Series Routers

Product Number: ACS-2600RPS=

This document describes how to install an adapter plate in Cisco 2600 series routers for use with the

Cisco Redundant Power System (RPS). The Cisco RPS provides power system redundancy to

external devices (such as routers, switches, or hubs). The system includes two fully redundant AC

input power modules and four DC output power modules for connection to external devices. The

Cisco RPS supports quasi-redundant and fully redundant power source conﬁgurations. To use the

Cisco RPS with Cisco 2600 series routers, you must remove the existing power supply and replace

it with a Cisco RPS adapter plate.

This document includes the following sections:

•Safety Recommendations on page 1

•Required Tools and Equipment on page 4

•Removing the Cover on page 5

•Removing the Power Supply on page 7

•Installing the Redundant Power Supply Adapter Plate on page 8

•Obtaining Service and Support on page 11

•Cisco Connection Online on page 11

•Ordering Documentation on page 12

Safety Recommendations

Follow these guidelines to ensure general safety:

•Keep the chassis area clear and dust-free during and after installation.

•Put the removed chassis cover in a safe place.

78-5172-01

2Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Safety Recommendations

•Keep tools away from walk areas where you or others could fall over them.

•Do not wear loose clothing that could get caught in the chassis. Fasten your tie or scarf and roll

up your sleeves.

•Wear safety glasses when working under any conditions that might be hazardous to your eyes.

•Do not perform any action that creates a potential hazard to people or makes the equipment

unsafe.

Safety Warnings

Safety warnings appear throughout this publication in procedures that, if performed incorrectly,

might harm you. A warning symbol precedes each safety warning.

Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before

you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with

standard practices for preventing accidents.

Waarschuwing Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die

lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust

te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van

standaard maatregelen om ongelukken te voorkomen.

Varoitus Tämävaroitusmerkkimerkitseevaaraa.Olettilanteessa,joka voijohtaaruumiinvammaan.

Ennen kuin työskentelet minkään laitteiston parissa, ota selvää sähkökytkentöihin liittyvistä

vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista.

Attention Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation

pouvant causer des blessures ou des dommages corporels. Avant de travailler sur un équipement,

soyez conscient des dangers posés par les circuits électriques et familiarisez-vous avec les

procédures couramment utilisées pour éviter les accidents.

Warnung Dieses Warnsymbol bedeutet Gefahr. Sie beﬁnden sich in einer Situation, die zu einer

Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie

sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur

Vermeidung von Unfällen bewußt.

Avvertenza Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare

infortuni alle persone. Prima di lavorare su qualsiasi apparecchiatura, occorre conoscere i pericoli

relativiaicircuitielettrici edessere alcorrente delle pratiche standard per la prevenzionedi incidenti.

Advarsel Dette varselsymbolet betyr fare. Du beﬁnner deg i en situasjon som kan føre til

personskade. Før du utfører arbeid på utstyr, må du vare oppmerksom på de faremomentene som

elektriske kretser innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å unngå ulykker.

Aviso Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos

físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos

relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir

possíveis acidentes.

¡Advertencia! Este símbolo de aviso signiﬁca peligro. Existe riesgo para su integridad física.

Antes de manipular cualquier equipo, considerar los riesgos que entraña la corriente eléctrica y

familiarizarse con los procedimientos estándar de prevención de accidentes.

Varning! Denna varningssymbol signalerar fara. Du beﬁnner dig i en situation som kan leda till

personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med

elkretsar och känna till vanligt förfarande för att förebygga skador.

Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers 3

Safety with Electricity

To see translations of the remaining warnings that appear in this publication, refer to the Regulatory

Compliance and Safety Information document that accompanied the device.

Safety with Electricity

Follow these guidelines when working on equipment powered by electricity:

•Locate the emergency power-OFF switch in the room in which you are working. Then, if an

electrical accident occurs, you can quickly shut the power OFF.

•Disconnect all power before doing the following:

—Installing or removing a chassis

—Working near power supplies

•Do not work alone if potentially hazardous conditions exist.

•Never assume that power is disconnected from a circuit. Always check.

•Look carefully for possible hazards in your work area, such as moist ﬂoors, ungrounded power

extension cables, and missing safety grounds.

•If an electrical accident occurs, proceed as follows:

—Use caution; do not become a victim yourself.

—Turn OFF power to the system.

—If possible, send another person to get medical aid. Otherwise, determine the condition of the

victim and then call for help.

—Determine if the person needs rescue breathing or external cardiac compressions; then take

appropriate action.

Warning Read the installation instructions before you connect the system to its power

source.

Warning Ultimate disposal of this product should be handled according to all national

laws and regulations.

Warning Onlytrained and qualiﬁed personnelshould be allowedto install or replace this

equipment.

Warning Before working on a chassis or working near power supplies, unplug the power

cord on AC units; disconnect the power at the circuit breaker on DC units.

Warning Before working on equipment that is connected to power lines, remove jewelry

(including rings, necklaces, and watches). Metal objects will heat up when connected to

power and ground, and can cause serious burns or weld to the terminals.

Caution Use the Cisco RPS (model PWR600-AC-RPS) only to power the external

device.

4Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Required Tools and Equipment

Seul le système d’alimentation redondant Cisco (RPS modèle PWR600-AC-RPS) doit servir à

alimenter le dispositif externe.

Das externe Gerät darf nur mit einer redundanten Stromversorgung von Cisco, Modell

PWR600-AC-RPS, betrieben werden.

Para alimentar el dispositivo externo, usar exclusivamente el sistema de alimentación redundante

(redundant power system = RPS) Cisco, modelo PWR600-AC-RPS.

Preventing Electrostatic Discharge Damage

Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. It occurs when

electronic printed circuit cards are improperly handled and can result in complete or intermittent

failures. Always follow ESD prevention procedures when removing and replacing cards. Ensure that

the chassis is electrically connected to earth ground. Wear an ESD-preventive wrist strap, ensuring

that it makes good skin contact. Connect the clip to an unpainted surface of the chassis frame to

safely channel unwanted ESD voltages to ground. To properly guard against ESD damage and

shocks, the wrist strap and cord must be used correctly. If no wrist strap is available, ground yourself

by touching the metal part of the chassis.

Required Tools and Equipment

This kit includes the following items:

•Cisco RPS adapter plate, shown in Figure 1

•DC power rating label

Caution For safety, periodically check the resistance value of the antistatic strap, which

should be between 1 and 10 megohms (Mohm).

Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers 5

Removing the Cover

Figure 1 Cisco RPS Adapter Plate for Cisco 2600 series Routers

To install the Cisco RPS adapter plate, you will also need the following tools and equipment (which

are not included):

•Cisco 2600 series router

•Medium-size Phillips screwdriver

•ESD-preventive wrist strap

•Antistatic bag (optional)

•Wire cutters or scissors for cutting the cable tie-wraps (optional)

Removing the Cover

You must remove the chassis cover to access the internal power supply.

Warning Do not touch the power supply when the power cord is connected. For systems

with a power switch, line voltages are present within the power supply even when the

power switch is OFF and the power cord is connected. For systems without a power

switch, line voltages are present within the power supply when the power cord is

connected.

Warning Before performing any of the following procedures, ensure that power is

removed from the DC circuit. To ensure that all power is OFF, locate the circuit breaker

on the panel board that services the DC circuit, switch the circuit breaker to the OFF

position, and tape the switch handle of the circuit breaker in the OFF position.

WARNING:

Lorem ipsum dolor sit amet, consectetuer sed

diam nonummy nibh euismod tincidunt ut

dolore magna aliquam erat volutpat.

H9430

Adapter plate

6Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Removing the Cover

Take these steps to remove the chassis cover:

Step 1 Power OFF the router.

Step 2 Attach an ESD-preventive wrist strap.

Step 3 Disconnect all cables from the rear panel of the router.

Step 4 Place the router so that the front panel is facing you. Remove the screws located on top

of the cover near the front edge.

Step 5 Slide the cover away from you until the metal tabs on the side edges separate from the

chassis bottom, as shown in Figure 2.

Figure 2 Removing the Cover

Step 6 Lift the front edge of the cover until it clears the front of the chassis, as shown in Figure 3.

Figure 3 Lifting the Cover

Step 7 Lift the cover until it is free from the chassis and then set it aside.

Warning Before opening the chassis, disconnect the telephone-network cables to avoid

contact with telephone-network voltages.

Warning Do not work on the system or connect or disconnect cables during periods of

lightning activity.

POWER RPS ACTIVITY

H11658

Cisco 2600

SERIES

H11659

POWER RPS ACTIVITY

Cisco 2600

SERIES

Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers 7

Removing the Power Supply

This section describes how to remove the internal power supply. Although the AC power supply is

shown in the illustrations that follow, the procedure is the same for removing both the AC and DC

power supplies.

Take these steps to remove the power supply:

Step 1 Locate the six-pin connector on the system board near the front of the router, and

disconnect it. (See Figure 4.)

Note If cable tie-wraps on the harness interfere with removing the connectors, cut the

tie-wraps, being careful not to cut the power supply wires.

Figure 4 Locating the Connectors

Step 2 Remove the mounting screw that secures the power supply to the chassis. (See Figure 5.)

Set aside this screw for later use.

Figure 5 Removing the Mounting Screw

H9081

Power connector

Fan connector

Fan

AC power supply

H9079

Input: 100-240VAC

Freq: 50/60 Hz

Current: 1.2-0.6A

Watts: 40W

Screw

8Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Installing the Redundant Power Supply Adapter Plate

Step 3 Slide the power supply forward slightly in the chassis. This disengages the built-in hooks

that help secure the power supply to the chassis. (See Figure 6.)

Figure 6 Removing the Power Supply

Step 4 Place the removed screw and power supply in an antistatic bag.

Installing the Redundant Power Supply Adapter Plate

Take these steps to install the Cisco RPS Adapter Plate:

Step 1 Place the router so that the rear panel is facing you. (See Figure 7.)

Figure 7 Cisco 2600 Series Rear Panel (Cisco 2610 Shown)

Step 2 Attach the DC power rating label over the ratings on the rear panel of the router.

(See Figure 8.)

Figure 8 Attaching the DC Power Rating Label

H9082

AC power supply Fan

SEE MANUAL BEFORE INSTALLATION

SERIAL 1

SERIAL 0

CONN CONN WIC

2A/S

SEE MANUAL BEFORE INSTALLATION

SERIAL 1

SERIAL 0

CONN CONN WIC

Cisco 2610

100-240V– 1A

50/60 Hz 47 W

AUX

CONSOLE

ETHERNET 0 ACT

LINK

Ethernet 0/0

10BaseT

port (RJ-45) Auxiliary port

(RJ-45)

Console

port (RJ-45)

Cisco 2610

H11580

SEE MANUAL BEFORE INSTALLATION

SERIAL 1

SERIAL 0

CONN CONN WIC

Cisco 2610

AUX

CONSOLE

ETHERNET 0

ACT

LINK

10748

CISCO2610

100-240V~ 1.5A/0.75A

50/60 Hz

Label

Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers 9

Installing the Redundant Power Supply Adapter Plate

Step 3 Align the Cisco RPS Adapter Plate with the chassis cutout for the power supply. Tilt the

adapter plate slightly toward you at the top, and rock it up and into place, ensuring that

the two small hooks at the top of the Adapter Plate engage the router chassis. (See

Figure 9.)

Figure 9 Installing the Cisco RPS Adapter Plate

Step 4 Install the mounting screw that came with the Cisco RPS Adapter Plate into the screw

hole. (See Figure 10.)

Figure 10 Installing the Mounting Screw

Step 5 Connect the six-pin connector to the system board. The connector is keyed so that it

cannot be connected to the system board incorrectly. (See Figure 11.)

Step 6 Connect the 4-pin environmental status connector only if your router, with the connector

connected, has been upgraded to the correct level of Cisco IOS software. Using any other

level of Cisco IOS software can cause the router to crash. Cisco IOS Release 11.1(12)AA

or later is compatible but will not show status from the RPS. Cisco IOS Release 11.2(7)P

or later will provide RPS status information to the network.

H9801

Front of chassis

H9805

Mounting

screw

DC INPUT FOR USE WITH CISCO RPS

+5V–––10A, +12V–––2A, -12V–––1A

10 Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Installing the Redundant Power Supply Adapter Plate

Figure 11 Reconnecting the Connectors

Replacing the Cover

Take the following steps to replace the cover:

Step 1 Position the two chassis sections, as shown in Figure 2.

Step 2 Referring to Figure 2, press the two chassis sections together and ensure the following:

•The top section ﬁts into the rear of the bottom section. The bottom section ﬁts into the

front of the top section.

•Each side of the top and bottom sections ﬁts together.

Step 3 When the two sections ﬁt together snugly, slide the chassis top so until it ﬁts into the front

bezel.

Step 4 Replace the cover screws. Tighten the screws to no more than 8 or 9 inches/pound of

torque.

Step 5 Reinstall the chassis on the wall, rack, desktop, or table.

Step 6 Reconnect all cables.

Caution To ﬁt the two sections together, it might be necessary to work them together at

one end and then the other, working back and forth; however, use care to prevent bending

of the chassis edges.

Six-pin

connector

10345

Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers 11

Obtaining Service and Support

For service and support for a product purchased from a reseller, contact the reseller. Resellers offer

a wide variety of Cisco service and support programs, which are described in the section “Service

and Support” in the information packet that shipped with your chassis.

Note If you purchased your product from a reseller, you can access Cisco Connection Online

(CCO) as a guest. CCO is Cisco Systems’ primary, real-time support channel. Your reseller offers

programs that include direct access to CCO’s services.

For service and support for a product purchased directly from Cisco, use CCO.

Cisco Connection Online

CiscoConnection Online(CCO) isCisco Systems’primary, real-time support channel. Maintenance

customers and partners can self-register on CCO to obtain additional information and services.

Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added

services to Cisco’s customers and business partners. CCO services include product information,

product documentation, software updates, release notes, technical tips, the Bug Navigator,

conﬁguration notes, brochures, descriptions of service offerings, and download access to public and

authorized ﬁles.

CCO serves a wide variety of users through two interfaces that are updated and enhanced

simultaneously: a character-based version and a multimedia version that resides on the World Wide

Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet

e-mail,and it is excellentfor quickaccess to information overlowerbandwidths. The WWW version

of CCO provides richly formatted documents with photographs, ﬁgures, graphics, and video, as well

as hyperlinks to related information.

You can access CCO in the following ways:

•WWW: http://www.cisco.com

•WWW: http://www-europe.cisco.com

•WWW: http://www-china.cisco.com

•Telnet: cco.cisco.com

•Modem: From North America, 408 526-8070; from Europe, 33 1 64 46 40 82. Use the

following terminal settings: VT100 emulation; databits: 8; parity: none; stop bits: 1; and

connection rates up to 28.8 kbps.

For a copy of CCO’s Frequently Asked Questions (FAQ), contact [email protected]. For

additional information, contact [email protected].

Note If you are a network administrator and need personal technical assistance with a Cisco

product that is under warranty or covered by a maintenance contract, contact Cisco’s Technical

Assistance Center (TAC) at 800 553-2447, 408 526-7209, or [email protected]. To obtain general

information about Cisco Systems, Cisco products, or upgrades, contact 800 553-6387,

408 526-7208, or [email protected].

12 Installing the Cisco RPS Adapter Plate in Cisco 2600 Series Routers

Ordering Documentation

Ciscodocumentation and additional literature are availablein a CD-ROMpackage,which shipswith

your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated

monthly. Therefore, it might be more current than printed documentation. To order additional copies

of the Documentation CD-ROM, contact your local sales representative or call customer service.

The CD-ROM package is available as a single package or as an annual subscription. You can also

access Cisco documentation on the World Wide Web at http://www.cisco.com,

http://www-china.cisco.com, or http://www-europe.cisco.com.

If you are reading Cisco product documentation on the World Wide Web, you can submit comments

electronically. Click Feedback in the toolbar, select Documentation, and click Enter the feedback

form. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.

This document is to be used in conjunction with the Cisco 2600 Series Hardware Installation Guide publication.

AccessPath, AtmDirector, the CCIE logo, CD-PAC, Centri, Centri Bronze, Centri Gold, Centri Security Manager, Centri Silver, the Cisco Capital logo, Cisco IOS, the Cisco IOS logo,

CiscoLink, the Cisco NetWorks logo, the Cisco Powered Network logo, the Cisco Press logo, ClickStart, ControlStream, Fast Step, FragmentFree, IGX, JumpStart, Kernel Proxy, LAN2LAN

Enterprise, LAN2LAN Remote Ofﬁce, MGX, MICA, Natural Network Viewer, NetBeyond, NetRanger, NetSonar, Netsys Technologies, Packet, PIX, Point and Click Internetworking,

Policy Builder, RouteStream, Secure Script, SMARTnet, StrataSphere, StrataSphere BILLder, StrataSphere Connection Manager, StrataSphere Modeler, StrataSphere Optimizer, Stratm,

StreamView, SwitchProbe, The Cell, TrafﬁcDirector, TransPath, VirtualStream, VlanDirector, Workgroup Director, Workgroup Stack, and XCI are trademarks; Empowering the Internet

Generation and The Network Works. No Excuses. are service marks; and BPX, Catalyst, Cisco, Cisco Systems, the Cisco Systems logo, EtherChannel, FastHub, FastPacket, ForeSight, IPX,

LightStream, OptiClass, Phase/IP, StrataCom, and StrataView Plus are registered trademarks of Cisco Systems, Inc. in the U.S. and certain other countries. All other trademarks mentioned

in this document are the property of their respective owners.
