Cisco RVS4000 - Gigabit Security Router Instruction Manual

Cisco Small Business
RVS4000 4-Port Gigabit Security Router with VPN
ADMINISTRATION
GUIDE

© 2011 Cisco Systems, Inc. All rights reserved. OL-22605-02
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found
at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply
a partnership relationship between Cisco and any other company. (1005R)

Cisco RVS4000 Security Router with VPN Administrator Guide 3
Contents
Chapter 1: Introduction 8
Chapter 2: Networking and Security Basics 9
An Introduction to LANs 9
The Use of IP Addresses 10
The Intrusion Prevention System (IPS) 11
Chapter 3: Planning Your Virtual Private Network (VPN) 13
Why do I need a VPN? 13
1) MAC Address Spoofing 14
2) Data Sniffing 14
3) Man in the middle attacks 14
What is a VPN? 15
VPN Router to VPN Router 16
Computer (using the Cisco QuickVPN Client software) to VPN Router 17
Chapter 4: Getting Started with the RVS4000 Router 18
Front Panel 18
Back Panel 19
Placement Options 20
Desktop Option 20
Stand Option 20
Wall Option 21
Installing the Router 22
Configuring the Router 23
Chapter 5: Setting Up and Configuring the Router 25
Setup 26
Setup > Summary 26
Setup > WAN 29
Setup > LAN 38

Cisco RVS4000 Security Router with VPN Administrator Guide 4
Contents
Setup > DMZ 40
Setup > MAC Address Clone 41
Setup > Advanced Routing 42
Setup > Time 44
Setup > IP Mode 45
Firewall 46
Firewall > Basic Settings 46
Firewall > IP Based ACL 48
Firewall > Internet Access Policy 51
Firewall > Single Port Forwarding 54
Firewall > Port Range Forwarding 55
Firewall > Port Range Triggering 56
ProtectLink 57
ProtectLink > ProtectLink Purchase 57
VPN 58
VPN > Summary 58
VPN > IPSec VPN 60
VPN > VPN Client Accounts 64
VPN > VPN Passthrough 66
QoS 67
QoS > Bandwidth Management 67
QoS > QoS Setup 70
QoS > DSCP Setup 71
Administration 72
Administration > Management 72
Router Access 72
Administration > Log 74
Administration > Diagnostics 76
Administration > Backup & Restore 78
Administration > Factory Default 79
Administration > Reboot 80
Administration > Firmware Upgrade 80

Cisco RVS4000 Security Router with VPN Administrator Guide 5
Contents
IPS 82
IPS > Configuration 82
IPS > P2P/IM 83
IPS > Report 84
IPS > Information 86
L2 Switch 86
L2 Switch > Create VLAN 86
L2 Switch > VLAN Port Setting 88
L2 Switch > VLAN Membership 89
L2 Switch > RADIUS 90
L2 Switch > Port Setting 91
L2 Switch > Statistics 92
L2 Switch > Port Mirroring 93
L2 Switch > RSTP 94
Status 95
Status > Gateway 95
Status > Local Network 97
Chapter 6: Using the VPN Setup Wizard 98
VPN Setup Wizard 98
Before You Begin 98
Running the VPN Setup Wizard 99
Building Your VPN Connection Remotely 109
Appendix A: Troubleshooting 116
Frequently Asked Questions 128
Appendix B: Using Cisco QuickVPN for Windows 2000, XP, or Vista 133
Overview 133
Before You Begin 133
Installing the Cisco QuickVPN Software 135
Installing from the CD-ROM 135

Cisco RVS4000 Security Router with VPN Administrator Guide 6
Contents
Downloading and Installing from the Internet 137
Using the Cisco QuickVPN Software 137
Distributing Certificates to QuickVPN Users 140
Appendix C: Configuring IPSec with a Windows 2000 or XP Computer 142
Introduction 142
Environment 143
Windows 2000 or Windows XP 143
RVS4000 143
How to Establish a Secure IPSec Tunnel 143
Establishing a Secure IPSec Tunnel 144
Appendix D: Gateway-to-Gateway VPN Tunnel 166
Overview 166
Before You Begin 166
Configuration when the Remote Gateway Uses a Static IP Address 167
Configuration when the Remote Gateway Uses a Dynamic IP Address 172
Configuration When Both Gateways Use Dynamic IP Addresses 177
Appendix E: Cisco ProtectLink Web Service 182
Overview 182
How to Access the Configuration Utility 182
How to Purchase, Register, or Activate the Service 183
ProtectLink 183
How to Use the Service 185
ProtectLink > Web Protection 185
ProtectLink > License 189
Appendix F: Specifications 190
Specifications 190
Performance 190

Cisco RVS4000 Security Router with VPN Administrator Guide 7
Contents
Setup/Config 190
Management 191
Security Features 191
QoS 191
Network 192
VPN 192
Routing 192
Layer 2 192
Environmental 193
Appendix G: Where to Go From Here 194
Product Resources 194
Related Documentation 195

1
Cisco RVS4000 Security Router with VPN Administrator Guide 8
Introduction
Thank you for choosing the Cisco RVS4000 4-Port Gigabit Security Router with
VPN. The 4-Port Gigabit Security Router with VPN is an advanced Internet-sharing
network solution for your small business needs. Like any router, it lets multiple
computers in your office share an Internet connection.
The 4-Port Gigabit Security Router with VPN also features a built-in 4-Port full-
duplex 10/100/1000 Ethernet switch to connect four PCs directly, or you can
connect more hubs and switches to create as big a network as you need.
The Virtual Private Network (VPN) capability creates encrypted “tunnels” through
the Internet, allowing up to 5 remote offices and 5 traveling users to securely
connect into your office network from off-site. Users connecting through a VPN
tunnel are attached to your company’s network — with secure access to files,
email, and your intranet — just as if they were in the building. You can also use the
VPN capability to allow users on your small office network to securely connect out
to a corporate network. The QoS features provide consistent voice and video
quality throughout your business.
The 4-Port Gigabit Security Router with VPN can serve as a DHCP Server, and has
a powerful SPI firewall and Intrusion Prevention System (IPS) to protect your PCs
against intruders and most known Internet attacks. You can configure the router to
filter internal users’ access to the Internet, and has IP and MAC address filtering so
you can specify exactly who has access to your network. Configuration is a snap
with the web browser-based configuration utility.
This administration guide will give you all the information you need to connect, set
up, and configure your router.

2
Cisco RVS4000 Security Router with VPN Administrator Guide 9
Networking and Security Basics
This chapter describes networking and security basics. It includes these sections:
•An Introduction to LANs, page 9
•The Use of IP Addresses, page10
•The Intrusion Prevention System (IPS), page11
An Introduction to LANs
A router is a network device that connects two networks together.
The router connects your local area network (LAN), or the group of PCs in your
home or office, to the Internet. The router processes and regulates the data that
travels between these two networks.
Therouter’s NetworkAddressTranslation (NAT)technologyprotects yournetwork
of PCs so users on the Internet cannot “see” your PCs. This feature keeps your
LAN remains private. The router protects your network by inspecting the first
packet received through the Internet port before delivering it to the final
destination on one of the Ethernet ports. The router inspects Internet port services
like the web server, ftp server, or other Internet applications, and, if allowed, it will
forward the packet to the appropriate PC on the LAN side.

Networking and Security Basics
The Use of IP Addresses
Cisco RVS4000 Security Router with VPN Administrator Guide 10
2
The Use of IP Addresses
IP stands for Internet Protocol. Every device in an IP-based network, including PCs,
print servers, and routers, requires an IP address to identify its location, or
address, on the network. This applies to both the Internet and LAN connections.
There are two ways of assigning IP addresses to your network devices.
A static IP address is a fixed IP address that you assign manually to a PC or other
device on the network. Since a static IP address remains valid until you disable it,
static IP addressing ensures that the device assigned it will always have that same
IP address until you change it. Static IP addresses are commonly used with
network devices such as server PCs or print servers.
If you use the router to share your cable or DSL Internet connection, contact your
ISP to find out if they have assigned a static IP address to your account. If so, you
will need that static IP address when configuring the router. You can get the
information from your ISP.
A dynamic IP address is automatically assigned to a device on the network. These
IP addresses are called dynamic because they are only temporarily assigned to
the PC or other device. After a certain time period, they expire and may change. If
a PC logs onto the network (or the Internet) and its dynamic IP address has
expired, the DHCP server will assign it a new dynamic IP address.
A DHCP server can either be a designated PC on the network or another network
device, such as the router. By default, the router’s Internet Connection Type is
Obtain an IP automatically (DHCP).
The PC or network device that obtains an IP address is called the DHCP client.
DHCP frees you from the requirement to assign an IP address manually when a
new user is added to your network.
For DSL users, many ISPs may require you to log on with a user name and
password to gain access to the Internet. This is a dedicated, high-speed
connection type called Point to Point Protocol over Ethernet (PPPoE). PPPoE is
similar to a dial-up connection, but PPPoE does not dial a phone number when
establishing a connection. It also will provide the router with a dynamic IP address
to establish a connection to the Internet.
By default, a DHCP server (on the LAN side) is enabled on the router. If you already
have a DHCP server on your network, you MUST disable one of the two DHCP
servers. If you run more than one DHCP server on your network, you will
experience network errors, such as conflicting IP addresses. To disable DHCP on
the router, see the Basic Setup section in Chapter 5, “Setting Up and
Configuring the Router.”

Networking and Security Basics
The Intrusion Prevention System (IPS)
Cisco RVS4000 Security Router with VPN Administrator Guide 11
2
NOTE Since the router is a device that connects two networks, it needs two IP
addresses—one for the LAN, and one for the Internet. In this Administration Guide,
you’ll see references to the “Internet IP address” and the “LAN IP address”.
Since the router uses NAT technology, the only IP address that can be seen from
the Internet for your network is the router’s Internet IP address. However, even this
Internet IP address can be blocked so the router and network seem invisible to the
Internet.
The Intrusion Prevention System (IPS)
IPS is an advanced technology to protect your network from malicious attacks. IPS
works together with your SPI Firewall, IP Based Access Control List (ACL),
Network Address Port Translation (NAPT), and Virtual Private Network (VPN) to
achieve the highest level of security. IPS works by providing real-time detection
and prevention as an in-line module in a router.
The RVS4000 has hardware-based acceleration for real-time pattern matching to
detect malicious attacks. It actively filters and drops malicious TCP/UDP/ICMP/
IGMP packets and can reset TCP connections. This feature prevents network
worm attacks against client PCs and servers with various operating systems
including Windows, Linux, and Solaris. However, this system does not prevent
viruses contained in email attachments.
The P2P (Peer-to-Peer) and IM (Instant Messaging) control allows the system
administrator to prevent network users from using those protocols to
communicate with people over the Internet. This helps the administrators to set up
company policies on how to use the Internet bandwidth wisely.
The signature file is the heart of the IPS system. It is similar to the Virus definition
file on your PC’s Anti-Virus software. IPS uses this file to match against packets
coming into the router and performs actions accordingly. The RVS4000 has a
signature file that contains 1000+ rules, which cover these categories: DDoS,
Buffer Overflow, Access Control, Scan, Trojan Horse, Misc., P2P, IM, Virus, Worm,
and Web Attacks.
Customers are encouraged to update their IPS signature file regularly to prevent
any new types of attacks on the Internet.

Networking and Security Basics
The Intrusion Prevention System (IPS)
Cisco RVS4000 Security Router with VPN Administrator Guide 12
2
IPS Scenarios

3
Cisco RVS4000 Security Router with VPN Administrator Guide 13
Planning Your Virtual Private Network (VPN)
This chapter provides information for planning your VPN. It includes these
sections:
•Why do I need a VPN?, page13
•What is a VPN?, page15
Why do I need a VPN?
Computer networking provides a flexibility not available when using an archaic,
paper-based system. With this flexibility, however, comes an increased risk in
security. Firewalls address this risk. Firewalls help to protect data inside of a local
network. But what do you do when information leaves your local network, when
emails go to their destination, or when you connect to your company’s network
from a hotel or remote office? How is your data protected?
A VPN can help. VPNs are called Virtual Private Networks because they secure
data moving outside of your network as if it were still within that network.
When data travels across the Internet from your computer, it is always open to
attacks. You may already have a firewall, which helps protect data in your network
from being corrupted or intercepted by entities outside of your network. When
data moves outside of your network—when you send data to someone via email
or communicate with an individual over the Internet—the firewall no longer
protects your data.
At this point, your data becomes open to hackers who use a variety of methods to
steal not only the data you transmit but also your network login and security data.
Some of the most common methods are described in on the next page.

Planning Your Virtual Private Network (VPN)
Whydo I needa VPN?
Cisco RVS4000 Security Router with VPN Administrator Guide 14
3
1) MAC Address Spoofing
Packets transmitted over a network, either your local network or the Internet, are
preceded by a packet header. These packet headers contain both the source and
destination information for that packet to transmit efficiently. A hacker can use this
information to spoof (or fake) a MAC address allowed on the network. With this
spoofed MAC address, the hacker can also intercept information meant for
another user.
2) Data Sniffing
Hackers use data “sniffing” to obtain network data as it travels through unsecured
networks, such as the Internet. Tools for just this kind of activity, such as protocol
analyzers and network diagnostic tools, are often built into operating systems and
allow the data to be viewed in clear text.
3) Man in the middle attacks
Once the hacker has either sniffed or spoofed enough information, he can now
perform a “man in the middle” attack. Hackers use this attack when data is
transmitted from one network to another, by rerouting the data to a new
destination. Even though the data never reaches its intended recipient, it appears
successful to the person who sent the data.
These are only a few of the methods hackers use, and they are always developing
more. Without the security of your VPN, your data is constantly open to such
attacks as it travels over the Internet. Data travelling over the Internet often passes
through many different servers around the world before reaching its final
destination. That’s a long way to go for unsecured data and this is when a VPN
serves its purpose.

Planning Your Virtual Private Network (VPN)
What is a VPN?
Cisco RVS4000 Security Router with VPN Administrator Guide 15
3
What is a VPN?
A VPN, or Virtual Private Network, is a connection between two endpoints—a VPN
router, for instance—in different networks that allows private data to be sent
securely over a shared or public network, such as the Internet. This establishes a
private network that can send data securely between these two locations or
networks.
This is done by creating a “tunnel”. A VPN tunnel connects the two PCs or
networks and allows data to be transmitted over the Internet as if it were still
within those networks. Not a literal tunnel, it is a connection secured by encrypting
the data sent between the two networks.
VPN was created as a cost-effective alternative to using a private, dedicated,
leased line for a private network. Using industry standard encryption and
authentication techniques—IPSec, short for IP Security—VPN creates a secure
connection that, in effect, operates as if you were directly connected to your local
network. You can use VPN to create a secure network that links a central office
with branch offices, telecommuters, and/or professionals on the road (travelers
can connect to a VPN router by using any computer with the Cisco QuickVPN
Client software).
There are two basic ways to create a VPN connection:
•VPN router to VPN router
•Computer (using the Cisco QuickVPN Client software) to VPN router
The VPN router creates a “tunnel” or channel between two endpoints, so that data
transmissions between them are secure. A computer with the Cisco QuickVPN
Client software can be one of the two endpoints (refer to Appendix B, “Using
Cisco QuickVPN for Windows 2000, XP, or Vista”). If you choose not to run the
VPN client software, any computer with the built-in IPSec Security Manager
(Microsoft 2000 and XP) allows the VPN router to create a VPN tunnel by using
IPSec (refer to Appendix C, “Configuring IPSec with a Windows 2000 or XP
Computer”). Other versions of Microsoft operating systems require additional,
third-party VPN client software applications that support IPSec to be installed.

Planning Your Virtual Private Network (VPN)
What is a VPN?
Cisco RVS4000 Security Router with VPN Administrator Guide 16
3
VPN Router to VPN Router
With a VPN-router-to-VPN-router VPN, a telecommuter uses his VPN router for his
always-on Internet connection. His router is configured with his office’s VPN
settings. When he connects to his office’s router, the two routers create a VPN
tunnel, encrypting and decrypting data. As VPNs utilize the Internet, distance is not
a factor. While using the VPN, the telecommuter now has a secure connection to
the central office’s network, as if he were physically connected. For more
information, refer to Appendix D, “Gateway-to-Gateway VPN Tunnel.”
VPN Router to VPN Router

Planning Your Virtual Private Network (VPN)
What is a VPN?
Cisco RVS4000 Security Router with VPN Administrator Guide 17
3
Computer(usingthe CiscoQuickVPNClientsoftware) to VPN
Router
In this illustration, you see an example of a computer-to-VPN router VPN. In her
hotel room, a traveling businesswoman connects to her ISP. Her notebook
computer has the Cisco QuickVPN Client software, which is configured with her
office’s IP address. She accesses the Cisco QuickVPN Client software and
connects to the VPN router at the central office. As VPNs utilize the Internet,
distance is not a factor. While using the VPN, she now has a secure connection to
the central office’s network, as if she were physically connected.
Computer to VPN Router
For additional information and instructions about creating your own VPN, please
visit www.cisco.com. You can also refer to Appendix B, “Using Cisco QuickVPN
for Windows 2000, XP, or Vista”, Appendix C, “Configuring IPSec with a
Windows 2000 or XP Computer” and Appendix D, “Gateway-to-Gateway VPN
Tunnel.”

4
Cisco RVS4000 Security Router with VPN Administrator Guide 18
Getting Started with the RVS4000 Router
This chapter describes the physical features of the RVS4000 router and explains
how to install the router. It includes these sections:
•Front Panel, page18
•Back Panel, page19
•Placement Options, page 20
•Installing the Router, page 22
•Configuring the Router, page 23
Front Panel
The LEDs are located on the front panel of the router.
Front Panel
POWER LED: Steady green when the router is powered on. Flashes when the
router is running a diagnostic test.
DIAG LED: Unlit when the system is ready. Flashes red during firmware
upgrades.

Getting Started with the RVS4000 Router
Back Panel
Cisco RVS4000 Security Router with VPN Administrator Guide 19
4
Back Panel
The Ethernet ports, Internet port, Reset button, and Power port are on the back panel of
the router.
Back Panel
IPS LED: Steady green when the Intrusion Prevention System (IPS) function is
enabled. Unlit when IPS functions are disabled. Flashes green when an
external attack is detected. Flashes red when an internal attack is detected.
Ethernet Port LEDs 1-4: For each LAN port, there are three LEDs. Steady
green when the router is connected to a device at the speed indicated through
the corresponding port (1, 2, 3, or 4). Flashes green when a router is actively
sending or receiving data on the port.
INTERNET LED: Steady green to indicate the line speed of the device
attached to the Internet port. Flashes to indicates activity. If the router is
connected to a cable or DSL modem, typically the 100 LED is the only LED lit
up, indicating 100 Mbps.
RESET Button: You can use the Reset button in two ways:
•If the router has problems connecting to the Internet, press the
Reset button for just a second with a paper clip or a pencil tip.
This is similar to pressing the reset button on your PC to reboot it.
•If you experience extreme problems with the router and have
tried all other troubleshooting measures, press and hold the
Reset button for 10 seconds. This action restores the factory
defaults and clear all of the router settings, such as port
forwarding or a new password.
INTERNET Port: Provides a WAN connection to a cable modem or DSL
modem.

Getting Started with the RVS4000 Router
Placement Options
Cisco RVS4000 Security Router with VPN Administrator Guide 20
4
Placement Options
You can place the router horizontally on the rubber feet, mount it in the stand, or
mount it on the wall.
Desktop Option
For desktop placement, place the Cisco RVS4000 router horizontally on a surface
so it sits on its four rubber feet.
Stand Option
To install the router vertically in the supplied stands, follow the steps below.
ETHERNET Ports 1-4: Provide a LAN connection to network devices,
such as PCs, print servers, or additional switches.
POWER Port: Connects the router to power via the supplied AC power
adapter.
274946
POWER DIAG IPS ETHERNET
RVS4000
10
100
1000
1 2 3 4
INTERNET
