Cisco Touchpad 10 User manual

Quick Reference Guide
Touchpad 10 - SX10/20/80, Room Kit Plus
Service Desk 204-940-8500 Option 4, Option 1
or toll-free 1-866-999-9698 Option 4, Option 1
Rev 04Apr2019 Page 1 of 2
www.mbtelehealth.ca
Touchpad Basics
Camera Control and Selfview Make a Call
Site to Site Call
Multi-Site Call
Tap the
touchpad
to wake up
the system.
Camera -
camera settings
and Selfview
option
Mute/unmute
Microphone
Volume
Tap a button to
activate its function.
Scroll in lists like
a smart phone.
Tap outside the
menu to exit.
Tap the desired
Camera Preset.
Turn Selfview
On and O󰀨.
Pan/tilt
controls.
(arrows)
You will be automatically connected (see note below).
Press End to disconnect at the end of every call
(Site to Site and Multi-site).
Out of Province/Network Calls
Zoom in
and out.
(+/-)
The Home screen should always be displayed prior to connecting to a site; if not, this may mean that a previous call was not
disconnected. If you do not see the Home screen, press End to disconnect prior to connecting to your site.
During a call: Tap Camera (a) and
then tap Selfview (b) to turn it on
(you may now resize the selfview
image or control the camera)
Selfview options
Press, drag and release
to move a box.
Call (access
to Directory/
Favourites)
a
b
Tap Camera
to invoke the camera
adjustment menu.
3
2
Keypad icon
1
1. Tap Call.
2. Tap in the search/dial eld and enter the 5 digit number
using the keypad. (Tap the keypad icon in the bottom
left corner of the screen if required.)
3. Tap Call to connect.
...
...
...
.
1. Tap Call.
2. Tap in the search/dial eld and enter the phone number
using the keypad. (Tap the keypad icon in the bottom
left corner of the screen if required.)
3. Tap Call to connect.
...
...
...
.
• Multi-site sessions will be connected automatically at the scheduled start time.
• If you are registered for the event and it is already in progress and you are NOT connected, you can join
by using the connection information shown on the Whiteboard.
• Multi-site sessions will be automatically disconnected at the scheduled end time.

Quick Reference Guide
Touchpad 10 - SX10/20/80, Room Kit Plus
Service Desk 204-940-8500 Option 4, Option 1
or toll-free 1-866-999-9698 Option 4, Option 1
Rev 04Apr2019 Page 2 of 2
www.mbtelehealth.ca
Screen Layout: Presentation
TIP If you are connected to another piece of equipment that has dual video enabled they are able to see both of
your feeds; both your camera view and your presentation and they will have full control over their own layout.
Tap Layout to change the layout. Tap the preferred layout (see options below).
Tap anywhere outside the menu when done.
Equal Overlay Prominent Single
Your Site Other Site
Selfview
Share Presentation
Tap Share and then tap Share in call.
Stop sharing
Tap Share and then tap Stop Sharing.
Tap Share and then
tap Share again.
Default Layout
During a call Outside a call
Far End Control Site to Site/Layout multi-site
Multi-site
The default layout is shown on the right. Other layout options may be
selected by the host/presenter when booking an event.
Fig 2Fig 1
Site to Site
• Tap Participants , tap the participant, then tap Camera. (Fig 1)
• Adjust the other site’s camera using the pan/tilt arrows and zoom +/-.
• Tap outside the controls to return to near end (Fig 2).
