Cisco 40-Gigabit QSFP+ Transceiver Modules
Installation Note
Revised: October 3, 2012
This installation note provides the installation instructions for the 40-Gigabit Quad Small Form-Factor
Pluggable Plus (QSFP+) transceiver modules. The modules are hot-swappable input/output (I/O) devices
that connect the system’s module port electrical circuitry with either a copper or a fiber-optic network.
This document contains these sections:
•Overview, page 2
•Safety, page 5
•Required Tools, page 11
•Installing the 40-Gigabit QSFP+ Transceiver Module, page 11
•Attaching the Optical Network Cable, page 13
•Removing the 40-Gigabit QSFP+ Transceiver Module, page 16
•Translated Safety Warnings, page 17
•Related Documentation, page 22
•Obtaining Documentation and Submitting a Service Request, page 23
Product Numbers: QSFP-H40G-CU1M= QSFP-H40G-CU3M= QSFP-H40G-CU5M=
QSFP-4SFP10G-CU1M= QSFP-4SFP10G-CU3M= QSFP-4SFP10G-CU5M=
QSFP-40G-SR4= QSFP-40G-CSR4= QSFP-H40G-ACU7M=
QSFP-H40G-CU10M= QSFP-4X10G-AC7M= QSFP-4X10G-AC10M=
QSFP-40GE-LR4=

2
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Overview
Overview
The 40-Gigabit QSFP+ transceiver module is a hot-swappable, parallel fiber-optical module with four
independent optical transmit and receive channels. These channels can terminate in another 40-Gigabit
QSFP+ transceiver, or the channels can be broken out to four separate 10-Gigabit SFP+ transceivers.
(See Figure 1.) The QSFP+ transceiver module connects the electrical circuitry of the system with either
a copper or an optical external network. (See Figure 2 for a view of the optical QSFP+ transceiver.) The
transceiver is used primarily in short reach applications in switches, routers, and data center equipment
where it provides higher density than SFP+ modules.
Figure 1 40-Gigabit QSFP+ Transceiver Module (Copper)
Figure 2 40-Gigabit QSFP+ Transceiver Module (Optical)
1QSFP+ transceiver body 3Pull tab
210GBASE SFP+ transceivers
140GBASE QSFP+ transceiver body 3Electrical connection to the module circuitry
2Bail-clasp latch
255430
3
1
1
2
3
255431
2
1
3
1
3

3
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Overview
Table 1 lists the different QSFP+ transceiver module types.
Note The multiple-fiber push-on (MPO) connectors and the duplex LC connectors on the optical QSFP+
transceivers support network interface cables with either Physical contact (PC) or Ultra-Physical Contact
(UPC) flat-polished face types. The MPO connectors and the duplex LC connectors on the optical
QSFP+ transceivers do not support network interface cables with an angle-polished contact (APC) face
type.
Table 1 40-Gigabit QSFP+ Transceiver Modules
QSFP+ Transceiver Module
Product Number
Description
QSFP-H40G-CU1M= Cisco 40GBASE-CR4 QSFP+ passive direct-attach copper transceiver
module assembly, 1 meter
QSFP-H40G-CU3M= Cisco 40GBASE-CR4 QSFP+ passive direct-attach copper transceiver
module assembly, 3 meter
QSFP-H40G-CU5M= Cisco 40GBASE-CR4 QSFP+ passive direct-attach copper transceiver
module assembly, 5 meter
QSFP-H40G-ACU7M= Cisco 40GBASE-CR4 QSFP+ active direct-attach copper transceiver
module assembly, 7 meter
QSFP-H40G-ACU10M= Cisco 40GBASE-CR4 QSFP+ active direct-attach copper transceiver
module assembly, 10 meter
QSFP-4SFP10G-CU1M= Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ passive
direct-attach copper transceiver assembly, 1 meter
QSFP-4SFP10G-CU3M= Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ passive
direct-attach copper transceiver assembly, 3 meter
QSFP-4SFP10G-CU5M= Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ passive
direct-attach copper transceiver assembly, 5 meter
QSFP-4X10G-AC7M= Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ active
direct-attach copper transceiver assembly, 7 meter
QSFP-4X10G-AC10M= Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ active
direct-attach copper transceiver assembly, 10 meter
QSFP-40G-SR4= Cisco 40GBASE-SR4 QSFP+ transceiver module for MMF, multi-fiber
MPO connector
QSFP-40G-CSR4= Cisco 40GBASE-CSR4 QSFP+ transceiver module for MMF, multi-fiber
MPO connector
QSFP-40GE-LR4= Cisco 40GBASE-LR4 QSFP+ transceiver module for SMF, duplex LC
connector

4
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Overview
Table 2 lists the 40-Gigabit optical QSFP+ port cabling specifications.
Table 3 lists the QSFP+ transceiver modules optical transmit and receive specifications.
Table 2 QSFP+ Transceiver Port Cabling Specifications
QSFP+ Product Number Nominal
Wavelength
(nm)
Cable Type Core Size
(microns)
Modal
Bandwidth
(MHz/km)
Maximum Cabling Distance
QSFP-40G-SR4= 850 MMF 50.0
50.0
50.0
500 (OM2)
2000 (OM3)
4700 (OM4)
30 m (98 ft)
100 m (328 ft)
150 m (492 ft)
QSFP-40G-CSR4= 850 MMF 62.5
50.0
50.0
50.0
200 (OM1)
500 (OM2)
2000 (OM3)
4700 (OM4)
33 m (108 ft)
82 m (269 ft)
300 m (984 ft)
400 m (1312 ft)
QSFP-40GE-LR4= 1310 SMF G.652 — 10 km (6.2 miles)
Table 3 QSFP+ Transceiver Optical Transmit and Receive Specifications
QSFP+ Product Number Transceiver Operating Mode Transmit Power
(dBm)
Receive Power
(dBm)
Transmit and
Receive
Wavelength (nm)
QSFP-40G-SR4= 40GBASE-SR4, 4 lanes, 850 nm -1 per lane
(Max)
–7.6 per lane
(Min)
2.4 per lane
(Max)
–9.5 per lane
(Min)
Four lanes, 840 to
860
QSFP-40G-CSR4= 40GBASE-CSR4, 4 lanes, 850 nm -1.2 per lane
(Max)
-7.3 per lane
(Min)
-1 per lane
(Max)
-9.9 per lane
(Min)
Four lanes, 840 to
860
QSFP-40GE-LR4= 40GBASE-LR4, 1310 nm 2.3 per lane
(Max)
-7 per lane
(Min)
2.3 per lane
(Max)
-13.7 per lane
(Min)
Four lanes, 1271,
1291, 1311, 1331

5
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety
Safety
Safety warnings appear throughout this publication in procedures that may harm you if performed
incorrectly or are ignored. A warning symbol precedes each warning statement.
Statement 1071—Warning Definition
Warning IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this
device.
SAVE THESE INSTRUCTIONS
Waarschuwing
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan
veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij
elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard
praktijken om ongelukken te voorkomen. Gebruik het nummer van de verklaring onderaan de
waarschuwing als u een vertaling van de waarschuwing die bij het apparaat wordt geleverd, wilt
raadplegen.
BEWAAR DEZE INSTRUCTIES
Varoitus
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin
käsittelet laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu
onnettomuuksien yleisiin ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen
mukana toimitettujen käännettyjen turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien
lausuntonumeroiden avulla.
SÄILYTÄ NÄMÄ OHJEET
Attention
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant
entraîner des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez
conscient des dangers liés aux circuits électriques et familiarisez-vous avec les procédures
couramment utilisées pour éviter les accidents. Pour prendre connaissance des traductions des
avertissements figurant dans les consignes de sécurité traduites qui accompagnent cet appareil,
référez-vous au numéro de l'instruction situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS

6
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety
Warnung
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen
kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und
den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder
Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
Avvertenza
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle
persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli
relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti.
Utilizzare il numero di istruzione presente alla fine di ciascuna avvertenza per individuare le
traduzioni delle avvertenze riportate in questo documento.
CONSERVARE QUESTE ISTRUZIONI
Advarsel
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du
begynner å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med
elektriske kretser, og kjenne til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten
av hver advarsel for å finne oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne
enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de
lesões corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos
perigos envolvidos no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de
prevenção de acidentes. Utilize o número da instrução fornecido ao final de cada aviso para
localizar sua tradução nos avisos de segurança traduzidos que acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
¡Advertencia!
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular
cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los
procedimientos estándar de prevención de accidentes. Al final de cada advertencia encontrará el
número que le ayudará a encontrar el texto traducido en el apartado de traducciones que acompaña
a este dispositivo.
GUARDE ESTAS INSTRUCCIONES

7
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety
Varning!
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.
Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och
känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av
varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna
anordning.
SPARA DESSA ANVISNINGAR

8
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety
Aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões
corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os
circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o
número da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de
segurança traduzidos que acompanham o dispositivo.
GUARDE ESTAS INSTRUÇÕES
Advarsel
VIGTIGE SIKKERHEDSANVISNINGER
Dette advarselssymbol betyder fare. Du befinder dig i en situation med risiko for
legemesbeskadigelse. Før du begynder arbejde på udstyr, skal du være opmærksom på de
involverede risici, der er ved elektriske kredsløb, og du skal sætte dig ind i standardprocedurer til
undgåelse af ulykker. Brug erklæringsnummeret efter hver advarsel for at finde oversættelsen i de
oversatte advarsler, der fulgte med denne enhed.
GEM DISSE ANVISNINGER

9
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety

10
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Safety
Warning Because invisible laser radiation may be emitted from the aperture of the port when no cable is
connected, avoid exposure to laser radiation and do not stare into open apertures. Statement 70
Warning Class 1 laser product. Statement 1008
Warning Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040
Warning Use of controls, adjustments, or performing procedures other than those specified may result in
hazardous radiation exposure. Statement 1057

11
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Required Tools
Required Tools
You need these tools to install the 40-Gigabit QSFP+ transceiver modules:
•Wrist strap or other personal grounding device to prevent ESD occurrences.
•Antistatic mat or antistatic foam to set the transceiver on.
•Fiber-optic end-face cleaning tools and inspection equipment.
For complete information on inspecting and cleaning fiber-optic connections, see the white-paper
document at this URL:
http://www.cisco.com/en/US/tech/tk482/tk876/technologies_white_paper09186a0080254eba.shtm
l
Installing the 40-Gigabit QSFP+ Transceiver Module
The QSFP+ transceiver module can have either a bail-clasp latch or a pull-tab latch. Installation
procedures for both types of latches are provided.
Caution The QSFP+ transceiver module is a static-sensitive device. Always use an ESD wrist strap or similar
individual grounding device when handling QSFP+ transceiver modules or coming into contact with
system modules.
To install an QSFP+ transceiver module, follow these steps:
Step 1 Attach an ESD wrist strap to yourself and a properly grounded point on the chassis or the rack.
Step 2 Remove the QSFP+ transceiver module from its protective packaging.
Step 3 Check the label on the QSFP+ transceiver module body to verify that you have the correct model for your
network.
Step 4 For optical QSFP+ transceivers, remove the optical bore dust plug and set it aside.
Step 5 For transceivers equipped with a bail-clasp latch:
a. Keep the bail-clasp aligned in a vertical position.
b. Align the QSFP+ transceiver in front of the module’s transceiver socket opening and carefully slide
the QSFP+ transceiver into the socket until the transceiver makes contact with the socket electrical
connector. (See Figure 3.)
Step 6 For QSFP+ transceivers equipped with a pull-tab:
a. Hold the transceiver so that the identifier label is on the top.
b. Align the QSFP+ transceiver in front of the module’s transceiver socket opening and carefully slide
the QSFP+ transceiver into the socket until the transceiver makes contact with the socket electrical
connector.

12
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Installing the 40-Gigabit QSFP+ Transceiver Module
Figure 3 Installing the 40-Gigabit QSFP+ Transceiver Module (Optical Transceiver Equipped
with a Bail-Clasp Latch Shown)
Step 7 Press firmly on the front of the QSFP+ transceiver with your thumb to fully seat the transceiver in the
module’s transceiver socket. (See Figure 4.)
Caution If the latch is not fully engaged, you might accidently disconnect the QSFP+ transceiver
module.
255432

13
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Attaching the Optical Network Cable
Figure 4 Seating the 40-Gigabit QSFP+ Transceiver Module (Optical Transceiver Equipped with
a Bail-Clasp Latch Shown)
Step 8 For optical QSFP+ modules, reinstall the dust plug into the QSFP+ transceivers optical bore until you
are ready to attach the network interface cable. Do not remove the dust plug until you are ready to attach
the network interface cable.
Attaching the Optical Network Cable
Before removing the dust plugs and making any optical connections, follow these guidelines:
– Keep the protective dust plugs installed in the unplugged fiber-optic cable connectors and in the
transceiver optical bores until you are ready to make a connection.
– Inspect and clean the MPO connector or the duplex LC connector end faces just before you
make any connections. See the Tip following step 2 in the next procedure for a pointer to a
fiber-optic inspection and cleaning white paper.
– Grasp the MPO or the duplex LC connector only by the connector housing to plug or unplug a
fiber-optic cable.
Note The MPO connectors on the 40-Gigabit SR4 and CSR4 QSFP+ transceiver modules are keyed
to prevent incorrect insertion.
255433

14
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Attaching the Optical Network Cable
Note The multiple-fiber push-on (MPO) connectors and the duplex LC connectors on the optical QSFP+
transceivers support network interface cables with either physical contact (PC) or ultra-physical contact
(UPC) flat polished face types. The MPO and duplex LC connectors on the optical QSFP+ transceivers
do not support network interface cables with an angle-polished contact (APC) face type.
Step 1 Remove the dust plugs from the optical network interface cable MPO connectors. Save the dust plugs
for future use.
Step 2 Inspect and clean the MPO or duplex LC connector’s fiber-optic end faces. See the Tip below for a
pointer to a fiber-optic inspection and cleaning white paper.
Tip For complete information on inspecting and cleaning fiber-optic connections, see this URL:
http://www.cisco.com/en/US/tech/tk482/tk876/technologies_white_paper09186a0080254eba.
shtml
Step 3 Remove the dust plugs from the QSFP+ transceiver module optical bores.
Step 4 Immediately attach the network interface cable MPO connector (see Figure 5) or duplex LC connector
(see Figure 6) to the QSFP+ transceiver module.
Figure 5 Cabling a 40-Gigabit QSFP+ Transceiver Module Equipped with an MPO Connector
255434

15
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Attaching the Optical Network Cable
Figure 6 Cabling a 40-Gigabit QSFP+ Transceiver Module Equipped with a Duplex LC
Connector
Step 5 Verify that the optical network cable is fully seated by pulling gently on the cable’s MPO or duplex LC
connector boot. If the network cable disconnects, reinstall it and make sure that the cable connector is
fully seated and that the connector latch engages.
1
LINK
LINK ACTIVE
ACTIVE
2
334629
QSFP+ transceiver
Network interface
cable
LC connector

16
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Removing the 40-Gigabit QSFP+ Transceiver Module
Removing the 40-Gigabit QSFP+ Transceiver Module
Caution The QSFP+ transceiver module is a static-sensitive device. Always use an ESD wrist strap or similar
individual grounding device when handling QSFP+ transceiver modules or coming into contact with
modules.
To remove a QSFP+ transceiver, follow these steps:
Step 1 For optical QSFP+ transceivers, disconnect the network interface cable from the QSFP+ transceiver
connector.
Step 2 For QSFP+ transceivers equipped with a bail-clasp latch (See Figure 7, top view):
a. Pivot the bail-clasp down to the horizontal position.
b. Immediately install the dust plug into the transceivers optical bore.
c. Grasp the sides of the QSFP+ transceiver and slide it out of the module socket.
Step 3 For QSFP+ transceivers equipped with a pull tab latch (See Figure 7, bottom view):
a. Immediately install the dust plug into the transceiver’s optical bore.
b. Grasp the tab and gently pull to release the transceiver from the socket.
c. Slide the transceiver out of the socket.
Step 4 Place the QSFP+ transceiver into an antistatic bag.
Figure 7 Removing the 40-Gigabit QSFP+ Transceiver Module
255435

17
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Translated Safety Warnings
Translated Safety Warnings
This section repeats in multiple languages the basic warnings that appear in this document.
Statement 70—Invisible Laser Radiation Warning
Warning Because invisible laser radiation may be emitted from the aperture of the port when no cable is
connected, avoid exposure to laser radiation and do not stare into open apertures.
Waarschuwing
Omdat er onzichtbare laserstraling uit de opening van de poort geëmitteerd kan worden wanneer er
geen kabel aangesloten is, dient men om blootstelling aan laserstraling te vermijden niet in de open
openingen te kijken.
Varoitus
Kun porttiin ei ole kytketty kaapelia, portin aukosta voi vuotaa näkymätöntä lasersäteilyä. Älä katso
avoimiin aukkoihin, jotta et altistu säteilylle.
Attention
Etant donné qu’un rayonnement laser invisible peut être émis par l’ouverture du port quand aucun
câble n’est connecté, ne pas regarder dans les ouvertures béantes afin d’éviter tout risque
d’exposition au rayonnement laser.
Warnung
Aus der Öffnung des Ports kann unsichtbare Laserstrahlung austreten, wenn kein Kabel
angeschlossen ist. Kontakt mit Laserstrahlung vermeiden und nicht in offene Öffnungen blicken.
Avvertenza
Poiché quando nessun cavo è collegato alla porta, da quest’ultima potrebbe essere emessa
radiazione laser invisibile, evitare l’esposizione a tale radiazione e non fissare con gli occhi porte
a cui non siano collegati cavi.
Advarsel
Usynlige laserstråler kan sendes ut fra åpningen på utgangen når ingen kabel er tilkoblet. Unngå
utsettelse for laserstråling og se ikke inn i åpninger som ikke er tildekket.
Aviso
Evite uma exposição à radiação laser e não olhe através de aberturas expostas, porque poderá
ocorrer emissão de radiação laser invisível a partir da abertura da porta, quando não estiver
qualquer cabo conectado.
¡Advertencia!
Cuando no esté conectado ningún cable, pueden emitirse radiaciones láser invisibles por el orificio
del puerto. Evitar la exposición a radiaciones láser y no mirar fijamente los orificios abiertos.
Varning!
Osynliga laserstrålar kan sändas ut från öppningen i porten när ingen kabel är ansluten. Undvik
exponering för laserstrålning och titta inte in i ej täckta öppningar.

18
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Translated Safety Warnings
Statement 1008—Class 1 Laser Product
Warning Class 1 laser product.
Waarschuwing
Klasse-1 laser produkt.
Varoitus
Luokan 1 lasertuote.
Attention
Produit laser de classe 1.
Warnung
Laserprodukt der Klasse 1.
Avvertenza
Prodotto laser di Classe 1.
Advarsel
Laserprodukt av klasse 1.
Aviso
Produto laser de classe 1.
¡Advertencia!
Producto láser Clase I.
Varning!
Laserprodukt av klass 1.
Aviso
Produto a laser de classe 1.
Advarsel
Klasse 1 laserprodukt.

19
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Translated Safety Warnings
Statement 1040—Product Disposal
Warning Ultimate disposal of this product should be handled according to all national laws and regulations.
Waarschuwing
Het uiteindelijke wegruimen van dit product dient te geschieden in overeenstemming met alle
nationale wetten en reglementen.
Varoitus
Tämä tuote on hävitettävä kansallisten lakien ja määräysten mukaisesti.
Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives
de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes
erfolgen.
Avvertenza
Lo smaltimento di questo prodotto deve essere eseguito secondo le leggi e regolazioni locali.
Advarsel
Endelig kassering av dette produktet skal være i henhold til alle relevante nasjonale lover og
bestemmelser.
Aviso
Deitar fora este produto em conformidade com todas as leis e regulamentos nacionais.
¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales.
Varning!
Vid deponering hanteras produkten enligt gällande lagar och bestämmelser.

20
Cisco 40-Gigabit QSFP+ Transceiver Modules Installation Note
OL-24862-01
Translated Safety Warnings
Statement 1057—Hazardous Radiation Exposure
Aviso
O descarte definitivo deste produto deve estar de acordo com todas as leis e regulamentações
nacionais.
Advarsel
Endelig bortskaffelse af dette produkt skal ske i henhold til gældende love og regler.
Warning Use of controls, adjustments, or performing procedures other than those specified may result in
hazardous radiation exposure.
Waarschuwing
Het gebruik van regelaars of bijstellingen of het uitvoeren van procedures anders dan opgegeven
kan leiden tot blootstelling aan gevaarlijke straling.
