Citizen CMP-40 SERIES Installation and operation manual

Mobile Printer
CMP-40
Windows Driver Manual
VER.1.00
6-1-12 Tanashi-cho, Nishi-Tokyo-shi, Tokyo 188-8511
JAPAN
Tel [phone]
Fax [phone]
[e-mail]
http://www.citizen-systems.co.jp

CMP-40 Windows Driver
- 1 -
Caution
(1) You are hereby notified that any dissemination, distribution or copying of this document without written
consent is strictly prohibited.
(2) The contents of this document are subject to change without prior notice.
(3) We tried to ensure the content of this document but if you find any mistakes, please let us know.
(4) Regardless of article (3), we cannot be responsible for any damages/influences caused by the use of this
driver.
(5) If you do not agree any of above, you are not allowed to use the driver.
Trade marks
Microsoft, Windows 2000, Windows XP, Windows Server 2003, Windows Vista, Windows 7, Windows8,
Visual Basic, Visual C++, Visual C#, .Net, Microsoft Word, Microsoft Access and TrueType are trademarks of
Microsoft Corporation.
All other company names or product names are the trademarks or registered trademarks of their respective
holders.
CITIZEN is a registered trade mark of CITIZEN WATCH CO., LTD., Japan
CITIZEN es una marca registrada de CITIZEN WATCH CO., LTD., Japón

CMP-40 Windows Driver
- 2 -
Index
1. About This Document ..........................................................................................................................3
2. Support OS............................................................................................................................................3
3. Driver Installation..................................................................................................................................3
3-1 Preparation of Driver Installation......................................................................................................3
3-2 Installation for USB interface ............................................................................................................4
3-3 Installation for Serial or Bluetooth interface....................................................................................7
3-4 Serial Port Setting...............................................................................................................................9
4. Uninstallation of Driver ...................................................................................................................... 11
5. Driver for Receipt (ESC/POS)............................................................................................................12
5-1. Driver Function................................................................................................................................12
5-2. Driver Device Font...........................................................................................................................23
5-3. Logo Utility.......................................................................................................................................25
6. Driver for CPCL (Label)......................................................................................................................26
6-1. Driver Function................................................................................................................................26
6-2. Driver Device Font...........................................................................................................................30

CMP-40 Windows Driver
- 3 -
1. About This Document
This document describes about Window driver for CMP-40 (ESC/POS or CPCL emulation).
2. Support OS
The driver supports following OS.
Microsoft Windows 2000
Microsoft Windows XP
Microsoft Windows 2003 Server
Microsoft Windows Vista
Microsoft Windows 2008 Server
Microsoft Windows 7
Microsoft Windows 8
Microsoft Windows 2012 Server
3. Driver Installation
3-1 Preparation of Driver Installation
CD-ROM which comes with printer includes the Windows driver for CMP-40.
And latest driver can be downloaded from our web site as well.
If the interface is Bluetooth, Serial or WLAN, check the COM port or TCP/IP address before starting driver
installation. If the interface is serial, check the serial port setting of CMP-40 by self-printing.
Run the driver installer file “CITIZENCMP-40PrinterDriver1.xx.exe”.
(1.xx means the version of the driver installer.).
CMP-40 has emulation setting and either ESC/POS or CPCL can be chosen.
CMP-40 Receipt driver is only for ESC/POS and CMP-40 Label driver is only for CPCL.
Change the emulation setting to have same emulation between printer and driver.

CMP-40 Windows Driver
- 4 -
3-2. Installation for USB interface
Before connecting printer, run “CITIZENCMP-40PrinterDriver1.xx.exe” to start driver installation.
Check the model (emulation) to install driver and press “Installation”.
If necessary, you can install both drivers together.
If you use USB interface for the driver, choose USB from “Printer Port” drop-down menu and press “OK”.

CMP-40 Windows Driver
- 5 -
When you see the message below, connect printer to the PC, turn the printer on and press “OK”.

CMP-40 Windows Driver
- 6 -
If you see the message below, choose “Install this driver software anyway”.
When the message below appears, installation is finished.
Please check if you can see the CMP-40 driver in “Devices and Printers”

CMP-40 Windows Driver
- 7 -
3-3 Installation for Serial, Bluetooth or WLAN interface
Beginning procedures are same as USB.
Choose the COM port for serial or Bluetooth. If interface is WLAN, choose TCP/IP.
If you choose COM port, you see the message below.
Choose Yes for Bluetooth and choose No for Serial interface.
If you choose WLAN interface (TCP/IP), enter TCP/IP address of printer in the dialogue below.

CMP-40 Windows Driver
- 8 -
Last steps of installation procedure are same as USB.

CMP-40 Windows Driver
- 9 -
3-4 Serial Port Setting
For Serial port, you may need to change port setting.
In “Devices and Printers”, choose CMP-40 drive icon and right-click. Then choose “Printer properties”.
Choose ”Port” tab and press “Configure Port”.

CMP-40 Windows Driver
- 10 -
You can change the Bits per second (Baud rate), Data bits, Parity, Stop bits, and Flow control here.

CMP-40 Windows Driver
- 11 -
4. Driver Uninstallation
1) Move to “C:\CMP-40 1.X” folder and run “DriverUninstaller.exe”.
or you can do the same from “Uninstall a program”.
2) Choose the driver to uninstall and press “Uninstallation(D)”.
(You can uninstall both drivers altogether.)
When you see the message below, press OK to complete the uninstallation.

CMP-40 Windows Driver
- 12 -
5. Driver for Receipt (ESC/POS)
5-1. Driver Function
5-1-1. Printer Commands
You can add command to the top/bottom of print data generated by the driver.
“Begin Document” is added to the top of print data. “End Document” is added to the bottom of print data.
Paper feeding length at the end of printing can be changed as well.

CMP-40 Windows Driver
- 13 -
5-1-2. Print Order
You can change the order of printing pages for multiple pages or multiple copies printing.
If you want reverse order, click ”Reverse Print Order”.

CMP-40 Windows Driver
- 14 -
5-1-3. Print Orientation and Adjusting Printing Size
This tab allows following function.
Choosing paper size, defining own paper size, choosing page orientation and adjusting printing size.

CMP-40 Windows Driver
- 15 -
5-1-4. Barcode
You can define barcode type, size and HRI setting for Font name Barcode1 through Barcode8.

CMP-40 Windows Driver
- 16 -
5-1-5. 2D Code
You can define 2D barcode type, module size, column number, error correction level to the Font name 2D-
Code1 through 2D-Code8.

CMP-40 Windows Driver
- 17 -
5-1-6. Logo Printing
Two ways of logo printing are supported.
One is printing logo data registered in NV memory. The other one is printing BMP file.
For the timing of logo printing, Start/End of Document or Start/End of page can be selected.
Horizontal position can be selected for NV logo. Dithering type, density and size can be selected for BMP file
printing. Logo Utility is installed together with driver and when you press “Logo Download”, the utility appears.
(See 5-3 section)

CMP-40 Windows Driver
- 18 -
5-1-7. Water Mark
Choose the bitmap file for watermark and specify the printing position, density and size.

CMP-40 Windows Driver
- 19 -
5-1-8. Coupon Printing
This is similar function as BMP file logo printing or water mark printing.
Choose BMP file, dithering type, vertical printing position, density and size.
