Clarion BKX-1276-07 User manual

2-DIN BKX-1276-07
Installation kit includes the following items:
* 1X Radio trim
* 1X Metal fixing band
* 4X Screws
* 2X Bolt
* 4X Plastic spacers
Installation manual for:
Ssang Yong Actyon 2006 -->
Remove the panel at the location of the
arrows. Remove the original bracket. This is
tighten by four screws at the location of
the arrows.
12

Place the plastic spacers in the metal
bracket.
This must be placed 2 centimeters
measured from the edges.
Remove the original plastic bracket from
the metal bracket. This is tighten by four
screws.
The inner plastic panel must be gently
removed. This is marked with white
stripes.
Connect all of the needed wiring harnesses and check the connections carefully.
34
5
Mount the metal band beneath the
original bracket.
6
Tighten the headunit onto the metal
band. There are various posistions of the
metal band possible. Choose the positions
which gives the best result.
7
2-DIN BKX-1276-07
Place the metal bracket which includes
the headunit. Place the dashboard panel.
Place the radio trim.
6
