Clarion OHM875VD User manual

OHM875VD / OHM1075VD / OHM1575VD 1
English
Owner’s manual
OHM875VD
OHM1075VD
OHM1575VD
OVERHEAD MONITOR SYSTEM WITH DVD PLAYER
OHMOwnersManual.indd 1OHMOwnersManual.indd 1 1/5/2007 12:26:41 PM1/5/2007 12:26:41 PM

2 OHM875VD / OHM1075VD / OHM1575VD
English
Thank you for purchasing this Clarion product.
• Please read this owner’s manual in its entirety before operating this equipment.
• After reading this manual, keep it handy, such as in your glove compartment.
• Save your sales receipt. The warranty at the end of this manual and your sales
receipt are essential for warranty service.
FCC Approval
The Clarion OHM875VD / OHM1075VD / OHM1575VD products have been tested
and found to comply within the limits of a Class B digital device, pursuant of Part 15
of the FCC rules. These limitations are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates
and uses radio frequency energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to a radio or television reception,
turn off the equipment and contact a local Clarion Dealer for assistance. Changes or
modifications to this product not approved by the manufacturer will void the warranty
and violate FCC Approval.
Contents
FCC Approval.......................................................................................................... 2
1. FEATURES.............................................................................................................. 4
Image features ........................................................................................................ 4
DVD video features ................................................................................................. 5
Other features ......................................................................................................... 5
2. PRECAUTIONS....................................................................................................... 6
Operating ................................................................................................................ 6
General ................................................................................................................... 6
Maintenance............................................................................................................ 7
Installation ............................................................................................................... 7
OHMOwnersManual.indd 2OHMOwnersManual.indd 2 1/5/2007 12:26:57 PM1/5/2007 12:26:57 PM

OHM875VD / OHM1075VD / OHM1575VD 3
English
3. CONTROLS............................................................................................................. 8
Monitor closed......................................................................................................... 8
DVD drive slot.......................................................................................................... 9
Monitor open ......................................................................................................... 10
Remote control...................................................................................................... 11
4. OPERATIONS ....................................................................................................... 12
Opening the monitor.............................................................................................. 13
Closing the monitor ............................................................................................... 13
Handling discs....................................................................................................... 14
Turning the player on............................................................................................. 14
Turning the player off............................................................................................. 14
Changing the image aspect ratio .......................................................................... 14
Playing a disc (DVD or CD) ................................................................................... 15
Using headphones ................................................................................................ 15
Playing DVDs ........................................................................................................ 17
Playing audio CDs................................................................................................. 21
Playing MP3s ........................................................................................................ 22
Care and maintenance.......................................................................................... 23
Changing the battery in the remote control........................................................... 24
5. INSTALLATION AND WIRING .............................................................................. 25
What is included in the box ................................................................................... 25
Tools and additional components.......................................................................... 25
Before you begin ................................................................................................... 26
Mounting and wiring precautions .......................................................................... 26
Installation procedure............................................................................................ 27
Wiring diagram ...................................................................................................... 30
6. SETTING PREFERENCES ................................................................................... 30
Accessing the on-screen display menus ............................................................... 30
Example: Setting parental control ......................................................................... 31
General setup page............................................................................................... 32
Speaker setup page .............................................................................................. 32
Preference page.................................................................................................... 33
7. TROUBLESHOOTING........................................................................................... 34
8. GLOSSARY........................................................................................................... 37
9. SPECIFICATIONS................................................................................................. 38
OHMOwnersManual.indd 3OHMOwnersManual.indd 3 1/5/2007 12:26:57 PM1/5/2007 12:26:57 PM

4 OHM875VD / OHM1075VD / OHM1575VD
English
1. FEATURES
WARNING
The Clarion OHM875VD / OHM1075VD / OHM1575VD
overhead monitor players are designed strictly for rear-seat
entertainment. Viewing the monitor while operating a motor
vehicle can result in serious injury and/or property damage.
Clarion is not responsible for any injury and/or property
damage as a result of the improper use or viewing of the
monitor.
The Clarion OHM875VD / OHM1075VD / OHM1575VD overhead monitor players are
engineered with advanced technological designs and components to combine flexibility
with reliability, and expandability for the best picture quality and ease-of-use.
Flexibility
Designed primarily for rear seat entertainment, the audio from a OHM875VD /
OHM1075VD / OHM1575VD can be enjoyed privately through wireless headphones
and/or incorporated into any head unit.
Reliability
High-grade electronic components and heightened electronic connections provide
years of service in extremely harsh, mobile environments.
Expandability
The player’s built-in audio/video (A/V) connectors allow you to add multiple A/V sources.
Image features
• Flip-down thin film transistor (TFT) active matrix display with screen width that
depends on the model:
OHM875VD: 8.0”
OHM1075VD: 10.2”
OHM1575VD: 15.4”
• WVGA LCD with 16:9 or 4:3 aspect ratios
• Screen resolution depending on the model:
OHM875VD: 800 x 480 pixels
OHM1075VD: 800 x 480 pixels
OHM1575VD: 1024 x 768 pixels
• NTSC and PAL support
OHMOwnersManual.indd 4OHMOwnersManual.indd 4 1/5/2007 12:26:57 PM1/5/2007 12:26:57 PM

OHM875VD / OHM1075VD / OHM1575VD 5
English
• Wide viewing angle (up/down/left/right) for all three models:
OHM875VD and OHM1075VD: 45/55/65/65
OHM1575VD: 10/30/40/40
• Manual display angle adjustment: vertically adjustable up and down with a
maximum angle of 150 degrees
• Adjustable color, contrast brightness, and hue (PAL) or tint (NTSC)
• On-screen display (OSD) of configuration options
DVD video features
• DVD drive that supports the following formats:
• Playback of CDs with two recorded sessions (one audio and one data).
• Multi-sound ( ): DVD audio that supports up to eight languages per film
• Multi-angle function ( ): for DVDs that provide multiple views of the same scene
• Subtitles ( ): support up to 32 languages
• The playback of MP3 music files stored on a CD-R/CD-RW disc
• Region number assigned based on the sales area; region number is indicated on
the box as follows:
Other features
• Roof mounting
• Automotive start-up protection
• 2 audio/video inputs and 1 audio/video output
• White LED built-in dome light
• Built-in IR transmitter for IR wireless headphones
• IR remote control
• Slot-in DVD mechanism
OHMOwnersManual.indd 5OHMOwnersManual.indd 5 1/5/2007 12:26:57 PM1/5/2007 12:26:57 PM

6 OHM875VD / OHM1075VD / OHM1575VD
English
2. PRECAUTIONS
Failure to observe these precautions may damage your car, the monitor, or the video
source, and may void the warranty.
For questions or problems not covered in this manual, contact your local Clarion Dealer.
Operating
• Do not operate this product in ways other than those described in this manual.
Failure to follow instructions may void the warranty.
• Do not use the unit with the ignition off. This could drain the car’s battery.
• If the internal temperature of the vehicle is extremely high (over 50 degrees
Celsius), let the unit cool down a bit before you use it.
• If the temperature in the car is very low (below -5 degrees Celsius), starting the
unit right after you start the car with its heater running may cause moisture to form
on the LCD. Turn the unit off immediately! Failure to do so may cause an electrical
short. Allow about one hour for the condensation to dissipate before using the unit.
• In extremely cold temperatures the picture may appear dark and move slowly. The
display returns to normal when the temperature rises.
• When using the system, make sure you are seated with your seat belt fastened.
Otherwise, you may hit your head on the unit if the driver breaks suddenly. In an
accident, injuries can be more severe if your seat belt is not fastened.
• Before leaving the car, eject the DVD disc and store it separately away from direct
sunlight. Heat and humidity can damage DVD discs causing them not to play.
General
• Do not leave the monitor extended when you’re not using it. Direct sunlight can
cause the monitor to malfunction.
• Do not hang onto or hang items from the overhead monitor.
OHMOwnersManual.indd 6OHMOwnersManual.indd 6 1/5/2007 12:26:58 PM1/5/2007 12:26:58 PM

OHM875VD / OHM1075VD / OHM1575VD 7
English
• Do not pour liquid into the unit or poke foreign objects into the DVD drive slot. Water,
humidity, and foreign objects may damage internal circuitry.
• If the unit becomes wet, turn off all power and ask your authorized Clarion Dealer to
clean or service the unit.
• Do not drop the unit or hit the LCD panel with a hard object. You may cause
permanent damage.
• If the LCD breaks, avoid touching the glass and fluid. If you do touch the fluid, clean
it off your body and/or clothes with plenty of water, then get medical attention.
Maintenance
• Do not clean the surface of the LCD with chemical solvents or corrosive detergent.
Permanent damage to the screen may result.
• Do not disassemble or modify this unit.You may damage the monitor, void the
warranty, and suffer electric shock.
Installation
Installation of mobile audio and video components requires experience with a variety
of mechanical and electrical procedures. Although this manual provides general
installation and operation instructions, it does not show the exact installation methods
for your particular vehicle.
If you do not have the required knowledge, experience, and/ortools to successfully
complete the installation, consult an authorized Clarion Dealer about professional
installation options.
OHMOwnersManual.indd 7OHMOwnersManual.indd 7 1/5/2007 12:26:58 PM1/5/2007 12:26:58 PM

8 OHM875VD / OHM1075VD / OHM1575VD
English
3. CONTROLS
Monitor closed
Dome light switch
ON OFF DOOR
Dome light Dome light
Power button
A/V input source button
Menu button
Decrease button
Release button
Increase button
Next button
Previous button
Stop button
Play or pause button
Eject button
IR window
Looking up from directly below at the player with the LCD panel closed
Quick reference to controls with monitor closed
Audio/video input
source (A/V)
Selects the video input source: DVD-IN, AV IN1 or AV IN2
Decrease button (-) Reduces a value in a menu, such as the volume.
Dome light Provides an interior light for the vehicle.
Dome light switch Configures the dome light: ON, OFF or door activated. To
manually turn the light on or off, move this switch to the ON
or OFF positions. In the door-activated position, the dome
light turns on and off when you open and close the car
door.
OHMOwnersManual.indd 8OHMOwnersManual.indd 8 1/5/2007 12:26:58 PM1/5/2007 12:26:58 PM

OHM875VD / OHM1075VD / OHM1575VD 9
English
Note:
The dome light switch works only when the green dome light wire
is connected to the door sensor and the polarity switch is set
correctly. See the vehicle’s wiring manual for connection details.
Eject button (EJECT) Ejects the disc.
Increase button (+) Increase a value in a menu, such as the volume.
IR window Receives infrared (IR) signals from the remote control and
sends IR signals to the headphones.
Menu button (MENU) Opens the Display menu. Press again to sequentially
select each menu item.
Fast Forward button
(FF)
Skips to the next chapter on a DVD or track on a CD. Press
and hold to fast forward at 2x, 4x, 8x, 16x and 32x speeds.
Play/pause button
(PLAY)
Plays or pauses the disc.
Power button
(POWER)
Turns power to the player on and off.
Rewind (fast reverse)
button (REW)
Skips to the previous chapter on a DVD or track on a CD.
Press and hold to fast reverse at 2x, 4x, 8x, 16x and 32x
speeds.
Release button Opens the LCD panel.
Stop button (STOP) Press once to stop playback. Then, to resume where the
player left off, press the play/pause button.
Press this button twice to fully stop playback. Then, to start
playing at the beginning of the disc, press the play/pause
button.
DVD drive slot
Insert DVD and CD discs into this slot
Back seat Front of the car
View of the player from the front seat, passenger’s side
OHMOwnersManual.indd 9OHMOwnersManual.indd 9 1/5/2007 12:26:58 PM1/5/2007 12:26:58 PM

10 OHM875VD / OHM1075VD / OHM1575VD
English
Monitor open
ON OFF D OOR
RESET
Reset button
LCD off switch
Screw hole Screw hole
Screw hole
Screw hole
Looking up from directly below at the player with the LCD panel open
Quick reference to controls with monitor open
LCD off switch Turns off the LCD screen.
Reset button Press with a pencil or other narrow-tipped tool to return all
setup options to their factory default values.
Screw holes Used to attach the player to the mounting plate.
OHMOwnersManual.indd 10OHMOwnersManual.indd 10 1/5/2007 12:26:59 PM1/5/2007 12:26:59 PM

OHM875VD / OHM1075VD / OHM1575VD 11
English
Remote control
1234
56
90
78
SETUP MUTEPOWER
DISPLAY GOTO
>
>
>
>
ENTER
MENU
VOL
SUBTITLE
TITLEREPEAT
A-B
RANDOM
SRC RETURN ANGLE ZOOM
AUDIO
Power Eject
Setup Mute
Numbers
Previous
Play or pause
Audio
Menu navigation
A-B
Source
Angle
Goto
Display
Stop
Next
Volume
Menu
Fast forward
Title
Repeat
Zoom
Return
Subtitle
Random
Remote control
Quick reference to remote control
A-B Repeats playback from previously identified points A to B.
Angle Changes a scene angle when playing back a DVD that includes
multiple scene angles.
Arrows Selects options on DVD menu and values on Display menu.
Audio DVD: Changes the language during playback. For a VCD/CD:
Changes audio channel (left, right, stereo) during playback.
DISPLAY Displays playback information: title, chapter, track and time.
OHMOwnersManual.indd 11OHMOwnersManual.indd 11 1/5/2007 12:26:59 PM1/5/2007 12:26:59 PM

12 OHM875VD / OHM1075VD / OHM1575VD
English
ENTER Accepts settings selected using the arrow keys.
Eject Ejects the current disc in the slot.
Fast forward Speeds playback forward at 2x, 4x, 8x, 16x and 32x speeds.
Goto Starts playback at the selected chapter, track or time.
Menu Displays the DVD’s main menu. Press and hold to view the
Display menu.
Mute Disables and enables sound.
Next Jumps to next chapter on a DVD or to next track on a CD.
Numbers Used to directly enter track numbers and to configure some
options.
Play or pause Starts and stops playback of a DVD or CD.
Power Turns the player on and off.
Previous Jumps to previous chapter on a DVD or previous track on a CD.
Random Plays back chapters or tracks in random order.
Repeat Alternates among repeat options. For a DVD: 1x Chapter, 2x
Title, 3x All. For a CD: 1x Track, 2x All.
Return Single press returns to main menu; second press returns to last
position of playback.
Rewind (fast
reverse)
Fast reverses playback at 2x, 4x, 8x, 16x and 32x speeds.
Setup Accesses the setup menu used to modify player options.
Source Selects the video input source: DVD-IN, AV IN1 and AV IN2.
Stop Stops playback. Then press the play/pause or ENTER buttons to
resume playing back at last position. Press the stop button twice
to fully stop playback, then press the play or ENTER buttons to
start playing back at the beginning of the DVD.
Subtitle Turns pre-recorded subtitles on and off.
Title Displays the DVD’s title menu.
Volume) Decreases and increases the volume.
Zoom Zooms in when viewing a movie or photographs. As you press
ZOOM, the player alternates among the available zoom settings
(2x, 3x, 4x, 1/2x, 1/4x and normal).
4. OPERATIONS
The monitor and DVD player provide the video; headphones provide the audio. The unit
receives power from the power connector used for the car’s dome light, which the unit
replaces.
OHMOwnersManual.indd 12OHMOwnersManual.indd 12 1/5/2007 12:26:59 PM1/5/2007 12:26:59 PM

OHM875VD / OHM1075VD / OHM1575VD 13
English
Opening the monitor
1. Press the release button to open the overhead monitor screen.
ON OFF D OOR
Release button
Looking up at the monitor from directly below
2. Gently swing the LCD down and adjust the angle for viewing.
150° maximum angle
Monitor open
CAUTION
The LCD opens to a maximum angle of 150 degrees. Do not
attempt to open it further.
The monitor turns on automatically when you fully open it (assuming the ignition
switch is on or in the ACC position).
Closing the monitor
Gently push the back side of the LCD until it clicks into the overhead housing. The
monitor turns off automatically when you return it to the closed position.
Note:
When closing the LCD panel, do not let cords or other items get
caught between the LCD and the overhead housing. Doing so can
seriously damage the TFT screen.
For safety, close the LCD panel when you are not using it.
OHMOwnersManual.indd 13OHMOwnersManual.indd 13 1/5/2007 12:26:59 PM1/5/2007 12:26:59 PM

14 OHM875VD / OHM1075VD / OHM1575VD
English
Handling discs
• To keep a disc clean, do not touch the play side (non-label side).
• Do not attach sticky notes to or put tape on a disc.
• Keep discs away from direct sunlight and heat.
• Store discs in a protective disc case.
• Before playback, wipe the disc outwards from the center with a clean
cloth.
Turning the player on
1. Turn the ignition to either ACC or ON.
AC C
OFF
ON
2. Press the power button ( ) on the player or on the remote.
If no disc is in the drive, it displays: “NO DISC.”
4. To change input sources, press SRC and alternate among A/V input sources: DVD-
IN, AV IN1 (first additional audio-video source) and AV IN2 (second audio-video
source). Additional AV sources must be connected.
Note:
You cannot insert a DVD into the slot if you’ve selected an
alternate audio-video source (AV IN1 or AV IN2).
Turning the player off
To turn the power off, press the power button ( ).
If a CD or DVD is playing when you turn the power off and back on again, the player
continues playback from where you stopped.
Note:
Once the player is turned off, you cannot eject a DVD or CD left in
the slot.
Changing the image aspect ratio
A common display setting to change is screen mode, which controls the aspect ratio
used to display images.
Do not leave the headphones in a place that is subject to direct sunlight or extreme
temperatures.
An IR receiver in the headphones that is exposed to direct sunlight for an extended
period of time may cause poor sound quality. Let the headphones cool off before you
use them.
OHMOwnersManual.indd 14OHMOwnersManual.indd 14 1/5/2007 12:26:59 PM1/5/2007 12:26:59 PM

OHM875VD / OHM1075VD / OHM1575VD 15
English
Playing a disc (DVD or CD)
1. Put the headphones on your head and turn the headphone power on.
2. Assuming the power is on, insert a DVD into the player.
The player displays “Loading.”
3. Aim the remote control directly at the IR receiver on the player and press the play/
pause button ( ) or press ENTER (on the remote).
Using the remote control
• Use the remote control only inside the vehicle.
• Use the remote control no further than five feet (three meters) from the sensor.
• Direct sunlight (or a very bright light) reduces sensitivity to remote signals. Do not
use the player in direct sunlight.
• Any object that comes between the infrared sensor and the remote control may
disrupt reception.
Controlling playback
• To pause and resume, press the play/pause button ( ).
• To stop playback, press the stop button ( ).
If you press the stop button ( ) and then press the play/pause button ( ) again,
playback begins from the beginning of the last chapter played, not the last exact
location when you interrupted playback.
• To play back the previous track or chapter, press the previous button ( ).
• To play back the next track or chapter, press the next button ( ).
• To remove the CD or DVD, press the eject button ( ).
• To mute the sound, press the MUTE button on the remote. Press this button again
to enable sound again.
Using headphones
To hear the audio requires headphones.
WARNING
Do not use the headphones while driving.
OHMOwnersManual.indd 15OHMOwnersManual.indd 15 1/5/2007 12:27:00 PM1/5/2007 12:27:00 PM

16 OHM875VD / OHM1075VD / OHM1575VD
English
Headphone components
POWER VOLUME
OFF--ON
Power light
Power switch
Volume dial
Headphones
Installing batteries in the headphones
If this is the first time you’re using the system, install batteries in the headphones.
Change the batteries when you begin to hear distorted audio that cuts in and out.
1. Rotate the left earpiece so the battery cover is
accessible.
2. Slide the battery cover down.
3. If replacing the batteries, remove the
discharged batteries.
Battery cover
Close-up of the left earpiece
4. Insert the new AAA batteries according to the
polarity marked inside the battery compartment.
5. Slide the battery cover back into place. Batteries installed
Close-up with batteries
installed
Setting the volume
The volume control is on the headphones. Turn the volume dial up or down.
Note:
Some noise may be audible depending on the type of encoder
software used while recording. This noise is not caused by the
OHM875VD / OHM1075VD / OHM1575VD.
OHMOwnersManual.indd 16OHMOwnersManual.indd 16 1/5/2007 12:27:00 PM1/5/2007 12:27:00 PM

OHM875VD / OHM1075VD / OHM1575VD 17
English
Direct sunlight and temperature extremes
Do not leave the headphones in direct sunlight or extreme temperatures.
Playing DVDs
Accessing the root menu
A DVD is divided into titles and chapters. The root menu shows the contents of the disc.
Some DVDs only allow you to select disc playback options from the DVD root menu.
To access the root menu of the DVD, press the MENU button during playback.
DVD root menu
Status information
To view status information about the current viewing session, press the DISPLAY
button continuously to cycle through the following information.
Status information
Changing languages
Note:
All audible languages must be pre-recorded on the DVD. Some
DVDs only allow language access through the DVD menu.
• To change the audible language, press the AUDIO button on the remote.
The player displays the current language number and name, and the total number
of languages available.
OHMOwnersManual.indd 17OHMOwnersManual.indd 17 1/5/2007 12:27:00 PM1/5/2007 12:27:00 PM

18 OHM875VD / OHM1075VD / OHM1575VD
English
Sample language option
• To cycle through all available languages, continue pressing the AUDIO button.
The audio information disappears automatically if you wait three seconds.
Using subtitles
Language subtitles are normally off.
Note:
Subtitles must be on the DVD. Some DVDs only allow subtitle
access through the DVD menu.
• To turn subtitles on, press the SUBTITLE button.
The player displays the current language number and name, and the total number
of languages for which subtitles are available.
Sample subtitle option
• If the DVD provides subtitles in multiple languages, continue pressing the
SUBTITLE button to change the subtitle language.
• To turn subtitles off, press the SUBTITLE button until the screen displays “subtitle
off.”
The display of the subtitle options disappears automatically if you wait for three
seconds.
OHMOwnersManual.indd 18OHMOwnersManual.indd 18 1/5/2007 12:27:01 PM1/5/2007 12:27:01 PM

OHM875VD / OHM1075VD / OHM1575VD 19
English
Repeating DVD chapters and titles
To repeat a chapter, title or both, during playback continue pressing REPEAT to
alternate among options.
Sample repeat option
• Chapter repeats the current chapter.
• Title repeats the current title.
• All repeats all chapters and titles.
• Off resumes normal playback.
Repeating favorite sections
To repeat a favorite section you must first mark where it begins and ends.
1. Play back the DVD.
2. To identify the beginning of your favorite section (point A), press the A-B button
when the section starts playing back.
3. To identify the end of your favorite section (point B), press the A-B button again
when play back reaches the end of the section.
To repeat this section, press the A-B button on the remote.
To cancel the repeat playback and resume normal playback, press the A-B button
again.
Changing viewing angle
Note:
Multiple angles must be pre-recorded on the DVD. Look for the
multiple angles icon ( ) on the jacket of the DVD.
• To cycle through the available viewing angles, press the ANGLE button on the
remote while playing back the DVD.
The player displays the current angle number and the total number of angles
available.
OHMOwnersManual.indd 19OHMOwnersManual.indd 19 1/5/2007 12:27:01 PM1/5/2007 12:27:01 PM

20 OHM875VD / OHM1075VD / OHM1575VD
English
Sample angle options
• To change the angle, press the ANGLE button again.
• To return to normal viewing, press the ANGLE button again.
Zooming in and out
• To zoom in (enlarge) the image when watching a DVD, press ZOOM during
playback.
As you press ZOOM on the remote, the player alternates among the available zoom
settings (2x, 3x, 4x, 1/2x, 1/4x and normal).
• To zoom in when viewing photographs (JPEG/JPG images) stored on a disc, press
ZOOM on the remote, then press ( ) or ( ) to alternate among zoom settings (2x,
3x, 4x, 1/2x, 1/4x and normal).
Adjusting picture quality
1. Press and hold the MENU button on the remote for more than one second (may
require as many as three seconds).
The player displays the “Operation Menu.”
Setup options
2. Press the MENU button again to alternate among the available options:
Contrast Adjusts the differences between the light and dark areas of the
image.
Brightness Makes the whole image lighter or darker.
Color Adjusts color based on the color spectrum.
OHMOwnersManual.indd 20OHMOwnersManual.indd 20 1/5/2007 12:27:01 PM1/5/2007 12:27:01 PM
