Clarion Series User manual

NX302E
MULTIMEDIA STATION WITH BUILT-IN NAVIGATION & 6.2” TOUCH
PANEL CONTROL
Owner´s manual

English
2NX302E
1. FEATURES ........................................................................................................................ 3
Expanding Systems........................................................................................................... 3
2. PRECAUTIONS ................................................................................................................. 4
3. CAUTIONS ON HANDLING .............................................................................................. 5
4. CONTROLS ....................................................................................................................... 6
Operational Panel.............................................................................................................. 6
Names of Buttons.............................................................................................................. 6
5. MAIN MENU OPERATION ................................................................................................ 7
6. SYSTEM SETUP................................................................................................................ 8
7. USB OPERATION............................................................................................................ 11
Accessing an USB........................................................................................................... 11
USB Audio Operation ...................................................................................................... 11
USB Video Operation ...................................................................................................... 14
8. BLUETOOTH OPERATION............................................................................................. 15
Bluetooth Telephone Operation ...................................................................................... 15
Bluetooth Audio Operation .............................................................................................. 17
9. RADIO OPERATION........................................................................................................ 18
Radio Data System Operation......................................................................................... 20
10. iPod & iPhone OPERATION......................................................................................... 21
11. NAvIGATION OPERATION........................................................................................... 23
12. AUX OPERATION.......................................................................................................... 23
13. TROUBLE SHOOTING.................................................................................................. 24
14. SPECIFICATIONS ......................................................................................................... 26
15. WIRING AND CONNECTIONS...................................................................................... 27
Thank you for purchasing this Clarion product.
• Please fully read this owner’s manual before operating this equipment.
• Check the contents of the enclosed warranty card and store it in a safe place with this manual.
Contents

3
English
NX302E
1. FEATURES
• 6.2”Wide-VGAColorLCDTouchPanel
• Front-PanelAuxiliaryInputand2chRCAOutputwithSubwooferControl
• BEAT-EQwith3BandParametricEqualizerandMAGNABASSEXDynamic
BassEnhancement
• LatestMapGuarantee
Expanding Systems
PortablePlayer
(ConnectviaAUXINJack)
USBMemory
Bluetooth®
cellularphone
iPod®/ iPhone®
(ConnectviaCCA-750)
2ChannelAmplier
Expandingaudiofeatures
Rear
Monitor
Rear Vision
Camera
Expandingvisualfeatures
Notes:
•
•

English
4NX302E
2. PRECAUTIONS
For your safety, the driver should not operate the controls while driving.
Also, while driving, keep the volume to a level at which external sounds can be heard.
1. This unit uses precision parts and components for its operation. In the event that trouble
arises, never open the case, disassemble the unit, or lubricate the rotating parts. Contact your
Clarion dealer or service center.
2. “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been
designed to connect specically to iPod, or iPhone, respectively, and has been certied by
the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and
regulatory standards. Please note that the use of this accessory with iPod or iPhone may
affect wireless performance.
iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries.
3. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Clarion Co.,Ltd, is under license.
WARNING
CHINA
531-1602kHzAM
FM 87.5-108MHz
PN:127070009973TX-1092E-A
This product includes technology owned by Microsoft Corporation and
cannot be used or distributed without a license from MSLGP.
03 2234
NX302E

5
English
NX302E
Front Panel / Generalities
For a longer service life, be sure to read the following cautions.
• Do not allow any liquids on the unit from drinks, umbrellas, etc. Doing so may damage the
internal circuitry.
• Do not disassemble or modify the unit in any way. Doing so may result in damage.
• Do not let cigarettes burn the display. Doing so may damage or deform the body.
• If a problem should occur, have the unit inspected at your store of purchase.
• The remote control unit may not work if the remote control sensor is exposed to direct
sunlight.
Cleaning the body
• Use a soft, dry cloth and gently wipe off any dirt and/or dust.
• For tough dirt, apply some neutral detergent diluted in water to a soft cloth, wipe off the dirt
gently, then wipe again with a dry cloth.
• Do not use benzene, thinner, car cleaner, etc., as these substances may damage the body
or cause the paint to peel. Also, leaving rubber or plastic products in contact with the body for
long periods of time may cause stains.
USB Port
• The USB memory sticks must be recognized as “USB mass storage class“ to work properly.
Some models may not operate correctly.
 Whenthememorizeddataislostordamagedbyanychance,Clarionshallnotbeliable
foranydamage.
When using an USB memory stick, we recommend that you backup your data stored on it
before using a personal computer etc.
• Data les may be broken when using USB memory sticks in the following situation: When
disconnecting the USB memory stick or turning the power off during reading data.
When affected static electricity or electric noise.
Connect/disconnect the USB memory stick when it is not accessed.
• Connecting with the computer is not covered.
3. CAUTIONS ON HANDLING

English
6NX302E
[POWER/VOL]Knob
• Press to power on the system when ignition on.
• When power on, short press to mute the volume.
• Rotate the knob to increase or decrease the volume.
• Press and hold this key more than 1 second to turn off the system.
[ ALL]ALLMENUButton
• Short press to show/exit shortcut menu.
• Long press to show/exit main source menu.
[ ]NAVI/AVButton
• Press to enter navigation mode;
• Press again to return current source.
[ MIC ] Hole
• Internal microphone
[RESET]Button
• Press to load original settings.
Note: When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored
in memory are cleared.
4. CONTROLS
Operational Panel
Names of Buttons
AUXJack
[MIC]
RESET
[POWER/vOL]
[ ALL ] ALL MENU
[ ] NAvI/Av
MicroSDcardslot
Only navigation map
card is available and
don't remove it when
unit is power on.

7
English
NX302E
5. MAIN MENU OPERATION
Long press [ ALL ] button on the PANEL to
show main source menu.
Short press [ ALL ] button to show Short
cut menu.
Playing Source
Touch [-] on the bottom of screen to show
front zone sources.
Change page by dragging left or right or
touching other two [-] buttons.
Touch the icons on the screen to enter
corresponding work mode, such as USB
mode, Tuner mode, Telephone mode, etc.
Touch [AudioOff] to mute the volume.
Custom Setting
Touch [Custom] on the bottom of screen to
show custom setting menu.
[Settings]: Touch the icon to enter system
setting menu. (see “System Setup”)
[BeatEQ]: Touch the icon to enter equalizer
setting menu. (see “System Setup”)
[ShortCut]: Touch the icon to enter Shortcut
setting menu. Hold the desired icon for more
than 2 seconds until it’s activated, then drag
it to the bottom. The name will appear on the
bottom.
• Hold the center of the screen and drag left
or right to show more icons.
• You can make total 5 shortcuts.
• You can access the shortcut list by
pressing the [ ALL ] button.
[Wallpaper]: Touch the icon to enter
Wallpaper setting menu. (see “System
Setup”)
[MonitorOff]: Touch the icon to turn off the
monitor.
To turn on the monitor, touch the monitor
again.

English
8NX302E
At all mode, long press [ ALL ] button to
enter main source menu. Touch [Custom]
on the bottom left of the screen, then select
[Settings] on the screen to enter Setting
menu. Touch the icons on the left of screen
to select category: General, Time, Sound,
Display or Setup. To exit Setting menu, touch
[ ] on the bottom left of the screen.
General
Systemlanguage
Touch the button to the right of “System
language” to show language list. Select
desired language, touch [OK] to confirm, or
touch [Cancel] to exit without saving.
Closeoperationbar
When select [Auto], the operation bar will
close automatically after 10 seconds.
When select [Manual], the operation bar will
not close unless you touch the blank area on
the screen.
Wallpaper
Touch [Set] to the right of “Wallpaper” to
show Wallpaper setting menu.
Touch [ ] or [ ] button to select the scene,
and touch the picture le name on the right
to preview it, then touch [Set] to conrm the
setting.
To import images, touch [Import].
Select a mobile storage device on the
list, then select desired images and touch
[Import]. Touch [Cancel] to exit.
Beep
Touch [On] or [Off] to turn on/off the key
beep sound.
BlinkingLED
Touch [On] or [Off] to turn on/off the blinking
LED.
At blinking LED [On] mode, when ACC off,
the LED on the top left of the panel will blink.
Ampliercancel
Touch [On] or [Off] to set the internal
amplier on or off.
Systemsoftware
Touch [version] to show current software
version.
Factorydefault
Touch [Restore] to load the original factory
settings.
Time
GPSsync
Touch [On] to synchronize time with GPS
and the following setting is disable: “Time”.
Time
Touch the button to the right of “Time” to
show time setting menu. Touch [ ] or [ ]
button to select hour or minute. Touch [Set]
to conrm or [Back] to exit without saving.
24-Hourformat
Touch [On] to select 24-Hour format.
Touch [Off] to select 12-Hour format.
Sound
BeatEQ
Touch the button to the right of “Beat EQ” to
show EQ setting menu. You can select : “Bass
Boost”, “Impact”, “Excite”, “Custom” or “Off”.
To adjust the value, touch [-] or [+] button on
the screen.
Touch [Back] to exit.
Balance/Fader
Touch [Set] to the right of “Balance/Fader” to
show Balance/Fader setting menu.
6. SYSTEM SETUP

9
English
NX302E
Touch [ ] or [ ] button to adjust Fader,
and touch [ ] or [ ] button to adjust
Balance.
Touch [Center] to reset the value.
Touch [Back] to exit.
Subwoofercontrol
Touch [-] or [+] button on the right of “Sub
woofer control” to adjust sub woofer level.
Subwooferphase
Touch to select sub woofer phase Normal or
Reverse.
Highpasslter
Touch the button to the right of “High pass
lter” to show the sub-menu, then select the
lter: “Through”, “55Hz”, “85Hz” or “120Hz”.
Touch [Cancel] to exit.
Lowpasslter
Touch the button to the right of “Low pass
Filter” to show the sub-menu, then select the
lter: “Through”, “62Hz”, “95Hz” or “135Hz”.
Touch [Cancel] to exit.
Lineout
Touch [SW] to choose Subwoofer.
Touch [Rear] to choose Rear Line out.
MagnaBassEx
Touch [On] to turn on the loudness.
Display
DimmerMode
Touch [Auto], [Day] or [Night] to choose
dimmer mode.
Auto: The dimmer is controlled by your car
light.
Dimmer
Touch [-] or [+] button to the right of “Dimmer”
to adjust dimmer.
The setting is only for Day or Night.
Setup
Touch [Setup] on the right of screen to
spread the setting list. then touch the button
to the right of desired option to adjust or
show the sub-menu. Touch [Close] to close
the list.
AUX
• Input Aux Level (AUX1)
Choose “Low”, “Middle“ or “High” input
level of auxiliary device.
Bluetooth
• Bluetooth
Choose Bluetooth function on or off.
• TelephoneSpeaker
Choose Front Left or Front Right speaker
at telephone mode.
• ToneSelect
Touch [Auto] to use ringtones of your
mobile phone.
Touch [Internal] to use preset ringtone of
the unit.
• SoftwareUpdate
Update the software.
Camera
• CameraInterrupt
Choose [On], the screen will switch to rear
camera menu automatically when backing.
Navigation
• NavigationInterrupt
Select navigation interrupt On, Pop-Up or
Off.
• VoiceGuidance
ON: Interrupt function of voice guidance
is on. While interrupting no attenuate
function of AV sound.
MUTE: Interrupt function of voice guidance
is on. While interrupting attenuate function
of AV sound is on.
OFF: Interrupt function of voice guidance
is off. While interrupting no attenuate
function of AV sound.

English
10 NX302E
Anti Theft
• AntiTheftcode
You can set an Anti-theft code. After set
successfully, when Battery wire reconnect,
you need to input the Anti-theft code.
1. Long press the [General] button until a
dialog box popped up. Touch [Yes] to set
a personal code of Anti-Theft.
2. Input a 4-digit code. Touch [OK] to conrm.
Then input it again for conrmation.
3. To remove the code, long press the
[General] button and input the old
password.
Note:
Please make a note of the Anti theft code not
to forget. if the right code is not inputted, it
becomes impossible to operate this unit.

11
English
NX302E
1. Insert an USB device into the USB cable.
When connecting an USB device, the unit
will read the les automatically.
2. To remove the USB device, you should
first select another source or turn off
the power, in order to avoid damaging
the USB device. Then take off the USB
device.
3. T o acc e s s an US B d evi c e a lre a dy
connected to the unit, long press [ ALL ]
button to enter main source menu, then
select [USB] to enter USB mode.
If [USB] is not on the current source menu,
touch [-] buttons on the bottom of the
screen, or hold the center of screen and
drag left/right to show more icons.
Accessing an USB
7. USB OPERATION
USB Audio Operation
This system can play audio les (MP3/WMA)
stored in an USB memory. You can use it as
an audio device by simply copying desired
audio les into it.
Notes:
• Thissystemwillnotoperateor may
operateimproperlywithsomeUSB.
• Filesprotected with anyDRM cannotbe
played.
Select USB Audio mode
Touch top left corner of the screen until USB
Audio appears.
MP3/WMA Playback
This unit is an ID3 Tag compatible model.
This unit supports the ID3 TAGs of the
Version 2.4, 2.3, 1.1 and 1.0.
In displaying, this unit gives priority to the
Version 2.3 and 2.4 TAGs.
What is MP3/WMA
MP3 is an audio compression method
and classied into audio layer 3 of MPEG
standards.
WMA is an audio compression method
developed by Microsoft Corporation.
These audio compression methods have
penetrated into PC users and become a
standard format.
Displaying MP3/WMA TAG titles
Tag information such as title, artist and album
title can be displayed for MP3/WMA le
containing Tag information.
Precautions when creating MP3/
WMA le
Usablesamplingratesandbitrates
1. MP3: Sampling rate 8 kHz-48 kHz, Bit rate
8 kbps-320 kbps / VBR
2. WMA: Bit rate 8 kbps-320 kbps

English
12 NX302E
Fileextensions
1. Always add a file extension “.MP3”,
“.WMA” to MP3, WMA le by using single
byte letters. If you add a file extension
other than specified or forget to add the
le extension, the le cannot be played.
2. Files without MP3/WMA data will not play.
The les will be played soundlessly if you
attempt to play files without MP3/WMA
data.
* When VBR les are played, the play time
display may differ the play location.
* When MP3/WMA les are played, a little
no sound part is caused between tunes.
Folderstructure
A storage with a folder having more than 8
hierarchical levels will be impossible.
Numberoflesorfolders
1. Up to 999 files can be recognized per
folder.
Up to 6000 les can be played.
2. Tracks are played in the order that they
were stored. (Tracks may not always be
played in the order displayed on the PC.)
3. Some noise may occur depending on
the type of encoder software used while
recording.
PlayingMP3folders
When selected for play, files and folders
(Folder Search, File Search or Folder Select)
are accessing in the order in which they were
written to the media.
As a result, the order in which they are
expected to be played may not match the
order in which they are actually played.
You may be able to set the order in which
MP3/WMA les are to be played by assigning
file names beginning with play sequence
numbers such as “01” to “99”.
For example, a medium with the following
folder/file hierarchy is subject to Folder
Search, File Search or Folder Select.
See the diagram below.
()
0

1

2♪①
♪②

5
♪⑧
♪⑦

6

7♪⑨
♪③

3

4
♪④
♪⑤
♪⑥
Layer1 Layer 2 Layer 3 Layer 4 Layer5
○Root Folder
Folder
♪File
The player will only recognize three folder
levels and does not display folders containing
other folders. In the example above, the unit
will display folders 2, 3, 5 and 7, but 1 and 6
since they do not contain others.
Playback menu
Touch the bottom half of screen to show
operation bar.
1. Show folder/le list(Browse)
2. Folder/Title/Artist/Album information
3. Play/Pause
4. Repeat play
5. Previous track
Fast reverse (long press)
6. Progress bar
7. Next track
Fast forward (long press)
8. Random play
9. Show other options

13
English
NX302E
10. Scan play
11. Back to main operation bar
Browse mode
Touch the [ ] button to show track list.
Drag up/down to browse the tracks, and
touch desired track to select it.
Pausing play
1. Touch the [ ] button on the bottom left of the
screen to pause play.
“PAUSE” appears in the display, and [ ]
button becomes [ ] .
2. Touch [ ] button to resume play.
Selecting a track
Track-up
1. Touch the [ ] button to move to the
beginning of the next track.
Track-down
1. Touch the [ ] button to move back to
the beginning of the current track.
2. Touch the [ ] button twice to move back
to the beginning of the previous track.
Fast forward/Fast reverse
Fastforward
Touch and hold the [ ] button .
Fastreverse
Touch and hold the [ ] button .
Folder Select
This function allows you to select a folder
containing MP3/WMA les and start playing
from the rst track in the folder.
Touch the [ ] button on the upper left of
the screen to show folder/file list. You can
select a folder or le by touching it.
Search Function
1. Touch the [ ] button to show folder/
le list. Touch [ ] button to enter search
menu.
2 Input numbers by touching digit buttons,
then touch [Search] to begin searching.
To delete numbers, touch [ ] button.
Other various play functions
Scanplay
This function allows you to locate and play
the rst 10 seconds of all the tracks.
Touch the [] button, then touch [Scan] to
scan play.
Repeatplay
This function allows you to play the current
track repeatedly or play a track currently
being played in the MP3/WMA folder
repeatedly.
Touch the [ ] button to select Track
Repeat, Folder Repeat or All Repeat.
Randomplay
This function allows you to play all tracks in a
random order.
Touch the [ ] button to perform random
play.

English
14 NX302E
USB Video Operation
This system can play video files (MP4, etc)
stored in an USB memory. You can use it as
an video device by simply copying desired
video les into it.
Notes:
• Thissystemwillnotoperateor may
operateimproperlywithsomeUSB.
• Filesprotected with anyDRM cannotbe
played.
• Whilevoiceguidanceisin,USBvideo
playback is interrupted.
Select USB Video mode
Touch top left corner of the screen until USB
Video appears.
Touch [ ] button to show folder/file list.
Select a desired le to play.
Playback menu
When playing, touch the bottom half of
screen to show operation bar.
1. Play/Pause
2. Repeat playback
3. Previous le
Fast reverse (long press)
4. Progress bar
5. Next le
Fast forward (long press)
6. Stop and show list menu (Browse)
7. Show other options
8. Show playback information
9. Back to main operation bar
Browse mode
Touch the [ ] button to show folder/le list.
Drag up/down to browse, and touch desired
option to select it.
Pausing play
1. Touch the [ ] button on the screen to pause
play.
“ PAUSE” appears in the display.
2. Touch [ ] button to resume play.
Selecting a le
File-up
Touch the [ ] button to move to the
beginning of the next le.
File-down
Touch the [ ] button to move back to the
beginning of the current or previous le.
Fast forward/Fast reverse
Fastforward
Hold the [ ] button .
Fastreverse
Hold the [ ] button .
Repeat play
This function allows you to play the current
file repeatedly or play files currently being
played in the folder repeatedly.
Touch the [ ] button to select File Repeat,
Folder Repeat, All Repeat or Repeat Off.
Search function
1. At video main menu, touch the [ ] button
to show folder/le list.
2. Touch [ ] button to enter search menu.
3 Input numbers by touching digit buttons,
then touch [Search] to begin searching.
To delete numbers, touch [ ] button.

15
English
NX302E
Bluetooth Telephone Operation
Pairing
1. Turn on the Bluetooth function of the unit.
(see <System Setup>, <Bluetooth>)
2. Turn on Bluetooth function of your mobile
phone.
3. Enter mobile phone’s Bluetooth setup
menu.
4. Search for new Bluetooth devices.
5. Select NX302E from the pairing list on the
mobile phone.
6. Enter “0000” as the password.
7.
After pairing successfully, indicator on
the bottom right of the screen turns blue.
Search from the unit
You can search Bluetooth device from the
unit.
1. Touch [Add] on the right of the screen, the
unit will search the Bluetooth devices and
list on the screen.
2. If your desired device isn’t on the list,
touch the button on the bottom left of the
screen to refresh.
To stop searching, touch [Cancel].
3. Touch the device name on the screen to
select it, then input PIN code on the sub-
menu.
4. After paired successfully, select device
image, touch [OK] to conrm.
5. If connect unsuccessfully, select [Retry] to
reconnect or select [Cancel] to return to
list menu.
Choose paired device
After paired, the mobile device information
appears on the right of screen, such as
model number, Signal, Battery.
1. To select other paired device, hold the
middle right of the screen, and drag it left
or right, touch it to show control buttons.
2. Touch [Connect] to connect the Bluetooth
device. Touch [Cut] to disconnect.
3. Touch [ ] to delete the paired device
from pairing list.
Telephone menu
Long press [ ALL ] button to enter main
source menu, then select [Telephone] to
enter telephone mode.
If [Telephone] is not on the current source
menu, touch [-] buttons on the bottom of the
screen, or hold the center of screen and drag
left/right to show more icons.
8. BLUETOOTH OPERATION
The Bluetooth allows you to utilize your car’s built-in audio system for wireless mobile phone or
music handsfree communication. Some Bluetooth mobile phones have the audio features, and
some portable audio players support Bluetooth feature. This system can play audio data stored
in a Bluetooth audio device. The car stereo with Bluetooth will be able to retrieve phonebook
contacts, received call, dialled call, missed call, incoming calls, outgoing call and listen to music.
Notes:
• DonotsetthemicrophoneofBluetoothhandsfreeintheplaceswithwindpassingsuchasair
outlet of the air conditioner, etc. This may cause a malfunction.
• Ifsetitintheplacessubjectedtodirectsun,hightemperaturecancausedistortion,
discolorationwhichmayresultinamalfunction.
• ThissystemwillnotoperateormayoperateimproperlywithsomeBluetoothaudioplayers.
• Clarioncannotguaranteethecompatibilityofallmobilephonestogetherwiththeunit.
• Audioplaybackwillbesettothesamevolumelevelassetduringtelephonecall.Thismight
causeproblems,ifextremevolumelevelissetduringtelephonecall.

English
16 NX302E
1. Show history categories
2. Backspace
3. Paired device information
4. Number pad
5. Call/Hang up
6. Turn on/off Auto Connect function
7. Turn on/off Auto Answer function
8. Set PIN code
9. Select internal or external microphone
10. Show next page
11. Back to main operation bar
12. Show previous page
13. Adjust microphone gain
14. Show Bluetooth information
15. Bluetooth indicator
Making a call
•DialNumber
1. Input numbers by digit-keys on the screen.
2. Touch [ ] button to dial.
Touch [ ] button to delete characters.
3. Touch [ ] button to terminate call.
•Dialed/Received/MissedCallHistory
You can search any Dialled/Missed/Received
Call History.
1. Touch [ ] button to show following history
categories: Dialed, Received, Missed and
Contacts.
Touch [Dialer] to dial number manually.
2. Touch to select a category, the numbers of
the category are displayed.
3. Select a number, touch [ ] button to
dial.
Touch [ ] to return previous menu.
•CallfromPhonebook
You can search the contact name in the
phonebook and make call.
1. Touch [ ] button and select [Contacts].
It may take a few minutes to synchronize
the phone book at rst time.
2. Select a number, touch [ ] button to
dial.
Touch [ ] to return previous menu.
Note:
Some cellular phones may not be able to
transferthePhoneBookdata.
•Answeringacall
You can answer an incoming call by pressing
the [ ] button.
* Touch [ ] b ut to n to reject a n
incoming call.

17
English
NX302E
Bluetooth Audio Operation
Audio Streaming Operation
What is audio streaming?
Audio streaming is a technique for transferring
audio data such that it can be processed as
a steady and continuous stream. Users can
stream music from their external audio player
to their car stereo wirelessly and listen to the
tracks through the car’s speakers. Please
consult your nearest Clarion dealer for more
information on the product of wireless audio
streaming transmitter offered.
CAUTION
Pleaseavoidoperatingyourconnected
mobilephonewhileaudiostreamingas
thismaycausenoiseorsoundchoppyon
thesongplayback.
Audiostreamingmayormaynotresume
aftertelephoneinterruptasthisis
dependentonmobilephone.
Note:
Besuretoreadthechapter“Pairing” and
“Choosepaireddevice”beforeproceeding.
Playback menu
Touch the bottom half of screen to show
operation bar.
1. Title/Artist/Album information
2. Play/Pause
3. Previous track
Fast reverse (long press)
4. Stop
5. Next track
Fast forward (long press)
Play / Pause a track
1. Touch the [ ] button to pause audio
playback.
2. To resume audio playback, touch the [ ]
button.
Selecting a track
Track-up
1. Touch the [ ] button to move to the
beginning of the next track.
2. Each time you touch the [ ] button, the
track advances to the beginning of the
next track.
Track-down
1. Touch the [ ] button to move back to
the beginning of the current track.
2. Touch the [ ] button twice to move back
to the beginning of the previous track.
Stop playback
Touch [ ] button to stop playback.
Note:
PlayingorderwilldependonBluetoothaudio
player. When []button is pressed, some
A2DPdeviceswill restartthecurrenttrack
depends on the duration of playback.
SomeBluetoothaudioplayersmaynot
haveplay/pausesynchronizedwiththisunit.
Pleasemakesurebothdeviceandmain
unitareinthesameplay/pausestatus in
BluetoothAudiomode.

English
18 NX302E
Select tuner for listening to the radio
Long press [ ALL ] button to enter main
source menu, then select [Tuner] to enter
Tuner mode.
If Tuner is not on the current source menu,
touch [-] buttons on the bottom of the
screen, or hold the center of screen and drag
left/right to show more icons.
Menu of listening to the radio
Touch the bottom half of screen to show
operation bar.
1. Band switch
2. Information area
3. Preset station number
4. Current station frequency
5. Show preset stations list
6. Scan preset stations
7. Manual tune backward
Auto tune backward (long press)
8. Frequency bar
9. Manual tune forward
Auto tune forward (long press)
10. Show other options
11. Choose local or distant seeking mode
12. Turn on/off Trafc Announcement
13. Turn on/off Alternative Frequency
14. Turn on/off Regional
15. Show next page
16. Back to main operation bar
17. Show previous page
18. Select Programme Type
19. Auto store preset stations
Select one radio band
Touch the top left corner of the screen to
select one radio band among FM1, FM2,
FM3 and AM.
Manual tuning
During manual tuning, the frequency will be
changed in steps.
Touch the [] or [ ] button on the
operation bar to tune in a higher / lower
station.
Auto tuning
Hold the [] or [ ] button on the
operation bar for more than 2 seconds to
seek a higher / lower station.
To stop searching, repeat the operation
above or press other buttons having radio
functions.
Note:
Whenastationisreceived,searchingstops
and the station is played.
Preset scan
Preset scan receives the stations stored
in preset memory in order. This function is
useful when searching for a desired station
in memory.
1. Touch the [ ] button on the operation
bar.
2. When a desired station is tuned in, press
the [ ] button to continue receiving that
station.
9. RADIO OPERATION

19
English
NX302E
Auto store
Only stations with sufcient signal strength
will be detected and stored in the memory.
To star automatic station search, touch
following buttons on the operation bar in
sequence: [ ] -> [ ] -> [OK]
To stop auto store, press other buttons
having radio functions.
Notes:
1. Afterauto store,the previousstored
stationswillbeoverwritten.
2. Theunithas4bands,suchasFM1,FM2,
FM3andAM.FM3andAMcan store
by AS function. Each bands can store 6
stations,NX302Ecanstore24stationsin
total.
Manual store
When one expected radio station has been
detected, touch [ ] button on the right
edge of the screen to show the preset
station list, hold one of the six preset stations
for more than 2 seconds to store it in the
memory. Touch [ ] button near the center
of screen to hide the preset station list.
Recall the stored stations
Touch [ ] button on the right edge of the
screen to show the preset station list, touch
to select a preset station.
Touch [ ] button near the center of screen
to hide the preset station list.
Local seeking
When LOCAL seeking is on, only those radio
stations with strong radio signal could be
received.
To open LOCAL function, touch [ ] button
on the operation bar, then touch the [Mode]
button to select “Local” or “DX”.
Note:
The number of radio stations that can be
receivedwilldecreaseafterthelocalseeking
mode is on.

English
20 NX302E
Radio Data System
This unit has a built-in “Radio Data System”
decoder system that supports broadcast
stations transmitting “Radio Data System”
data.
When using the “Radio Data System”
function, always set the radio to FM mode.
AF function
The AF function switches to a different
frequency on the same network in order to
maintain optimum reception.
To turn on or off AF function, touch [ ]
button on the operation bar, then touch the
[AF] button to select “On” or “Off”
 •AFON:
“AF” indicator lights up and AF function
turns on.
 •AFOFF:
“AF” indicator turns gray and AF function
turns off.
REG (Regional programme)
function
When the REG function is ON, the optimum
regional station can be received. When this
function is OFF, if the regional station area
switches as you drive, a regional station for
that region is received.
To turn on or off REG function, touch [ ]
button on the operation bar, then touch the
[REG] button to select “On” or “Off”
 •REGON:
“REG” indicator lights/blinks up and REG
function turns on.
 •REGOFF:
“REG” indicator turns gray and REG
function turns off.
Notes:
• Thisfunctionis disabledwhenanational
stationsuchasBBCR2isbeingreceived.
• TheREGfunctionON/OFFsettingisvalid
whentheAFfunctionisON.
Radio Data System Operation
TA (Trafc Announcement)
In the TA standby mode, when a trafc
announcement broadcast starts, the trafc
announcement broadcast is received as top
priority regardless of the function mode so
you can listen to it. Trafc programme (TP)
automatic tuning is also available.
* This function can only be used when
“TP” appears in the display. When “TP”
appears, this means that the “Radio Data
System” broadcast station being received
has trafc announcement programmes.
To turn on or off TA function, touch [ ]
button on the operation bar, then touch the
[TA] button to select “On” or “Off”
 •TAON:
“TA” indicator lights up and the unit is set
into the TA standby mode until a traffic
announcement is broadcast.
 •TAOFF:
“TA” indicator turns gray and the TA
standby mode is cancelled.
PTY (Programme Type)
This function enables you to listen to a
broadcast of the selected programme type.
Selecting PTY
To select PTY type, touch following buttons
on the operation bar in sequence:
[ ] -> [ ] -> [PTYSelect]
Then select desired type on the dialog box,
touch [Seek] to begin searching.
