Clarke HLS130 Instruction Manual

WARNING: Do not use the machine without reading this manual
OPERATION & MAINTENANCE
INSTRUCTIONS
GC0413
HOT WASHER
MODEL NO: HLS130
PART NO: 7320525

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Hot Washer.
The machine has been designed to use hot or cold water to clean any
surfaces which can stand the force of the high pressure water jet and the
action of the detergents used.
The machine must only be used for the purpose for which it was designed.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
LIST OF CONTENTS
The following items should be supplied in the carton. If any parts are missing or
damaged, please see your Clarke dealer where you purchased the machine.
1 x Hot Washer
1 x High Pressure Hose
1 x Spray Gun Assembly
1 x Lance Assembly
1 x Operating & Maintenance Manual

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
1. WARNING: High pressure water jets can be dangerous if subject to misuse.
They must not be directed at animals or people in order to clean clothes.
2. WARNING: Never allow children or untrained personnel to use this product.
3. NEVER operate the pressure washer with any of the covers removed.
4. NEVER attempt any electrical or mechanical repairs to this pressure washer.
Always refer to your Clarke dealer.
5. NEVER supply any liquid other than water to the water inlet.
6. WARNING: Never use the detergent facility to introduce flammable
liquids/solvents, e.g. paint thinners, petrol, oil due to risk of explosion.
7. ALWAYS release any residual pressure in the machine by turning off the
water supply and operating the trigger, before disconnecting the hose.
8. ALWAYS keep the pressure washer itself dry and clear of water spray.
9. WARNING: Never direct the spray jet at the pressure washer itself or any
other electrical equipment.
10. ALWAYS wear protective clothing, safety shoes and safety glasses. Loose
particles & other debris may be propelled at high speed by the water jet.
11. ALWAYS hold the spray gun firmly & expect the gun to ‘kick’ when starting.
12. WARNING: Only use chemical cleaning agents (detergents), that are
approved for pressure washers. CLARKE Traffic Film Remover or CLARKE
Wash and WAX (available from your dealer), are recommended.
13. WARNING:Always disconnect from the electrical power supply and
remove the plug from the socket before carrying out user maintenance.
14. ONLY use original spare parts from the Clarke service department.
15. WARNING: High pressure hoses, fittings and couplings are important
for the safety of the machine. Use only hoses, fittings and
couplings recommended by the manufacturer.
16. NEVER use the pressure washer if a power cable or important
parts of the pressure washer are damaged.
17. Use only clean Diesel Oil. NEVER use gasoline, kerosene, paint thinners,
alcohol or other highly flammable fuels.
18.WARNING: If an extension cable is used, the cable/plug must be be
fully watertight. Inadequate extension cables can be dangerous.
WARNING: WATER AT HIGH PRESSURE CAN BE DANGEROUS AND CAN
CAUSE DAMAGE IF THE OPERATOR IS CARELESS. NEVER ALLOW ANYONE
TO OPERATE THIS MACHINE UNLESS THEY ARE FAMILIAR WITH THE SAFETY
PRECAUTIONS.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY SYMBOLS
WARNING: Do not discharge the water
spray at persons or animals. Keep clear
of nozzle.
WARNING: Never direct spray toward
any electrical device or electrical
outlet.
WARNING: Risk of hot surfaces. Avoid
hot exhaust components. Don't allow
hoses to contact the exhaust exit
during or after use.
Fuel Tank
High Pressure Water Outlet
Total Stop System
Detergent Tank
Water Input

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECRICAL CONNECTIONS
Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. This product is
designed to operate on 230VAC 1ph 50Hz. Connecting it to any other power
source may cause damage.
Connect the mains lead to a suitably fused 230V, 1 phase electrical supply via
a 16 Amp inductrial 3-pin connector (to BSEN 60309-1/2).
IMPORTANT: A domestic 13Amp plug MUST NOT be fitted to this appliance.
The electrical supply connection shall be made by a suitably qualified
electrician and comply with IEC 60364-1.
As the colours of the wires in the power cable of this product may not
correspond with the markings on the terminals of your plug, proceed as
follows.
If the colours of the wires in the power cable of this product do not correspond
with the markings on the terminals of your plug, proceed as follows.
• The wire which is coloured Blue must be connected to the terminal
which is marked N.
• The wire which is coloured Brown must be connected to the terminal
which is marked L.
• The wire which is coloured Yellow and Green must be connected to the
terminal which is marked E or or coloured Green.
We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD).
FUSE RATING
The fuse rating for this pressure washer is 16Amps.
EXTENSION CABLES
If an extension cable is used, always ensure it is fully unwound. When used
outdoors, ensure that the extension cable is specifically designed for outdoor
use. Ensure that the cable is rated for the voltage and amperage of the
machine.
If in any doubt, consult a qualified electrician. DO NOT attempt any repairs
yourself.
WARNING! Read these electrical safety instructions thoroughly
before connecting the product to the mains supply.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS IDENTIFICATION
1 Spray Gun and Lance 11 Electric Motor
2 High Pressure Hose 12 Braked Castor
3 Water Outlet 13 Exhaust
4 Water Inlet 14 Boiler
5 Power Cable 15 High Pressure Pump
6 Detergent Pickup Hose 16 Fuel Tank Filler Cap
7 On/OFF Switch 17 Detergent Tank
8 Temperature Regulator 18 Transformer
9 Pressure Gauge 19 Burner Head
10 Control Panel 20 By-pass Valve

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
BEFORE USE
CHECKING THE OIL
1. Remove the cover from the
pressure washer by removing the
securing thumbscrew from the
front and then the rear of the
cover then lifting it off.
2. Turn the oil filler cap anticlockwise
to remove it from the pump and
wipe the integral dipstick with a
clean cloth.
3. Insert the oil filler cap fully back
into place and then remove it
again.
4. If the oil is near the low mark on
the dipstick, add oil to the oil
reservoir.
• Do not overfill the oil reservoir.
• We recommend the use of
SAE30 oil.
• Do not mix grades of oil as this may effect the machine’s performance.
WARNING: TO CARRY OUT THIS CHECK, PLACE THE PRESSURE WASHER ON
LEVEL GROUND WHILE SWITCHED OFF.
WARNING: TAKE CARE NOT TO TOUCH ANY HOT PARTS WHEN CHECKING
THE OIL LEVEL.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. Replace the oil filler cap.
6. Replace the cover and tighten the securing screws
FILLING WITH FUEL
• Refuel in a well-ventilated area.
• Do not leave fuel within the
reach of children.
• Refuel carefully to avoid
spillages.
1. Remove the diesel filler cap and
fill the tank with diesel fuel.
• Maximum 22 litres.
2. Replace the diesel filler cap
securely.
FILLING WITH DETERGENT
If you intend to use the detergent injection facility:
1. Unscrew the Detergent Filler Cap
located at the front of the
machine and fill with detergent.
• Only use detergents
recommended for use with
pressure washers, such as
CLARKE Traffic Film Remover
which is a powerful ‘low
foaming’ agent for car
cleaning, patio cleaning etc.,
or CLARKE Wash & Wax, both
available from your CLARKE dealer. The use of unsuitable cleaning
agents may adversly affect the safety of the machine. Do not exceed
the correct operating temperature.
CAUTION: RUNNING THE PUMP WITH INSUFFICIENT OIL WILL CAUSE
DAMAGE
WARNING: INCORRECT FUELS MUST NOT BE USED AS THEY MAY PROVE
HAZARDOUS.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CONNECTING THE MAINS WATER SUPPLY
The pressure washer must never be connected to the drinking water supply
without using a system separator (also known as a backflow preventer)
available from most hardware stores.
Always follow the regulations of your local water supplier.
1. Connect the water supply hose to
the inlet adaptor supplied with the
machine. A standard proprietary
hose is suitable.
2. Screw the inlet adaptor to the
water inlet as shown.
• It is recommended to use a
reinforced hose having an
inner diameter of at least 10
mm.
• The water supply must be able to deliver at least 15 l/min and have a
max inlet temperature of 65°C.
ASSEMBLING THE LANCE
1. Connect the spray lance to the gun assembly and tighten securely by
turning the locking ring.
CAUTION: WATER THAT HAS FLOWED THROUGH A SYSTEM SEPARATOR IS
CONSIDERED NON-DRINKABLE.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CONNECTING THE HIGH PRESSURE HOSE
1. Screw the high pressure hose onto
the gun assembly.
2. Use a spanner to tighten the
connector.
3. Screw the other end of the hose
on to the pressure washer outlet.
• Tighten the connector hand
tight only;- do not use a
spanner.
NOTE: Make sure the connections
are secure.
PARKING BRAKE
Before you operate your pressure
washer you should make sure that
the parking brake is engaged.
To do this press the brake flap shown
in the picture against the wheel to
engage the parking brake.
Flip the flap upwards to release the
brake and allow you to move the
pressure washer.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OPERATION
1. The pressure washer should always be located on a firm level surface
where it is not exposed to extreme weather conditions such as strong wind,
freezing or rain.
2. It is recommended that where possible a partition be erected between the
wash area and the pressure washer to prevent accidental spraying of the
pressure washer. Moisture entering the machine may cause damage.
CONTROL PANEL
l
WARNING: DO NOT OPERATE THE PRESSURE WASHER INDOORS, OR IN
ENCLOSED AREAS WITHOUT ADEQUATE VENTILATION, OR IN AREAS
WHERE FLAMMABLE VAPOURS (PETROL, SOLVENTS ETC.) MAY BE PRESENT.
WARNING: IF THE PRESSURE WASHER IS TO BE USED IN AN ENCLOSED
AREA THE BURNER EXHAUST MUST BE VENTED TO THE OUTSIDE
ATMOSPHERE. THE USE OF A DRAFT REGULATOR IS RECOMMENDED. ALL
VENTING MUST BE IN ACCORDANCE WITH APPLICABLE LAWS AND LOCAL
ORDINANCES FOR SUCH INSTALLATIONS.
A Pressure Gauge Displays hot water temperature
B Temperature regulator
(from 30°C to 150 °C.)
Selects water temperature.
C ON/OFF Switch Turns machine On/Off.

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GETING STARTED
1. Ensure that the water supply is correctly connected and turned on.
2. Set the start switch (C) to ‘I’.
3. Release the trigger lock.
4. When using the machine for the
first time, let it run for a few
moments without the nozzle so
that any air bubbles or other
impurities are discharged.
5. Then re-fit the nozzle. pull the
trigger for a few seconds to
discharge any air contained in
the hose.
NOTE: When the trigger is pulled the
pressure of water will cause
the lance/gun assembly to
kick back suddenly.
6. The washer incorporates a total
stop system. When the trigger is
released the motor will stop. This
system is designed to protect the
motor and is also an important
safety feature.
USING THE WASHER AT DIFFERENT TEMPERATURES
1. Set the Temperature Selector (B) to the required temperature.
2. Set the start switch (C) to ‘I’ .
3. Set the Temperature Selector (B).
4. Ensuring that you have a firm footing and that you are also holding the gun
and spray lance firmly, pull the trigger on the gun to start water flow.
WARNING: FAILURE TO TURN ON THE WATER FULLY COULD CAUSE
DAMAGE TO THE PRESSURE WASHER.
WARNING: THE BURNER EXHAUST MUST BE VENTED TO THE OUTSIDE
ATMOSPHERE. ALL VENTING MUST BE IN ACCORDANCE WITH APPLICABLE
LAWS AND LOCAL ORDINANCES FOR SUCH INSTALLATIONS.

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
• The lance and gun will kick back when the trigger is first pulled.
• If heating of the water is required, the burner will light up to produce hot
water at the required temperature.
• The pressure washer is now ready for use.
• The machine should always be attended during hot wash operation.
5. Having used the pressure washer with hot water, set the temperature
selector to the minimum temperature and allow it to run with cold water for
a few moments before switching off.
6. At the end of the working session, switch off at the start switch (C) and by
pulling the trigger, to allow any residual pressure to be released.
USING DETERGENT
The detergent is applied by twisting
the cap on the lance as shown to
produce a wider spray patern with
lower pressure, and then pulling the
trigger on the gun.
When the nozzle is adjusted to a high
pressure and a narrow spray patern,
the detergent flow is halted.
When the nozzle is adjusted to high pressure and a narrow spray patern, the
detergent flow is halted.
WARNING: IF OPERATING THE MACHINE WITH DETERGENT INCLUDING
CLARKE CLEANING PRODUCTS, TAKE CARE NOT TO SET THE MACHINE TO
OPERATING TEMPERATURES OF GREATER THAN 100OC.
CAUTION: IF YOUR EYES COME INTO CONTACT WITH ANY CLEANING
FLUIDS, RINSE THEM IMMEDIATELY WITH PLENTY OF FRESH CLEAN WATER
AND SEEK MEDICAL ADVICE IF REQUIRED.

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
AFTER USE
1. Set the start switch (C) to ‘O’.
2. Turn the water supply off at the
tap.
• NEVER turn the water off with
the pressure washer running.
3. Release the pressure in the pump
and hose by squeezing the trigger
for a few seconds until no more
water comes out of the nozzle.
4. Move the trigger lock to the
locked position.
5. Store the pressure washer in a dry
safe place to prevent
unauthorised persons from using it.

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE
• All repairs and maintenance operations must be carried out by
technically qualified personnel.
• All maintenance operations must be carried out with the machine on a
level floor while disconnected from the power and water supplies.
• Correct use and maintenance is necessary to guarantee the pressure
washer's reliability and best performance.
• The pressure washer requires regular checks to be carried out at the
following intervals. Please only use the correct spare parts as supplied by
your Clarke dealer.
DAILY (BEFORE EACH USE)
CHECK THE OIL LEVEL OF THE PUMP
1. See “Checking the oil” on page 7.
2. Check that the power cable is not damaged.
EVERY 2 WEEKS OR AFTER 50 HOURS WORKING
CLEAN THE WATER FILTER
1. Use a pair of square nosed pliers,
pull out the the inlet water filter
located in the water inlet and
clean out any foreign matter.

16
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
EVERY 3 MONTHS 0R AFTER 300 HOURS OF WORK
CLEANING/REPLACING THE FUEL FILTER
1. Remove the cover from the
pressure washer.
2. Rmove & replace the fuel filter
(A).
3. Clean or replace the detergent
filter (B).
If dirty, either clean with a jet of
compressed air or replace it with a
new filter.
SERVICING
These tasks must be carried out by skilled service personnel.
EVERY MONTH OR AFTER 100 HOURS OF OPERATION
CLEANING THE COMBUSTION HEAD & CHECKING THE ELECTRODES
It is recommended that the burner and electrodes be serviced yearly, or
as needed depending upon the pressure washers' usage.
Please contact the CLARKE International Service Dept.
LIMESCALE
Periodically the heating coil should be checked for limescale buildup,
dependant upon the hardness of the local water supply.
Please contact the CLARKE International Service Dept.
SOOT BUILD UP
Poor grades of fuel oil or inadequate combustion will cause heavy build
up of soot on the heating coil. This deposit will insulate the coil and

17
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
reduce its efficiency. It will also restrict air flow through the coil, further
aggravating the soot build up.
Contact your CLARKE dealer or CLARKE International Service Dept on:
020 8988 7400 if de-sooting is required.
DE-COMMISSIONING PRODUCT
Should the product become completely unserviceable and require disposal,
draw off the oil into an approved container and dispose of the product and
the oil according to local regulations.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is
compatible with the environment.
CONSUMABLES ETC
A range of suitable hoses, shampoo and traffic film remover are available
from your Clarke dealer.

18
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
No water delivery. Water filter blocked. See “Clean the water filter”
on page 15.
Pump valves jammed. Contact Clarke Service
Department.
Clogged lance nozzle. Clean the nozzle.
Low or irregular
pressure
Insufficient water supply. Check connections.
Pump taking in air. Check connections.
Detergent valve sucking in
air.
Check connections and that
detergent supply is toppedup
Water filter dirty. Clean or replace.
Worn out gaskets or valve
components.
Contact Clarke Service
Department for replacement.
Exceeding the inlet water
temperature.
Make sure the water supply is
below 65 degrees.
Damaged or warn out
nozzle components.
Contact Clarke Service
Department for replacement
Coil is covered in limescale. Contact Clarke Service
Department for advice on
de-scaling.
The burner does
not turn on.
Dirty burner nozzle. Contact Clarke Service
Department.
Faulty thermostat. Contact Clarke Service
Department.
Broken/blocked actuated
valve.
Contact Clarke Service
Department.
Dirty fuel filter. Clean or replace as shown on
page16.
Insufficient spark at the
electrodes.
Contact Clarke Service
Department.
Worn out pump mechanism. Contact Clarke Service
Department.
Low Voltage. Make sure the pressure
washer is connected to a
suitable power supply.

19
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PRODUCT SPECIFICATIONS
Machine is noisy. Air intake worn out / dirty/
blocked valves. Excess
water temperature.
Check air inlet. Contact
Clarke Service Department.
Reduce water temperature.
Water in the oil. Worn out piston rings/failed
gaskets.
Contact Clarke Service
Department.
Oil leaking from
the head.
Worn out o-rings or gaskets. Contact Clarke Service
Department.
Motor suddenly
stops.
Thermal protection has
activated due to
overheating.
Switch off the machine and
wait until the unit has cooled
down sufficiently.
Model Number HLS130
Part Number 7320525
Voltage 230 V / 50 Hz / 1 Phase
Motor Input Power 3.1 kw
Motor Input Current 14.3 A
Duty Cycle S1 (continuous)
Max Inlet Water Pressure 2.5 Bar (250,000 Pa)
Working pressure 125 Bar / 1813 PSI / 12,500 Pa
Maximum output pressure 130 Bar / 1900 PSI / 13,000 Pa
Maximum output flow rate 600 Litres / hour
Maximum output temperature 150oC
Maximum input temperature 65oC
Fuel tank capacity 22 Litres
Detergent tank capacity 4 Litres
Sound power level (LWA) 93 dB
Guaranteed sound power level (LWA) 94 dB
Vibration 1.23 m/s2
Uncertainty Factor 1.5 m/s2
Dimensions (L x W x H) 1000 x 570 x 820 mm
Weight 97.5 kg

20
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST - FRAME & BODY
POS DESCRIPTION CODE POS DESCRIPTION CODE
1 Machine Cover AR3160731 10 Detergent Tank AR3163900
2 Front Hose Carrier AR3160100 11 Braked Caster AR3164410
3 Screw AR2100300 12 Bracket AR3163910
4 Rear Hose Carrier AR3160110 13 Fuel Tank AR3161550
5 Wheel AR3164380 14 Wheel Retaining Clip AR3162010
6 Securing Knob AR3163890 15 Hub Cover AR3161940
7 Washer AR3163290 16 Power Cable Carrier AR3160090
8 Exhaust Guard AR3163880 17 Screw AR2360360
9 Detergent Filler Cap AR3161920 18 Chassis Frame AR3160710
