Clarke woodworker CMS10 6501305 Installation and operation manual

©02/08
Part Number 6501305
Operating & Maintenance
Instructions
10” COMPOUND MITRE SAW
10” COMPOUND MITRE SAW
Model CMS10

2
For Parts & Servicing, please contact your nearest dealer, or
CLARKEInternational,ononeofthefollowingnumbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
or e-mail as follows:
PARTS: [email protected]
SERVICE: [email protected]
PARTS & SERVICING
SPECIFICATIONS
Motor: ........................................230V 50Hz 1 phase.
InputCurrent ..............................8.35Amps
PowerRating: ............................1600 Watts
Speed: .......................................4800RPM
FuseRating ...............................13Amps
Dimensions:(HeadLowered)......(H) 375 x (W) 767 x (D) 545 mm
Dimensions:(HeadRaised) ........(H) 575 x (W) 767 x (D) 545 mm
Blade type/size: (Fitted).............TCT/ 255mm,30 mmbore, 60T
DriveSpindleDiameter ...............16 mm
DustPort Diameter ....................31/37mm(Inner/Outer)
SoundPowerlevel(measured) ...99.3 dBLWA
VibrationLevel............................<2.5 m/s²(NormalLoad)
Netweight..................................11.5 kg
PartNumber...............................6501305
Please note that the details and specifications contained herein, are correct at the
time of going to print. However, CLARKE International reserve the right to change
specifications at any time without prior notice. Always consult the machine’s data
plate
Type of Cut Depth Thickness
Cross (90°) 65mm 130mm
Mitre(45°) 65mm 90mm
Bevel (at 45°) 40mm 130mm
Compound (at 2x 45°) 90mm 32mm
Maximum Cutting Sizes
DO NOT dispose of theis product with general household waste. It must be disposed
ofinaccordancewithalllawsgoverningwasteelectricalandelectronicequipment
at a recognised disposal facility.

Thankyou forpurchasing thisCLARKE 10inchCompound MitreSaw which
is designed for DIY/hobby and medium trade use only.
Before operating the Mitre Saw please read this leaflet thoroughly and
carefully follow all instructions. This will ensure the safety of yourself and
that of others around you, and you can also look forward to the machine
giving you long and satisfactory service.
GUARANTEE
ThisCLARKEproductisguaranteedagainstfaultymanufacture foraperiod
of12 monthsfromthedateof purchase.Please keepyour receiptasproof
of purchase. This guarantee is invalid if the product is found to have been
abused or tampered with in any way, or not used for the purpose for
which it was intended.
Faulty goods should be returned to their place of purchase, no product
can be returned to us without prior permission.
This guarantee does not effect your statutory rights.
CONTENTS
Specifications.........................................................................2
Maximum CuttingSizes......................................................... 2
SafetyPrecautions.................................................................4
Additional Precautions for Mitre Saws ................................ 6
ElectricalConnections.......................................................... 7
Principle Parts ........................................................................8
Features ............................................................................9
Assembly ............................................................................10
Operation Cross Cutting .....................................................10
Mitre Cutting ...................................................... 11
BevelCutting ..................................................... 12
Compound Mitre Cutting ................................ 12
Maintenance .........................................................................13
Bladerenewal.................................................... 13
Adjustments............................................................................ 15
Parts Lists and Diagrams....................................................... 16 - 17
3

SAFETY PRECAUTIONS
GENERAL SAFETY RULES FOR OPERATING MACHINERY
WARNING:
As with all machinery, there are certain hazards involved with their
operation and use. Exercising respect and caution will considerably
lessen the risk of personal injury. However, if normal safety precautions
are overlooked or ignored, personal injury to the operator or damage to
property, may result.
1. READ and BECOME FAMILIAR with the entire operating manual. Learn
the machines’ applications and limitations as well as the specific
potential hazards peculiar to it.
2. EARTH ALL MACHINES. Ifthe machine is equippedwith three-pinplug,
it should be plugged into a three-pin electrical socket. Never remove
the earth pin.
3. ALWAYS ensure that ADEQUATE LIGHTING is available. A minimum
intensity of 300 lux should be provided. Ensure that lighting is placed
so that you will not be working in your own shadow.
4. CHECK for DAMAGE. Before using the machine, any damaged part,
such as a guard etc., should be checked to ensure that it will operate
properly, and perform its intended function. Check for alignment of
moving parts, breakage of parts, mountings, and any other condition
that may affect the machines’ operation. Any damage should be
properly repaired or the part replaced. If in doubt, DO NOT USE the
machine. Consult your local dealer.
5. DISCONNECT the MACHINE from the power supply before servicing
and when changing accessories such as blades, etc.
6. KEEP GUARDS in place and in working order.
7. ALWAYSWEAR SAFETY GOGGLES,manufacturedto thelatestEuropean
SafetyStandards. Also usea faceordust maskif the cuttingoperation
isdusty. Everydayeyeglasses donot haveimpact resistantlenses, they
are NOT safety glasses.
8. KEEPWORKAREACLEAN.Clutteredareasandbenchesinviteaccidents.
9. ALWAYS WEAR EAR PROTECTORS/DEFENDERS asthis machinegenerates
considerable noise which can be in excess of 97dBA.
10. DON’T FORCE the machine. It will do a better and safer job at the rate
for which it was designed. 4

11. REMOVE ADJUSTING KEYS AND WRENCHES. Formthehabit ofchecking
tosee that keys andadjusting wrenches areremoved from the
machinebefore switching on.
12. DRUGS, ALCOHOL, MEDICATION. Donotoperatemachinewhileunder
the influence of drugs, alcohol or any medication.
13. USE RECOMMENDED ACCESSORIES. The use of improper accessories
could be hazardous.
14. NEVER LEAVE MACHINE RUNNING UNATTENDED. Turn power OFF. Do
not leave machine until it comes to a complete stop.
15. ALWAYS REMOVE PLUG fromelectricaloutletwhenadjusting,changing
parts, or working on machine.
16. AVOIDDANGEROUSENVIRONMENT.Don’tusepowermachinesindamp
or wet locations or expose them to rain. Keep your work area well
illuminated. DO NOT USE in explosive atmosphere (around paint,
flammable liquids etc.).
17. KEEP CHILDREN AWAY. All visitors should be kept a safe distance from
the work area, especially whilst operating the unit.
19. MAINTAIN MACHINE IN TOP CONDITION. Keep tools sharp and clean
forthe bestand safestperformance. Followmaintenance instructions.
21. DON’T OVERREACH. Keepyourproperfooting andbalanceatall times.
For best footing, wear rubber soled footwear. Keep floor clear of oil,
scrap wood, etc.
22. WEAR PROPER APPAREL. Loose clothing or jewelry may get caught in
moving parts. Wear protective hair covering to contain long hair.
23. MAKE WORKSHOP CHILDPROOF. Coverthe saw adequatelywhennot
inuse,to prevent childrenfromdamaging themselves by tampering
with it.
24. NEVER STAND ON THE MACHINE. Serious injury could occur if the
machine is tipped or if a cutting tool is accidentally contacted. Do
not store materials above or near a machine, such that it is necessary
to stand on the machine to reach them.
25. HANDLE WITH EXTREME CARE Whenever transporting or installing
machinery, and always use a lifting tool.
26. AVOID ACCIDENTAL STARTING. EnsuretheswitchisOFFbeforeplugging
in to mains.
27. BE AWARE that ACCIDENTS arecaused by carelessnessdue to familiarity.
ALWAYSconcentrateonthejobinhand,nomatterhowtrivialitmayseem.
5

ADDITIONAL SAFETY INSTRUCTIONS
for MITRE SAWS
1. Wear safety goggles as protection against flying wood chips and saw dust. In
many cases, a full face shield is even better protection. A dust mask is also
recommended to keep saw dust out of your lungs.
2. Use a solid wood workbench which will not move under load.
3. This saw is for indoor, DIY or medium trade use only.
4. Clear the work table of all objects except the workpiece (tools, scraps, rulers
etc.) before switching on the saw.
5. Keep your fingers well away from the blade.
6. Switch off the saw, and make sure the blade has come to a complete stop
before clearing sawdust or off-cuts from the table.
7. Make sure there are no nails or foreign objects in the part of the workpiece to
besawn.
8. Setupthe machine and make all adjustmentswiththepower OFF, and
disconnected from the supply.
9. DO NOT operate the machine with the guards removed. They must all be in
place and securely fastened when performing any operation.
10. Use ONLY approved replacement saw blades. Contact your local CLARKE
dealer for advice. The use of inferior blades may increase the risk of injury.
11. DO NOT saw any material that does not have a flat surface on which to bear.
12. This machine is designed for cutting wood. DO NOT use for cutting metal,
plastics or masonry.
13. Do Not force the blade, lower it gently into the work.
14. Ensureyou havecompletecontroloftheCuttingHeadatall times.When acut
iscompleted,return it toitsuppermost position gently.DONOT allow ittosnap
back heavily under spring pressure.
15. Always clamp the work to the table...DO NOT perform freehand operations.
16. Ensure that the portion of the workpiece being cut bears firmly against the
back fence.
17. Provide adequate support for long workpieces.
18. Never use solvents for cleaning plastic parts as this could cause damage to
the material. A soft damp cloth only is required.
19. Thesaw blademusthavea rated capacitygreaterthan the maximumspeed
of the machine - see Specifications
6

ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply
through an approved 13 amp BS 1363 plug, or a suitably fused isolator
switch.
WARNING! THIS APPLIANCE IS DOUBLE INSULATED
IMPORTANT: The wires in the mains lead are coloured in accordance with
the following code: Blue - Neutral
Brown - Live
As the colours of the flexible lead of this appliance may not correspond
with the coloured markings identifying terminals in your plug proceed as
follows:
Connect BROWN cord to terminal marked with “L” or coloured RED.
Connect BLUE cord to the terminal marked with “N” or coloured BLACK.
If this appliance is fitted with a plug which is moulded onto the electric
cable (i.e. non-rewirable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There
is a danger of electric shock if it is subsequently inserted into a socket
outlet.
2. Neveruse the plug withoutthe fuse coverfitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the
correctreplacementisused(as indicatedby markingorcolour code).
4. Replacement fuse covers can be obtained from your local dealer or
mostelectrical stockists.
Fuse Rating
Thefuseintheplug mustbereplacedwithone ofthesamerating-13amps
andthis replacement mustbe ASTA approvedto BS1362.
Cable Extension
If a cable extension is needed, it is essential to ensure that the size of the
conductors is at least the same size as those of the power cable supplied.
7

PRINCIPAL PARTS OF THE SAW
8
Fig.1
Fig.2

FEATURES
As its’ name implies, the machine is a Bevel/Mitre Saw, capable of straight cross
cutting, and cutting bevels and mitres, or a combination of the two.
The main arm, or Cutting Head, carries the motor and the tungsten carbide saw
blade. The head, complete with table, is allowed to swivel to produce mitre cuts
and the head may also tilt to the left to produce bevel cuts. A combination of
swivellingheadand tilting headwillalsoproduce compound mitres
Thetable,with head, is designed toswivelupto 45 degrees ineitherdirectionand
is provided with positive stops at 90, 60, 45 and 22.5 degrees.
The maximum sizes of wood that may be cut in any of these processes is given in
the Specifications on page 3.
Adust extractionoutlet isprovidedat therear ofthemachine,onto whichthe dust
bag(supplied)isfitted.Ifnecessary,hosefrom avacuumcleanermaybeattached
to provide fast and efficient removal of sawdust. The vacuum cleaner may be
usedcontinuouslyor intermittently dependinguponyourrequirements.
The blade drive shaft has a 16mm diameter. A 60T TCT blade is provided with a
bore of 30mm. A reducer bush is therefore used, and one spare is provided.
This saw is not designed for cutting metal, plastics or masonry.
To transport the saw, simply pick it up using the carry handle on top of the head.
NOTE: The cutting head must be in its lower position as shown below, locked in
positionusingtheHeadLockingPin.
A saw blade spindle locking lever is provided - see Fig.3, used in order to remove
the saw blade. WARNING! NEVER touch this lever when the saw is operating.
9
Fig.3

ASSEMBLY and INSTALLATION.
The saw is fully assembled and adjusted at the factory. On receipt inspect the
machine to ensure that all parts are accounted for and that no damage was
incurredduringtransit.
Loose items are:
1 x socket spanner: 1 x spare set of carbon brushes.
1 x spare blade bore reducer bush. 1 x plastic 90/45Otemplate.
1 x dust bag 1 x work clamp with support bar
1 x rear support with nut and bolt 2 x work supports
Anydeficiencyordamageshould bereportedtoyourCLARKE dealerimmediately.
Mountthe machineona firmsolid basethatwill notmove underload.Ensure there
is an appropriate electrical supply, and adequate lighting, so that you will not be
workinginyourownshadow.
Fourholes are provided,one at eachcornerof thebase,so thatthemachine may
be bolted permanently to a workbench for added stability, using 8mm bolts (not
provided).Alternativelyit maybebolted to apieceof plywood withathickness of
16mm (5/8”).
If not bolted to a workbench, the rear support must be fitted - see Figs 1 and 2. A
single bolt secures the support to the rear of the base housing.
TheCutting Head islockedin its lowerpositionfor transitpurposes.To release it,pull
outthe Head LockingPin - seeFig 3 (Itmaybe necessarytoapply slightdownward
pressure to the head in order to do so), and allow the head to rise to its upper
positiongently,under control.
The head will lock in its upper position, and is prevented from being lowered until
the Safety Lever (see Fig 2) is pushed to one side.
OPERATION. (Ref Fig.4)
A. Cross Cutting. (at90°)
Setthetableat 0 degrees as shown on the scale atthefrontofthe table. To do this,
firstlyunscrewthe largetableknobafewturns,thenpressdownonthe tablelocking
lever-seeFig.3,andturnthetable,usingthelargetableknob,untilitclicksintoplace.
Tosecurethe table, screw in the table knob fully.
Set the work in place with the left end firmly clamped against the table and back
fence.
It is important to ensure that one end of the workpiece is completely free to move
i.e.NOT clamped orheld in anyway.This willnormallybe theoff-cutor shorterend.
10

11
Fig.4
NOTE: If the workpiece is not entirely straight, ensure that the portion at either side
of the intended cut rests firmly against the table and back fence.
Whensatisfied, make a final check to ensure that all safety precautions are being
complied with, then pull and hold the trigger and allow the blade to reach full
speed. If any unusual sounds or vibrations occur, release the starter switch
immediatelyand investigate thecause.
Whensatisfied, push theSafetyLevertoone sidewith yourthumbor forefingerand
gentlylower thehead sothat theblademakescontactwiththeworkpiece.Donot
force the blade, a light pressure is all that is required.
You will notice that to provide maximum safety, the blade is not exposed at any
time, and the guard rises automatically as the blade is lowered. Nevertheless,
NEVER treat the machine with indifference, and NEVER be casual with your
approach.
Toswitchoff,releasethetriggerwhilststillmaintainingfullcontrolofthehead. NEVER
allowtheheadtospringupwards-alwaysmaintaincontrol.Waitforthebladetostop
completely before removing the workpiece, off-cuts etc.
B. Mitre Cutting
Thisisa cross cuttingoperation,exceptthat the sawbladeisset at anangletothe
work, but remains perpendicular to the table. This is achieved by mounting the
complete head assembly on a table which is free to rotate by up to 45° in either
direction.
To set the required mitre angle, unscrew the table knob a few turns, then depress
the table locking lever and rotate the table, with the head and saw blade, to the
desiredposition,usingthelargetableknob,lininguptheangleonthescalewith the
pointer.Notethatthetablewilllockinpositioninthe0O,22.5O,30Oand45Opositions.
The procedure for cutting is the same as that for cross cutting.
To secure the table, screw in the table knob.

C. Straight Bevel Cutting
As with Mitre Cutting, this is a cross cutting operation, except that the blade is not
perpendicular to the table, (see fig. 5).
Ensure the table is set to 0O, and is
lockedinplaceusingthetableknob.
The bevel adjuster is factory set so
that when the head is tilted to its
fullest extent the blade will cut a
perfect 45° bevel.
If however you require any other
angle, you should proceed as
follows:
Cut a mitre of the required angle,
on a spare piece of wood, and use
thisas atemplate foryourbevelcut.
Slacken off the bevel locking lever, and
swing the head to the side. Lower the
arm, and bring your template up to the
sawblade. Whensatisfiedthat theedge
oftemplateand blade areparallel,lock
the head in position with locking lever.
Your angle is now set.
The procedure for cutting is the same as
thatforcross cutting....press trigger, wait
for full speed to develop, push safety
lever to one side, then lower the blade
to the workpiece.
D. Compound Mitre and Bevel Cutting.
Having determined the angles you
require,firstlysetthebevelangle,using
theprocedure described above,and
thenthemitre angle.
NOTE: Compound mitre and bevel
cuts, at a full 45°, can only be made
when the head is turned to the left.
The procedure for cutting is the same
as that for cross cutting.
12
Fig.5
Fig.6

MAINTENANCE
1. General
The machine is maintenance free, except for changing the saw blade when
necessary,maintainingadjustments,andensuringthatafteruse,youclean away
any sawdust or wood chips, with a low pressure air line or brush, paying particular
attention to the motor air vents which should be kept clear at all times.
Should the motor not function normally, it is possible that it has become clogged
withsaw dust, in which case, it will be necessary to disassemble the motor in order
to clean the various components. Contact your CLARKE dealer for advice.
2. Changing the Saw Blade
IMPORTANT: Exercise extreme care when handling the saw blade. The tips are
extremely sharp, and careless handling could result in severe personal injury.
13
2. Move the safety lever to one side
to allow the clear plastic blade
guard to be pulled around the saw
bladeasshown in Fig.9.
3. Holdtheblade guard inthispositionwhilst
slackening off the screw, indicated,
sufficient for the cover to become
disengaged - note the slotted hole. It is not
necessary to remove the screw.
1. With the machine disconnected from
themains supply,and thecutting head
intheraised position,undoandremove
the screw securing the link arm
attached to the clear plastic blade
guard,indicated inFig.8.
Fig.8
Fig.9

14
4. Allow the blade guard to fully reassert,
as shown in Fig.10, then unscrew and
remove the second cover screw, as
shown.
Thiswillallowthecomplete bladeguard
withcentrehubandlinkagetobe
carefullypulledfrom the head.
Fig.10
5. Lower the saw head and lock in place
withthe locking pin
6. With the clear plastic blade guard
removed,holddownthespindlelocking
lever, arrowedinFig. 11, and undo,but
do not remove the saw blade centre
screw,usingthe box spannersupplied,
byturningCLOCKWISE .i.e.The screw
has a left hand thread.
Fig.11
7. Pullout thehead lockingpin andallowthesawheadtorise, undercontrol, then
unscrew and remove the blade centre bolt. Finally, pull off the outer flange
followedbythesaw blade.
NOTE: You should take this opportunity to thoroughly clean parts previously
inaccessible.
By removing the collar, it is possible to use blades with a 16mm bore.
8. Replace the blade, ensuring it is of the correct bore, or, where necessary a
collaris used toensureitisa perfectfit on theshaft.Ensure alsothatall parts are
perfectly clean and the blades’ teeth point down at the front.
Additionally,thebladeMUST be ratedwithamaximumspeed greater that
4850RPM
Please note that spare blades are available from Clarke International. Please
see your Clarke dealer.
Replace the outer flange and screw in the centre bolt, remembering it has a
left hand thread - i.e. turn anticlockwise to tighten.
9. Replace the clear plastic blade guard in reverse order to that when
disassembling.
WARNING! NEVER push IN the Spindle
Locking Lever with the motor running

15
3. Carbon Brushes Replacement
A spare pair of carbon brushes are supplied with the machine. Should it become
necessary to change these, evidenced by erratic performance, then simply
unscrew the brush holder plugs, ensuring the machine is disconnected from the
mainssupply, andpullout thewornbrushes.Replacewith newbrushes,and screw
in the plug, taking care not to cross thread it.
If you find that the cross cut is not entirely square, it will be necessary to adjust the
head using the 90° adjuster screw shown in Fig. 13.
Todo this, slackenoffthe bevellockinglever, then lowerthearm andlockin place
withthehead lockingknob.
Place a small square on the table, and bring the square up to the blade to test for
accuracy.
Shouldany adjustmentberequired, slackenoff the90°adjuster screwlocknut and
screwthe adjusterinor out,asnecessary, whilstholdingthe headfirmlyagainst the
stop.Tightenthesecuringnutwhentheheadisexactly perpendicular.
Similarly should the 45° stop require adjusting, use a 45° template up against the
saw blade to set the adjuster to the correct position.
4. Head Adjustments
Fig.12
Fig.13

PARTS DIAGRAM
16

No. Description Part No.
PARTS LIST
No. Description Part No.
17
1 Circlip ForShaft 1 GRCMS1001
2 PressureRod 1 GRCMS1002
3 Screw M4×55 2 GRCMS1003
4 Spring LockWasher 2 GRCMS1004
5 Screw M4×10 4 GRCMS1005
6 CableClip 2 GRCMS1006
7 Shaft 1 GRCMS1007
8 SplitWasher 1 GRCMS1008
8-1 Screw M4.2×9 1 GRCMS1008-1
9 SplitWasher 1 GRCMS1009
10 CablePlug 1 GRCMS1010
11 ExtensionSpring 1 GRCMS1011
12 PushRod 1 GRCMS1012
13 Head 1 GRCMS1013
14 PlainWasher 9 GRCMS1014
15 SpringLock Washer 9 GRCMS1015
16 ScrewM4×30 4 GRCMS1016
17 O-Ring 1 GRCMS1017
18 StopLever 1 GRCMS1018
19 PlainWashe 1 GRCMS1019
20 NutM12 1 GRCMS1020
21 NutM5 4 GRCMS1021
22 Handle(Upper) 1 GRCMS1022
23 Capacitor 1 GRCMS1023
24 Switch 1 GRCMS1024
25 Inductor 1 GRCMS1025
26 Handle(UpperDown) 1 GRCMS1026
27 ScrewM4×22 3 GRCMS1027
28 Cover 1 GRCMS1028
29 BoltM8×15(left) 1 GRCMS1029
30 WheelFlange 1 GRCMS1030
31 BelowWheel Flange 1 GRCMS1031
32 WheelFlange Washer 1 GRCMS1032
33 ScrewM4×8 3 GRCMS1033
34 BearingCover plate 1 GRCMS1034
35 ProtectiveCover 1 GRCMS1035
36 BearingD180201 1 GRCMS1036
37 ForeCover 1 GRCMS1037
38 OutputSpindle 1 GRCMS1038
39 WoodruffKey 1 GRCMS1039
40 ScrewM5×10 1 GRCMS1040
41 BevelGear 1 GRCMS1041
42 AxleElasticity Ring12 1 GRCMS1042
43 OilBearing 1 GRCMS1043
44 CableBase 1 GRCMS1044
45 Screw 1 GRCMS1045
46 Cable 1 GRCMS1046
47 CableArmor 1 GRCMS1047
48 RubberWasher 2 GRCMS1048
49 CableArmor 1 GRCMS1049
50 NutWrench 1 GRCMS1050
51 LengtheningNut 1 GRCMS1051
52 Armor 1 GRCMS1052
53 Spring 2 GRCMS1053
54 Frame 1 GRCMS1054
55 CopperWasher 1 GRCMS1055
56 SpringLock Washer 4 GRCMS1056
57 ScrewM5×8 4 GRCMS1057
58 BladeProtective Plate 2 GRCMS1058
59 SocketHd CapScrew 4 GRCMS1059
60 BoltM8×70 2 GRCMS1060
61 TurntableLocking Screw 3 GRCMS1061
62 SocketHd CapScrew 2 GRCMS1062
62-1 SocketHdCap Screw GRCMS1062-1
63 Washer 2 GRCMS1063
64 NutM8 1 GRCMS1064
65 NutM12 2 GRCMS1065
66 FrameRotation 2 GRCMS1066
67 SpringFixedSeat 1 GRCMS1067
68 Washer 1 GRCMS1068
69 BladeCarrier Rotation 1 GRCMS1069
70 Base 1 GRCMS1070
71 ScrewM5×12 2 GRCMS1071
72 Fence 1 GRCMS1072
73 Turntable 1 GRCMS1073
74 NutM6 4 GRCMS1074
75 PlainWasher 6 2 GRCMS1075
76 Base Table 1 GRCMS1076
77 Right-anglePiece 2 GRCMS1077
78 BasetableWasher 6 GRCMS1078
79 ScrewM4×65 2 GRCMS1079
80 BrushHolder 2 GRCMS1080
81 CarbonBrush 2 GRCMS1081
82 Screw 4 GRCMS1082
83 BearingD18201 1 GRCMS1083
84 Armature 1 GRCMS1084
85 Bearing80029 1 GRCMS1085
86 FanGuide 1 GRCMS1086
87 Stator 1 GRCMS1087
88 Bushing 1 GRCMS1088
89 Housing 1 GRCMS1089
90 RearCover 1 GRCMS1090
91 Wrench 1 GRCMS1091
92 WrenchSocket 1 GRCMS1092
93 ScrewM4x16 2 GRCMS1093
94 Nut 2 GRCMS1094
95 ConnectionBox 1 GRCMS1095
96 ConnectionBoxCover 1 GRCMS1096
97 Screw 2 GRCMS1097
98 ConnectionTerminal 1 GRCMS1098
99 CableClip 1 GRCMS1099

18

19
