Clas Ohlson MH-306B User manual

EnglishSvenskaNorskSuomi EnglishSvenskaNorskSuomiDeutsch
Ver. 20130503
Wireless Headset
Trådlöst headset
Trådløst headset
Langaton kuulokemikrofoni
Schnurloses Headset
Art.no Model
38-4699 MH-306B

2

3
English
Wireless Headset
Art.no 38-4699 Model MH-306B
Please read theentire instruction manual before use and save it for future reference.
Wereserve theright for any errors in text or images and for making any necessary
technical changes to this document. Ifyou should have any questions concerning
technical problems please contact our Customer Services.
1. Safety
• Check your local regulations regarding mobile phone and handsfree use in
combination with driving or in other situations which may require your extra attention.
• Shut off both theheadset and mobile phone in areas where you are required
to do so, such as in hospitals, aeroplanes or in areas where there is therisk of
anexplosion.
• Protect thekeyboard from extreme heat/cold, strong magnetic fields and moisture.
• Never expose theheadset to moisture, liquids or high humidity.
• Do not dismantle theheadset or its accessories. Thisproduct contains no parts
that you can repair yourself.
• Use only theincluded charger cable.
• Protect theproduct from blows and vibrations.
2. Protecting your hearing
Warning:
• This product can produce high volume.
• Extended exposure to high volume can cause hearing damage and cause
permanent hearing impairment.
• Do not wear theheadset when first turning it on as it can produce aloud sharp
popping noise when turned on. Makeit ahabit of turning down thevolume when
you before turning off theheadset so that it will not be at full volume thenext time
it is turned on.
• Take off theheadset when turning on theconnected audio source (stereo, mobile,
computer, etc.) or when plugging into or from these sources.
3. Product description
• Wireless Bluetooth communication with your mobile for streaming music or
handsfree operation. Headset keys for changing tracks, adjusting volume,
answering and terminating calls.
• Works also with other Bluetooth devices like your laptop, tablet, etc.
• Up to eight hours of talk/listening time and 100 hours of standby time.
• Range: up to 10m.
• Charged via theincluded USBlead.
• Can even be used as astandard wired headset.

4
English
1
2
3
4
5
6
7 8
Package contents
• Headset
• USB charge cable
• Instruction manual
• Audiocable
• Pouch
4. Buttons and functions
1. [ ] Multi-functional button:
- On/off
- Pairing
2. [ 9 ] Previous track
3. [-] Decrease volume
4. [ ] Multifunction button:
- Start playback
- Stop playback
- Call answer
- Makecall
- Endcall
5. [ : ] Nexttrack
6. [+] Increase volume
7. Audioand charge cable socket
8. Microphone

5
English
5. Getting started
5.1 Charging thebatteries
Note: Chargetheheadset for about four hours before using it for thefirsttime.
1. Firstconnect theincluded charger cable to theheadset and then to aUSB port.
Thered LED will comeon.
2. Whencharging is complete thecharge indicator will shut off. Youshould now
remove thecharger cable.
Normal charge time for theheadphones is about twohours.
A fully charged battery will give you up to eight hours of talk time, six to eight hours of
music playback and up to 100 hours of standby time.
5.2 Power On/Off
Power on
1. Press and hold [ ] for 3 seconds to turn theheadset on.
2. The blue LED will begin to flash when theunit is turned on.
3. An audible signal will beheard.
Power off
1. Depress and hold [ ] until thered LED starts toflash.
2. The LED will flash red when thedevice is turned off.
3. An audible signal will beheard.
Note: Thedevice will turn off automatically after 5 minutes to save energy if no signal
is received.
5.3 Pairing with another Bluetooth device
Pairing is afunction which connects theheadphones to another Bluetooth device.

6
English
Activating pairing mode
1. Turnon thedevice to be connected.
2. Makesure that theheadset is turned off (no LEDs lit).
3. Pressand hold [ ] for about 5 seconds and release when theLEDs begin
alternatively flashing between red andblue.
4. Activate theexternal device’s Bluetooth and begin scanning for other Bluetooth
devices. SelectMH-306B from thelist once scanning is complete.
5. Itmay be required that you enter passcode 0000 to be able to connect.
6. Oncepairing is complete theblue LED will flash in two second intervals.
Note: Pairing mode is active for about 1 ½ minutes. Iftheheadset does not establish
contact with another Bluetooth device within this timeframe it will automatically
turnoff.
Once pairing is complete both Bluetooth devices will be synchronised with each
other and thepairing procedure does NOT need to be repeated for any following
connections. However, your settings will be erased if you pair theheadset to another
Bluetooth device.
The headset always connects to thelatest paired Bluetooth device. Ifyou desire to
pair to another Bluetooth device, first turn off theBluetooth feature on thecurrent
device and repeat thepairing procedure with thenew device.
6. Operation
The headband is adjustable. Extendit to thecorrect size.
Placetheside with thecontrols over therightear.
Read theinstruction manual for your mobile or device before
connecting it to theheadset.
Function Procedure
Answering acall Press [ ] to answer acall.
End acall Press [ ] to end acall.
Ringup If you ring up using your mobile thecall will automatically be
transferred to theheadset depending on your mobile’s settings.
Voice activated
call
Press and hold [ ] for approx. 2 seconds (in standby mode).
Validonly if your mobile supports this feature along with
theheadset. Refer to your mobile phone’s instruction manual.
Automatic redial-
ling of thelast
dialled number
Press [ ] twice for redial (not available during aduring
acurrent call).
Call blocking Press [ ] twice to block acall.
Volume control Adjust theheadset’s volume with [+] and [-].

7
English
7. Listening to music wirelessly
Pair theheadset to theaudio source (the device must support theA2DP Bluetooth
profile) see 5.3 Pairing with another Bluetooth device. Usethecontrols on
theconnected device to control music playback.
If you receive or make acall, playback will automatically be paused until thecall isended.
Function Description
Resume play orpause Press [ ]
Music volume Press[+] to increase volume
Press [-] to decrease volume
Return to previous track Press [ 9 ]
Advance to thenext track Press [ : ]
8. Normalheadphone use
Connect theheadset to theheadphone socket to anaudio source using theincluded
audio cable. Theintegrated microphone will not function in thismode.
In this mode you must adjust thevolume from theconnected device.
9. Careand maintenance
Never use strong cleaning agents/solvents to clean theproduct.
Wipewithasoftcloth.
Never expose theheadset to moisture ordamp.
10. Troubleshooting
Continuous crackling noise.
Make sure that thedistance between theheadset and thepaired device does not
exceed ten metres.
No sound isheard.
• Press [+] to increase volume.
• Make sure that theheadset and thedevice are paired to eachother.
• Make sure that theheadset and thedevice are on and correctly set.
Unable to achieve contact.
Repeat thepairing process. See5.3 Pairing with another Bluetooth device.

8
English
Is theheadset compatible with thedevice it is to be paired with?
• The headset is designed to be paired with mobile phones.
• It is compatible with Bluetooth Versions 1.1, 1.2 and 2.0 and supports usage
together with other Bluetooth devices.
11. Disposal
This product should be disposed of in accordance with local regulations.
Ifyou are unsure how to proceed, contact your local authority.
12. Specifications
Bluetooth Supports V2.1 + EDR with Handsfree Profile 1.5,
Headset Profile 1.1 and A2DP Profile 1.2 (Class 2).
Standby time 100hours
Talk time 8hours
Music listening 6–8hours
Range Up to 10 metres
Weight 115grams
Certifications CE, FCC, ROHS, BQB

9
Svenska
Trådlöst headset
Art.nr 38-4699 Modell MH-306B
Läs igenom hela bruksanvisningen före användning och spara den sedan för fram-
tida bruk. Vireserverar oss för ev. text- och bildfel samt ändringar av tekniska data.
Vidtekniska problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter
påbaksidan).
1. Säkerhet
• Kontrollera lokala lagar om användning av mobiltelefon och handsfreeutrustning
isamband med bilkörning eller iandra situationer där du måste vara extra uppmärksam.
• Stäng av både headset och mobiltelefon när du vistas iutrymmen där du är skyldig
att stänga av mobiltelefonen, som t.ex. sjukhus, flygplan eller områden där det
finns explosionsrisk.
• Skydda headsetet från stark värme/kyla, starka magnetfält ochfukt.
• Utsätt aldrig headsetet för fukt, väta eller hög luftfuktighet.
• Demontera inte headsetet eller dess tillbehör. Detinnehåller inga delar som du kan
byta ut eller reparera själv.
• Använd endast den medföljande laddningskabeln.
• Skydda headsetet mot slag och vibrationer.
2. Skyddadin hörsel
Varning!
• Produkten kan ge ifrån sig hög ljudvolym.
• Långvarig exponering av hög ljudvolym kan orsaka skador på din hörsel och ge dig
bestående hörselnedsättning.
• När du slår på headsetet bör du inte ha hörlurarna på dig då det kan ge ifrån sig
höga klickljud när det slås på. Taför vana att ställa ner volymen innan du stänger
av headsetet så att inte ljudet har full volym när du slår på headsetet nästagång.
• Du bör ta av dig headsetet när du slår på och av din anslutna ljudkälla
(stereoanläggning, mobiltelefon, dator, etc.) eller kopplar in eller drar ut
kontakternatill ljudingångarna.
3. Produktbeskrivning
• Trådlös kommunikation med din mobiltelefon via Bluetooth för musiklyssning och
handsfree. Viaknappsatsen på hörlurarna kan man byta spår, höja/sänka volymen
samt svara och läggapå.
• Kan även anslutas till annan Bluetooth-kompatibel hårdvara, t.ex. PC eller surfplatta.
• Upp till 8 tim tal-/musiklyssningstid och 100 tim passningstid.
• Räckvidd upp till 10m.
• Laddas via medföljande USB-kabel.
• Kan även användas som vanlig kabelansluten hörlur.

10
Svenska
1
2
3
4
5
6
7 8
Förpackningen innehåller
• Headset
• Laddningskabel USB
• Bruksanvisning
• Audiokabel
• Förvaringspåse
4. Knappar och funktioner
1. [ ] Multifunktionsknapp:
- Stäng av/slå på headset
- Pairing
2. [ 9 ] Gå till föregående spår
3. [-] Sänk ljudvolymen
4. [ ] Multifunktionsknapp:
- Starta uppspelning
- Stoppa uppspelning
- Besvara samtal
- Ringupp
- Avsluta samtal
5. [ : ] Gå till nästaspår
6. [+] Höj ljudvolymen
7. Anslutning för audiokabel eller laddningskabel
8. Mikrofon
