CleanCraft VCA Series User manual

VCA - SERIES
flexCAT 262 VCA
flexCAT 141 VCA
Special Vacuum Cleaner
Operating Instructions
flexCAT 141 VCA
flexCAT 262 VCA

2 VCA - Series | Version 1.04
Imprint
Product identification
Special Vacuum Cleaner Item number
flexCAT 141 VCA 003160
flexCAT 262 VCA 003165
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Fax: [phone] - 55
E-Mail: [email protected]
Internet: www.cleancraft.de
Indications regarding the operating instructions
Original Instructions
Publication: 22.04.2021
Version: 1.04
Author: FL
Indications regarding the copyright
Copyright © 2021 Stürmer Maschinen GmbH, Hallstadt,
Germany.
The contents of these operating instructions are the sole
property of the company Stürmer Maschinen GmbH.
Passing on as well as copying of this document, the use
and distribution of its content are prohibited if not expli-
citly permitted. Contra-ventions are liable to compensa-
tion.
Subject to technical modifications and error.
Content
1 Introduction .............................................................3
1.1 Copyright ............................................................ 3
1.2 Customer service................................................ 3
1.3 Limitation of liability............................................. 3
2 Safety........................................................................3
2.1 Symbol explanation ............................................ 3
2.2 Obligations of the operating company ................ 4
2.3 Requirements to staff.......................................... 5
2.4 Personal protective equipment ........................... 5
2.5 General safety regulations.................................. 5
2.6 Safety labels on the special vacuum cleaner......
2. Safety data sheets..............................................
3 Intended Use............................................................7
3.1 Unintended use...................................................
3.2 Residual risks .....................................................
4 Technical Data .........................................................8
4.1 Type plate........................................................... 8
Transport, packaging, storage...............................8
5.1 Transport ............................................................ 8
5.2 Packaging........................................................... 8
5.3 Storage ............................................................... 8
6 Description of device..............................................9
6.1 Scope of device .................................................. 9
6.2 Accessories ........................................................ 9
7 Operation ...............................................................10
.1 Mounting........................................................... 10
.2 Start and Stop................................................... 11
.3 Emptying of the tank......................................... 11
.4 Seal control....................................................... 11
8 Care, maintenance and repair ..............................11
8.1 Care by cleaning............................................... 11
8.2 Cleaning the filter.............................................. 12
8.3 Maintenance and repair.................................... 12
9 Disposal, recycling of used devices....................12
9.1 Decommissioning ............................................. 12
9.2 Disposal via municipal collection points............ 12
9.3 Disposal of dust bags and filters....................... 12
10 Troubleshooting ..................................................12
11 Spare parts...........................................................13
11.1 Ordering spare parts...................................... 13
11.2 Spare parts drawings flexCAT 141 VCA........ 14
11.3 Spare parts drawings flexCAT 262 VCA....... 15
12 EC Declaration of Conformity ............................18
13 Notes ....................................................................19

Introduction
VCA - Series | Version 1.04 3
1 Introduction
You have made a good choice by purchasing the
CLEANCRAFT special vacuum cleaner.
Read the operating manual thoroughly before com-
mis-sioning the machine.
It gives you information about the proper commissioning,
intended use and safe and efficient operation and main-
tenance of your special vacuum cleaner.
The operating manual is part of the special vacuum cle-
aner package. Always keep this operating manual in the
location where your vacuum cleaner is being operated.
All local accident prevention regulations and general
safety instructions for the operating range of your va-
cuum cleaner must also be complied with.
1.1 Copyright
The contents of these instructions are copyright. They
may be used in conjunction with the operation of the va-
cuum cleaner. Any application beyond those described
is not permitted without the written approval of Stürmer
Maschinen GmbH. For the protection of our products, we
shall register trademark, patent and design rights, as this
is possible in individual cases. We strongly oppose any
infringement of our intellectual property.
1.2 Customer service
Please contact your dealer if you have questions con-
cerning your vacuum cleaner or if you need technical ad-
vice. They will help you with specialist information and
expert advice.
Germany:
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Repair service:
Fax: [phone]-111
E-Mail: [email protected]
Internet: www.cleancraft.de
Spare part orders:
Fax: [phone]-119
E-Mail: ersatz[email protected]
We are always interested in valuable experience and
knowledge gained from using the application which then
could be shared and be valuable to develop our products
even further.
1.3 Limitation of liability
All information and notes in these operating instructions
were summarised while taking applicable standards and
rules, the state-of-the-art technology and our long-term
knowledge and experiences into consideration.
In the following cases the manufacturer is not liable for
damages:
- Non-observance of the operating instructions,
- Inappropriate use
- Use of untrained staff,
- Unauthorised modifications
- Technical changes,
- Use of not allowed spare parts.
The actual scope of delivery may deviate from the expla-
nations and presentations described here in case of spe-
cial models, when using additional ordering options or
due to latest technical modifications.
The obligations agreed in the delivery contract, the gen-
eral terms and conditions as well as the delivery condi-ti-
ons of the manufacturer and the legal regulations at the
time of the conclusion of the contract are applicable.
2 Safety
This section provides an overview of all important safety
packages for the protection of operating personnel as
well as for safe and fault-free operation. Other task ba-
sed safety notes are included in the paragraphs of the in-
dividual phases of life.
2.1 Symbol explanation
Safety instructions
The safety notes in these operating instructions are high-
lighted by symbols. The safety notes are introduced by
signal words which express the concern of the risk.
ANGER!
This combination of symbol and signal words indi-
cates an imminently dangerous situation which may
lead to death or severe injury if not avoided.

4 VCA - Series | Version 1.04
Safety
Tips and recommendations
It is necessary to observe the safety notes written in
these operating instructions in order to reduce the risk of
personal injuries and damages to property.
2.2 Obligations of the operating company
The operating company is the person who operates the
vacuum cleaner for business or commercial reasons by
herself, or leaves it to a third party for use or application,
and who bears the legal product responsibility for the
protection of the user, the staff or for third parties.
Obligations of the operating company:
If the vacuum cleaner is used for commercial purposes,
the operating company of the vacuum cleaner must com-
ply with the legal working safety regulations. Therefore,
the safety notes in this operating manual, as well as the
safety, accident prevention and environment protection
regulations applying for the area of application of the va-
cuum cleaner must be met. The following applies in parti-
cular:
- During the entire lifetime the vacuum cleaner, the
operating company must verify whether the opera-
ting manuals prepared by her correspond to the
current status of the regulations, and must adapt
these if necessary.
- The operating company must be informed about
the applying industrial safety regulations and fur-
ther analyse hazards resulting from the special
working conditions at the place of use of the vac-
uum cleaner. She must implement these in form of
operating manuals for the operation of the vacuum
cleaner.
- The operating company must unambiguously regu-
late and determine the responsibilities for installa-
tion, operation, troubleshooting, maintenance and
cleaning.
- The operating company must ensure that all per-
sons who work with the vacuum cleaner, have read
and understood this manual. Furthermore she
must instruct the staff in regular intervals and in-
form them about the hazards.
- The operator must provide the necessary protec-
tive equipment to the staff and order the use of the
necessary protective equipment in a binding way.
Furthermore the operating company is responsible to
keep the vacuum cleaner always in a technically flawless
state. Thus, the following applies:
- The operator must ensure that the maintenance in-
tervals described in this manual are kept.
- The operator must have all safety devices checked
regularly for their good working order and their in-
tegrity.
WARNING!
This combination of symbol and signal words indi-
cates a potentially dangerous situation which may
lead to death or severe injury if not avoided.
CAUTION!
This combination of symbol and signal words indi-
cates a potentially dangerous situation which may
lead to slight or minor injury if not avoided.
ATTENTION!
This combination of symbol and signal words indi-
cates a possibly dangerous situation which may lead
to property and environmental damages if they are
not avoided.
NOTE!
This combination of symbol and signal words indi-
cates a potentially dangerous situation which may
lead to material or environmental damage if not avoi-
ded.
Tips and recommendations
This symbol highlights useful tips and recommenda-
tions as well as information for an efficient and trou-
ble-free operation.

Safety
VCA - Series | Version 1.04 5
2.3 Requirements to staff
The different tasks described in this manual represent
different requirements to the qualification of the persons
entrusted with these tasks.
Only persons reliable working procedures can be ex-
pected from, are allowed to perform all works. Persons
the responsiveness of which is affected by e. g. drugs,
alcohol or medication, are not allowed to work with the
machine.
The qualifications of the personnel for the different tasks
are mentioned below:
Operator:
The operator is instructed by the operating company
about the assigned tasks and possible risks in case of
improper behaviour. Any tasks which need to be per-for-
med beyond the operation in the standard mode must
only be performed by the operator if it is indicated in
these instructions and if the operating company expres-
sively commissioned the operator.
Electrically qualified person:
Electrically qualified person is due to their professional
training, knowledge and experience as well as knowl-
edge of the relevant standards and regulations, in a posi-
tion to carry out work on the electrical systems and to in-
dependently recognize and avoid possible dangers.
Qualified personnel:
Due to their professional training, knowledge and experi-
ence as well as their knowledge of relevant regulations
the specialist staff is able to perform the assigned tasks
and to recognise and avoid any possible dangers them-
selves.
Manufacturer:
Certain works may only be performed by specialist per-
sonnel of the manufacturer. Other personnel is not au-
thorized to perform these works. Please contact our cus-
tomer service for the execution of all arising work.
2.4 Personal protective equipment
The personal protective equipment serves to protect per-
sons against impairments of safety and health while wor-
king. The staff member has to wear personal protec-tive
equipment while performing different tasks on and with
the machine which are indicated in the individual para-
graphs of these instructions.
The personal protective equipment is explained in the
following paragraph:
2. General safety regulations
Please note the following:
- Use the guards and secure them securely. Never
work without protections and get them working.
- Always keep the vacuum cleaner and its working en-
vironment clean. Ensure adequate lighting.
- The special vacuum cleaner must not be modified in
its design and should not be used for purposes other
than those specified by the manufacturer.
- Never work under the influence of concentration-di-
sturbing illnesses, fatigue, drugs, alcohol or medici-
nes.
- Keep children and persons not familiar with the spe-
cial vacuum cleaner away from their working env-
ironment.
- The packaging elements can pose possible dangers
(e.g. plastic bags): for children and other persons
who are not aware of their actions and keep animals
out of reach.
- Any use other than that specified in this handbook
may be dangerous and must be avoided.
- The device must be mounted correctly before use. It
must also be checked that the filter elements are
correctly mounted and efficient.
- Do not absorb materials that could damage the filter
elements (e.g. glass splitters or metal).
- Eliminate disturbances that affect safety immedi-
ately.
WARNING!
anger in case of insufficient quali-
fication of the staff!
Insufficiently qualified persons cannot estimate the
risks while using the vacuum cleaner and expose
themselves and others to the danger of severe or let-
hal injuries.
- Have all works only performed by qualified persons.
- Keep insufficiently qualified persons out of the wor-
king area.
Protective gloves
The protective gloves serve to protect the hands
against sharp components as well as against fric-
tion, abrasions or deep injuries.
Safety boots
Safety boots protect the feet from being crushed, fal-
ling parts and slipping over on slippery ground.
Protective clothes
Protective clothes are made of a tightly fitted fabric
without the protruding parts of low tear strength.

6 VCA - Series | Version 1.04
Safety
- Do not pull on the mains lead to pull the plug out of
the socket. Protect the cable from heat, oil and
sharp edges.
- Do not ever pull or lift the apparatus through the
electrical cable.
- Do not immerse the device into water and neither
use water jets to clean it.
- Always unplug the device from the wall outlet before
handling the switched-off device.
- Always check the power cable for damage such as
cracks or signs of aging. Replace the cable before
using it again.
- The replacement of a defective power cable must be
carried out by the technical service or by qualified
personnel.
- When using extension cords, make sure that they
are compatible with the power cord (larger or equi-
valent cross-section) and that they do not come into
contact with liquids or conductive surfaces.
- Maintenance and repairs must always be carried out
by qualified personnel.
- Protect the special vacuum cleaner against moisture
(risk of short circuit).
- Before each use, make sure that no parts are dama-
ged on the special vacuum cleaner. Damaged parts
must be replaced immediately to avoid danger sour-
ces.
- Do not overload the special vacuum cleaner! You
work better and safer in the specified performance
range.
- Only use original spare parts and accessories to
avoid possible risks and risks of accidents.
ATTENTION!
Never absorb liquids!
ATTENTION!
The special vacuum cleaner is not suitable for recol-
lection of dangerous dust. Do not exhaust toxic,
explosive, flammable or incandescent substances.
The maximum temperature for flexCAT 262 VCA allo-
wed is 40°C / 104°F.
ATTENTION!
Don’t ever point the suction opening towards deli-
cate parts of the body – of people or animals - such
as eyes, ears, mouth, etc.
ATTENTION!
Store the device under consideration of its weight, i.e.
on a firm, level surface and only in a closed room
without humidity.
ATTENTION!
This device should only be used for dry vacuuming
and must not be used or stored outdoors in wet con-
ditions.
ATTENTION!
Only use the parts supplied with the device or those
are specified in this instructions. The use of other
parts may damage safety.
ATTENTION!
Never leave the running special vacuum cleaner
uncontrolled. Always disconnect the power plug from
the wall outlet when the vacuum cleaner is not in use
and keep it out of the reach of children or unauthori-
zed persons.
ATTENTION!
If the device is equipped with an additional socket,
the power indicated on the socket must not be
exceeded. Failure to comply with this requirement
may result in fire, personal injury or even death to the
user.
ATTENTION!
The device is not suitable for areas protected against
electrostatic discharges.
ATTENTION!
It is forbidden to carry out changes to the device.
Tampering could cause fires and damages even let-
hal to the user and the forfeiture of the guarantee.

Intended Use
VCA - Series | Version 1.04
2.6 Safety labels on the special vacuum cle-
aner
The following safety labels and instructions are attached
to the vacuum cleaner (Fig. 1) and must be observed.
Fig. 1: Safety labels
If safety labels on the machine are damaged or missing,
this can cause errors, personal injury and material dam-
age. The safety symbols attached to the machine must
not be removed. Damaged safety symbols must be re-
placed immediately. As soon as the signs are not clearly
visible and compre-hensible at first glance, the machine
must be stopped until new signs have been attached.
2.7 Safety data sheets
Safety data sheets for hazardous materials can be obtai-
ned from your specialist dealer or by phone: +49 (0)951/
96555-0. Specialist dealers can find safety data sheets
in the download area of the partner portal.
3 Intended Use
The special vacuum cleaner suitable for reliably and ea-
sily vacuum cleans of the cold ashes, sand and coarse
dirt Not suitable for wet vacuuming! The vacuum cleaner
must not be operated in potentially explosive environ-
ments. It is ideal for use in public buildings such as ho-
tels, schools, hospitals, factories or offices. Proper use
also includes compliance with all information in this ma-
nual. For structural and technical changes to the vacuum
cleaner, the company Stürmer Maschinen GmbH assu-
mes no liability.
Claims of any kind due to damage due to improper use are
excluded.
3.1 Unintended use
3.2 Residual risks
Even if all safety regulations are observed and the dry
vacuum cleaner is used correctly, there are still residual
risks, which are listed below:
- There is a risk of injury to the upper limbs (e.g.
hands, fingers).
ATTENTION!
It is forbidden to carry out changes to the device.
Tampering could cause fires and damages even let-
hal to the user and the forfeiture of the guarantee.
The manufacturer declines any responsibility for
damages caused to people or things due to noncom-
pliance with these instructions or if the device is
unreasonably used.
WARNING!
angers in case of unintended use!
Unintended use of the vacuum cleaner can cause
hazardous situations.
- Only operate the vacuum cleaner within the perfor-
mance limits stated in the technical data.
- Do not bypass or disarm safety equipment.
- Only use the vacuum cleaner in technically perfect
condition.
ATTENTION!
This special vacuum cleaner is not suitable for absor-
bing dangerous dust. Never soak up glowing, flam-
mable, explosive or toxic substances.
The maximum allowable service temperature for
flexCAT 141VCA is 120 ° C.
The maximum allowable service temperature for
flexCAT 262 VCA is 40 °C.
- Do not absorb any materials that may damage the
filter elements (e.g., broken glass, metal, etc.).
- Do not absorb materials that could damage the filter
elements (e.g. powder, toner, gypsum and other
substances with very small particle sizes).
- Do not absorb any water or other liquids.

8 VCA - Series | Version 1.04
Technical ata
4 Technical Data
4.1 Type plate
Fig. 2: Type plate flexCAT 262 VCA
Transport, packaging, storage
.1 Transport
Check the special vacuum cleaner after delivery for vi-
sible transport damage. If you discover damage to the
vacuum cleaner, immediately report it to the transport
company or the dealer.
.2 Packaging
All used packaging materials and packaging aids are
recyclable and should be taken to a materials recycling
depot to be disposed of.
The delivery packaging is made of cardboard, so please
dispose carefully by having it chopped up and given to
the recycling collection.
The film is made of polyethylene (PE) and the cushioned
parts of polystyrene (PS). Deliver these substances to a
collection point for recyclable materials or to the waste
disposal company which looks after your region.
.3 Storage
Store the vacuum cleaner in a dry, clean and frost-free
environment.
flexCAT 141 VCA 262 VCA
Length 395 mm 550 mm
Width / Depth 385 mm 600 mm
Height 900 mm 930 mm
Weight 12 kg 24 kg
Drive motor output 45 , W 45 , x 2 W
Input power 1600 W 2800 W
Motor speed 26631U/min 26631U/min
Current consumption 6,9 A max. 6,9 A x 2
Total rated value 1300 W
Electrical connection 220-240 V 220-240 V
Phase(s) 1 1
Supply frequency 50/60 Hz 50/60 Hz
Cable length 8,5 m 8,5 m
Air volume 210 m³/h 420 m³/h
Tank volume 41 Liter 62 Liter
Tank material Stainless steel
Hose diameter 38 mm 38 mm
Hose length 2,8 m 2,8 m
Sound pressure level 2 dB(A) 4 dB(A)
Filter surface 2300 cm² 362 +
3000 cm²
Number of motor(s) 1 2
WARNING!
anger to life!
The packaging elements may pose potential hazards
(e.g., plastic bags):
- Packaging material for children and persons
who are unaware of their actions or keep ani-
mals inaccessible.

escription of device
VCA - Series | Version 1.04 9
6 Description of device
flexCAT 141 VCA
Fig. 3: Description flexCAT 141 VCA
1 Power supply cable
2 Fastening clamps
3 Tank
4 Castors
5 Intake socket
6 ON/OFF switch
Handle
flexCAT 262 VCA
Fig. 4: Description flexCAT 2 62 VCA
1 Handgrip
2 Handle
3 ON/OFF switch Motor 1
4 Fastening clamps
5 Handle
6 Castors
Tank
8 Intake socket
9 ON/OFF switch Motor 2
6.1 Scope of device
Fig. 5: Scope of device
The Special Vacuum Cleaner is delivered with:
- High temperature pre-filter
- HEPA cartridge filter
6.2 Accessories
- Hose and nozzle set Ø 38 mm heat resistant up to
200 °C
Item number: 7013325
Fig. 6: Accessories oven vacuum cleaner SET 1
- Hose and nozzle set Ø 38 mm heat resistant up to
120 °C
Item number: 7013326
Fig. : Accessories oven vacuum cleaner SET 2
- Flat nozzle Ø45mm (suitable for adapter Ø38mm)
Item number: 7013044
- High temperature pre-filter
Item number: 7013320
1
7
6
5
2
3
4
1
2
3
4
5
6
7
8
9

10 VCA - Series | Version 1.04
Operation
- Cartridge filter HEPA H13
Item number: 7013321
- Metal hose Ø38 mm / 2.8 m flexible
Item number: 7013330
- Suction tube extension Ø 38 / 1500 mm, with heat
protection
Item number: 7013331
- Suction tube Ø 38 / 1000 mm
Item number: 7013332
- Oven cleaning nozzle with heat resistant rubber wiper
Item number: 7013333
- Hose EPDM Ø 38 mm / 3 m
Item number: 7013334
- Hose & nozzle set Ø38mm antistatic
Item number: 7013335
- Hose Ø38mm/2m with connections antistatic
Item number: 7013336
- Suction tube Ø38mm length 0.5m antistatic
Item number: 7013337
- Handle with false air control antistatic
Item number: 7013338
- Floor nozzle dry antistatic
Item number: 7013339
- Joint nozzle antistatic
Item number: 7013340
- Round nozzle with brush antistatic
Item number: 7013341
- Antistatic upholstery nozzle
Item number: 7013342
7 Operation
7.1 Mounting
- Insert the filter into the vacuum cleaner tank
(Fig. 8).
Fig. 8: Mounting the filter flexCAT 141 VCA
- Place the motor head on the container and fasten
with the clamps on the left and right side (Fig. 9)
Fig. 9: Mounting of the head flexCAT 141 VCA
- Connect the suction nozzle (Pos. 3, Fig. 10) to the
tank and connect the extension (Pos. 4, Fig. 10) to
the end of the hose. Connect the suction brush
(Pos. 5, Fig. 10)) to the end of the hose extension.
ANGER!
anger of potentially fatal electric
shock!
There is a risk of fatal injury from contact with live
parts. Electrical components which are switched on
can carry out uncontrolled movements and cause
serious injuries.
- Disconnect the plug before starting adjustments to
the vacuum cleaner.
ATTENTION!
The device must be correctly installed before use. It
must be checked that the filter elements are mounted
correctly and that they function correctly.
The device should only be operated, mounted, repai-
red and transported on a stable, flat surface.
Make sure that the electrical data indicated on the
motor block match those of the mains to which the
special vacuum cleaner is to be connected and that
the mains plug of the special vacuum cleaner fits the
socket.
ATTENTION!
Always disconnect the power plug from the socket
before handling the disconnected vacuum cleaner.
Always check the supply cable for damage such as
cracks or signs of aging. If necessary, replace the
cable before further use.
The replacement of a defective power cord must be
carried out by the technical service or by qualified
personnel.
When using an extension cord, make sure that it has
the same cable dimension as the power cord of the
vacuum cleaner and avoid contact of the cables with
liquids or conductive surfaces.
WARNING!
Before putting the device into operation, make sure
that the voltage indicated on the type plate corre-
sponds to the mains voltage.

PCare, maintenance and repair
VCA - Series | Version 1.04 11
Fig. 10: Assembly of the hose
7.2 Start and Stop
Start
- Insert the plug of the vacuum cleaner into a wall
outlet.
- Press the ON/OFF switch in the Position „I“.
Stop
- Switch off the device, press the On/Off button, set
the switch to position „O“ and disconnect the mains
plug.
- When removing the plug, always pull the plug, ne-
ver the cable.
7.3 Emptying of the tank
Step 1: Check that the device is switched off and dis-
connected from the mains.
Step 2: Open the clamping hooks and remove the tank
cap.
Step 3: Remove the filters and empty the tank.
Step 4: Replace the filters in the tank. Make sure that the
filter is correctly positioned and tightly seated.
Step 5: Put on the container cover (check correct posi-
tion!) and close the clamping hooks. Check that
the cap is tightly closed.
7.4 Seal control
Over time, it is possible that the seals will partially lose
their function. This leads to a decrease in the suction po-
wer. We recommend periodically checking the locking
hooks, flexible suction hoses and seals for proper func-
tion.
Clean all seals after completion of work. Dirt can prevent
correct operation and cause damage.
Also, check that the edges of the container are not da-
maged.
8 P Care, maintenance and repair
8.1 Care by cleaning
.
The special vacuum cleaner should always be kept in a
clean condition.
The ventilation slots of the motor must be kept clean to
ensure adequate cooling.
Step 1: Clean the vacuum cleaner after use and empty
the container.
Step 2: Clean all painted surfaces with a soft, damp
cloth.
NOTE!
The special vacuum cleaner flexCAT 262 VCA has 2
separate ON/OFF switches. Thus it is possible to
choose how many motors should work. This allows a
significant saving of energy.
ATTENTION!
In order for the device to function properly, it is
necessary to clean the filter by shaking and cleaning
it well after each use.
ANGER!
anger of potentially fatal electric
shock!
There is a risk of fatal injury from contact with live
parts. Electrical components which are switched on
can carry out uncontrolled movements and cause
serious injuries.
- Disconnect the mains plug before starting cleaning
and maintenance work.
ATTENTION!
Cleaning must not be carried out by children, if
they're not supervised by adults.
Maintenance and repairs must always be carried out
by qualified personnel. Damaged parts must only be
replaced with original spare parts.
ATTENTION!
Never use solvents to clean plastic parts or painted
surfaces. The surface may become detached and
consequential damage may occur.
Protective gloves
For cleaning, wear suitable protective gloves to pro-
tect against injury.

12 VCA - Series | Version 1.04
isposal, recycling of used devices
8.2 Cleaning the filter
Knock out the filters.
Clean the filters with a brush.
Fig. 11: Cleaning the filter
8.3 Maintenance and repair
If the special vacuum cleaner does not function properly,
contact a specialist dealer or our customer service. Con-
tact details can be found in chapter 1.2 Customer Ser-
vice.
9 Disposal, recycling of used devices
Please take care in your own interest and in the interest
of the environment that all component parts of the ma-
chine are only disposed of in the intended and permitted
way.
9.1 Decommissioning
Immediately decommission disused machines in order to
avoid later misuse and endangering of the environment or
personal safety.
- Eliminate all environmentally hazardous operating
materials from the used device.
- If required, disassemble the machine into easy to-
handle and usable components and parts
- Dispose of machine components and operating mate-
rials by the disposal channels provided.
9.2 Disposal via municipal collection points
Disposal of used electrical and electronic equipment
(Applicable in the countries of the European Union and
other European countries with a separate collection sys-
tem for these appliances).
The symbol on the product or its packaging indi-
cates that this product should not be treated as normal
household waste, but must be returned to a collection
point for the recycling of electrical and electronic equip-
ment. By helping to properly dispose of this product, you
are protecting the environment and the health of others.
Environment and health are endangered by improper
disposal. Material recycling helps to reduce the con-
sumption of raw materials. For more information about
recycling this product, contact your local community, mu-
nicipal waste management, or the shop where you pur-
chased the product.
9.3 Disposal of dust bags and filters
The dust bags and filters are made of eco-friendly mate-
rials. The filters can be disposed of with normal house-
hold waste. This also applies to the dust bag as long as it
does not contain any dirt prohibited in household waste.
10 Troubleshooting
ATTENTION!
Maintenance and repairs must always be carried out
by qualified personnel; Any damaged parts can only
be replaced by original spare parts.
ANGER!
If one of the following errors occurs, immediately stop
working with the special vacuum cleaner. Before you
begin troubleshooting, turn off the special vacuum
and unplug the power cord. Otherwise it could lead to
serious injuries. All repairs or replacement work may
only be carried out by qualified and trained specialist
personnel.
NOTE!
If you can not solve the problem with your vacuum
cleaner yourself, then please contact your nearest
Cleancraft dealer. Please write down the following in-
formation from the vacuum cleaner or the operating
instructions in advance to help you with your problem
in the best possible way.
-Model name of the device
-Serial number of the device
-Construction year
-Exact error description

Spare parts
VCA - Series | Version 1.04 13
11 Spare parts
11.1 Ordering spare parts
The spare parts may be purchased by the authorised dealer.
Indicate the following basic information for requests or orders
of spare parts:
- Type of device
- Item No.
- Position No.
- Year of construction:
- Quantity
- Required mode of dispatch (mail, freight, sea, air,
express)
- Address of dispatch
Spare part orders which do not include the above indi-
cations may not be taken into consideration. If the indi-
cations regarding the mode of dispatch are missing, the
product is dispatched at the discretion of the supplier.
You will find information regarding the device type, item
No. and year of manufacture on the type plate fixed to
the vacuum cleaner.
Example
The engine for the Multifunctional Inverter KOMBI 1 1
ED must be ordered. The engine has the number 24 in
the spare parts drawing 1.
By ordering spare parts, send a copy of the spare parts
drawing (1) with the marked part (engine) and marked
positon number (24) to the dealer or spare parts depart-
ment and provide the following information:
Type of device: flexCAT 141 VCA
Item number: 7003160
Position number: 24
Drawing number: 1
The item number of your device:
flexCAT 141 VCA: 003160
flexCAT 262 VCA: 003165
Fault Possible Cause Solution
Device
does not
work.
1. Power plug is
not plugged in.
2. Supply lines is
defective.
3.Switch is
defective
4. Motor is
defective.
1. Plug in mains
plug.
2. Call the service
technician
3. Call the service
technician.
4. Call the service
technician
Suction
decrea-
ses.
1. Blockages in
the suction
nozzle, suc-
tion pipe, suc-
tion hose or
filter.
2. Seals are
leaking.
1. Remove blocka-
ges, clean or
change the filter.
2. Clean or re-
place seals.
Check the posi-
tion of the seals,
filters and tank
cover.
Check hose and
connections for
leaks.
ANGER!
anger of injury by the use of
wrong spare parts.
Dangers may result for the user and damages as well
as malfunctions may be caused by using wrong or
damaged spare parts.
- Only use original spare parts of the manufacturer or
spare parts admitted by the manufacturer.
- Always contact the manufacturer in case of uncer-
tainties.
Tips and recommendations
The manufacturer's warranty will become null and
void if non-permissible spare parts are used.

14 VCA - Series | Version 1.04
Spare parts
11.2 Spare parts drawings flexCAT 141 VCA
In case of service, the following drawings shall help to
identify the necessary spare parts. If necessary, send a
copy of the parts drawing with the marked components
to your authorised dealer.
Spare parts drawing 1: Head
Fig. 12: Spare parts drawing 1 flexCAT 141 VCA
Spare parts drawing 2: Filter unit
Fig. 13: Spare parts drawing 2 flexCAT 141 VCA
Spare parts drawing 3: Chassis

Spare parts
VCA - Series | Version 1.04 15
Spare parts drawing 4: Tank
Fig. 14: Spare parts drawing 4 and 5 flexCAT 141 VCA
11.3 Spare parts drawings flexCAT 262
VCA
In case of service, the following drawings shall help to
identify the necessary spare parts. If necessary, send a
copy of the parts drawing with the marked components
to your authorised dealer.
Spare parts drawing 1: Head
Fig. 15: Spare parts drawing 1 flexCAT 262 VCA
Spare parts drawing 5: Sealing ring
1

16 VCA - Series | Version 1.04
Spare parts
Spare parts drawing 2: Filter unit
Fig. 16: Spare parts drawings 2 and 3 flexCAT 141 VCA
Spare parts drawing 3: Tank
A

Spare parts
VCA - Series | Version 1.04 1
Spare parts drawing 5: Chassis
Fig. 1 : Spare parts drawings 5,6 and
Spare parts drawing 6: Filter block disc
Spare parts drawing 7: Sealing ring

18 VCA - Series | Version 1.04
EC eclaration of Conformity
12 EC Declaration of Conformity
According to Machinery Directive 2006/42/EC, Annex II 1.A
Manufacturer / distributor: Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
hereby declares that the following product
Product group: Cleancraft® Cleaning technology
Machine type: Special Vacuum Cleaner
esignation of the device*: flexCAT 161 VCA Item number *: 003160
flexCAT 262 VCA 003165
Serial number*: ____________________
Year of manufacture*: 20_________
* fill in these fields using the information on the nameplate
complies with all relevant provisions of the above mentioned directive as well as the other applied directives (below) -
including their applicable modifications at the time of the declaration.
Relevant EU irectives: 2011/65/EU RoHS Directive
2014/30/EU EMC Directive
Following standards where applied:
DIN EN 60335-1:2020-08 Household and similar electrical appliances - Safety - Part 1: General
requirements
DIN EN 60335-2-69:2015-0 Household and similar electrical appliances - Safety - Part 2-69: Particular
requirements for wet and dry vacuum cleaners, including power brush for
commercial use
DIN EN 62233:2008-11 Measurement methods for electromagnetic fields of household appliances and
similar apparatus with regard to human exposure
DIN EN 55014-1:2018-08 Electromagnetic compatibility - Requirements for household appliances,
electric tools and similar apparatus - Part 1: Emission
DIN EN 55014-2:2016-01 Electromagnetic compatibility - Requirements for household appliances, electric
tools and similar apparatus - Part 2: Immunity - Product family standard
DIN EN 61000-3-2:2015-03 Electromagnetic compatibility (EMC) - Part 3-2: Limits - Limits for harmonic
current emissions (equipment input current ≤ 16 A per phase)
DIN EN 61000-3-3:2014-03 Electromagnetic compatibility (EMC) - Part 3-3: Limits - Limitation of
voltage changes, voltage fluctuations and flicker in public low-voltage
supply systems, for equipment with rated current ≤ 16 A per phase
and not subject to conditional connection
Responsible for documentation: Kilian Stürmer, Stürmer Maschinen GmbH,
Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt
Hallstadt, 30.03.2021
______________________
Kilian Stürmer
Managing Director

Notes
VCA - Series | Version 1.04 19
13 Notes

www.cleancraft.de
