Cleerline SSF-TKITP-500 User manual

SSF-TKITP-500
SSF™ Pro Fiber Test Kit
Manual

1
WARNING
To avoid the risk of serious eye damage, do not look into the laser at any time.
OPTICAL FIBER TEST KIT

2
Overview 3
Features 3
Accessories 3
Specications 4
Ports 5
Function Keys 7
Screen Icons 8
Light Source 9
Sequencing and Tracking 10
RJ45 Sequencing 10
RJ45 Cable Tracking 10
System Settings 11
Maintenance and Troubleshooting 12
Troubleshooting 12
Warranty 14
OPTICAL FIBER TEST KIT
Overview 15
Features 15
Accessories 15
Specications 16
Ports 17
Function Keys 19
Screen Icons 20
Operating the Optical Power Meter 22
User dened wavelength 22
View saved results 22
OPM Settings 22
Calibration mode 22
Sequencing and Tracking 23
RJ45 Sequencing 23
RJ45 Cable Tracking 23
SystemSettings 24
Maintenance and Troubleshooting 25
Troubleshooting 25
Warranty 26
CONTENTS
Handheld Light Source
Handheld Power Meter

3
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Features
• Includes carrying case & strap
• Tests both multimode and single mode bers
• Wavelengths of 850, 1300, 1310, and 1550 nm
• Wave ID – auto wavelength identication
• Storage of up to 1000 test records
• Included PC Software and USB cable
• 2.8” Color LCD screen with ambient light detection
• Built-in LED Flashlight
• Built-in VFL with 2.5 mm to 1.5 mm adapter included
• Built-in RJ45 sequencer
• Included AC power supplies
• Auto shut-off function
• Rechargable lithium ion battery
Accessories
(1) Operation Manual
(1) 5.0 V Power Supply
(1) USB-C Charging Cable
(1) Carrying Case & Strap
HANDHELD OPTICAL LIGHT SOURCE
This handheld optical light source is controlled by a chip microprocessor
and displayed by 2.8 inches color LCD. Constructed using advanced
thermoplastic molding technology for improved durability. It supports both
SM/MM light source output wave ID and TWINS mode output. The output
power is adjustable. Stable Laser Source, RJ45 Sequence and ashlight
are standard conguration. RJ45 Tracking, Laser Ranging, and Bluetooth
are optional. They are mainly used for continuous optical signal power
measurement, optical ber link loss test and optical ber line on-off test.
They are widely used in optical cable construction and maintenance,
optical ber communication, optical cable sensing, optical CATV and other
elds.

4
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Specications
Model Optical Light Source
Operating wavelength (nm) 850/1300±20 nm 1310/1490/1550±20 nm
Applicable ber SM, MM
Laser type FP-LD
Maximum output power (dBm) ≤-5 dBm
Adjustable step size (dBm) 0.1 dB/1 dB
Stability (dB, 15min, 20°C) ±0.2 dB/15min
( After preheating for 15 minutes )
Modulation (Hz) CW, 270, 330,1K, 2K
Fiber port `
RJ45 cable sequence
Testing range ≤300 m
Display 2.8 inch color LCD , 240x320
Power supply Rechargeable Li-battery , 2200 mAh
Automatic shutdown time 10min/30min/1 hour
Battery operating time ≥12 hours
Operation temperature -10 ºC - +50 ºC
Storage temperature -40 °C - +70 ºC
Relative humidity 0-95% No condensation
Dimensions (mm) / Weight 140 mm x 32 mm x 73 mm / 235 g

5
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
TOP
RIGHTLEFT
BOTTOM
(SM or MM)
Left Panel
1
2
3
4
5
6
7
8
10 11
9
12345678
Ports

6
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
LEFT
1 Charging indicator
2 TypeC port
3 RJ45 sequencer port
4LCD screen
5 Sequence indicators
6 Function keys
BOTTOM
7RJ45 Remote Sequence Module
TOP
8 Dust Cover
9LED Flashlight
10 MM laser source port
11 SM laser source port
Ports

7
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Power On/Off: Short press to turn the unit on or off.
Auto Shut-Off Selection: After power is on, short press
this key to turn the auto shut-off function on or off.
Flashlight: Short press to turn the ashlight on or off.
Long press to turn VFL on or off.
Selection keys (up & down): Toggle items to be set
Selection keys (left & right): Adjust an item’s value
Menu: Toggle the different function modules
Wavelength: Toggle the different wavelengths
Function Keys

8
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Icons
Automatic Shutdown: in the set time without any operation
the instrument will automatically shut down
Data Transmission: data is being transmitted through the
data line connected to the computer, copying the internal
data of the instrument
Bluetooth: Not Supported
Save Completed: indicates that the test results have been
saved
Flashlight: indicates the LED ashlight is turned on
Time: displays local time
Battery: indicates current batter capacity
According to different functions and specic operations, the
corresponding icon will appear on the screen. When an icon appears,
it means that the corresponding function has been opened or the
corresponding operation has been completed.
The main icons of the instrument are as follows:

9
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Light Source
Light source: used for telecommunication, CATV, LAN cable parameter
test; The insertion loss, isolation and return loss of optical passive
components are tested; Wavelength responsivity test of detector.
Press this button to switch the output wavelength. When
the wavelength is selected the laser source is turned on by
default.
Adjust the step to 0.1 dB or 1 dB.
Adjust the output power, the range is -5.0 dBm to -11.0 dBm.
After the laser source is turned on, switch CW
(continuous), modulation 270/330/1k/2 kHz, ID, twins
mode.
ID Used for wavelength identication with OPM ID function.
TWINS After turned on, the LS emits 1310&1550 nm alternately,
and the OPM automatically identies and tests the power
of 1310 nm and 1550 nm alternately.

10
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
RJ45Sequence&Tracking
RJ45Sequence: When testing, please use the remote module at the
bottom of the instrument
RJ45CableTracking: Once this function is turned on, touch the tested
cable with the cable nder. You will then hear a continuous beeping sound
which indicates the target cable.
This equipment can be used for line searching directly and can withstand
voltage and prevent burning. Ethernet switches, routers, and other weak
current equipment with DC voltage less than 60 V.
/Use the up & down arrows to switch between RJ45
sequence test and cable tracking test. After selection is
made, the function is turned on by default

11
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
System Settings
System Settings: set the relevant information of this machine
Up and down keys: Select the item to be set
Left and right keys: Adjust the value of the item set
Auto-Off: set the automatic shutdown time; options are 10 minutes,
30 minutes, or 1 hour.
Language: Set the language for this machine; options are English or
Chinese
Time: Press the left and right buttons to switch the date and time,
press the left and right buttons to switch between elds, and press
the λ to conrm and exit edit mode.
Restore factory settings: Press λ until “Y/N?” appears on the display
screen. Press the left and right keys to select either Y (yes) or N (no)
and press λ again to conrm the operation.
OFF

12
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Maintenance and Troubleshooting
Connectors
The optical output interfaces must be kept clean during use and you
should alwasy clean connectors prior to testing.
Small amounts of dust on the connector will affect the accuracy of the
measurement.
To clean the connector, rst turn off the LS function. Moisten a cotton
swab with isopropyl alcohol, insert the cotton swab in the connector, and
slightly rotate the cotton swab. Always dry using a second dry cotton swab.
LCD Screen
To prevent damage, do not click on the LCD with sharp objects, or the LCD
screen may be damaged.
When cleaning, clean the LCD screen with microber cloth. Do not wipe the
LCD screen with organic solvent, otherwise it may damage the LCD screen.
Troubleshooting
Issue Possible Reason Solution
Faint screen display Low battery power Charge or replace the
battery.
Unit fails to turn on
Low battery power
or battery inserted
incorrectly
(A) Replace the battery
(B) Re-insert the
battery
Optical power is not
stable after when light
source turned on
Allow a 15 minute
warm-up period
Warning
1. Ensure the connector is clean before testing.
2. Only use the supplied adapter.
3. Do not look into the laser when unit is on.
4. Charge the batteries before use. Do not charge in unit.
5. Cover laser with dust-proof cap when not in operation.
6. Clean the optical port of the power meter regularly.

13
OPTICAL FIBER TEST KIT
Handheld Optical Light Source
Warranty
Caution: Do not attempt to repair as doing so will void warranty.
This Optical Power Meter is covered by an 18 month warranty.
1. We warrant that this power meter will be free from defects in
material and workmanship for 18 months. Should the device fail at
any time during this warranty period, we will, at our sole discretion,
replace and repair or refund the purchase price of the product. The
worth of the repair or replacement will not be higher than purchasing
price of this unit.
2. If device issues cannot be solved by the troubleshooting methods,
please contact us or the local distributor directly.
3. We will repair or replace the unit free of charge in case of defects in
production, workmanship or material. This warranty only applies to the
unit under normal operation without any damage or misuse/abuse.
4. The shipping costs incurred by repair or replacement for the unit under
warranty will be shared by both parties.

15
OPTICAL FIBER TEST KIT
Handheld Optical Power Meter
Features
• Wave ID: auto wavelength identication & switching
• Frequency ID: auto frequency identication
• Manual and automatic (ambient light sensing) backlight control
modes
• Storage of up to 1000 data records, downloadable via USB cable
• Mini USB port for downloading and saving testing records
• Adjustable/storable reference power level
• User self-calibration function
• Auto shutdown function
• Up to 200 hours battery life
Accessories
(1) Operation Manual
(1) USB Cable
(1) AC Power Supply Adapter
(1) 1.25mm & 2.5mm One Click Cleaners
The SSF-TKITP-500 Power Meter adopts a 1mm large photosensitive
surface detector. It’s 2.8-inch color LCD screen allows for ease of use.
The design and layout both provide functionality and durability for use in
the eld. It includes a built-in VFL (Visible Fault Locator) as well as an LED
ashlight and RJ45 tracker/sequencer.
The SSF-TKITP-500 Power meter measures optical signal power, optical
ber link loss, and optical ber line on-off test. The LSPM test kit can
be utilized for all optical cable installations and maintenance to certify
optical loss measurements of installed ber optic cable.
HANDHELD OPTICAL POWER METER

16
OPTICAL FIBER TEST KIT
Handheld Optical Power Meter
Specications
Optical Power Meter
Wave Range 800 ~ 1700 nm 800 ~ 1700 nm
Connector Universal joint FC/SC/ST
Detector Type InGaAs
Power Range -70~+10 dBm -50~+26 dBm
Uncertainty ±5%
Standard Wave 850/980/1300/1310/1490/1550/1625/1650 nm
Custom Wave 50
Display Resolution Linear Display: 0.1%
Logarithmic Display: 0.001/0.01/0.1 dBm
Identied Frequency 270 Hz, 330 Hz, 1 kHz, 2 kHz
Storage 1000 items
Visual Fault Locator
Wavelength 650±30 nm
Output Power 10 mW
Mode CW/1Hz/2Hz
Connector Universal joint
FC/SC/ST
RJ45CableSequence
Test Range ≤300 m
RJ45CableTracking
Test Range ≤300 m
Tracking Mode Digital tracking
Live/line to line
search Support
Other
Display 2.8in color LCD,
240x320
Power Supply Rechargable Li-
battery, 2200 mAh
Wireless
Interface
Bluetooth (not
supported)
Automatic
Shutdown Time 10min/30min/1hr
Battery Duration ≥12hr
Operating
Temperature -10 ºC ~ +50 ºC
Storage
Tempurature -40 ºC ~ +70 ºC
Relative Humidity 0-95% No
condensation
Weight 235g
Dimensions 140 mm x 32 mm
x 73 mm

17
OPTICAL FIBER TEST KIT
Handheld Optical Power Meter
TOP
RIGHTLEFT
BOTTOM
Left Panel
1
2
3
4
11
12
5
9
6
7 8
12345678
Ports

18
OPTICAL FIBER TEST KIT
Handheld Optical Power Meter
Ports
LEFT
1 Charging indicator
2USB-C port
3 RJ45 tracking port
4LCD screen
BOTTOM
5 RJ45 tracking remote module
TOP
6LED Flashlight
7 VFL port
8OPM port
9Dust cover
RIGHT
11 RJ45 sequencing indicator
12 Function keys

19
OPTICAL FIBER TEST KIT
Handheld Optical Power Meter
Function Keys
Power On/Off: Short press to turn the unit on or off.
Auto Shut-Off Selection: After power is on, short press
this key to turn the auto shut-off function on or off.
Flashlight: Short press to turn the ashlight on or off
Selection keys (up & down): Toggle items to be set
Selection keys (left & right): Adjust an item’s value
Menu: Toggle the different function modules
Wavelength: Toggle the different wavelengths
