Clevertronics FBKLED Series Installation and operating instructions

1949357
V2.1
30 September 2022
Instruction Sheet Template - V1.5 –Updated 09/06/2022
240V LED Bunkalite
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Models:
FBKLED-vv-xx-yy-zz-uu
Options:
Microwave Sensor
xx = MS
DALI LED Driver
zz = RL
Black in Colour
zz = BLK
Warm White
vv = WW
Inline Filters
uu = FLT
Spare Parts:
8002801
Replacement Emergency Driver
8002801
Replacement Emergency Driver (-WW Option)
1330049
Replacement 240V Driver
1330045
Replacement 240V Driver (-DD option)
1190310
Replacement Microwave Sensor
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1949357
V2.1
30 September 2022
Instruction Sheet Template - V1.5 –Updated 09/06/2022
Installation:
The LED Bunkalite (FBKLED) can be installed either Ceiling or Wall Mounted.
•Remove the four (4) screws holding the ring to the fitting.
•Remove the four (4) screws holding the gear tray to the base.
•At this point you must decide if the supply cable entry will be via the entry point provided, in the
channel recess between the outer-rim and the base, or if a new cable entry is to be drilled into the
rear of the base. NOTE: if you choose to use the cable entry point provided the luminaire cannot be
positioned/centred over the supply cable point on the wall or ceiling. The supply cable must line up
with the recessed channel as shown below.
•Using the base as a guide, mark 2 holes for mounting and one for mains access.
•Mount the base using appropriate fixings and seal these fixings with silicone (fill any additional entry
points with silicone also)
•Route the power inside the base.
•Connect the 240VAC (A, E, N) supply to the terminal block of the gear tray.
•Connect the DALI Lines to the terminals marked “DA DA” on the gear tray.
•Install the gear tray to the base.
•Apply power to the fitting and test per the instructions.
Dimensions:
Maintenance:
Lamp Replacement::
•Use only the LED panel inside the Bunkalite and listed on this instruction
•To replace the LED panel, remove the screws, disconnect the signal wires and install the new LED
panel
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
