Click FT-40MD User manual

40cm Drum Pedestal Fan
Model Number: FT-40MD
USER MANUAL
AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761
E209

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
2
Important Safety Instructions 3
Product Overview 6
Getting Started 7
Instructions 10
Other Useful Information 12

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 3
Important Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to. Make sure you under-
stand all instructions and warnings. Keep the manual in a safe place for future
reference, along with any warranty information, your purchase receipt and the
packaging carton. If you sell or transfer ownership of this product, please pass
on these instructions to the new owner. Always follow basic safety precau-
tions and accident prevention measures when using an electrical appliance,
including the following:
Electrical safety and cord handling
• Voltage: Make sure your outlet voltage and circuit frequency correspond to
the voltage stated on the rating label. If this is not the case, do not use the
fan.
• Water: To protect against fire and electric shock, do not immerse the cord,
plug or the fan in water or other liquid, or expose the electrical connections
to water. Ensure your hands are dry before handling the plug or switching
on the fan. Do not use the fan outdoors or on wet surfaces. Protect it from
liquid spills.
• Damage: Check the power cord regularly for visible damage. If the cord is
damaged, it must be replaced by the manufacturer, its authorised service
centres or appropriately qualified personnel in order to avoid any hazards.
• WARNING! Do not pick up or operate the appliance if the supply cord, plug
or housing is damaged, or after it malfunctions or has been dropped or
damaged in any manner. In case of damage, contact our after sales support
centre.
• Protect the power cord:
- Do not operate the fan with the cord coiled up; always fully unwind.
- Do not twist or kink the cord or let it touch heated surfaces.
- Do not put any stress on the cord where it connects to the product.
- Never carry the fan by the cord.
- Arrange the cord away from any trac area so no one will trip over it.
- Do not run the cord under carpeting or cover it with rugs or runners.
• WARNING! No extension cord, no timer: Do not use this fan with an
extension cord, plug adaptor, external timer or separate speed control
device.
• Connection: To insert the plug, grasp it firmly and guide it into outlet.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
4
Important Safety Instructions (Cont.)
• Disconnection: Unplug the appliance from the power outlet when it is
not in use and before cleaning, servicing, moving or storing the appli-
ance. Grasp the plug and remove it from the outlet, do not pull the cord
when disconnecting.
• Guard removal: Ensure that the fan is switched o from the supply
mains before removing the guard (grille).
• WARNING! Do not leave unattended during use! Always switch it o
and unplug when not in use, if left unattended, and before cleaning and
storing.
• WARNING! Electric shock hazard! Do not plug in the fan until fully as-
sembled.
• RCD: Unless your home is already fitted with a residual current device
(safety switch), we recommend installing an RCD with a rated residual
operating current not exceeding 30mA to provide additional safety
protection when using electrical appliances. See your electrician for
professional advice.
Usage conditions and restrictions
• Domestic use only: This fan is intended for indoor household use only.
It is not suitable for commercial, industrial or outdoor use. Do not use it
for anything other than its intended purpose (do not use it as a dryer),
and only use it as described in this manual. Any other use may cause
fire, electric shock or injury.
• Attachments: The use of accessory attachments not recommended in
this manual may cause injury or hazards.
• Usage restriction: This fan is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure they do not play with the
appliance. Close supervision is necessary when any appliance is used by
or near children.
• Location: Place the fan on a dry, flat, stable surface to avoid overturning.
• Keep the top clear: Do not place anything on top of fan.
• Proper assembly: Do not operate the fan until fully assembled with all
parts. Do not use the appliance without the protective grilles (rear and
front guards). Do not attempt to force the grille in order to stop or start
the fan.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 5
Important Safety Instructions (Cont.)
• WARNING! DO NOT use the fan in the following areas:
- Near an open flame, a hot burner, oven or other source of high heat.
- On a soft surface (such as carpet) or where it may tip over during use.
- Outdoors or in areas of high humidity without suitable ventilation
(e.g., in a bathroom, laundry area), near a sink, washer, pool or any
source of water.
- Near curtains or in tight corners, to enjoy maximum airflow.
- In areas where flammable substances (e.g., paint, petrol, etc.) are
stored or being sprayed and there is a risk of explosion or fire.
• CAUTION! Personal safety: Avoid contact with moving parts. Never
insert fingers, pencils or any other objects through the grilles when
the fan is running. Keep hair and loose clothing well away from the fan
when it is in use.
• Free airflow: Ensure nothing is blocking the airflow outlet and air intake
grilles. Do not insert foreign objects into any opening as this may cause
electric shock and/or a fire hazard.
• Liability: We assume no liability for any damages or personal injury
caused by misuse of the product and/or failure to follow these
instructions.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
6
Parts List
1
2
4
5
7
Parts list
1 Safety guards
(front and rear grilles)
2 Fan blade
3 Motor with speed control
and oscillation knob
(at the back, not visible
here)
4 Pivot knob
(see page 8 for details)
5 Oscillation knob
6 Extension pole
7 Height adjustment
knob
8 Stand base
3
6
8
NOTE: Due to continued product
improvement, images and illustrations
in this manual may vary slightly from
the product purchased. All images in this
manual are for reference purposes only.
Parts are not necessarily pictured to scale.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 7
Getting Started
Before first use
• Unpacking: This product has been packaged to protect it against
transportation damage. Unpack the appliance and keep the original
packaging carton and materials in a safe place. It will help prevent any
damage if the product needs to be transported in the future, and you can
use it to store the appliance when it is not in use. In the event it is to be
disposed of, please recycle all packaging materials where possible.
• Safe packaging disposal: Plastic wrapping can be a suocation hazard
for babies and young children, so ensure all packaging materials are out
of their reach and disposed of safely.
• Inspection: Unwind the cord to its full length and inspect it for damage.
Do not use the appliance if the appliance or its cord have been damaged
or are not working properly. In case of damage, contact our after
sales support centre for advice on examination, repair or return of the
damaged product.
• Documentation: Make sure you have read and understood all
instructions and warnings in this manual. Refer to the illustrations to
familiarise yourself with the product and identify all parts. Pay particular
attention to the safety instructions on the previous pages.
• Assembly: Your new fan has been shipped partially assembled to
minimise packaging waste. Assembly instructions are provided on the
following pages; the illustrations show how all the parts fit together.
WARNING: Electric shock hazard!
Do not plug the power supply cord into an electrical outlet until fully
assembled.
Parts of the fan
Fan head
and motor
assembly
Column sub-
assembly
Base
Fig. 1
Weight
Washer
L-shaped
screw

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
8
Getting Started (Cont.)
Assembly
Fig. 2: Attaching the telescopic stand to the stand base
• The washer and L-shaped screw are attached to the lower column, or
supplied separately. Unscrew the bolt, if applicable, and remove both
from the bottom of the lower column.
• Turn over the stand base. Place the weighted base centre in its place on
the underside of the base and the washer in the centre of the weighted
base. Then thread the L-shaped screw through the assembly and into the
thread in the lower column. Tighten firmly, but do not overtighten.
• Loosen the height adjustment knob and pull out the extension pole to
the desired height, then retighten the knob.
Fan head assem-
bly
Extension pole
Height adjustment
knob
Lower column
Stand base
Fig. 2
Weight
Washer
L-shaped screw

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 9
Getting Started (Cont.)
• First remove the pivot knob (2) and the large pivot bolt (6) from the top of
the telescopic stand, then remove the neck retaining screw (3) and small
adjustment knob (5) from the motor housing bracket.
• Place the fan head and motor assembly on the top of the stand and
thread the large pivot bolt (6) through the bracket. Screw in the neck
retaining screw (3) and tighten, but do not overtighten.
• Fit the large pivot knob (2) onto the end of the bolt (6) and the small
adjustment knob (5) at the other side above the bolt. Tighten the knobs
while holding the fan motor upright.
Assembly
Fig. 3
1 Telescopic stand
2 Pivot knob
3 Neck retaining screw
4 Motor housing
5 Small adjustment knob
6 Large pivot bolt
NOTE: The illustration above
shows the motor housing
without the fan head. On the
fan model you purchased, the
fan head is already assembled
to the motor housing.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
10
The fan is equipped with 3 speeds and an oscillation option. To use the
fan, follow the simple instructions below.
Place the fan on a dry, level surface where it will not overturn during use.
Make sure the speed control at the back of the motor housing is in the
OFF [ 0 ] position, then insert the power plug into an appropriate electrical
outlet.
Speed selection
The speed control is located at the back of
the motor housing (Fig. 4). To select the fan
speed, move the speed control from the OFF
[ 0 ] position to the desired setting:
0 = OFF - 1 = LOW - 2 = MEDIUM - 3 = HIGH
Oscillation
• Press the oscillation knob on top of
the motor housing to activate the
oscillation function for widespread breeze
distribution. The fan head will pivot from
one side to the other.
• For stationary operation, pull up the oscillation knob when the air is
blowing in the desired direction.
CAUTION: Do not reach across the front of the fan when operating the
oscillation control to avoid the possibility of your clothing, sleeves, etc.
entering and getting caught in the front guard.
Adjusting the height
• Loosen the height adjustment knob (turn anticlockwise), pull out or push
down the extension pole to the desired height, then retighten the knob
firmly.
Instructions
Fig. 4

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 11
Instructions (Cont.)
Tilt adjustment
The fan head assembly can be tilted to direct the breeze upwards or
downwards to your desired angle.
• CAUTION: Make sure the fan is unplugged from the power supply
before adjusting the tilt angle.
• Loosen both the larger tilt adjustment knob and the smaller tilt range
knob. Tilt the head to the desired angle, and then tighten both knobs
securely.
CAUTION: Do not tilt back the fan head further than it is intended to go.
Doing so will damage the unit.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
12
Other Useful Information
Cleaning and maintenance
• Dusting: Clean your fan periodically by lightly running a vacuum
cleaner nozzle (soft brush) over the front and rear guards to remove
any dust or dirt that may have accumulated inside or on the unit.
Alternatively, use a soft, dry cloth for dusting.
• Stubborn stains: Use a slightly damp, soapy cloth for stubborn stains
but be sure the cloth is not too wet. Use caution around the motor
housing. Do not allow the motor or other electrical components to be
exposed to water.
• End of season cleaning: When you have finished using the fan at the
end of the season, wipe o any dust to maintain it in good working
order for the next season. To clean the blades, carefully remove the front
grille: loosen the screws around the rim of the front grille and take o
the grille. Carefully wipe the blades clean using a dry or slightly damp
cloth and a little mild detergent, then wipe dry. Ensure all parts are
thoroughly dry before reassembly.
• Storage: In the o season, store the clean and dry fan in a safe, dry
location, protected from dust. We recommend using the original
carton for storage of the disassembled product (follow the assembly
instructions in reverse order to disassemble). Alternatively, place a large
plastic bag or piece of material over the top of the cleaned fan for dust
protection.
WARNING!
• Before cleaning, maintenance or moving the fan, and before
removing a front or rear guard, switch o the fan and unplug it from
the wall outlet.
• Do not immerse the fan in water or other liquids. Do not spray it
with liquids. Do not allow water to drip on or into the fan motor
housing.
• Never use petrol, solvents, harsh detergents, or abrasive or alkaline
cleaners on the fan.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 13
Other Useful Information (Cont.)
Technical specifications
Power 50W, 220-240V~, 50-60Hz
Fan speeds 3 (Low - Medium - High)
Dimensions (mm) 1230 (height)
400 (base diameter)
455 (fan head diameter)
Weight 6.7kg (approx.)
Responsible disposal
• At the end of its working life, make the appliance unserviceable by
unplugging it from the power outlet and cutting the power cord.
• Do not throw this appliance out with your household rubbish.
Electrical and electronic products contain substances which can have a
detrimental eect on the environment and human health if disposed of
inappropriately. Observe any local regulations regarding the disposal of
electrical consumer goods and dispose of it appropriately for recycling.
Contact your local authorities for advice on recycling facilities in your area.
Compliance
This appliance has been fully tested and meets all requirements as set out
by standards AS/NZS 60335.1 and AS/NZS 60335.2.80.
The RCM Mark (Regulatory Compliance Mark) indicates that the
product complies with the relevant guidelines of the ACMA as well as
corresponding government requirements for the safety of electrical
devices.
• Service/repair: The appliance requires no maintenance and contains no
user-serviceable parts. Do not attempt to take the motor housing apart.
Do not try to repair or modify the appliance. Do not operate the fan if
its power cord or plug is damaged, or when it is working abnormally. In
case of damage or malfunction, or if the cord is damaged, have the unit
repaired by trained personnel only, or contact the after sales support
line for advice on repair or replacement. Before phoning for a service,
please ensure that your fan is properly assembled and connected to
your power supply.

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
14

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail] 15

AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Warranty returns
Should you for any reason need to return this product for
a warranty claim, make sure to include all accessories with
the product.
Product does not work?
If you encounter problems with this product, or if it fails to
perform to your expectations, make sure to contact our
After Sales Support Centre on (AU) 1300 886 649 or
(NZ) 0800 836 761 for advice.
Distributed by Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Australia NSW 2086
Customer Helpline:
(AU) 1300 886 649 (NZ) 0800 836 761
Email: [e-mail]
For an electronic copy of this manual, please contact our after sales support
centre.
IM Version No: V1.0 Issue: May 2020
