Clicker KLIK1C User manual

CLICKER® MODEL KLIK1C
Universal Garage Door Opener Remote Control To prevent possible SERIOUS INJURY or DEATH from a moving gate or
garage door:
• ALWAYS keep remote controls out of reach of children. NEVER permit
children to operate, or play with remote control transmitters.
• Activate gate or door ONLY when it can be seen clearly, is properly
adjusted and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed.
NEVER permit anyone to cross path of moving gate or door.
© 2011, Clicker Corporation
114A3486D All Rights Reserved
Thank you for your purchase of a Clicker®universal remote control.
PLEASE DO NOT RETURN TO THE RETAIL STORE. If for any reason you
have questions or need help with troubleshooting please call: 1-800-442-1255.
Read instructions thoroughly BEFORE beginning.
Start with garage door closed. Identify garage door opener type - Smart/Learn
button or DIP Switch. Smart/Learn button or DIP Switches are located on motor
unit or external receiver. Refer to owner’s manual if necessary.
Clicker products are intended to be used only with garage door openers
manufactured after 1993 that utilize photo-eyes safety sensors. These are
always located on or near the bottom of the door track. If your garage door
does not have the sensors attached and working, the opener is not
compliant with current federal safety regulations and should be replaced.
Proceed with instructions according to your type of garage door opener.
ON
23
1
KG KG
NOTE:
2 Position DIP Switch:
If programming fails reverse
DIP switches (OFF to ON and
ON to OFF).
**3 Position DIP Switch:
For Chamberlain remotes DO NOT
use the “0” position, use “+” or “-”.
If you already have a 3-button
remote, DIP switch #1 must be set to “-” if the large
button is to open the door. It may be necessary to
reprogram original remote controls.
2
1211109853 7641 2
Clicker Remote
Existing Remote
3
4
Press program button
until LED lights.
5
Match DIP switches. Turn
extra switches OFF.**
OR
DIP SWITCH
SMART/LEARN BUTTON
23
1
KG KG
4
Motor Unit
Select a button to program.
Press button times
ensuring LED stops
flashing after each
press. Code is accepted
when door activates.
REMOTE CONTROL BATTERY
NOTICE: To comply with FCC and or Industry Canada (IC) rules, adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the battery.
THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Dispose of batteries properly. Replace ONLY with 3V2032 coin
batteries.
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
To reduce risk of fire, explosion or chemical burn:
• Replace ONLY with 3V2032 coin batteries.
• DO NOT recharge, disassemble, heat above 212° F (100° C) or
incinerate.
CHART B
# of times Brand Description Year
to press
button
11 Chamberlain®* 9 Position ’90-’92
12 Chamberlain®* 9 Position
Canada ’83-’89
13 Genie®12 Position ’85
14 Linear Multicode®10 Position ’76
15 Chamberlain®8 Position ’83-’89
16 Stanley/Multicode®10 Position ’76
17 Genie®9 Position ’85
18 Linear®
Moore-O-Matic®8 Position ’76
19 Chamberlain®* 7 Position ’83-’89
CHART A
# of times Brand Type/Color of Year
to press Smart/Learn
button
1 Linear®Mega-Code ’97-Current
2 Chamberlain®* Orange ’97-’05
3 Chamberlain®* Purple ’05-Current
4 Chamberlain®* Green ’93-’96
5 Genie®
Overhead Door®Intellicode ’95-Current
6 Genie®**
Overhead Door®Intellicode ’93-Current
7 Stanley®Secure Code ’98
8 Chamberlain®* Yellow ’11-Current
9 Wayne Dalton®Rolling Code ’99
11 Chamberlain®* 9 Position ’90-’92
1-800-442-1255
Chamberlain, LiftMaster and Moore-O-Matic are Trademarks of Chamberlain Group. Genie
and Intellicode are Trademarks of GMI Holdings, Inc. Overhead Door is a Trademark of
Overhead Door Corporation. Linear is a Trademark of Linear Corporation. Master Mechanic
is a Trademark of TruServ. Sears is a Trademark of Sears & Roebuck. Stanley is a
Trademark of The Stanley Works. Wayne Dalton is a trademark of Wayne Dalton
Corporation. Do It is a trademark of Do It Best Corporation.
Press program button.
6
7
Programming complete.
Press selected button
to test. If unit does not
work, return to Step 3.
Press and release the
smart/learn button.
5
Select a button to program.
Press button times
ensuring LED stops flashing
after each press. Code is
accepted when one of the
following occurs:
OR
OR
1
See Chart B to
determine # of times to
press button and write
in blank on step 5.
DIP SWITCH
SMART/LEARN BUTTON
Press program button.
6
7
Programming complete.
Press selected button
to test. If unit does not
work, return to Step 3.
3
Press program button
until LED lights.
2
1
See Chart A to
determine # of times to
press button and write
in blank on step 5.
NOTE: Your opener may
appear different and you
may have to remove the
light lens to access the
learn button.
*NOTE: LiftMaster, Do-It, Master Mechanic, Raynor, True Value and Sears Craftsman are compatible
with Chamberlain technology.
**NOTE: Visit www.clickerproducts.com for Genie Intellicode II instructions.
Click
PRODUCT REGISTRATION AND
TROUBLESHOOTING
www.clickerproducts.com
1211109853 7641 2
LED Indicator
Button 1 Button 2
Program Button
Battery
DIP Switches
Battery Cover
Motor Unit
ON
STOP
