Clover DQ205 User manual

Features
• Easy To Install
• Ceiling Mounted Dome
• Real Time Displa
• yHigh Resolution Camera
• IR Remote Controls Switching & Quad Mode
• Cost Efficient Alternative To Using a Quad Monitor
• Compatible With Most TVs And Monitors
Model # DQ205
COLOR
Color Dome Quad Camera
With 4 Built-in Cameras and Quad Splitter
Color Dome Quad Camera
With 4 Built-in Cameras and Quad Splitter

COLOR
Color Dome Quad Camera
With 4 Built-in Cameras and Quad Splitter
Color Dome Quad Camera
With 4 Built-in Cameras and Quad Splitter
Image PickupDevice
No. of Pixels
Sync System
Usable Innumination
Gamma Characteristic
Electronic shutter speed
Dwell Time
Operation Temperature
Dimensions
TV System
Scanning
System
Resolution
S/N Ratio
Video Output
Real Time
Power Supply
Storage Temperature
Weight
1/4” Color CCD Sensor
NTSC, 512(H)*492(V)
PAL, 512(H)*582(V)
Internal Sync
3 Lux/F2.0
0.45
NTSC : 1/60 - 1/100,000 sec
PAL : 1/50 - 1/100,000 sec
1 to 5 sec
-10°C to 50°C RH95% Max
165(Ø)*105(H)mm
NTSC, PAL
NTSC : 525 lines, 60 fields/sec
PAL : 625 lines, 50 field/sec
380 TV Lines
More than 46 db
1 V p-p 75 ohms
30 frames/sec
DC 18V 2.5A for Dome Quad
DC 12V 200 230mA for IR Receiver
-20°C to 60°C RH95% Max
6Lbs
Specifications
