Clover Mini Service manual

Clover Mobile Security Policy 1
Clover Mini Security Policy

Clover Mobile Security Policy 2
Table of Contents
INTRODUCTION 3
GENERAL DESCRIPTION 3
INSTALLATION GUIDANCE 7
VISUAL SHIELDING 9
DEVICE SECURITY 10
DECOMMISSIONING 11
KEY MANAGEMENT 15
SYSTEM ADMINISTRATION 19

Clover Mobile Security Policy 3
Introduction
This document addresses the proper use of the Point of Interaction Device (POI)
in a secure fashion. This includes information about key-management
responsibilities, device functionality, identification, installation, operating
guidance, environmental requirements and administrative responsibilities. This
document addresses the security requirements listed in DTR B20 of the PCI PTS
POI Version 4.0 document. This device is vendor controlled and it is required
that the vendor manage all payment security related functions.
General description
1. Product overview
a. Clover Mini (see image 1) is designed as a pin entry device (PED)
to facilitate credit and debit based transaction. The device is only
approved for use in an attended environment. This device has a
color LCD with touch screen as the customer interface for PIN
entry. The device also runs software to support the business
operations of the owner.

2. Device Functionality

Clover Mobile Security Policy 4
a. This device obtains card data via Integrated Circuit Card Reader
(ICCR), Magnetic Stripe Reader (MSR), manually entered cards and
Near Field Communications (NFC).
b. This device uses a Remote Key Injection (RKI) process to distribute
symmetric keys used to secure transactions. There are no
administrative modes available to the end user.
c. This device uses cryptologic authentication on all code before
execution.
3. Device Identification
a. Identifying information is presented on the label inside the printer
as seen in Image 2 and 3.



Clover Mobile Security Policy 5

4. Version Information
a. Software and firmware are displayed on the settings section on the
device. The user should regularly check the software and firmware
version of the device.
b. From the main screen, click on “Settings”

Clover Mobile Security Policy 6
c. Click on “About tablet”
d. View version numbers

Clover Mobile Security Policy 7
Installation Guidance
1. General Instructions
a. Initial setup of the device is conducted by the end user and
requires that user to have administrative rights to the merchant
account. There are no additional roles required.
b. Upon receipt of the device, the end user must connect the device
to Clover’s servers via an Internet connection. Any Wi-Fi
connection must be encrypted. Merchants should use connectivity
secure at a level equal or greater than WPA or WPA2.
c. Once connected, the end user must enter a one-time security code
provided by Clover. This code is communicated via a different
communication channel than the device itself.
d. Once the code is verified against the requesting device, the device
shall perform security updates including injection of security keys.
The end user is not required to perform any jobs necessary for
security.
e. Upon completion of setup, the end user may determine which
additional employees will have access to the device. The end user
must follow PCI security best practices when training additional
users.

Clover Mobile Security Policy 8
f. In addition to the device, the end user also receives
i. A power adapter
ii. A PIN Shield
iii. An overview guide
iv. A link to the help website where updated documentation
and FAQs are stored
2. Software Development Guidance
a. Clover Mobile software implements PCI security requirements for
authenticated applications.
b. No external developers are permitted to touch unencrypted
payment data. Clover makes certain that this data is already
encrypted immediately, that no clear-text data is outputted, and
that all applications are signed.
c. There are two types of APKs used for running software on the
device:
i. System Image APKs are controlled by the vendor. These
APKs are signed with the Clover Platform App Validation
Keypair. A hash of the each APK is also included in the
system files list checked at boot. The app that controls
payments is a System Image APK.
ii. Data Image APKs are submitted by the developer and if
approved by the vendor are signed by the source
developer’s key. Each APK has a whole file signature added
and the APK is signed with the Clover App Validation
Keypair. No data image APK has access to the payment
systems.
d. Non-Payment applications may install certificates into the system
default keystore. Application developers developing non-payment
applications should pin their server certificate (or public key) using
one of the techniques described here:
https://www.owasp.org/index.php/Certificate_and_Public_Key_Pin
ning
3. Networking the device
a. If you are connecting the device via Wi-Fi, you must only connect
to an access point that requires both username and password
encrypted authentication.
4. Software update and patch procedures

Clover Mobile Security Policy 9
a. When required, the device must install software updates. Updates
are done over the air. If updates are not installed, the device will
no longer be able to access the payment processing network.
b. The user is not required to do anything to receive the software
updates.
c. Software updates cannot be performed via USB.
5. Self-tests are not initiated by the user. They include:
a. Checking the integrity and authenticity of the software.
b. Checking the security mechanisms for sign of tampering.
6. The following Open Protocols were considered during the PTS
evaluation:
a. Interfaces
i. HSPA
ii. USB
iii. WiFi
iv. Bluetooth [Disabled in Firmware and therefore excluded
from PCI PTS Review]
b. Protocols
i. USB HID (keyboard & mouse), Serial, 3G modem driver,
Ethernet
ii. ICMP
iii. TCP
iv. UDP
v. HTTPS (client)
vi. DNS (client)
vii. DHCP (client)
viii. Bluetooth (L2CAP, ATT, AVCTP, AV Remote, AVDTP,
Advanced Audio, AV Remote) [Disabled in Firmware and
therefore excluded from PCI PTS Review]
Visual Shielding
1. The device comes with a PIN Shield and supplied instructions on the
proper installation and use. Use of the device for PIN Entry without the
supplied PIN shield will invalidate the PCI PTS approval. The custom PIN
Shield lays over the screen as follows:

Clover Mobile Security Policy 10
2. In addition to the guidance on the PIN entry screen directing cardholders
to shield their PIN entry with their hand, the merchant should take these
additional precautions:
A. Employees must be trained to provide verbal guidance instructing
cardholders to shield their entry of a PIN number by covering the
number pad with their hand.
B. Any other customers who are "shoulder surfing" or standing too close
to the cardholder must be directed far enough away from a
cardholder to obstruct viewing during PIN entry.
C. Surveillance cameras sited around the POS PED device must be
positioned such that they cannot record the PIN number as it is
entered.
Device Security
1. Roles

Clover Mobile Security Policy 11
a. The device has no functionality that gives access to security
sensitive services, based on roles. Such services are managed
through dedicated tools, using cryptographic authentication.
2. Environmental Requirements
a. The device should be operated under the following environmental
parameters
i. Maximum temp 135C
ii. Minimum temp: -70C
iii. Voltage (VDD) high: 3.8V
iv. Voltage (VBAT) high: 3.8V
v. Voltage (VBAT) low: 2.1V
b. Crossing these thresholds will trigger the tamper mechanisms.
Tripping the tamper will require the device to be sent back to
Clover.
3. Hardware Security
a. The device contains a tamper mechanism.
b. After a tamper event, all payment related keys are permanently
erased. Payments will not be processed in this state.
c. The device must be returned upon a tamper event and will not be
reused.
4. Visual inspection
a. Before using the device the user must conduct a regular inspection
to check for evidence of tampering. The following is a partial list
of procedures. Check the PCI website for the latest best practices.
i. Exterior should show no evidence of cutting or disassembly
ii. No evidence of unusual wires or overlays connected inside
the ICC slot nor on or near the PIN entry area.
iii. No changes to the resistance when inserting or removing a
card from the ICC slot.
Decommissioning
1. To decommission your device, a factory reset will remove the payment
keys in the device. A device may then be provisioned to a new user.

Clover Mobile Security Policy 12
a. From the main screen select “Settings”:
b. Select the “Backup & reset” option:

Clover Mobile Security Policy 13
c. Select “Factory data reset”:
d. Select “Reset device”:

Clover Mobile Security Policy 14
e. Enter your assigned employee pin:
f. Select “Erase everything”:

Clover Mobile Security Policy 15
2. If a device’s tamper mechanism has been tripped, the device’s keys have
been erased and the device needs to be returned to Clover.
3. If a device is damaged in any way that prevents the user from checking
the commissioning status of the device, the device needs to be returned
to Clover.
4. If the device needs to be disposed of by the user for any other reason,
the device should be returned to Clover for decommissioning. Devices
should not be disposed of by the user.
Key Management
5. Key Management System
a. The device uses a Remote Key Injection (RKI) process to distribute
symmetric keys used to secure transactions. The keys are
protected during distribution by a Public key Infrastructure (PKI)
with X509 certificates.
b. The process distributes 3 keys to terminals:
i. PIN IPEK
ii. SRED IPEK
iii. MAC IPEK
c. Although IPEK is an abbreviation for Initial Pin Encryption Key, it is
used to refer to any initial symmetric key in a DUKPT key
management system.
d. The RKI process uses ANSI X9 TR-31 to distribute symmetric keys.
Under TR-31, the key to be authenticated is both encrypted and
authenticated via a symmetric Key Encryption Key (KEK).
e. Before a device is delivered to a merchant, the device generates
an RSA key pair. The public key is exported in a Certificate Signing
Request (CSR). The CSR is then used to create an X509 certificate.
The certificate is used to securely identify the device. The key
generation and certificate issuance process is part of a PKI.
f. When the merchant receives a device, it generates a RSA session
key pair. The device then sends a RKI request to the Key
Distribution Host (KDH). The RKI request consists of the public
session key, the device metadata, the request’s cryptological
signature and the device’s X509 certificate.
g. When a device receives an RKI response, it first verifies the
response signature. The device then uses the private session key

Clover Mobile Security Policy 16
to decrypt the KEK. In turn, the KEK is used to extract the IPEKs
from the TR31 containers. Once the IPEKs have been extracted,
the RKI process is complete and the device is ready to process
transactions.
h. There are no alternative key systems. The use of any alternative
key management system would not work and would invalidate any
PCI approval of this POI.
6. Cryptographic Algorithms
a. All code is cryptologically authenticated before execution. The
authentication process relies upon cryptological data stored in one
time programmable memory (OTP memory). Once programmed,
OTP memory cannot be rewritten so code signing keys cannot be
replaced.
i. Main Board (MB) - the mainboard uses 2048 bit RSA PSS to
validate code. Main Board code is authenticated via the MB
secure boot key (MB SBK). The bootloader cannot execute
unless it is validated by the MB SBK.
ii. Secure Board (SB) - the secure board uses 256 bit ECDSA to
validate code. The secure board is protected by the Clover
Root Key (CRK). The CRK is validated by the Maxim Root
Key (MRK). At boot, the CRK is validated with the MRK.
The CRK is then used to validate code.
7. Key Invalidation
a. In the case of a compromise of a certificate authority operating by
the vendor, the vendor will notify user and the device must be
decommissioned according the instructions provided in that
section of this document.
b. In the case that you have been notified by the acquirer that the
BDK or the IPEK has been compromised, you must decommission
your device according the instructions provided in that section of
this document.
8. Key table
Key Name Purpose/Usage Algorithm Size Stored
Maxim Root
Key (MRK) Verify CRK ECDSA
L=2048,
N=256
(See FIPS
186-4
Semiconductor
Mask

Clover Mobile Security Policy 17
Section
4.2)
SB code
signing key
(CRK) Verify SB ROM ECDSA
L=2048,
N=256
(See FIPS
186-4
Section
4.2) Maxim 32550 OTP
SB Master AES
Key Encrypt data stored in crypto RAM AES 128
Maxim 32550
hardware engine
that encrypts
crypto RAM
SB Auth
Keypair Identify and authenticate SB RSA 2048
Private: NVS RAM;
Public Key
Certificate: MB
SB Enc Keypair
Used for encrypting messages sent
to SB, in particular used to encrypt
RKI TMK RSA 2048
Private: NVS RAM;
Public Key: SB
MB Auth
Keypair Identify and authenticate MB RSA 2048
Private: MB (in msc
partition encrypted
under SSK); Public
Key Certificate: MB
Device Root
Keypair Signs Device Intermediate Keypair RSA 2048 MB ROM
PED Root
Keypair Signs PED Intermediate cert RSA 2048 SB ROM
FD
Manufacturer
Root Keypair
Sign
Manufacturer_Provisioning_CA RSA 2048 SB ROM
RKI TMK
Symmetric key used to encrypt
TR31 formatted IPEKs during
remote key injection process TDES 112
Maxim 32550 NVS
RAM
KDH Root
Keypair
Validating authenticitiy of remote
key injection responses RSA 2048 SB ROM
Clover KDH
Signature
Signer Keypair Sign the RKI TMK Signature RSA 2048 SB ROM
Transarmor
Intermediate
Cert Keypair
Validate authenticity of SRED RSA
key (in case of RSA Transamor) RSA 2048 SB ROM
TransArmor
Keypair Encrypt SRED data RSA 2048 SB RAM
PIN IPEK Initialize DUKPT key table 3DES 112 Maxim 32550 NVS

Clover Mobile Security Policy 18
RAM
PIN DUKPT
Future
Encrypt payment data. Used to
derive DUKPT variants 3DES 112
Maxim 32550 NVS
RAM
SRED IPEK
Initialize DUKPT key table for SRED
DUKPT Future 3DES 112
Maxim 32550 NVS
RAM
SRED DUKPT
Future
Encrypt SRED data. Used to derive
DUKPT variants 3DES 112
Maxim 32550 NVS
RAM
MAC IPEK Initialize DUKPT key table 3DES 112
Maxim 32550 NVS
RAM
MAC DUKPT
Future
Encrypt payment data. Used to
derive DUKPT variants 3DES 112
Maxim 32550 NVS
RAM
Scheme
CAPKs Validate EMV card transactions RSA 2048
MB linux
filesystem; SB RAM
Merchant
configuration
signing keypair
Verify EMV parameters message
sent to SB RSA 2048 SB Code
Time Server
Keypair
Verify time update message sent
to SB RSA 2048 SB Code
MB Secure
Storage Key
(SSK) Protect data on MB (msc partition) AES 128
Derived using SBK
and dev key upon
boot
MB SBK SSK generation AES 128
Tegra 4 efuse
(unreadable)
MB Dev Key SSK generation
IV for AES
key
derivation 32
Tegra 4 efuse
(unreadable)
Flashing
Server Keypair Encrypting (MB SBK | MB Dev Key) RSA 2048
Public: MB
TrusteZone
MB
Bootloader
PKC
Integrity protection of MB
bootloader RSA 2048 MB ROM
MB Kernel
PKC Integrity protection of MB kernel RSA 2048 MB Bootloader
Debug block
Allows loading of signed debug
blob RSA 2048 MB ROM
Clover
Developer
Keypair
Validates authenticity of Clover-
developed non-system apps RSA 2048 MB ROM
Clover
Platform App
Validation
Keypair
Authenticity of Android platform
apps RSA 2048 MB ROM

Clover Mobile Security Policy 19
Clover App
Validation
Keypair
Authenticity of non-platform
Android apps RSA 2048 MB ROM
Clover APK
Validation
Keypair Authenticity of Clover Store Apps RSA 2048 MB ROM
Clover Server
Keypair
Identifies Clover's servers to
device RSA 2048 MB ROM
Clover Offline
Keypair
Signs CAPKs, Revoked CAPKs and
bin whitelist RSA 2048 SB ROM
System Administration
There are no permissions granted to users regarding device security. The only
action a user may take is to factory reset the device, which will erase all payment
keys from the device and require it to be re-provisioned.
