6+6 Drop-In Radio Pack and Battery Charger Operating Guide
Model Number: CBT-RPC-66
We at CoachComm®want to thank you for purchasing the 6+6 Drop-In Radio Pack (RP) and Battery Charger. The Charger’s design
allows users to simultaneously charge up to six X-System™ Radio Packs and up to six CoachComm rechargeable lithium-polymer
batteries.
Charger Overview
A. X-System Radio Pack (RP) Bay
B. CoachComm Li-Poly Battery Bay
C. Horizontal LEDs: RP Charging Status
D. Vertical LEDs: Battery Charging Status
E. Micro-USB Port (on rear)
F. Cable Management Channels
G. Power Connection with Strain Relief
What’s in the Box?
• CBT-RPC-66 - Drop-In Charger
• 00004239 - Power Supply
• PC-PWR-B - AC Power Cord
• D0000556 - Operating Guide
LED Legend
Pre-Charging
Normal Charging
Charge Complete
Battery Fault
Charging ambient temperature
outside range. Charging will
continue when temperature
drops within range.

Safety Recommendations
• Do not place unit in areas where it will be exposed to weather.
• Exercise extreme care when working with electricity, and always connect
the device into a ground-fault interrupting circuit when working outdoors or
near water.
• CBT-RPC-66 should only be used at an altitude not exceeding 2000 m.
• Do not allow the power cord to become crimped, twisted, or frayed.
• Refer all CBT-RPC-66 service to qualied CoachComm service personnel.
• When the CBT-RPC-66 is exposed to electromagnetic (EM) disturbances,
the device may show abnormal behavior.
Tempest®TMA-BAT-02 (white label) batteries are not compatible with the
CBT-RPC-66 charger.
Charger Operation
Radio Pack charge time from empty is approximately 4 hours. Battery charge
time from empty is approximately 2.5 hours.
When inserting a Radio Pack into the charger, the Radio Pack will log off and
power down, and its LCD will display a “Charge Mode” screen, which contains
the device’s model number, serial number, rmware version, charge percentage,
and estimated time to charge completion.
When removing a Radio Pack from the charger, wait for the bay’s LED to turn off
(approx. 4 seconds) before inserting another Radio Pack into that bay. Failure to
do so will prevent the new Radio Pack from charging.
During static events, LED operation may display an errant charging status. It
will only be temporary and will recover without damage to the charger or its
contents.
WARNING – DANGER! Users should take special precautions to avoid
the introduction of hazards when operating, installing, servicing,
transporting, or storing this device and lithium-polymer batteries.
CoachComm, LLC
205 Technology Parkway
Auburn, Alabama 36830 USA
Phone [phone]
www.coachcomm.com
©2020 CoachComm, LLC. All rights reserved. CoachComm®and X-System™are trademarks of CoachComm, LLC. Any and all other trademark
references within this document are property of their respective owners. D0000556_C
Warranty
X-System™products are warranted to be free from defects in materials and
workmanship for a period of one year from the date of sale to the end user.
The purchase of a maintenance and support plan is not a condition of coverage
under this limited warranty; however, purchasing a plan does extend a product’s
warranty for an additional year.
Additional Resources
For questions not addressed in this guide, feel free to review the additional
product information provided on our website: www.coachcomm.com.
