Coaster 801574 User manual

COASTERFURNITURE.COM
Fine Furniture for every stage of life
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
PAGE 1 OF 14
REVISION 0 : 12/29/2021
REVISION 1 : 06/28/2022
801574
BOOKCASE

801574
ITEM:
COASTERFURNITURE.COM
PAGE 2 OF 14
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIME
PARTS IDENTIFICATION
60 MINUTES
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
ALEFT SIDE
PANEL 1 PC
BRIGHT SIDE
PANEL 1 PC
CDIVIDER PANEL 4 PCS
DBOTTOM PANEL 1 PC
ECROSS PANEL
11 PC
FCROSS PANEL
21 PC
GCROSS PANEL
31 PC
HCROSS PANEL
41 PC
ITOP PANEL 1 PC
JBACK PANEL 1 PC
KLEG 4 PCS
LDRAWER
FRONT PANEL 1 PC
MDRAWER
BACK PANEL 1 PC
NDRAWER LEFT
SIDE PANEL 1 PC

801574
ITEM:
COASTERFURNITURE.COM
PAGE 3 OF 14
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
HARDWARE IDENTIFICATION
Z
ODRAWER RIGHT
SIDE PANEL 1 PC
PDRAWER
BOTTOM PANEL 1 PC
QDRAWER
SUPPORT 1 PC
NO DESCRIPTION FIGURE Q’TY
1GLUE 40g 1 PC
2WOODEN DOWEL
Ø8x30mm 64 PCS
3CAM BOLT
Ø7x35.5mm SR 49 PCS
4CAM LOCK
Ø15x12mm SR 49 PCS
5SCREW
Ø4.5x42mm SR 10 PCS
6SCREW
Ø4.3x35mm SR 5 PCS
NO DESCRIPTION FIGURE Q’TY
7PLASTIC FEET
Ø15mm 4 PCS
8GLIDES
L = 300mm WHT DR
DL
CL
CR 1 SET
9GLIDES SCREW
Ø3x12mm SR 12 PCS
10 HANDLE
L=170mm SR 1 PC
11 HANDLE BOLT
Ø4x25mm SR 2 PCS
12 STICKER
Ø20mm 10 PCS
Z8,Z10 not included in blister packaging.

801574
ITEM:
PAGE 4 OF 14 COASTERFURNITURE.COM
INCORRECT
CORRECT
x 24
STEP 1
Apply glue on all wooden dowels to
ensure integrity of the structure.
2
D
J
2
3
C
x 18
3
2
I
K
x 4
x 4

801574
ITEM:
PAGE 5 OF 14 COASTERFURNITURE.COM
STEP 2
2
x 10
x 3
9
8 x 1
(CR)
8
(CL)
9
CL
A
A
A
4
12
3
x 10
4
x 6
7
x 2
12
x 6
8
(CL)
(CL)
9
3
2
4
7
K
K

801574
ITEM:
PAGE 6 OF 14 COASTERFURNITURE.COM
STEP 3
4
CR
2
x 10
x 3
9
8 x 1
3
x 10
4
x 6
7
x 2
12
x 6
(CR)
8
(CL)
9
8
(CR)
(CR)
B
B
B
K
K
2
7
3
9

801574
ITEM:
PAGE 7 OF 14 COASTERFURNITURE.COM
STEP 4
x 16
2
x 8
3
Apply glue on all wooden dowels to
ensure integrity of the structure.
E
G
F
2
2
3
3
H

801574
ITEM:
PAGE 8 OF 14 COASTERFURNITURE.COM
STEP 5
STEP 6
Apply glue on all wooden dowels to
ensure integrity of the structure.
5
x 2
12
x 2
4
x 2
12
x 4
5
x 2
1
5
12
F
C
5
12
4
C
G

801574
ITEM:
PAGE 9 OF 14 COASTERFURNITURE.COM
STEP 7
STEP 8
4
x 2
12
x 4
5
x 2
4
x 2
12
x 2
5
x 2
C
C
4
4
5
12
5
E
H

801574
ITEM:
PAGE 10 OF 14 COASTERFURNITURE.COM
STEP 9
STEP 10
4
x 2
12
x 2
5
x 2
4
x 20
12
x 20
4
4
5
D
J
4
1
A
B

801574
ITEM:
PAGE 11 OF 14 COASTERFURNITURE.COM
4 x 2
x 5
STEP 11-1
STEP 11-3
STEP 11-5
STEP 11-2
STEP 11-4
STEP 11-6
6
8
(DL)
8
(DR)
9
11 x 2
x 6
12
M
N
O
P
L
Q
N
O
L
8
(DR)
8
(DL)
10
x 1
2 x 4
12
4 x 1
3 x 3

801574
ITEM:
PAGE 12 OF 14 COASTERFURNITURE.COM
STEP 12
STEP 13
COMPLETE
x 6
x 6
12
4
L
4
Apply glue on all wooden dowels to
ensure integrity of the structure.
I
1

801574
ITEM:
PAGE 13 OF 14 COASTERFURNITURE.COM
Note : Dimension tolerance ±5%
15.5"
68"
35.5"
7.56"
31.46"
11.18"
5.12"
29.49"
1.97"
11.77"
13.66"
13.66"
9.8"
13.66"
15.5"
15.5"
15.5"
15.5"
13.78"
21.18"
21.18"
9.8"
13.78"
13.78"
13.78"
13.66"

ANTI-TIPPING INSTALLMENT INSTRUCTIONS
FURNITURE TIPPING RESTRAINT
WARNING
Injury may result from tipping furniture.
This restraint may protect against tipping furniture.
Do not allow children to climb on furniture.
This restraint is not a substitute for proper adult supervision.
Failure to detach this restraint before moving the furniture
may result in injury and damage.
1. To attach the anti-tip strap, securely mount one end to the top of the case piece with
the 5/8” screw.
2. Position the case piece against the wall in the desired location.
3. Pull the anti-tip strap taut and mark the position of where you will secure the other end
on the wall.
4. Drill a 1-1/4” hole in the spot you marked.
5. Tap in plastic wall plug.
6. Fasten anti-tip strap with wall screw provided.
(Please install the anti-tiping kit in the middle of the case piece if only have one set of anti-tipping kit.)
WALL
PAGE 14 OF 14 COASTERFURNITURE.COM
