COBHAM SAILOR 630 Series User manual

What’s in the box?
SAILOR 630x MF/HF Control Unit
Installation guide
What do I need to t it?
Power Drill Jigsaw Screwdriver
TORX 20
Drill for M4 or
Ø3.9 self-tapping
U-Mounting
Bracket
Transceiver Gasket
Flush Mount
Bracket (2 pcs.)
User Manual
Wheel Knob
(2 pcs.)
Screw M4x45
TORX 20
(5 pcs.)
Square Nut
M4x7x2.2
(5 pcs.)
Screw M4x12
TORX 20
(5 pcs.)
Screw ø3.9x19
TORX 20
(5 pcs.)
Emergency Call
SAILOR 6300MF/HF DSC
Usermanual
150W/250W/500W
VHF and MF/HF
Emergency call
98-132369-NEU-B
MAYDAY-MAYDAY-MAYDAY
Thisis
NAME-NAME-NAME
CALLSIGN
orotherIDENTIFICATION
MMSI
(Iftheinitial alert is sent by DSC)
UsetheHANDSET for voice calling
SHIP‘sNAME:
CALLSIGN:
MMSI:
OWNID
DSC Radiotelephony NBDP
VHF Channel70 Channel16 -----
MF 2187.5kHz 2182.0kHz 2174.5kHz
HF4 4207.5kHz 4125.0kHz 4177.5kHz
HF6 6312.0kHz 6215.0kHz 6268.0kHz
HF8 8414.5kHz 8291.0kHz 8376.5kHz
HF12 12577.0kHz 12290.0kHz 12520.0kHz
HF16 16804.5kHz 16420.0kHz 16695.0kHz
Press
DISTRESSand COMMUNICATION
FREQUENCIES
Remembertousethe correct HF-procedures
Don‘tforgetyourEPIRB is the secondary means of alerting
MAYDAY
NAMEofthe VESSEL in distress
CALLSIGNorother IDENTIFICATION
MMSI
(Iftheinitial alert is sent by DSC)
POSITION
givenaslatitude and longitude
or
Iflatitudeand longitude are not known
or if time is insufcient,
inrelationto a known geographical location
NATUREofdistress
KindofASSISTANCErequired
Anyotheruseful INFORMATION
LiftCover
PressRED Button
untilbeepsounds continuously
(morethan3 seconds)
How to install the VHF on desktop and overhead
Tilting ±20°
How to install the VHF ush mount
How to install the handset
Drilling plan on desktop and overhead
99-131985
200mm
53mm
71mm
247mm
9mm
4 x M4 or hole for
self-tapping ø3.9
23.5mm
Disclaimer: Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed
by Thrane & Thrane. The information in this manual is provided for information purposes only, is subject to change without notice and may contain errors or
inaccuracies. Manuals issued by Thrane & Thrane are periodically revised and updated. Anyone relying on this information should acquire the most current
version e.g. from cobham.com/satcom or from the distributor. Thrane & Thrane is not responsible for the content or accuracy of any translations or reprodu-
ctions, in whole or in part, of this manual from any other source. Thrane & Thrane A/S trading as Cobham SATCOM
Copyright © 2013 Thrane & Thrane A/S. All rights reserved.
Handset for transceiver
This Handset has a hook-on/off function,
which is activated by a small magnet embedded
in the cradle.
The cradle must be installed as illustrated in
order to ensure the hook-on/off functionality
of the Handset.
75mm
62mm
226mm
* 120mm
min. 100mm
Space for handset access
Space for cable and handset cable
54mm
45mm
135mm
39655C
Weight
Handset for transceiver 0.4 kg
TT99-129987-A
All manuals and user guides at all-guides.com
all-guides.com

98-132396-B
www.cobham.com/satcom
Flush mount template
Remove material from shaded area only!
99-132034
89mm
227mm
R2.5mm x 4
Scale 1:1
Cutout template for ush mounting of the Control Unit
IMPORTANT!
If this template was printed from an elec-
tronic le or copied, scaling (1:1) may not be
correct. Consequently do not attempt to use
a printed or copied template without prior
checking of dimensions.
System Conguration - Example
SAILOR 6209
Accessory
Connection Box
SAILOR 6209
Accessory
Connection Box
Unit
Antenna Tuning
MF/HF
Handset
SAILOR 638x
Message Terminal
DSC Watch receiver
250W MF/HF with 6 ch. Scanning
SAILOR 636x
MF/HF DSC Telex Aerial
(Optional)
Keyboard
MF/HF Control Unit
SAILOR 630x
Alarm Panel
SAILOR 6103
Box
Switch
Handset
GPS option
2182 select option
SAILOR 6270
Power Supply
SAILOR 608x
Connection Box
Control Unit
Distress Alarm
Other Alarm
SAILOR 6201
Transceiver Unit
SAILOR 6201
SAILOR 6208
SAILOR 6001
SAILOR 6006
(Optional)
99-131805-C
Telex option
Printer
SAILOR H1252B
For further information, download the installation
manual 98-130890 at www.cobham/satcom
