Cobra G100 User manual

G100 - G300
ISTRUZIONI COMPLETE
COMPLETE INSTRUCTIONS

COMPLETE INSTRUCTIONS G100
33
Dear Customer,
Thank you and congratulations for choosing our product. It is a technologically
advanced alarm system which meets the performance standards set by automobile
manufacturers and complies with the European directives.
After the system was installed, dear Customer, you were given the radio controls and the
user’s manual, which also contains the product’s declaration of conformity and the
relative installation certificate.
The manual is divided into 2 parts G100 - G300:
Page
34/35 _______ LEGENDA AND KIT CONTENTS G100.
36 _______ INFORMATION.
37 _______ INTRODUCTION.
38 _______ ADDITIONAL PROTECTIONS.
39/40 _______ LIST OF FUNCTIONS G100.
41/43 _______ STANDARD FUNCTIONS LIST.
44 _______ COUPLING OF MODULES, SIREN 4310, ALARM ICD 31.
45 to 48 _______ LIST OF BASIC / ADVANCED FUNCTIONS.
49/50 _______ FITTING OF SYSTEM COMPONENTS.
51 _______ VEHICLE SPEED SENSOR CONNECTION - VSS (G100) -
_______ AUXILIARY OUTPUT AUX2.
52 _______ PROGRAMMING (G100).
53 _______ RADIO CONTROL FUNCTIONS CHECK.
54 to 56 _______ PROGRAMMING PAGES (G100).
57 _______ HOW TO PROGRAMME THE (G100) SYSTEM.
58 _______ PROCEDURE FOR ADDING NEW RADIOCONTROL DEVICES.
59 _______ HOW TO CONFIGURATE POSITIVE PERIMETRICAL INPUT - AND
_______ ALARM MEMORY.
60/61 _______ EMERGENCIES, PERSONALIZING THE PIN CODE.
62/63 _______ MAINTENANCE TROUBLESHOOTING .
153 _______ SYSTEM TECHNICAL CHARACTERISTICS.
120 to 156 _______ DIAGRAMS AND GUARANTEE.
Please read the manual carefully to get the full benefit of the product purchased. We also
advise you to keep this manual in the same place as your car documents for easy consultation
when needed. If any problem arises that cannot be resolved, please contact your dealer.
GB

COMPLETE INSTRUCTIONS G100
34
1 - LEGENDA AND KIT CONTENTS G100.
8772
Centralina
Central unit
Centrale
Centralita
Central
Çëåêôñïíéêüò åãêÝöáëïò
Centrální jednotka
Styrenhet
Sentralenhet
Central
Steuergerät
Cablaggio
Wiring harness
Câblage
Cableado
Conjunto de fios
Êáëùäßùóç
Kabelá
Kablar
edningsnett
Kabler
Leitungssatz
Sacchetto accessori
Fittings bag
Sachet des accessoires
Bolsa de accesorios
Saco de acessórios
Óáêßäéï ìå áîåóïõÜñ
Sáèek p isluenstvím
Tillbehörspåse
Pakke med monteringsdeler
Pose med tilbehør
Zubehör
Sensori ultrasuoni
Sensor transducers
Capteurs à ultrasons
Sensores a ultrasonido
Detectores de ultra-sons
ÁéóèçôÞñáò õ åñÞ÷ùí
Ultrazvukové snímaèe
Ultraljudssensorer
Ultralydsensorer
Ultralydsfølere
Ultraschallsensoren
Sirena autoalimentata
Siren with backup battery
Sirène autoalimentée
Sirena autoalimentada
Sirene auto-alimentada
Áõôïôñïöïäïôïýìåíç óåéñÞíá
Siréna s nezávislým napájením
Självförsörjande sir n
Sirene med selvmatingsbatteri
Sirene med batteri
Sirene mit bac up Batterie
Sirena non autoalimentata
Siren without backup battery
Sirène non autoalimentée
Sirena no autoalimentada
Sirene não auto-alimentada
Ìç áõôïôñïöïäïôïýìåíç óåéñÞíá
Siréna bez vlastní o napájení
Ej självförsörjande sir n
Sirene uten selvmatingsbatteri
Sirene uden batteri
Sirene ohne bac up Batterie
Pannello di controllo
Control panel
Tableau de commande
Panel de control
Painel de controlo
Ðßíáêáò åëÝã÷ïõ
Ovládací panel
Kontrollpanel
Kontrollpanel
Styrepanel
Emergency Panel
Manuale utente/installatore
User installation manual
Manuel utilisateur/Installateur
Manual del usuario/instalador
Manual de uso/instalação
Åã÷åéñßäéï ÷ñÞóôç
Návod pro uivatele/instalatéra
Användar-/installattionshandbok
Brukermanual/installatørmanual
Bruger- installatørmanual
Montage und Bedienungsanleitung
Pin Code Card
Pin Code Card
Carte Code PIN
Tarjeta de código PIN
Cartão do código PIN
Pin code card
Karta s pin kódem
Pin code card
PIN-kodekort
Pin-kode card
Pin Code Karte
Vetrofania
Warning sticker
Vitrauphanie
Calcomanía de advertencia
Aviso autocolante
Áõôïêüëëçôá ãéá ôá ôæÜìéá
Fólie na sklo s upozornìními
Varningsetikett
Advarselssticker
Advarselsmærkat
Cobra Fensterauf leber
Staffa
Bracket
Patte de fixation
Estribo
Presilha
Âñá÷ßïíáò
Tømen
Bygel
Bøjle
Bøjle
Halter
Dima di foratura
Drilling mask
Gabarit de perçage
Escantillón para perforar
Escantilhão para perfuração
Åëáóìá ôñõ Þìáôïò
Vrtací ablona
Borrningsmall
Hullmal
Hulskabelon
Bohrschablone
Radiocomando
Radio controls
Radiocommande
Radiomando
Comando por rádio
Ôçëå÷åéñéóìüò
Rádiové ovládání
Fjärrkontroller
Fjernkontroller
Fjernbetjeninger
Fembedienungen
Cablaggio sirena
Siren wiring harness
Câblage sirène
Cableado de sirena
Conjunto de fios da sirene
Êáëùäßùóç óåéñÞíáò
Kabelá sirény
Sir nkablar
edningsnett sirene
Sirenekabler
Leitungssatz Sirene
www.cobra-at.com

COMPLETE INSTRUCTIONS G100
35
3
3
3
3
3
3
3
33
3
3
3
AKG 198
3
3
AKG 193 ACG 196
33
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
KIT CONTENTS
www.cobra-at.com

COMPLETE INSTRUCTIONS G100
36
2 - INFORMATION.
The system is equipped with a self-learning function which makes it possible to simplify
all operations necessary for adding or replacing radio controls but only with the user’s
consent. For the procedure make reference to the manual at page 58.
2.1 - Personal Pin Code.
Each G100 system has a Pin Code that is used to disarm the system in emergencies.
This is a PIN CODE CARD sample
(PIN CODE is a factory - setted):
We advise you to stick the PIN CODE adhesive label onto the PIN
CODE card (which may be found on the rear of the control unit).
ATTENTION!
Don’t leave the PIN CODE CARD inside the vehicle.
www.cobra-at.com
STICK ON PIN
CODE ABE
PERSONA PIN CODE
4C4415A2A
S/N 0003 050524
PIN
CODE 1122

COMPLETE INSTRUCTIONS G100
37
Mod.

AKG 198







VOLUMETRIC
PROTECTION
PERIMETRIC
PROTECTION
WIRING CUT
PROTECTION
AKG 193
ACG 196
ENGINE LOCK
PROTECTION
3 - INTRODUCTION.
These anti - intruder alarm systems are controlled by a radio control device G100. This
technology provides an extremely high degree of protection against any attempt to reproduce
the code.
The radio control makes it possible to activate the system from a distance of 5 - 10
metres from the vehicle.
In some circumstances the range may be shorter due to interference from other
sources (e.g. radio transmitters operating on the same band).
If the radio control is not effective in the usual range, get as close to the vehicle as
you can.
If radio - controlled window closing is foreseen, we advise you to stay very close to
the vehicle when carrying out this operation to make sure it is performed under safe
conditions.
Your vehicle’s complete protection is assured by:

COMPLETE INSTRUCTIONS G100
38
4 - ADDITONAL PROTECTIONS G100.
You can increase the protection level of the system with the following additional sensors:
5452: Level monitor module.
When the system is armed, this sensor will detect the vehicle being jacked up to tow it
away or steal the wheels.
5462: Hyperfrequency module.
When the system is armed, hyperfrequency emissions from the module hidden in the car
will ensure volumetric protection of the vehicle.
2980: Windows lift module.
The electric windows of your car will raise automatically when the system is armed.

COMPLETE INSTRUCTIONS G100
39
5 - LIST OF FUNCTIONS G100.
5.1 - Standard functions list.
The following list indicates the main functional characteristics of the alarm system.
•Radiocontrol button functions.
•Arm / Disarm by means of dynamic - code radio controls.
•Disablement of the sensor transducer and / or external sensor.
•Panic alarm.
•Volumetric protection of the vehicle’s interior by ultrasonic sensor not requiring sensitivity
adjustment.
•Perimetric protection. When the alarm is armed, after 25 s the siren will sound if a door
or the bonnet or boot is opened.
•Protection of start attempts. With the alarm connected the engine is blocked and a start
attempt generates an alarm.
•When an alarm occurs the siren sounds for 30 s. The direction lamps flash.
•Emergency disarming by Pin - Code.
•Wire - cutting protection.
•Original centralised door and boot closing system.
•LED indicating the system’s status with alarm - record memory function.
•Safety circuit to prevent the system being armed when the engine is running.
•Coupling of modules / siren 4310 / satellite alarm ICD31 on Cobra Bus line.

COMPLETE INSTRUCTIONS G100
40
5.2 - List of basic functions (programmable).
These are the functions that require programming in keeping with the vehicle model and
desired operating characteristics of the alarm system. Please refer to the basic functions
table in the programming tables section.
•Centralised closing times.
•Controlled comfort window closing.
•Silent arming.
•Armed / disarmed blinker
•Open door/ bonnet / boot signal.
•Automaticsystem arming.
•Automatic start prevention arming (starter).
•Start prevention alarm.
•Perimetrical input polarity selection procedure.
5.3 - List of advanced functions (programmable).
These are special functions that require programming in keeping with the desired operating
characteristics of the alarm system. Please refer to the advanced functions table in the
programming tables section.
•Autolock - Automatic door locking.
•Autolock - AMERICAN STYLE.
•AutoHazard (switching on indicator lights in the case of emergency braking).
•Door closing by anti - diversion alarm.
•Car Finder.
•Trunk Release (truck opening).
•Automatic anti Hi - Jack protection.
•· Voluntary anti Hi - Jack protection.
•Anti Hi - Jack protection delay with odometer.
•Pager output.
•Anti - diversion blocker.
•Anti - diversion alarm.
•Buzzer.
•Speed limit signal.

COMPLETE INSTRUCTIONS G100
41
B
A
B
A
B
A
6 - LIST OF STANDARD FUNCTIONS G100 (not programmable).
RADIOCONTROL BUTTON FUNCTIONS.
Button A This button arms the alarm and blocker system, deactivates
the volumentric input and additional sensors input, activates
the panic option, gives access to the programming function,
selects the line and raises the buzzer volume in the
programming table, and activates the Car Finder option.
Button B This button deactivates the alarm, block system,
activates / deactivates the function and lowers the
buzzer volume.
6.1 - Arming.
•When radiocontrol button “A” is pressed, the doors lock (if the
vehicle is equipped with a centralized locking system).
•The direction lights flash twice.
•The buzzer emits two acoustic signals (if enabled).
•The protection functions activate after 25 s.
•The LED lights up and stays on for 25 s, then flashes.
6.2 - Silent arming.
For temporary elimination of the buzzer signal when arming the system, press radiocontrol
button “A” before turning off the ignition.The next time it is armed, the buzzer will start
working again.

COMPLETE INSTRUCTIONS G100
42
6.3 - Disarming.
•When radiocontrol button “B” is pressed, the doors unlock.
•The direction lights flash once.
•The buzzer emits one acoustic signal (if enabled).
•The protection functions are immediately deactivated.
•The LED is switched off.
6.4 - Interrupting an alarm during the warning-signal cycle.
While the system is sounding the alarm it is possible to deactive the siren
and flashing lights by pressing radio control button “B” once (one press).
This operation interrupts the alarm cycle, but the system stays armed. To
deactivate the system completely, it is necessary to disarm it by pressing
radiocontrol button “B” again (two presses).
RADIOCONTRO FUNCTIONS Button
AButton B
Arming

Disarming

Interrupt alarm
Panic alarm

Deactivate ultrasonic volumetric
sensor and additional sensor
(if installed)

Car finder


B
A
B
A

COMPLETE INSTRUCTIONS G100
43
B
A
6.5 - Deactivating the ultrasonic volumetric sensor.
If you wish to activate the protection system with the windows left open or when a
passenger will be staying inside the passenger compartment, it is possible to deactivate
the volumetric sensor so that it will not generate any alarms.
1) Activate the system by pressing radiocontrol button “A”.
2) Press radiocontrol button “A” again within 25 s.
If a hyperfrequency or anti - lifting sensor is installed, it is possible to disable it by
pressing button “A” twice within 25 s. The reception of the signal is confirmed by one
flash of the direction indicators and by an acoustic signal from the buzzer (if enabled).
The sensor has been disabled; all the other protection functions remain active. The
sensors will be automatically reactivated the next time the system is armed.
6.6 - Panic Alarm.
Whenever you press radiocontrol button “A”, provided 25 s have elapsed after arming the
system, it will produce an alarm cycle (siren sound and flashing direction lamps). If the
Car Finder function is enabled, press radiocontrol button “A” twice (2 consecutive presses).
To stop the panic alarm, press radiocontrol button “B”.
6.7 - Protection functions.
When the system is armed, opening the bonnet / boot / door or attempting to start the
vehicle generates an acoustic and visual alarm cycle that lasts approximately 30 s. In
products that include a volumetric sensor, the alarm will be triggered off by intrusion into
the passenger compartment. At the cycle’s end the system stays armed.
6.8 - Alarm record.
If any alarms have occurred during your absence, the direction lamps and buzzer will
emit their signals 5 times instead of once.

COMPLETE INSTRUCTIONS G100
44
6.9 - Coupling of modules / siren 4310 / satellite alarm ICD31 engine imobiliser
8509 on Cobra Bus line.
On the Cobra Bus line (pin 14) it is possible to connect the following additional modules
(Siren 4310 / anti - lifting module / satellite alarm ICD 31 / Engine lock 8509) by means of
the following programming procedure:
1. Disconnect system.
2. Enter programming mode using the dedicated procedure for the product.
3. Move from page 1 to page 6 by activating and de - activating the panel (+15 ON /
OFF).
4. The storage and completion of programming is signalled by flashing indicator
lights.
Repeat from point 1 if a module of the Cobra Bus line is disconnected.
NOTE: with the alarm disconnected, disconnecting a self learning
module from the Cobra Bus line, when the G100 is armed the indicator
lights will flash 8 times and if the Buzzer is activated it will signal 8
times by the buzzer.
ATTENTION!
If both radiocontrol devices have been lost, proceed as follows:
A. Disarm the system by keying in the Pin Code.
B. Cut off the system’s power feed (disconnnect the connector from the central
unit).
C. Open a door and the vehicle’s bonnet.
D. Turn on the ignition.
E. Reconnect the power feed.
F. Key in the Pin Code.
G. The LED will confirm with a long flash that the code you have entered is correct.
H. After about 5 s the LED will light up with a steady light and by 5 flashes from the
direction indicators to signal that you have entered the self-learning procedure.
I. Ref. subsection 16 point 7 page 58 of the procedure for adding on new radiocontrol
devices for all the transmitters to be enabled.
NOTE: when a new remote control is coupled, the system automatically
prevents use of the previous ones. They can only be used if they are re -
enabled through the self - learning procedure.The system can memorize up
to a maximum of 4 radiocontrol devices.

COMPLETE INSTRUCTIONS G100
45
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
7 - LIST OF BASIC FUNCTIONS G100.
As the functional characteristics of this system can be personalised, the installer will
have clearly marked in this manual which of them are enabled. The standard factory
setting is the one indicated by a dark square.
7.1 •Controlled comfort window closing.
When arming, if radio control button “A” is kept pressed down the windows close in
controlled comfort mode. This makes it possible to stop the window rising by releasing the
button.
7.2 •Window control delay activation.
If radiocontrol window output is enabled, when this function is activated the windows
will rise with a delay of 1 s after closing the doors.
7.3 •Silent arming.
For temporary elimination of the buzzer signal when arming the system, press radiocontrol
button “A” before turning OFF the ignition. The next time it is armed, the buzzer will start
working again.
7.4 •Armed / Disarmed blinker.
The system signals it has been armed with two blinks of the direction lamps, and signals
that it has been disarmed with one blink. If this function is disabled, the direction lamps
blink only when an alarm cycle is triggered.
7.5 •Automatic system arming.
Once the ignition key has been turned OFF and the last door is closed a 20 s countdown
starts, at the end of which the system is automatically armed without locking the doors.
7.6•Automatic engine cut-off .
The engine block is automatically activated 2min. after the ignition key has been turned
OFF. The LED will flash. The engine cannot be started up now; to disarm the system it is
necessary to press radio control button “B”.
Enabled Disabled

COMPLETE INSTRUCTIONS G100
46
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
7.7 •Engine cut-off alarm.
This allows the alarm function to be added to the automatic engine cut - OFF function
when armed. After 20 s have passed, once the engine cut - OFF function is activated,
turning ON the ignition generates an alarm.
7.8 •Open door/bonnet/boot warning signal.
When armed, the system emits signals consisting of buzzing and blinking (5 blinks instead
of 2) if any doors and / or the bonnet or boot are open. If it is closed within 25 s, the
system will continue to monitor their status and will signal again if another door / bonnet
/ boot opening occurs later. If the 25 s elapse and the door / bonnet / boot has not yet been
closed, the system will not monitor their status until another closing / opening operation
occurs that triggers an alarm.
7.9 •Autohazard (switching on indicator lights in the case of emergency
braking).
If activated, the system turns on the four hazard lights if the vehicle’s speed drops by
50% in one s.
8 - LIST OF ADVANCED FUNCTIONS G100 (programmable).
8.1 •Select automatic door lock mode.
This makes it possible to have the doors close automatically at a pre - set speed or within
20 s after the ignition key is turned ON. In this case the doors are automatically unlocked
when the ignition key is turned OFF.
8.2 •Autodoor lock (AMERICAN STYLE).
If the American Style closing is activated, ref. Section “Programming closing times”. To
correctly carry out the function, activate also line 4 page 2 in the programming tables. In
this way when the ingnition key is switched OFF, the driver door will be unlocked.
8.3 •Anti - diversion allarm door closing.
This function adds door - closing to the anti - diversion alarm procedure.
Disabled
Enabled

COMPLETE INSTRUCTIONS G100
47
8.4 •Car Finder.
This function will allow you to find where your car is, e.g. in a parking lot. With the alarm
system armed and once the inhibition time has elapsed, when radiocontrol button “A” is
pressed the system generates a visual alarm by activating the blinkers (and the buzzer
too, if enabled) for a maximum of 10 s. The Car Finder function can be used only when the
system is armed.
8.5 •Automatic anti - HiJack.
With this mode, the user of the vehicle must be recognised before the vehicle is started.
In order to be recognised it is necessary to enter the first 2 digits of the Pin Code, or the
optional Driver Card signal must be recognised (if self-learned), within 25 s from switching
the ignition key. The recognition is confirmed by flashing of the LED.
This enables normal use of the vehicle until the ignition key is next switched OFF; if the
ignition key is switched OFF after being recognised, there are 7 s within which to switch
ON the ignition key again without the need to be recognised. If there is no recognition, the
remote controls are no longer working and after 4 min. a 4 min. alarm cycle is generated.
As soon as the alarm cycle is elapsed and after 25 s the ignition key has been turn off the
alarm system and engine immobiliser will arm again. To disarm the system, it is necessary
to enter the full Pin Code.
8.6 •Voluntary anti - Hijack.
In this mode the vehicle user voluntarily activates the function by pressing button “B” on
the remote control with the ignition key switched ON. The activated status is confirmed by
fast flashing of the LED; it is possible to deactivate the function by pressing button “A” on
the remote control.
If you open a door, the LED stops flashing and after 4 min., a 4 min. alarm cycle is
generated; to avoid this situation, the driver must be recognised by digiting the first two
digits of the Pin Code.
As soon as the alarm cycle is elapsed and after 25 s the ignition key has been turn off the
alarm system and the engine immobiliser will arm again. To disarm the system, it is necessary
to enter the full Pin Code.
When the system goes in alarm, the siren will sound for 30 s and the direction indicators
will flash for 4 min.; instead, if the loudspeaker or the horn have been connected, a visual
and acoustic signalling alarm will be emitted for 4 min..
8.7 • Speed limit signal.
If activated, the system signals that the speed limit has been exceeded by means of a
buzzer. In order to store the speed limit, press button “A” on the remote control when the
vehicle is travelling at the desired speed. To deactivate the function, press button “A” on
the remote control once whilst the vehicle is moving.
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled

COMPLETE INSTRUCTIONS G100
48
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
8.8 •Trunk Release (truck opening)
If the Trunk Release function is activated, with the pressure of both radio control keys to
“A” and “B” one has the trunk opening. This is signalled by a 4 s flashing of the indicator
lights, and the automatic exclusion of the internal and door ultrasound devices, and the
additional modules, too, if they are connected. When the trunk is closed the system
automatically reactivates.
8.9 • Automatic anti - theft protection delay with odometer.
If the theft protection function is controlled by a movement sensor (page 4 line 6 active in
the programming tables), at a speed other than 0, there is a delay of 4 min.; if the vehicle
stops this calculation is suspended. A cyclic sequence of alarms is generated after 4 min.
which last 4 min.. Enter the full Pin Code at this point to be recognised.
8.10 • Pager.
Negative command to control a Pager module.
8.11 •Anti - diversion block.
After the system has been disarmed by radiocontrol, if the ignition key is not turned ON
within 40 s the block is automatically rearmed.
8.12 •Anti - diversion alarm.
After the system has been disarmed by radiocontrol, if the ignition is not turned on within
40 s the system is automatically rearmed. If a door or the boot are opened, the count -
down is cancelled.
8.13 •Buzzer.
The buzzer emits acoustic signals synchronized with the blinking of the direction
lamps when the system is armed / disarmed.
Disabled
Enabled

COMPLETE INSTRUCTIONS G100
49
K.O.
O.K.
1
2
3
4
Ø 3 mm.
9 - POSITIONING THE SYSTEM’S COMPONENTS.
All system components must be positioned in places that are not readily accessible and
are not close to sources of heat.
9.1 - Alarm Central Unit.
To be fixed in place inside the passenger compartment using the bi - adhesive provided in
the kit, making sure that the main connector faces downwards.
9.2 - Siren with backup
battery.
To be fixed in place inside the
engine compartment, making sure
that it is positioned so as to face
in the direction indicated.
9.3 - Siren without backup battery.
To be fixed in place inside the engine compartment, making
sure it is fastened with the screws provided for this purpose
to a metal surface that allows the heat from the magnet to
disperse.

COMPLETE INSTRUCTIONS G100
50
9.4 - Ultrasonic volumetric sensor (if foreseen).
The sensor heads can be installed on the upper part of the front windshield or back
window side - columns, making sure that they are not covered when the sun - shield
flaps are lowered. Check that the heads are correctly oriented when you perform the
functional test on the system. The type of sensor used in this alarm system does not
require any adjustment. It is suitable for vehicles of all types regardless of the dimensions
of their passenger compartment.
231
9.5 - Bonnet button.
The installation of this button is indispensable to protect the bonnet and to allow access
to the alarm programming and Driver Card self-learning procedures.
When installation is completed, check that the button is pressed by the bonnet to the
extent of at least 5 mm. Check that the button does not press on the sound-absorbing
panels or the outer bodywork plate - metal, as these materials could beome dented with
the passing of time.
9.6 - Antenna.
The correct positioning of the antenna is essential for the proper operation of the
radiocontrols. The cable must not be cut, rolled up, or connected to another cable or to the
bodywork and must be kept separate from the wiring harness. Position the antenna so
that it is at least 20 mm away from metal parts.
9.7 - Emergency Panel.
To be installed on the dashboard in a position that also ensures that the button can be
reached and the LED can be seen by the user, as in addition to its deterrent function the
panel (LED + button) is used during programming operations and in the user recognition.

COMPLETE INSTRUCTIONS G100
51
10 - VEHICLE SPEED SENSOR CONNECTION / VSS.
The VSS signal frequency is proportional to the speed of the vehicle (it is normally a
rectangular signal with f max = 4 KHz).
If the activated function requires it, the VSS signal must be connected to the PINK - BLACK
wire of the alarm. In some vehicles, the signal must be taken straight from the combined
instrument. The signal must not be taken from the ABS control system or from control
circuits as this could impair the vehicle’s safety and the way it operates.
11 - AUXILIARY OUTPUT AUX2.
It is the dedicated output for the “Pager” module connection and for the followings functions:
•Pager.
•Trunk Release.
•Windows lift closing.
•Automatic doors looking (AMERICAN STYLE).
