Cobra SPYBALL 6829 User manual

1
SPYBALL®6829 Alarm + Immobiliser
Thatcham cat. MC1
SPYBALL®6809 Alarm Upgrade
Thatcham cat. MC2>1
Meeting The British Insurance Industry’s
Criteria for Motorcycle Security
USER INSTRUCTIONS
Thank you for choosing Spyball by Cobra. We recommend you read this guide carefully
and keep it for future reference.
VEHICLE SECURITY

2
Table of contents
1.
Kit composition
2.
Features of the radio transmitter
2.1.
Realignment of a transmitter
2.2.
Pairing of new transmitters
3.
Biker Recognition function
3.1.
Selection of the Biker Recognition function
4.
Arming / disarming of the security system
4.1.
Passive arming / disarming of the engine immobiliser (applies only to model 6829)
4.1.
Arming / disarming of the full security system without Biker Recognition function
(use as a conventional transmitter)
4.2.
Arming / disarming of the full security system with Biker Recognition function
5.
Protection functions
6.
Temporary deactivation of the movement sensor
7.
Adjustment of movement detection sensitivity (this is a dealer operation)
8.
Alarm cycle
8.1.
Reduction of audible alarm power
8.2.
Check control function
9.
Alarm memory and diagnostics
10.
Anti-hijack function
11.
Back-up battery supply
12.
Service Mode
13.
“Turn indicator on” audible warning signal

3
14.
Selectable functions –Enabling and disabling procedures
15.
Automatic timed switch-off function (sleep function)
16.
Emergency disarming via PIN code
16.1.
Reading the PIN code
16.2.
Changing the PIN code
17.
Troubleshooting guide
18.
Technical data
1. KIT COMPOSITION
The kit includes
A control unit with its protective metal shield
Two remote control transmitters with Biker Recognition function
A set of fitting accessories and a wiring harness
A user manual (This is not a DIY product. Fitting instructions are available for download
from the professional installer area of the Cobra website www.cobra-at.com)
2. FEATURES OF THE RADIO TRANSMITTER
The radio transmitter (p/n 8742) has two buttons with different
functions and a small LED in the middle, that flashes during
transmission. It is protected against the use of code scanners
and grabbers.

4
It is powered by a Lithium CR 2032 3V-battery. When the battery is close to flat, the user is
warned by an additional flash of the turn indicators upon disarming.
Replace it as soon as possible and dispose of it at the appropriate collection points. Do not
delay the replacement of the battery, especially if you are using the Biker Recognition function,
because the system activates automatically when it does not receive any signals from the
transmitter!
Remark: to ensure good contact, take the new battery out of its packaging and place it into the
transmitter without touching it directly with your fingers (use a soft cloth).
2.1.Realignment of a transmitter
The transmitters that come with the kit are paired in advance and are already operational.
Realignment is needed when a paired transmitter is de-synchronised from the receiver.
This can happen if for example the transmitter is operated repeatedly outside the range of the
receiver because the transmitted code changes every time the alarm is turned on/off thanks to
an advanced method of random encryption (anti-scanning / anti-grabbing protection).
To realign, just press and hold down push-button n. 1 of the transmitter for at least 7 seconds.
A sequence of flashes of the turn indicators will confirm the success of realignment. If the
system is armed, it will disarm.
2.2. Pairing of new transmitters
In the event of loss of failure, one or two new transmitters can be paired as follows:
If the security system is armed, disarm it with the remaining transmitter (if it is available)
or enter your emergency disarming PIN code (see procedure in paragraph 16).

5
Turn ignition on and wait 20 seconds. The dashboard LED illuminates and remains
on about 3 seconds.
Before the dashboard LED extinguishes, turn ignition off and then on again. A short
and sharp sound signal confirms that the system is ready for pairing. The LED switches
off. You have 6 seconds to complete the operation as described below.
Press push-button n. 1 of a transmitter (or press both transmitters in turn, if you want to
pair two).The LED illuminates shortly, to confirm that pairing has been successful.
Once the operation is completed, turn the ignition off. If the ignition remains on, the
system will automatically quit the pairing procedure In both cases the exit from the
procedure is confirmed by a short sharp audible signal.
Important:
1) For security reasons, each system can accept a maximum of two remote
transmitters.
2) Every pairing procedure disables the transmitters which the receiver had previously
been paired with. Therefore: if you have lost a transmitter and you wish to pair a
spare one, do not forget that the one which has remained in your possession has to
be re-paired too (or it will stop working). If you are not able to acquire a replacement
transmitter quickly, then simply repeat the process to re-pair your existing
transmitter, and this will disable the missing transmitter.

6
3. BIKER RECOGNITION FUNCTION
Besides its operation as a conventional remote control key, the transmitter can be used in
Biker Recognition mode.This function is selectable.
When the Biker Recognition function is enabled, the transmitter sends a coded signal at
regular intervals (1.5 secs). The small LED on the transmitter flashes at the same rate. In this
configuration the full security system (6829 = immobiliser + alarm, 6809 = alarm) activates
automatically as the transmitter goes beyond the range of the receiver, i.e when the biker
walks more than approximately 3 metres away from the parked motorcycle with the transmitter
in his/her pocket. Similarly, it deactivates when the biker returns to his/her vehicle and the
transmitter signal reaches the receiver. For more details regarding arming and disarming in
Biker Recognition mode, please see also the information provided in the paragraphs below.
3.1. Selection of the Biker Recognition function
This selection needs to be made on both the control unit and the transmitter.
For the setting of the control unit, please refer to the chart included in paragraph 14, which
provides general information about the possible configurations of the system (5 selectable
functions).
Additionally, the Biker Recognition function needs to be activated/deactivated via the
transmitter:
To activate, press and hold down both push-buttons at the same time until the small LED
located on the transmitter starts to flash quickly for about 2 seconds. (*)
To deactivate, press and hold down both buttons until you get a long flash from the LED (*).

7
If you expect to leave this function unused for a long time, you are strongly recommended to at
least deactivate it from the transmitter, because this reduces the battery drain considerably
and prolongs the life of the battery.
(*): to avoid accidental arming (which may occur if the two buttons are not pressed exactly at
the same time), carry out this operation at a distance from the motorcycle, beyond the range of
the receiver.
4. ARMING / DISARMING OF THE SECURITY SYSTEM
4.1. Passive arming / disarming of the engine immobiliser (applies only to
model 6829*)
To conform with the British Insurance Industry’s Criteria for cat. MC1 security systems, the
immobiliser section always activates automatically 27 secs after the motorcycle’s ignition
has been turned off, whether the full system is activated or not. This is confirmed by a short
flash of the turn indicators.
To disarm the engine immobiliser, turn the ignition on, wait for the LED to start flashing
quickly, then press push-button n. 1 of the transmitter (there is no need to press the button if
the Biker Recognition function is activated). Disarming is confirmed by a long flash of the turn
indicators.
(*): The 6809 has no immobiliser function. It is a Thatcham cat. MC2 1 alarm upgrade,
intended for fitment to motorcycles pre-equipped with a cat. 2 immobiliser.

8
4.2. Arming / disarming of the full security system without Biker Recognition
function (use as a conventional transmitter)
To activate the full system (6829 = immobiliser + alarm, 6809 = alarm), press push-button n. 1
of the transmitter once. This can be done also if the immobiliser has already armed passively
(Spyball 6829).
Arming is confirmed by:
Three short flashes of the turn indicators.
Three sharp sound signals (if this function is enabled –see paragraph 14) (*)
The dashboard LED lights up.
The LED permanently illuminates for about 60 seconds. This is the arming period, which
allows for the stabilisation of the control unit (first 25 seconds) and for subsequent testing of
the functions (35 secs) –see paragraph 8.2., “Check control function”.
Once this period has elapsed, the LED starts flashing to indicate that the system is fully active.
The immobiliser is already operational during the arming period.
To deactivate the full system (6829 = immobiliser + alarm, 6809 = alarm), press push-button n.
1 of the transmitter once.
Disarming is confirmed by:
A long flash of the turn indicators (**)
A deep sound signal (if this function is enabled –see paragraph 14)
The dashboard LED extinguishes.
If disarming is not followed by starting the vehicle, the immobiliser will re-arm as described in
paragraph 4.1 (Spyball 6829).

9
(*) Three additional sound signals in quick succession indicate that there is an irregularity in
peripheral protection (e.g. the seat is open, the side stand is up), which will be disabled during
that arming period.
(**) A short additional flash indicates that the battery is low and needs replacement.
4.2. Arming/disarming of the full security system with Biker Recognition
function
Once the ignition is turned off, the full security system (6829 = immobiliser + alarm, 6809 =
alarm) activates automatically within 21 seconds of the transmitter leaving the operating
range of the receiver (about 3 meters). If the immobiliser has already armed passively (Spyball
6829), it is followed by the activation of the alarm section.
Arming is confirmed by:
Three short flashes of the turn indicators.
Three sharp sound signals (if this function is enabled –see paragraph 14) (*)
The dashboard LED lights up.
The LED remains permanently illuminated for approximately 25 seconds. This is the short
arming period, which the unit needs to stabilise. Once this period has elapsed, the LED starts
flashing, to indicate that the system is fully active. The immobiliser (Spyball 6829) is already
operational during the arming period.

10
If the Biker Recognition function is activated, the disarming of the alarm section is also
automatic as the biker returns to the protected vehicle and the transmitter signal reaches the
operating range of the receiver. For security reasons the immobiliser remains on and can be
deactivated only following the procedure described at paragraph 4.1. (Spyball 6829).
The disarming of the alarm section is confirmed by:
A long flash of the turn indicators (**)
A deep audible tone (if this function is enabled –see paragraph 14)
The dashboard LED extinguishes.
(*) Three additional sound signals in quick succession indicate that there is an irregularity in
peripheral protection (e.g. the seat is open, the side stand is up), which will be disabled during
that arming period.
(**) A short additional flash indicates that the battery is getting low and needs replacing.
5. PROTECTION FUNCTIONS
Dual engine immobilisation (Spyball 6829). Twenty-seven seconds after the ignition has
been turned off, the immobiliser activates automatically and inhibits two vital circuits of the
motorcycle’s electrical system. Starting becomes impossible. This function prevents the
motorcycle from being driven under its own power by an unauthorised person.
Peripheral protection. The system has a negative instantaneous alarm trigger input for
contact switches (not supplied). These can be fitted to for example the seat or the topcase.
Any attempt to gain access to the protected area will trigger the alarm. The trigger polarity is
selectable (positive or negative), so that the storage compartment under the seat can be also
protected by sensing the positive signal that controls the illumination of the courtesy light.

11
Movement detection. Triggers the alarm in the event of for example lifting, towing, forcing the
steering lock by means of a revolutionary sensor (Spyball®patent) that detects changes in the
motorcycle’s position over 360 degrees.
Ignition lock tamper protection. Triggers the alarm if the ignition is turned on while the
system is armed.
Anti-sabotage protection (see also paragraph 11). In the event that the normal power
supply is interrupted (for example if the cables of the motorcycle battery are cut), the
integrated back-up battery allows the alarm system to sound (if armed) and signal sabotage.
6. TEMPORARY DEACTIVATION OF THE MOVEMENT SENSOR
The system can be armed without activating the movement sensor.
This facility may be useful to prevent a false alarm when anti-theft protection is required but
the motorcycle is subject to movement (for example on a ferry).
Procedure:
Press push-button n. 1 to arm the system.
Within 25 seconds press push-button n. 2.
A sharp audible signal will confirm that the sensor has been deactivated.
The cancellation is temporary and is valid for an arming period only. The movement detection
function is reinstated the next time the system is armed.

12
7. ADJUSTMENT OF MOVEMENT DETECTION SENSITIVITY (this is a dealer
operation)
The movement detector can be adjusted to 8 different levels of sensitivity to displacement
and 8 different levels of sensitivity to shock. The detector is fine-tuned for optimal
performance by the dealer upon installation. Please consult your dealer if you require a
different setting.
8. ALARM CYCLE
Any irregularity that is detected by:
-the peripheral protection circuit (e.g. the opening of a protected storage compartment or
case)
-the movement sensor (e.g. an attempt to drag the motorcycle away)
-the ignition lock tamper protection circuit (e.g. an attempt to force the lock)
generates a 30-sec. alarm cycle.
The alarm condition is signalled by the 114dB piezoelectric siren that is integrated within the
device (sound warning) as well as by the flashing of the turn indicators (visual warning).
After that the device automatically returns to the set condition.
During the alarm condition pressing the remote control button n. 1 once will simply silence the
siren and stop the indicators, leaving the system armed and ready to detect further
irregularities. To disarm the system, press the push-button twice.
For environmental protection, the alarm cycles in an activation period are limited to a
maximum of 10/sensor trigger input.

13
8.1. Reduction of audible alarm power
The volume level of the alarm can be reduced when the motorcycle is parked in areas where
noise pollution needs to be minimised. When arming, keep push-button n. 1 of the transmitter
pressed for about 7 seconds. Upon arming, keep push-button n. 1 pressed for about 7
seconds. The reduction of the sound power is confirmed by two deep short audible signals.
This setting is valid for one arming period only.
8.2. Check control function
During the arming time the protection functions of the system can be tested without generating
an alarm cycle.
Arm the system, wait 25 seconds to allow for stabilisation, then test the protection functions as
appropriate during the remaining 40 seconds:
a) If the instantaneous alarm trigger input has been used to protect a case or the storage
compartment under the seat, simulate the removal / opening. If the simulation is
detected correctly, it is signalled by sharp audible signals.
b) Test the movement sensor, by e.g. simulating an attempt to force the steering lock,
dragging the motorcycle or tilting it up from the side-stand to vertical. If the simulation
is detected correctly, it is signalled by sharp audible signals. If required, adjust sensitivity.
c) Turn ignition on. If the ignition lock tamper protection circuit works properly, you will
hear a sequence of sharp audible signals.

14
9. ALARM MEMORY AND DIAGNOSTICS
If the security system has been triggered during your absence, upon disarming you will be
warned by different audible signals, depending of the nature of the alarm cause:
a) 1 audible signal = tampering with the ignition lock, unauthorised access to a
protected compartment / case (instantaneous trigger input), cut of power supply
b) 2 audible signals = lifting or dragging the motorcycle
c) 3 audible signals = a + b
The warning signal remains stored until the end of the inhibition time (60 secs) that follows the
subsequent arming.
10. ANTI-HIJACK FUNCTION
This function has been designed in response to the fast growing phenomenon of vehicle hi-
jacking, typically while the driver is waiting before a stop sign or at traffic lights.
The system switches to anti-hijack mode if the stolen motorcycle is running and the victim of
the seizure is still in possession of the remote control transmitter with enabled Biker
Recognition function.
After the coded signal from the transmitter has been absent for 2 minutes, the siren starts to
sound –firstly at low volume rising to full volume –and the turn indicators flash in an
uninterrupted sequence of alarm cycles. When the motorcycle ignition is turned off, the
complete security system arms itself automatically and engine starting becomes impossible.
Disarming is only possible via the remote control or the emergency disarming PIN code.

15
Remark: the same will happen if you leave the range of the transmitter while the
ignition of your motorcycle is on.
Important: To benefit from this functionality, remember to ALWAYS keep the transmitter
on your person in a pocket or wallet. NEVER attach it to the ignition key of the
motorcycle!
This function is also selectable and can be enabled or disabled as chosen by the user. Please
refer to the table included in paragraph 14, which provides general information about the
possible configurations of the system (5 selectable functions).
11. BACK-UP BATTERY SUPPLY
The 6829 is equipped with internal Ni-MH back-up batteries that are automatically recharged
when the motorcycle is driven. In the event that normal power supply is interrupted (e.g. in the
event that the cables of the motorcycle battery are cut), the integrated back-up battery will
allow the alarm system to sound (if armed) and will signal any sabotage.
When the power supply is reinstated, the system sets itself to the same status
(armed/disarmed) as it was before the interruption.
12. SERVICE MODE
If you are using the transmitter in Biker Recognition mode and you need to have your
motorcycle serviced but you prefer not to leave the transmitter with it, this quicker procedure

16
will allow you to temporarily disable automatic arming / disarming and the anti-hijack function
without entering the selection procedure (Service set-up).
Disarm the system via the emergency disarming PIN code (see paragraph16). The system
sets itself to service mode:
-The Biker Recognition signal is over-ridden, the alarm will not activate automatically;
-The immobiliser remains active (Spyball 6829).
The Biker Recognition operation mode will be reinstated the first time push-button n. 1 is
pressed again. In the meantime you will hear four short sharp audible reminder signals every
time the ignition is turned off.
13. ”TURN INDICATOR ON” AUDIBLE WARNING SIGNAL
This ancillary function does not relate to anti-theft protection, but it can make riding easier and
safer. If you enable it, the system will remind you with audible warning signals after a turn
indicator has been flashing for more than 24 seconds.
The procedure of selection is described in paragraph 14.
14. SELECTABLE FUNCTIONS –ENABLING AND DISABLING PROCEDURES
The functions listed below are selectable and can be enabled or disabled as chosen by the
user. The set-up is stored until a different configuration is selected.
-Biker Recognition (see paragraph 3)
-On/off audible signals (see paragraph 4)
-“Turn indicator on” audible warning signal (see paragraph 13)

17
-Anti-hijack function (see paragraph 10)
-Polarity of instantaneous alarm trigger input (this selection should be set up by the
installer and must not be altered by the user once the security system has been fitted).
Procedure:
While the security system is disarmed, turn ignition on, press and hold down push-button n. 1
of the transmitter about 7 seconds, until the LED lights up, then release. The LED remains
on about 3 seconds. During this lapse of time, press push-button n. 1 again. A short
sharp audible signal confirms that the procedure has been initiated. The LED switches off, and
then provides five different visual indications that relate to the five selectable functions. Please
refer to the chart below:
VISUAL
INDICATION
SELECTABLE
FUNCTION
TO SELECT
TO DESELECT
CONFIRMATION
SIGNAL
CONFIRMATION
SIGNAL
1 flash
Biker Recognition
Press push-button n. 1 of
the transmitter after the
first flash
Three (3) sharp audible
signals follow
Press push-button n. 2 of
the transmitter after the
first flash
One (1) sharp audible
signal follows
2 flashes
Arming and disarming
audible signals
Press push-button n. 1 of
the transmitter after the
second flash
Three (3) sharp audible
signals follow
Press push-button n. 2 of
the transmitter after the
second flash
One (1) sharp audible
signal follows

18
3 flashes
“Turn indicator on” audible
warning signal
Press push-button n. 1 of
the transmitter after the
third flash
Three (3) sharp audible
signals follow
Press push-button n. 2 of
the transmitter after the
third flash
One (1) sharp audible
signal follows
4 flashes
Anti-hijack function
Press push-button n. 1 of
the transmitter after the
fourth flash
Three (3) sharp audible
signals follow
Press push-button n. 2 of
the transmitter after the
fourth flash
One (1) sharp audible
signal follows
5 flashes
Polarity of the
instantaneous alarm
trigger input (for dealer
use only)
Press push-button n. 1 of
the transmitter after the
fifth flash
Positive polarity
Press push-button n. 2 of
the transmitter after the
fifth flash
Negative polarity
Once the selections are finalised, a long low audible sound will confirm that they have been
entered successfully.
Note1): If you wish to modify any functions, you can reset them individually without needing to
reset all 5 functions.
Note 2): in the event of an error, turn ignition off to quit without making any changes.
Note 3): do not alter the polarity of the instantaneous alarm trigger input (5 flashes) as set up
by the installer, or this protection function will stop working.
Note 4): the audible on/off signals are illegal in some Countries. Please check your local
regulations and set up the system accordingly.

19
15. AUTOMATIC TIMED SWITCH-OFF FUNCTION (SLEEP FUNCTION)
Although the current consumption rate of Spyball security systems is extremely low, another
special feature has been implemented with the purpose of protecting the battery of your
motorcycle: the radio receiver that is integrated within the unit switches off automatically after
the motorcycle has been unused for 7 days and the current consumption rate drops
considerably. When it is in sleep mode, the alarm system does not therefore react to the radio
transmitter.
In order to reinstate the normal functions of the device:
If the system is disarmed, turn ignition on;
If the system is armed, turn ignition on and press push-button n. 1.
If the transmitter is not available, enter the emergency disarming pin code as
described in paragraph 16. If turning the ignition on is not followed by pressing the
transmitter on/off button or the pin code is not entered correctly, the siren will sound.
16. EMERGENCY DISARMING VIA PIN CODE
In the event of loss or failure of the radio remote control, you can deactivate the security
system by means of the procedure below, using the PIN code you can find on the last page of
this manual or the replacement code that you may have entered (see paragraph 16.2.). The
final page of this manual includes also a quick description of the disarming procedure; we
recommend that you record the PIN code there, then cut out the card and keep it in your wallet
for future reference.

20
If the full system is armed:
1. Turn ignition on. The alarm starts to sound.
2. Wait. The alarm stops. The LED switches off, then it starts to flash slowly.
3. Count the number of flashes. As soon as the number of flashes equals the first number of
your PIN code, turn the ignition off (for example, if the first number of your code is 3, then
wait for the LED to flash 3 times before turning the ignition OFF). The LED switches
off.
4. Within three seconds, turn the ignition on again. Count the number of flashes. As soon as
the number of flashes equals the second number of your PIN code, turn the ignition off
(for example, if the second number of your code is 10, then wait for the LED to flash ten
times before turning the ignition OFF). The LED switches off.
5. Enter the remaining numbers of the PIN code using the same procedure. In the event
of an error, an alarm cycle will follow. At the end of the alarm cycle you will be able to
repeat the procedure.
ONCE ALL THE DIGITS HAVE BEEN ENTERED CORRECTLY, THE SYSTEM DISARMS
WITH A LONG BLEEP AND THEN SWITCHES TO SERVICE MODE (see paragraph 12).
If only the immobiliser is armed (Spyball 6829):
1. Turn ignition on. The LED flashes quickly for 12 secs.
2. Wait. The LED switches off, then it starts to flash slowly.
3. Enter the digits of the PIN code using the same procedure as described above. In the
event of an error entering the first two digits, the LED will start to flash quickly. Turn the
ignition on and repeat the procedure.
