Cocraft PRO DT800-P User manual

ENGLISHSVENSKANORSKSUOMIDEUTSCH
Important!
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the
equipment. Keep the manual for future
reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre
deg om at du forstår dem, før du tar
produktet i bruk. Ta vare på anvisningene
til senere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin
alat käyttää laitetta. Säilytä ohjeet
myöhempää tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung sorgfältig
durchlesen und aufbewahren.
PROEDITION
Ver. 20160510
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung
Art.no Model
40-9912 PRO DT800-P
PRO DT800-P
DISTANCE METER
40-9912
AVSTÅNDSMÄTARE
AVSTANDSMÅLER
ETÄISYYSMITTARI
ENTFERNUNGSMESSER
80 M

ENGLISH
3
Laser Distance Meter
Art.no: 40-9912 Model: PRO DT800-P
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
Theperson responsible for theinstrument must ensure that all users understand these
directions and adhere to them.
Areas of responsibility
Responsibilities of the manufacturer
Themanufacturer is responsible for supplying theproduct, including theUser Manual
in acompletely safe condition.
Themanufacturer is not responsible for third party accessories.
Responsibilities of the person in charge of the instrument
• To understand thesafety instructions on theproduct and theinstructions in
theUser Manual.
• To be familiar with local safety regulations relating to accident prevention.
• Always prevent access to theproduct by unauthorised personnel.
Permitted use
• Measuring distances.
Prohibited use
• Using theproduct without instruction.
• Using outside thestated limits.
• Deactivation of safety systems and removal of explanatory and hazard labels.
• Opening of theequipment by using tools (screwdrivers, etc.).
• Carrying out modification or conversion of theproduct.
• Use of accessories from other manufacturers without express approval.
• Deliberate dazzling of third parties; also in thedark.
• Inadequate safeguards at thesurveying site (e.g. when measuring on roads,
construction sites, etc.).
• Deliberate or irresponsible behaviour on scaffolding, when using ladders, when
measuring near machines which are running or near parts of machines or
installations which are unprotected.
• Aiming directly in thesun.

ENGLISH
4
Hazards in use
WARNING! Watch out for erroneous measurements if theinstrument is defective
or if it has been dropped or has been misused or modified. Carry out periodic test
measurements. Particularly after theinstrument has been subject to abnormal use,
and before, during and after important measurements.
CAUTION! Never attempt to repair theproduct yourself. In case of damage,
contact alocal dealer.
WARNING! Changes or modifications not expressly approved could void
theuser’s authority to operate theequipment.
Limits of use
Refer to section Specifications in theInstruction manual. Thedevice is designed for
use in areas permanently habitable by humans. Do not use theproduct in explosion
hazardous areas or in aggressive environments.
Disposal
CAUTION! Flat batteries must not be disposed of with household waste. Care for
theenvironment and take them to thecollection points provided in accordance with
national or local regulations.
Theproduct must not be disposed with household waste.
Dispose of theproduct appropriately in accordance with thenational regulations in
force in your country.
Adhere to thenational and country specific regulations.
Product specific treatment and waste management can be downloaded from our homepage.
Electromagnetic Compatibility (EMC)
WARNING! Thedevice conforms to themost stringent requirements of therelevant
standards and regulations. Yet, thepossibility of causing interference in other devices
cannot be totally excluded. FCC statement (applicable in U.S.) This equipment
has been tested and found to comply with thelimits for aClass B digital device,
pursuant to part 15 of theFCC Rules. These limits are designed to provide reasonable
protection against harmful interference in aresidential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with theinstructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in aparticular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning theequipment off
and on, theuser is encouraged to try to correct theinterference by one or more of
thefollowing measures:
• Reorient or relocate thereceiving antenna. Increase theseparation between
theequipment and receiver.

ENGLISH
5
• Connect theequipment into anoutlet on acircuit different from that to which
thereceiver is connected.
• Consult thedealer or anexperienced radio/TV technician for help.
Laser classication
Thedevice produces visible laser beams, which are emitted from theinstrument:
It is aClass 2 laser product in accordance with:
• IEC60825-1 : 2014 “Radiation safety of laser products”
Laser Class 2 products
Do not stare into thelaser beam or direct it towards other people unnecessarily.
Eye protection is normally afforded by aversion responses including theblink reflex.
WARNING! Looking directly into thebeam with optical aids (e.g. binoculars,
telescopes) can be hazardous.
CAUTION! Looking into thelaser beam may be hazardous to theeyes.
For technical information for laser and labelling please check theuser manual.
Care
• Clean thedevice with adamp, soft cloth.
• Never immerse thedevice in water.
• Never use aggressive cleaning agents or solvents.

ENGLISH
6
Laser classication
This meter produces avisible laser beam from
thefront of theinstrument: it is aClass 2 laser
in accordance with: IEC60825-1 : 2014 Safety
of laser products.
Laser class 2 products
Do not stare into thelaser beam or direct it towards other people or animals.
Risk of serious damage to eyes.
Warning! Do not look directly into thebeam with optical aids such as
binoculars or telescopes. Risk of serious damage to eyes.
Product safety symbols
Read theentire instruction manual.
Laser class 2
Description Value
Maximum peak radiant output power 0.95 mW
Wavelength 635 nm
Pulse duration > 400 ps
Pulse repetition frequency 320 MHz
Beam divergence 0.16×0.6 mrad
• Make sure not to remove or damage thesafety symbols and warnings found on
thedistance meter.
• Never try to open thehousing, repair or modify thedistance meter in any way.
• Only use accessories that are recommended by themanufacturer or retailer.
• Never use thedistance meter where flammable or explosive substances are used
or stored.
• Do not use thedistance meter on or near highly reflective surfaces since thelaser
beam can be reflected back into your own or someone else’s eyes.

ENGLISH
7
1
2
37
8
9
4
5
6
Buttons and functions
1. Display
2. Turn on thedistance meter/
perform measurement
3. Add
4. Select area, volume,
Pythagoras or stake out
5. Clear, turn off
6. Memory
7. Subtract
8. Timer
9. Select measurement
reference/ select units of
measurement
• Labelling: Subject to change
(drawings, descriptions and
technical data) without prior
notice.

ENGLISH
8
10
11
12
18
17
13
21
14 22
15 23
16 24
19
20
Display
10. Area/ volume
11. Stake out
12. Selected measurement
reference
13. Circumference
14. Wall area
15. Addition/ subtraction
16. 2nd result
17. Info
18. Battery status
19. Timer
20. Memory
21. Pythagoras
22. Max/min measurement
23. Units of measurement
24. Main line
Operating instructions
Batteries
1. Fold out themultifunctional endpiece.
2. Remove thebattery cover and
insert 2×AAA/LR03 batteries. Note
thepolarity markings on thebottom
of thebattery compartment to
ensure correct insertion.
3. Refit thebattery cover and fold
down themultifunctional endpiece.
Switching on/off, clearing and entering default operation mode
On
Press .
Off
Hold in for 2 seconds.
Note: If no key is pressed for 3 minutes, thedistance meter switches off automatically.
Clear
Press .

ENGLISH
9
Go to default operation mode
Press twice.
Message Codes
If theinfo icon (17) appears with anumber, refer to thetable below.
No. Cause Correction
156 Transverse tilt greater than 10°. Hold themeter without any transverse tilt.
162 Calibration error Make sure that themeter is placed on
anabsolutely horizontal and flat surface.
Repeat thecalibration procedure. If theerror
remains, contact our customer services.
204 Measuring error Repeat themeasurement.
252 Themeter is too hot. Let themeter cool down.
253 Themeter is too cold. Warm themeter up.
255 Thereceived signal is too weak,
measuring time too long.
Change target surface (to e.g. white paper).
256 Thereceived signal is too strong. Change target surface (to e.g. white paper).
257 Too much background light. Shade target area.
258 Measurement is outside
themeasuring range.
Move meter closer to target area.
260 Laser beam interrupted. Repeat themeasurement.
Selecting the measurement reference
Measurements can be made from thefront or rear edge of thedistance meter, from
thecentre of thetripod thread, and using themultifunctional endpiece.
1. Press to switch thedistance meter on.
2. Press to change themeasurement reference, thecurrent reference appears on
thedisplay.

ENGLISH
10
Multifunctional endpiece
Note:
• Handle with care! In order for theendpiece to be folded out straight, it needs to be
slid sideways alittle.
• Themeasurement reference is adjusted automatically when theendpiece is folded
down straight.
Units of measurement
1. Press to switch thedistance meter on.
2. Hold in for 2 seconds repeatedly to toggle between thealternative units.
Metres (m), feet (′, ft) or inches (″, in). Toggle between thefollowing options:
0.000m – 0.0000m – 0.00m – 0.00ft – 0ʹ00″1/32 – 0.00in – 0in 1/32.
Timer (time-delayed release)
1. Press to switch thedistance meter on.
2. Press to to switch thelaser beam off.
3. Press to enter thetimer mode. Thestandard setting is 5 sec; to change
thedelay (1–60 sec) press or hold in or .
4. Press to start thetimer.
Atime-delayed release is recommended for precise measurements, e.g. at long distances.
It avoids meter movement/shaking when themeasurement button is pressed.
Beep signal
1. Press to switch thedistance meter on.
2. Hold in and simultaneously for 2 sec to activate/deactivate theBeep signal.
“BEEP On” or “BEEP Off” shows on thedisplay.

ENGLISH
11
Display light (illumination)
1. Press to switch thedistance meter on.
2. Hold in and simultaneously for 2 sec to switch thedisplay light on/off.
“ILLU On” or “ILLU Off” shows on thedisplay.
Keypad lock
1. Press to switch thedistance meter on.
2. Hold in and simultaneously for 2 sec to switch thekeypad lock on/off.
“KEY LOCK On” appears on thedisplay and thedistance meter shuts off.
3. To switch thedistance meter on when thekeypad lock is on: Press ,
themessage “PRESS MINUS” will appear on thedisplay. Press within
2 sec to switch thedistance meter on.
Single distance measurement
1. Press to switch thedistance meter on.
2. Aim thelaser beam at thetarget point.
3. Press , themeasured length will appear
on thedisplay.
Continuous length measurement
1. Press to switch thedistance meter on.
2. Hold in for 2 seconds.
3. Thedistance meter measures continuously. Uses include e.g.:
- Horizontal distance measurement (min value)
- Measuring room diagonals (max values).
Place thedistance meter on atripod and rotate
it to measure from corner to corner. Add thetwo
measurements together using theaddition function
(see below).
Themaximum and minimum distances measured are displayed as “max” and “min”.
Thelast value measured is displayed on themain line.

ENGLISH
12
Adding and subtracting measurements
Addition function
1. Press to switch thedistance meter on.
2. Aim thelaser beam at thefirst target point and press to make ameasurement.
Theresult is shown on themain line.
3. Press . Thefirst measurement moves up on thedisplay and anew line with
aplus “+” appears on thedisplay.
4. Aim thelaser beam at thesecond target point and press to make
ameasurement.
5. Thenew measurement will appear on the “+” line and thesum of thetwo
measurements will appear on themain line.
Subtraction function
Refer to theabove instructions but press instead. Aline with a “−” (minus sign) will
appear on thedisplay.
Area
Note: When measuring areas, volumes, Pythagoras 2-point, Pythagoras 3-point and
Pythagoras partial height measurements, thepart of thedisplay icon which is to be
measured next will flash.
1. Press to switch thedistance meter on.
2. Press once and aim thelaser beam at thefirst target point.
3. Press . Thefirst measurement will appear on thedisplay.
4. Aim thelaser beam at thesecond target point.
5. Press . Both of themeasurements will be shown at thetop of
thedisplay and thearea will appear on theline below them.
Circumference
Hold in for 2 seconds after completion of anarea measurement. Thecircumference
of themeasured area will appear on thedisplay.

ENGLISH
13
Volume
1. Press to switch thedistance meter on.
2. Press twice and aim thelaser beam at thefirst
target point.
3. Press .
4. Aim thelaser beam at thesecond target point.
5. Press .
6. Aim thelaser beam at thethird target point.
7. Press .
8. Thevolume is shown on thebottom line of thedis-
play and thelast distance measurement is shown on
thetop line.
Circumference and wall area
Hold in for 2 seconds after completion of avolume measurement.
Thecircumference and wall area of themeasured area will appear on thedisplay.
Pythagoras measurements (indirect measurement)
• Theresult is shown on themain line and themeasured distance on theline above.
• Areduced level of accuracy, lower than thelevel of accuracy of thedistance meter
itself, must be expected when thePythagoras measuring method is used. For best
results, we recommend using atripod or themultifunctional endpiece.
• Pressing in the key for 2 seconds when using thePythagoras function,
automatically activates theminimum or maximum measurement.
Pythagoras 2-point measurement
1. Press to switch thedistance meter on.
2. Press three times and aim thelaser beam at
theupper target point.
3. Press .
4. Aim thelaser dot at thelower target point, which must
be at thelevel of (horizontal with) thedistance meter,
otherwise anincorrect measurement will be given.
5. Press .
6. Theresult is shown on thebottom line of thedisplay
and thelast distance measurement is shown on
thetop line.

ENGLISH
14
Pythagoras 3-point measurement
1. Press to switch thedistance meter on.
2. Press four times and aim thelaser beam at
theupper target point.
3. Press .
4. Aim thelaser beam at thehorizontal target point.
5. Press .
6. Aim thelaser beam at thelower target point.
7. Press .
8. Theresult is shown on thebottom line of thedisplay
and thelast distance measurement is shown on
thetop line.
Pythagoras partial height
1. Press to switch thedistance meter on.
2. Press five times and aim thelaser beam at
theupper target point.
3. Press .
4. Aim thelaser beam at thesecond target point
(partial height).
5. Press .
6. Aim thelaser beam at thelower horizontal target point.
7. Press .
8. Theresult is shown on thebottom line of thedisplay
and thelast distance measurement is shown on
thetop line.

ENGLISH
15
Stake out
1. Press to switch thedistance
meter on.
2. Press six times.
3. Set thedesired distance by pressing
or holding in or .
4. Press to confirm theset value.
5. Move themeter slowly along thestake
out line. Thedistance to thenext stake
out point will be shown.
1
2
3
Memory
Memory of thelast 20 results displayed.
1. Press .
2. Press or to browse theresults in thememory.
3. Hold in to use thevalue in themain line for further calculations.
4. Hold in and simultaneously for 2 sec to completely delete thememory.
Care and maintenance
• Clean theproduct using alightly moistened cloth. Use only mild cleaning agents,
never solvents or corrosive chemicals.
• Never immerse thedistance meter in water or other liquid.
• Whenever thedistance meter is not to be used for anextended period,
thebatteries should be removed and it should be stored in adry, dust-free
environment, out of children’s reach.
Example:
While moving the distance meter, this shows that
0.240 m is left until the next 0.625 m measuring
point is reached.

ENGLISH
16
Responsible disposal
This symbol indicates that this product should not be disposed of with
general household waste. This applies throughout theentire EU. In order
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner. When
recycling your product, take it to your local collection facility or contact
theplace of purchase. They will ensure that theproduct is disposed of in
anenvironmentally sound manner.
Specications
Batteries 2×AAA/LR03 (sold separately)
Measuring range 0.05–80m
Accuracy in
favourable conditions ±1.5mm (0.06″)
Accuracy in
unfavourable conditions ±2.5mm (0.10″)
Range in favourable conditions 80m (262 ft). Favourable conditions mean
targets that are white and diffuse reflecting
(white painted wall), low background illumination
and moderate temperatures.
Range in
unfavourable conditions 60m (197ft). Unfavourable conditions mean
targets with lower or higher reflectivity,
high background illumination or temperatures
at theupper or lower end of thespecified
temperature range.
Smallest unit displayed 0.1mm (1/32″)
Diameter of laser dot At 10m: 6mm; at 50m: 30mm; at 80m: 48mm
Laser type 635 nm, Class 2, <1mW
IP rating IP54
Automatic laser shut-off after 90 s
Automatic meter shut-off after 180 s
Operating temperature −10 to 50 °C (14–122 °F)
Storage temperature −25 to 70 °C (−13–158°F)
Size 117×57×32mm (4.6×2.4×1.3″)
Weight 0.4kg (4.9oz) (with batteries)

SVENSKA
17
Laseravståndsmätare
Art.nr 40-9912 Modell PRO DT800-P
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska
problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
Den som ansvarar för produkten måste försäkra sig om att alla användare förstår och
följer dessa föreskrifter.
Ansvarsområden
Tillverkarens ansvar
Tillverkaren ansvarar för att produkt, såväl som bruksanvisning, är hel och komplett
vid leverans.
Tillverkaren är inte ansvarig för tillbehör från annan tillverkare.
Instrumentansvariges åligganden
• Att förstå säkerhetsinstruktionerna för instrumentet och instruktionerna i bruksanvisningen.
• Att känna till lokala säkerhets- och arbetarskyddsföreskrifter.
• Att alltid se till att obehöriga inte får tillgång till instrumentet.
Tillåten användning
• Mätning av avstånd
Förbjuden användning
• Användning av instrumentet utan instruktioner.
• Användning utanför angivna gränser.
• Inaktivering av säkerhetssystem och eliminering av förklarande text eller varningsetiketter.
• Öppna instrumentet med hjälp av verktyg (t.ex. skruvmejsel).
• Modifiering eller konvertering av instrumentet.
• Användning av tillbehör från annan tillverkare utan medgivande.
• Medvetet blända annan person, även i mörker.
• Otillräckliga förebyggande säkerhetsanordningar vid uppställning av instrument
(t.ex. vid mätningar av vägar eller byggnadsplatser).
• Medveten eller oansvarig hantering på byggnadsställningar vid användning av
stege när mätning pågår i närheten av drifttagna maskiner eller nära oskyddade
maskiner eller installationer.
• Direkt inriktning mot solen.

SVENSKA
18
Risker vid användande
VARNING! Se upp för felaktiga mätningar om ett defekt instrument används,
efter ett fall eller andra otillåtna påfrestningar resp. förändringar av instrumentet.
Utför periodiska kontrollmätningar. Särskilt efter onormal påfrestning och före/efter
viktiga mätningar.
Obs! Försök inte själv att reparera instrumentet. Vänligen kontakta din
återförsäljare vid defekt instrument.
VARNING! Ändringar och modifikationer, utan användarens uttryckliga tillstånd,
kan inskränka användarens rätt att använda instrumentet.
Begränsningar i användande
Se kapitel Specifikationer i bruksanvisningen. Instrumentet är anpassat för användning
i miljö lämpad för människor. Använd inte instrumentet i aggressiv eller explosiv miljö.
Avfallshantering
Obs! Tomma batterier får inte avfallshanteras som hushållssopor. Tänk på miljön
och lämna in batterierna till närmaste återvinningsstation enligt gällande miljölagstiftning.
Instrumentet får inte avfallshanteras som hushållssopor.
Se till att instrumentet skrotas på ett sådant sätt att nationella regler efterlevs.
Följ nationella och landsspecifika regler.
Information om avfallshantering kan laddas hem från vår hemsida.
Elektromagnetisk acceptans EMV
VARNING! Instrumentet uppfyller kraven för gällande regler och normer.
Möjligheten för inverkan på annan utrustning kan trots detta inte uteslutas.
Laserklassicering
Instrumentet genererar en synlig laserstråle utgående från instrumentet:
Instrumentet motsvarar laserklass 2 enligt:
• IEC60825-1 : 2014 Lasersäkerhet
Laserklass 2-produkter
Titta inte in i laserstrålen och rikta den inte mot andra personer i onödan. Skydd av
ögat uppstår normalt genom bortvändningsreaktioner och blinkreflexen.
VARNING! Det kan vara farligt att titta in i strålen med ett optiskt instrument,
t.ex. kikare eller teleskop.
Obs! Titta inte in i laserstrålen, det kan vara farligt för ögonen. Se bruksanvisningen
för teknisk information om laser och märkning

SVENSKA
19
Avståndsmätaren genererar ensynlig laserstråle
utgående från instrumentet: avståndsmätaren
motsvarar laserklass 2 enligt:
IEC60825-1 : 2014 Lasersäkerhet.
Laserklass 2-produkter
Titta inte in ilaserstrålen och rikta den inte mot andra personer eller djur.
Risk för ögonskada.
Varning! Titta aldrig in ilaserstrålen med ettoptiskt instrument, t.ex. kikare
eller teleskop. Risk för ögonskada.
Produktmärkning med säkerhetssymboler
Läs hela bruksanvisningen.
Laserklass 2
Beskrivning Värde
Maximal topp-impulsuteffekt 0,95 mW
Frekvens 635 nm
Pulstid > 400 ps
Pulsfrekvens 320 MHz
Stråldivergens 0,16×0,6 mrad
Laserklassicering
Underhåll
• Rengör instrumentet med mjuk fuktig trasa.
• Doppa inte instrumentet i vatten.
• Använd inga aggressiva rengöringsmedel eller lösningsmedel.

SVENSKA
20
1
2
37
8
9
4
5
6
• Se till att inte avlägsna eller skada de säkerhetssymboler och varningar som finns
på avståndsmätaren.
• Försök aldrig öppna höljet, reparera eller modifiera avståndsmätaren på något sätt.
• Använd endast tillbehör som rekommenderats av tillverkaren eller försäljningsstället.
• Använd aldrig avståndsmätaren imiljöer där explosiva ämnen används eller förvaras.
• Använd inte avståndsmätaren på eller nära högreflekterande ytor, laserstrålen kan
reflekteras in idina eller andras ögon.
Knappar och funktioner
1. Display
2. På, utför mätning
3. Addera
4. Välj area, volym,
Pythagoras eller utsättning
5. Nollställ, av
6. Minne
7. Subtrahera
8. Timer
9. Välj referenspunkt
för mätning, välj enhet
• Produktmärkning:
Illustrationer, beskrivningar och
tekniska specifikationer är icke
bindande och kan ändras vid behov.
