Code Reader™ 3500 (CR3500) - Cabled

Quickstart Guide

C004418_03_CR3500_Cabled_Quickstart

Included with your Cabled CR3500

Depending on the reader conguraon ordered, you will have received some of the

following with your CR3500:

Blank Baery Cartridge H2 Handle USB Cable RS232 Cable

Installing a Blank Baery Cartridge

1. To install a blank baery cartridge, place the plasc

tab on the boom of the baery cartridge into the

slot on the reader. Slide the locking mechanism up,

and press the baery into place. Slide the locking

mechanism down to secure the baery.

2. To detach a baery, slide the locking mechanism on

the reader up and pull the baery cartridge up and

away from the slot on the reader.

CR3500’s unique

targeng funcon uses

two converging targeng

LEDs to guide the user to

opmal reading range.

Reading Tips

Quick Tips

1. Press either trigger buon to turn the reader on, or to scan a bar code.

2. Press the So Key, under ‘Opons’ to: manually enter data, view stored data, connect to a

Bluetooth device, send all stored data to a PC, and change reader sengs.

3. Use the arrow buons to navigate through lists, data and more.

4. Use the Enter buon to select an item.

Visit www.codecorp.com to download the CR3500 User Manual for a complete reference guide of

CR3500 funcons.

The reader is too far from a

bar code (more than 12”

from the bar code reader).

The reader is too close to a

bar code (less than 1”

from the bar code reader).

The opmal distance to read

most bar codes is 3-4” away

from the bar code reader.

Installing a H2 Handle

1. Push the 8-pin DIN connector at the end of the reader

into the exible connector at the end of the handle.

2. Gently push the reader back, unl the tab on the

handle sits in the recessed slot on the reader. Press

the reader down towards the handle unl it snaps

into place. Oponally, the reader can be further

secured to the handle with two threaded screws on

the underside of the reader and handle (screws are

included with Handles).

3. To detach the H2 Handle, slide the locking mechanism

on the reader up, pull the 8-pin DIN connetor out

and away from the reader, and pull the reader up and

away from the tab on the handle.

Powering On a CR3500

1. Line up and push the 8-pin DIN connector into the

reader, plug the USB or RS232 end of the cable into

the computer, and plug the Power Supply (with RS232

cables only) into a wall socket.

2. To power on a CR3500, press and hold either trigger

buon for approximately one second.

The default seng on the CR3500 has Sux Enter disabled. To enable the Sux Enter for

USB and Carriage Return/Line Feed for RS232 scan the conguraon code, followed by the

Save Sengs (M188_02) bar code:

CR3500 Default Sengs

Codabar

Codablock F

Code 11

Code 39

Code 39 Short Margin

Int 2 of 5

PDF417

Telepen

UPC

UPC Short Margin

UPC-E Expansion

Code 39 Triopc

Code 93

Code 128

Code 128 Short Margin

Data Matrix

The CR3500, out of the box, will read the following bar codes:

To congure a CR3500 to read bar codes not listed, please download the CR3500 User Manual

from www.codecorp.com and scan the appropriate ‘Enable’ bar code reading symbology

conguraon code.

Sux Enter Conguraon

Enable Sux Enter - USB Enable Carriage Return/Line Feed - RS232

For more conguraon opons, including disabling the Sux Enter conguraon, download the

CR3500 User Manual from www.codecorp.com.

The cable has a locking mechanism that will rmly hold the

cable in place. To detach the cable, pinch the plasc on the

8-pin DIN and pull back to disengage the connector.

Installing a Cable

Line up the 8-pin DIN connector into the back end of the

unit, or boom of the handle. The arrows on the connector

should be facing down. When the two items are aligned,

rmly push the cable into the reader.

Scan the Save Sengs code to save the Sux Enter Conguraon.

Save Sengs
