Cognex MX-1000 User manual

MX-1000 Series
Quick Reference Guide
2021 June 14
Revision:6.3.0.21

Precautions
To reduce the risk of injury or equipment damage, observe the following precautions
when you install the Cognex product:
lRoute cables and wires away from high-current wiring or high-voltage
power sources to reduce the risk of damage or malfunction from the
following causes: over-voltage, line noise, electrostatic discharge (ESD),
power surges, or other irregularities in the power supply.
lChanges or modifications not expressly approved by the party responsible
for regulatory compliance could void the user’s authority to operate the
equipment.
lEnsure that the cable bend radius begins at least six inches from the
connector. Cable shielding can be degraded or cables can be damaged or
wear out faster if a service loop or bend radius is tighter than 10X the cable
diameter.
lThisdevice should be used in accordance with the instructions in this
manual.
lAll specifications are for reference purposes only and can change without
notice.
lThe safety of any system incorporating this product is the responsibility of
the assembler of the system.
lThis product is intended for industrial use in automated manufacturing or
similar applications.
lThisproduct does not contain user-serviceable parts. Do not make
electrical or mechanical modifications to product components.
Unauthorized modifications can void your warranty.
2

Symbols
The following symbols indicate safety precautions and supplemental information:
WARNING:This symbol indicates a hazard that could cause death, serious personal injury or electrical
shock.
CAUTION:This symbol indicates a hazard that could result in property damage.
Note: This symbol indicates additional information about a subject.
Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.
3

MX-1000 Layout
Layout
1 Scanner head (rotatable by 45°)
2 Indicator LEDs
3 Side trigger buttons
4 Power button
5 Touch screen
6 Home button
7 Speaker vents
8 Recessed area for mobile camera
9 Slider to lock battery cover
4

10 Battery cover
11 Lanyard hook
12 End cap of pistol grip*
13 Trigger button on the pistol grip*
*Pistol grip is optional
5

MX-1000 Series Accessories
Accessory
Battery for reader (3120 mAh) DMA-MTBATTERY-01
Battery for pistol grip accessory (3070 mAh) DMA-HHBATTERY-01
Pistol grip
Note: The grip features its own
trigger button and an additional
battery which can be charged via the
charging station.
DMA-GRIP-01
Belt holster DMA-HOLSTER-01
DMA-HOLSTER-02
Charging station (inductive) DMA-MTBASE-US
DMA-MTBASE-EU
Charging station (non-inductive) DMA-MTBASEP-US
DMA-MTBASEP-EU
Multi-device charger DMA-MTBASE4-US
DMA-MTBASE4-EU
DMA-MTBASE4BKT-US
DMA-MTBASE4BKT-EU
Multi-battery charger DMA-MBC-US
DMA-MBC-EU
Wireless car charger DMA-VMCHARGER-00
6

Accessory
Power supply for charging station 24V/24W DMA-24VPWR-US
DMA-24VPWR-EU
USB Type-C battery charger kits
1. USB Type-C Battery Cover
(DMA-MXUSB-00) + USB
Type-C 3Amp Car Charger
(DMA-MXUSB-CHARGER)
2. USB Type-C Battery Cover
(DMA-MXUSB-00) + Handstrap
(DMA-MXSTRAP-00)
3. USB Type-C Battery Cover
(DMA-MXUSB-00) + USB
Type-C 3Amp Car Charger
(DMA-MXUSB-CHARGER) +
Handstrap (DMA-MXSTRAP-
00)
1. DMA-MXUSB-01
2. DMA-MXUSB-02
3. DMA-MXUSB-03
Passive car holder1DMA-VMHOLDER-00
1Using or storing the device outside of the recommended temperature ranges may damage or reduce the lifespan of
the battery. Leaving the MX Series Mobile Terminal with a mobile device in direct sunlight for an extended amount
of time can raise the temperature above the recommended limit.
7

Accessory
Top Cover DMA-COVERKIT-S6
DMA-COVERKIT-S7
DMA-COVERKIT-S8
DMA-COVERKIT-S9
DMA-COVERKIT-I5
DMA-COVERKIT-I6
DMA-COVERKIT-S4
DMA-COVERKIT-S5
DMA-COVERKIT-J3
DMA-COVERKIT-J327
DMA-COVERKIT-J330
DMA-COVERKIT-A3
DMA-COVERKIT-X4
DMA-COVERKIT-N42
DMA-COVERKIT-s10e
DMA-COVERKIT-iX
8

Dimensional Drawings
9

Field of View and Reading Distances
Note: Due to tolerances, ranges can vary by +/- 5 mm for small codes to +/- a couple of centimeters for
large codes.
10

Assembling the Reader
1. Place the rubber insert on the base unit.
2. Plug the USBcable into the base unit.
3. Put the mobile device on the rubber
insert and connect it to the base unit with
the USB cable.
4. Attach the top cover.
5. Tighten the screws to fix the top cover.
6. Open the back cover to take out the
reader battery.
7. Plug the pistol grip cable into the grip
connector.
8. Insert the reader battery.
9. Assemble the reader with the pistol grip
and tighten the screws.
Note: For details, see the MX-1000 Reference Manual.
For a list of supported mobile devices, please contact Cognex.
11

Installation
Installation procedures and specifications are presented in detail in the MX-1000
Reference Manual, which is installed with the DataMan Setup Tool. From the
Windows Start menu, select the following to accessthe manual: All Programs >
Cognex > DataMan Software v6.1.0 > Documentation.
Note: If a standard component is missing or damaged, immediately contact
your Cognex Authorized Service Provider (ASP) or Cognex Technical
Support.
CAUTION:All cable connectors are keyed to fit the connectors on the reader.
Do not force the connections or damage may occur.
Install Software and Documentation and
Connect the Reader
To configure an MX-1000 reader, the DataMan Setup Tool software must be
installed on a networked PC. The DataMan Setup Tool is available from the
DataMan support site: http://www.cognex.com/support/dataman.
Note: The DataMan Setup Tool only works if the DataMan Quick Setup is
installed on the mobile device. For further details, see the MX-1000 User
Guide.
1. After installing the software, connect the MX-1000 to your PC.
2. Launch the DataMan Setup Tool and click Refresh.
3. Select your MX-1000 reader from the list and click Connect.
12

MX-1000 Specifications
Specification MX-1100 Imager
Weight 510 g (675 g with pistol grip)
Operating Temperature 0ºC— +40ºC (+32ºF — +104ºF)
Storage Temperature -40ºC — +60ºC (-40ºF — +140ºF)
Charging Temperature 0ºC — +35ºC (+32ºF — +95ºF)
Maximum Humidity < 95% (non-condensing)
Environmental IP65
Codes 1-D: UPC/EAN/JAN, Codabar, Interleaved 2 of 5, Code 39, Code 128, Code 93,
Pharmacode, GS1 DataBar, PDF417, Micro PDF417
2-D: Data Matrix, QR Code, and MicroQR Code, DotCode and postal code
Power Supply Requirements Battery power
Expected operating time for
typical scan batches (400 scan
per hour) with a fully charged
battery
12 hours
Imager Specifications
13

Specification MX-1000 Imager
Image Sensor 1/3 inch CMOS
Image Sensor Properties 6.0 μm square pixels
Image Resolution (Pixels) 752 x 480 global shutter sensor
Lens Type 6.2 mm with different focal positions for MX-1000 and MX-1100, M12 lens with
IR blocking filter
LED Wavelengths
The following table shows LED types and the related wavelengths:
LED λ [nm]
RED 617
14

Charging Station Specifications
Specification Charging Station
Weight 380 g
Operating Temperature 0ºC — +40ºC (+32ºF — +104ºF)
Storage Temperature -40ºC — +60ºC (-40ºF — +140ºF)
Maximum Humidity 95% (non-condensing)
Power Supply Requirements 24 V, 24 W maximum LPS or NEC Class 2 power supply
0.5A (inductive) and 1A (non-inductive)
15

Compliance Statements
The MX-1000 has Regulatory Model 1AA7 (inductive) and Regulatory Model
R00078 (non-inductive) , and meets or exceeds the requirements of all applicable
standards organizations for safe operation. However, as with any electrical
equipment, the best way to ensure safe operation is to operate them according to
the agency guidelines that follow. Please read these guidelines carefully before using
your device.
The following specifications apply to the MX-1000 readers:
Regulator Specification
USA FCC 47 CFR Part 15, Subpart B Class A
Canada ICES-003, Class A
European Community EN55022, Class A
EN55024
Australia AS/NZS 3548 Class B
Japan VCCI V-2/2015.04
Korea IEC/CISPR 22
IEC/CISPR 24
KN22
KN24
Registration number: MSIP-REM-CGX-DM9050
Note: For the most current CE declaration and regulatory conformity information, see the Cognex support
site: cognex.com/support.
16

Safety and Regulatory
European Compliance This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
This equipment complies with the essential requirements of EU Directive
2014/30/EU. Declarations are available from your local representative.
FCC Class A Compliance
Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Canadian Compliance This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe A est conforme à la norme NMB-003 du Canada.
TÜV MX-1000, inductive: Regulatory Model 1AA7
MX-1000, non-inductive: Regulatory Model R00078
NTRL: TÜV SÜD SCC/NRTL OSHA Scheme for UL/CAN 61010-1.
CB report available upon request. TÜV SÜD, IEC/EN 61010-1.
Korea MX-1000: Regulatory Model 1AA7 (inductive), R00078 (non-inductive)
For European Union Users
Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment
(WEEE).
17

This product has required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health and the
environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment and to
diminish the pressure on the natural resources, we encourage you to use the
appropriate take-back systems for product disposal. Those systems will reuse or
recycle most of the materials of the product you are disposing in a sound way.
The crossed out wheeled bin symbol informs you that the product should not
be disposed of along with municipal waste and invites you to use the appropriate
separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling systems, please
contact your local or regional waste administration.
You may also contact your supplier for more information on the environmental
performance of this product.
Compliance Statements: Wireless Charging
Station
The Wireless Charging Station has Regulatory Model 1ABA (inductive) and
Regulatory Model R00080 (non-inductive), and meets or exceeds the requirements
of all applicable standards organizations for safe operation. However, as with any
electrical equipment, the best way to ensure safe operation is to operate them
according to the agency guidelines that follow. Please read these guidelines carefully
before using your device.
18

Regulator Specification
USA FCC 47 CFR Part 15, Subpart B Class A
Canada ICES-003, Class A
European Community EN55032, Class A
EN55024
Australia AS/NZS 3548 Class A
Japan VCCI V-3/2015.04 Class A
Korea IEC/CISPR 22
IEC/CISPR 24
KN22
KN24
Registration number: MSIP-REM-CGX-DMA-MT-BASE
For European Union Users
Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment
(WEEE).
This product has required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health and the
environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment and to
diminish the pressure on the natural resources, we encourage you to use the
appropriate take-back systems for product disposal. Those systems will reuse or
recycle most of the materials of the product you are disposing in a sound way.
19

The crossed out wheeled bin symbol informs you that the product should not
be disposed of along with municipal waste and invites you to use the appropriate
separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling systems, please
contact your local or regional waste administration.
You may also contact your supplier for more information on the environmental
performance of this product.
Safety and Regulatory
European Compliance This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
This equipment complies with the essential requirements of EU Directive
2014/30/EU. Declarations are available from your local representative.
FCC Class A Compliance
Statement
FCC Part 15, Class A
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Canadian Compliance This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe A est conforme à la norme NMB-003 du Canada.
20
