Coleman PEAK 1 User manual

English-5
To Clean
• Make sure stove is cool.
• Move stove away from flame (including pilot
lights) and other ignition sources.
• Remove LPG cylinder from stove. (Fig. 10)
• MAINTENANCE DURING EACH USE
• Keep stove area clear and free from
combustible materials, gasoline and other
flammable vapors and liquids.
• Do not obstruct the flow of combustion and
ventilation air.
• A good flame should be blue with minimal
yellow tip. Some yellow tips on flames are
acceptable as long as no carbon or soot
deposits appear.
• Wipe clean with soft cloth and mild dish
detergent. Do not use abrasives.
•To check if the gas cylinder is empty,
disconnect the cylinder from the appliance
and shake from side to side. If there is no
sound or movement of liquid, the cylinder
is empty.
• Annual service by an authorised person
is recommend. Or if any of the following
conditions are noticed; incomplete
ignition, appreciable yellow tipping, carbon
deposition, lifting, floating, lighting back or
objectionable odor.
• DO NOT use this appliance if it has damaged
or worn seals. DO NOT use this appliance if
it is leaking, damaged or does not operate
properly.
• Check that all seals between the appliance
and the gas cylinder are in place and in
good condition before connecting the gas
cartridge. Remove all transit protection
material.
• DO NOT move the appliance during
operation.
Things You Should Know
1. It is unsafe and illegal in some places to store
or use LPG cylinders of greater than 1.14 kg
(2.5 lbs) water capacity (approximately 1 lb.
LPG) in occupied enclosures.
2. The usual storage areas for camping and picnic
equipment are the basement, attic, or garage.
To avoid the accumulation of dust, cobwebs,
etc., that is common in these areas, place
your stove in a plastic bag and seal it with a
rubber band.
3. If your stove burns with a yellow smokey flame,
pull to remove the burner, and check the
burner and air tube for spider webs (Fig. 11).
4. If not completely satisfied with the performance
of this product, please call one of the numbers
listed on the cover of this manual.
www.coleman.com
DANGER
• EXPLOSION - FIRE HAZARD
• Never store LPG near high heat, open
flames, pilot lights, direct sunlight, other igni-
tion sources or where temperatures exceed
120 degrees F (49 °C).
• The cylinder must be disconnected when the
stove is in storage.
To Store
English-6 English-7
3001 Series
Camp Stove
Butane/Propane Stove
Instructions for use
© 2016 The Coleman Company, Inc.
www.coleman.com
Fig. 10
TM
Fig. 11
Check for spiderwebs
Warranty
IMPORTANT
Important. Read these instructions for use carefully. Familiarise
yourself with the appliance before connecting it to its gas container.
Keep these instructions for future reference.
This instruction manual contains important information necessary for
the proper assembly and safe use of the appliance. Follow all warnings
and instructions when using the appliance. If you have questions
about assembly, operation, servicing or repair of this product, please
call Coleman on 1800 224 350. Coleman Brands Pty Ltd. Suite W2C1,
75-85 O’Riordan St, Alexandria, NSW 2015.
Gas cylinders shall be changed in a well-ventilated location, preferably
outside away from people and any sources of ignition, such as naked
ames, pilot ames, electric heaters / equipment. If there is a leak
on your appliance (smell of gas) and you cannot stop the gas ow,
remove the appliance to a well-ventilated location away from any
ignition source. Check for leaks using soapy water. Do not try to
detect leaks using a ame. This appliance must only be serviced by
an authorised person. Gas cylinders must be stored outdoors in a well
ventilated area out of the reach of children, any indoor storage shall
comply with AS/NZS 1596.
This appliance shall only be used with 70% butane / 30% propane
mix gas cartridge certied to EN 417. IT MAY BE HAZARDOUS TO
ATTEMPT TO FIT OTHER TYPES OF GAS CONTAINERS.
CAUTION: accessible parts may be very hot. Keep young children
away, USE OUTDOORS ONLY. Must only be operated on a horizontal
surface. Not suitable for marine environments. Do not modify this
appliance.
Limited One Year Warranty
EXPRESS WARRANTY
Coleman Brands Pty. Ltd. (“Coleman”) warrants
that for a period of one (1) year from the date
of original retail purchase, this product will be
free from defects in material and workmanship.
Coleman will, depending on the circumstances,
refund, repair or replace this product or any
component of the product found to be defective
during the warranty period. Replacement
will be made with a new or remanufactured
product or component. If the product is no
longer available, replacement may be made
with a similar product of equal or greater value.
To the extent permitted by law and subject to
your non-excludable rights under the Australian
Consumer Law (Schedule 2 to the Competition
and Consumer Act 2010 (Cth)) and the New
Zealand Consumer Guarantees Act, which are
not limited to a one (1) year period, this is your
exclusive remedy for any breach of this limited
warranty or for any other claims otherwise
relating to this limited warranty.
In Australia, our goods come with guarantees
that cannot be excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major failure
and compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
The benefits provided under this warranty are
in addition to and do not affect purchaser’s
statutory rights under the Australian Consumer
Law or other rights at law.
This warranty is valid for the original retail
purchaser from the date of initial retail purchase
and is not transferable. Please keep your
proof of purchase documentation, such as the
original sales receipt or the relevant credit card
statement. Proof of purchase is required to
obtain warranty performance. Coleman dealers,
Coleman service centres, or retail stores selling
Coleman®products do not have the right to
alter, modify or in any way change the terms
and conditions of this warranty. The warranty is
valid only for products that are purchased new
and unused in Australia and New Zealand, from
Coleman or Coleman dealers or retailers.
WARRANTY EXCLUSIONS AND
LIMITATIONS
THE AUSTRALIAN CONSUMER LAW
PROVIDES CONSUMERS WITH CERTAIN
‘CONSUMER GUARANTEES’. THESE
GUARANTEES APPLY WHERE THE GOODS
AND SERVICES COLEMAN SUPPLIES TO YOU
ARE OF A KIND ORDINARILY ACQUIRED FOR
PERSONAL, DOMESTIC OR HOUSEHOLD USE
OR COST LESS THAN $40,000, AND IN THE
CASE OF GOODS, ARE NOT RE-SUPPLIED BY
YOU. NOTHING IN THIS LIMITED WARRANTY
EXCLUDES, RESTRICTS OR MODIFIES
RIGHTS WHICH YOU HAVE UNDER THE
AUSTRALIAN CONSUMER LAW IN RESPECT
OF THE CONSUMER GUARANTEES AND ALL
OF THE PROVISIONS IN THIS SECTION ARE
TO BE READ SUBJECT TO THE AUSTRALIAN
CONSUMER LAW.
This warranty does not cover: (a)normal wear
of the product and/or its parts; (b) parts that
are not genuine Coleman®parts, consumables,
lost parts and accessories; (c) damage resulting
from any of the following: negligent use or
misuse of the product, commercial use of
the product, use contrary to the operating
instructions; disassembly, repair or alteration
by anyone other than Coleman or Coleman
service centre, the use of a part other than a
genuine Coleman®part; or (d) acts of God,
such as fire, flood, hurricanes and tornadoes.
To the extent permitted by the Australian
Consumer Law, the Competition and
Consumer Regulation 2010 and the New
Zealand Consumer Guarantees Act,
Coleman’s liability is limited, depending on
the circumstances, to refund, replacement or
repair of Coleman®products or components.
For the avoidance of doubt, any and all
other warranties or conditions which are not
guaranteed by the Australian Consumer Law,
the Competition and Consumer Regulation
2010 and the New Zealand Consumer
Guarantees Act and which are not expressly
included in this warranty as additional
warranties or conditions are expressly
excluded, including liability for incidental
or consequential damages caused by the
breach of any express or implied warranty or
condition.
MAKING A WARRANTY CLAIM -
RETURN TO COLEMAN FOR REPAIR
Take the product to an authorised Coleman
retailer or Coleman service centre as soon
as the warranty claim arises. You may locate
the nearest authorised Coleman retailer or
Coleman service centre by visiting www.
coleman.com or calling 1800 224 350 or + 61
2 8762 5000. Please ensure that you provide
a written description of the problem with the
product, together with your contact name,
address and telephone number and proof of
purchase.
Subject to the applicable consumer laws in
your jurisdiction, you must pay for the costs of
transporting the product, including packaging,
freight and insurance costs, to an authorised
Coleman retailer or Coleman service centre
for warranty service. If the warranty claim
is substantiated and accepted by Coleman,
Coleman will at its cost, repair or replace
any product or parts and return the product
to you. Additionally, if the warranty claim is
substantiated and accepted by Coleman,
Coleman will reimburse you for the costs of
transporting the product to an authorized
Coleman retailer or Coleman service
centre. Coleman reserves the right to seek
reimbursement for any costs and expenses
incurred for a warranty claim if the product is
found to be in good working order.
If you have any questions regarding this
warranty please call 1800 224 350 or + 61 2
8762 5000.
Coleman Brands Pty. Ltd.
ABN 74 091 681 195
Suite W2C1, 75-85 O’Riordan Street,
Sydney Corporate Park, Alexandria, NSW 2015
Australia
Telephone: [phone] or + 61 2 8762 5000
Email: [email protected]
www.coleman.com
Coleman Brands Pty. Ltd.
ABN 74 091 681 195, Suite W2C1, 75-85 O’Riordan Street, Sydney Corporate
Park, Alexandria, NSW 2015, Australia
Telephne: 1800 224 350 or + 61 2 8762 5000
www.coleman.com
© 2016 The Coleman Company, Inc. All rights reserved.
Coleman®, and are registered trademarks and TM is a
trademark of The Coleman Company, Inc.
The Coleman Company, Inc., a Jarden Corporation company (NYSE:JAH)
4010051748 (ECN20055731-01)

English-4
To Light
DANGER
• EXPLOSION - FIRE HAZARD
• LPG is heavier than air and can accumulate
in low places. If you smell gas, leave the
area immediately.
• Always attach or detach LPG source
outdoors; never while stove is lighted, near
flame, pilot lights, other ignition sources or
while stove is hot to touch.
• This stove is very hot during use and can
ignite flammables too close to the burners.
Keep flammables at least 24 inches from
the sides and 48 inches from the top of the
stove. Keep gasoline and other flammable
liquids and vapors well away from stove.
• The stove must not be exposed to flammable
vapors or liquids during lighting.
WARNING
• BURN HAZARD
• Never leave stove unattended when
hot or in use.
• Keep out of reach of children.
Fig. 8
Match Light:
• Set on sturdy, flat surface. For outdoor use only.
• Hold lighted match at burner and open FUEL
VALVE. (Fig. 7)
• Adjust flame to desired heat with FUEL VALVE.
(Fig. 8)
• Flame should be blue with hint of yellow
on tips.
Fig. 7
To Turn Off
• Turn FUEL VALVE “off”. (Fig. 9)
Fig. 9
WARNING
• Perform leak test outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the outdoor stove until connec-
tion has been leak tested and does not leak.
Leak Check
Fig. 6
Fig. 5
English-3
To Set Up
Technical
Characteristics
Input: 10,000 BTU/H / 9.5MJ/h
Category: Unregulated LPG
Fuel: 70% Butane 30% Propane mix
Injector: 0.25mm
DANGER
• CARBON MONOXIDE HAZARD
• For outdoor use only.
• Never use inside house, camper, tent, vehicle
or other unventilated or enclosed areas. This
stove consumes air (oxygen). Do not use
in unventilated or enclosed areas to avoid
endangering your life.
• NOTE: Use Coleman®7 3/4 oz. disposable
butane/propane mix cylinder only. Do not con-
nect to bulk LPG systems. The LP-gas cylinder(s)
used with stoves must be constructed and
marked in accordance with the specifications
for LP-gas cylinders of the U.S. Department of
Transportation or Transport Canada, CAN/CSA
B339.
CAUTION
• SERVICE SAFETY
• Keep all connections and fittings clean.
Inspect LPG cylinder and stove LPG connec-
tions for damage before attaching.
• During set up, check all connections and
fittings for leaks using soapy water. Bubbles
indicate a leak. Never use a flame.
• Screw LPG cylinder into stove. Take care not to
cross thread. HAND TIGHTEN only. (Fig. 3)
Fig. 3
• Take stove outdoors away from
ignition sources.
• Turn fuel valve off. (Fig. 2)
• Set pan supports to desired position. (Fig. 4, 5,
and 6)
Fig. 4
Fig. 1
“O” Ring
English-2
• This product is fueled by LPG. LPG is
invisible, odorless, and flammable. An odorant
is normally added to help detect leaks and
can be described as a ”rotten egg” smell. The
odorant can fade over time so leaking gas is
not always detectable by smell alone.
• LPG is heavier than air and leaking LPG
will sink to the lowest level possible. It can
ignite by ignition sources including matches,
lighters, sparks or open flames of any kind
many feet away from the original leak. Use
only LPG set up for vapor withdrawal.
• LPG should be stored or used in compliance
with local ordinances and codes or with ANSI/
NFPA 58. Turn off LPG when not in use.
WARNING
DANGER
• EXPLOSION - FIRE HAZARD
• Never store LPG (liquefied petroleum gas)
near high heat, open flames, pilot lights, direct
sunlight, other ignition sources or where
temperatures exceed 120 degrees F (49°C).
• LPG is heavier than air and can accumulate in
low places. If you smell gas, leave the
area immediately.
• Never install or remove LPG cylinder while
outdoor stove is lighted, near flame, pilot
lights, other ignition sources or while outdoor
stove is hot to touch.
• During lighting and operation, this product
can be a source of ignition. Never use the
stove in spaces that contain or may contain
volatile or airborne combustibles, or products
such as gasoline, solvents, paint thinner, dust
particles or unknown chemicals. Minimum
clearances from combustible materials: 24
inches from the sides and 48 inches from
the top.
• Provide adequate clearances around air
openings into the combustion chamber.
WARNING
Not for home or recreational vehicle use.
We cannot foresee every use which may be
made of our products.
Check with your local fire safety authority if
you have questions about use.
Other standards govern the use of fuel gases
and heat producing products for specific
uses. Your local authorities can advise you
about these.
• Never refill disposable cylinders.
• Use only Coleman®accessories or parts.
During stove set-up, check all fittings for
leaks using soapy water. Never use a flame.
WARNING
• BURN HAZARD
• Never leave stove unattended when
hot or in use.
• Keep out of reach of children.
DANGER
• CARBON MONOXIDE HAZARD
• This stove is a combustion appliance. All
combustion appliances produce carbon
monoxide (CO) during the combustion
process. This product is designed to produce
extremely minute, non-hazardous amounts
of CO if used and maintained in accordance
with all warnings and instructions. Do not
block air flow into or out of the stove.
• Carbon Monoxide (CO) poisoning produces
flu-like symptoms, watery eyes, headaches,
dizziness, fatigue and possibly death. You
can’t see it and you can’t smell it. It’s an
invisible killer. If these symptoms are present
during operation of this product get fresh
air immediately!
• For outdoor use only.
• Never use inside house, camper, tent,
vehicle or other unventilated or enclosed
areas. This stove consumes air (oxygen).
Do not use in unventilated or enclosed
areas to avoid endangering your life.
CAUTION
• SERVICE SAFETY
• Use only LPG set up for vapor withdrawal.
• Keep all connections and fittings clean.
Always inspect gas cartridge, stove
connections and “O” ring seal for damage,
dirt and debris before attaching cartridge
(Fig. 1). Replace if damaged or worn. Never
use stove with damaged or worn seals.
• During set up, CHECK FOR LEAKS in
one or more ways: Apply soapy water to
connections. Bubbles indicate a leak. Listen
for hiss of escaping gas. Feel for extreme
cold. Smell for rotten egg odor. Never use
a flame. Check that the connection is not
cross-threaded and that it is tight. Perform
another leak check. If there is still a leak,
remove the cylinder and contact Coleman for
service or repairs.
• Use as a cooking appliance only. Never alter
in any way or use with any device or part not
expressly approved by Coleman.
• Never use as a space heater.
• Clean stove frequently to avoid grease
accumulation and possible grease fires.
English-1
If you smell gas:
1. Do not attempt to
light appliance.
2. Extinguish any
open flame.
3. Disconnect from
fuel supply.
FOR YOUR
SAFETY
Do not store or use
gasoline or other liquids
with flammable vapors
in the vicinity of this or
any other appliance.
FOR YOUR
SAFETY
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
This manual contains important information
about the assembly, operation and maintenance
of this outdoor LPG (liquefied petroleum gas)
appliance. General safety information is presented
on this page and is also located throughout these
instructions. Particular attention should be paid
to information accompanied by the safety alert
symbol “ DANGER”,
“ WARNING”, “ CAUTION”.
Keep this manual for future reference and
to educate new users of this product. This manual
should be read in conjunction with the labeling on
the product.
Safety precautions are essential when any
mechanical or LPG fueled equipment is involved.
These precautions are necessary when using,
storing, and servicing. Using this equipment with
the respect and caution demanded will reduce the
possibilities of personal injury or property damage.
The following symbols shown below are used
extensively throughout these instructions. Always
heed these precautions, as they are essential when
using any mechanical or LPG fueled equipment.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate personal injury, or
property damage.
Failure to comply with the precautions and
instructions provided with these stoves can
result in death, serious bodily injury and
property loss or damage from hazards of fire,
explosion, burn, asphyxiation, and/or carbon
monoxide poisoning.
Only persons who can understand and follow
the instructions should use or service
these stoves.
If you need assistance or information such
as an instruction manual or labels, contact
The Coleman Company, Inc.
DANGER
Fig. 2
• CHECK FOR LEAKS in one or more ways:
Apply soapy water to connections. Look for
bubbles. Listen for hiss of escaping gas. Feel
for extreme cold. Smell for rotten egg odor.
Never use a flame. Do not use if leaking.
CARBON MONOXIDE
HAZARD
• ONLY USE IN
WELL-VENTILATED
AREAS.
• CARBON MONOXIDE
HAZARD—USING
THIS APPLIANCE
IN AN ENCLOSED
SPACE MAY CAUSE
DEATH.
• DO NOT USE
IN CARAVANS,
TENTS, MARINE
CRAFT, CARS,
MOBILE HOMES
OR SIMILAR
LOCATIONS.
DANGER
