Colortrac SMARTLF SCAN User manual

1
DOCUMENT NO.88N001D Colortrac Ltd © 2015
User Instructions
For SmartLF Scan!
Large Format Scanner
Rev.D October 2015
(f/w 0.19)

2
DOCUMENT NO.88N001D Colortrac Ltd © 2015
Scans stored in scanner memory
Scan to computer mode
Scan to scanner mode (default)
Scan to USB flash drive mode
Settings
Processing
Active Settings
PANEL CONTROLS
top
move left
move right
accept function
SCAN
up one level
eject paper
SCAN MODES
CONTROL PANEL
SCANNER STATUS INDICATOR
Blue –POWER ON, NORMAL OPERATION
Orange –PAPER TRAY OPEN (MAINTENANCE
DISPLAY

3
DOCUMENT NO.88N001D Colortrac Ltd © 2015
INSTALLATION
Input: 100 - 240V, 50-60Hz
Output: 3.42A at 19V

4
DOCUMENT NO.88N001D Colortrac Ltd © 2015
Indicates a selected scan mode. Click
SCAN button to scan
Click OK to select sub-menu. Click OK to
select sub-level item
OK
Click OK to select. Menu returns to level
above
COLOR MODE
scan to PDF file
OK
scan to TIFF file
OK
DETAIL
SCAN PAPER SIZE
BRIGHTNESS
BLACK POINT
WHITE POINT
MORE SETTINGS
full color mode
OK
grayscale mode
OK
automatic normal picture detail
OK
automatic high picture detail
OK
automatic normal document
detail
OK
automatic high document detail
OK
fixed low detail
OK
fixed normal detail
OK
fixed high detail
OK
PAPER SIZING
ISO/DIN PAPER SIZES
ANSI PAPER SIZES
ARCHITECTURAL PAPER SIZES
bright
OK
MENU / OPERATION
SCANNER TOP-MENU SETTINGS
SCANNER SUB-MENU SETTINGS

5
DOCUMENT NO.88N001D Colortrac Ltd © 2015
brighter
OK
very bright
OK
low black point
OK
medium black point
OK
high black point
OK
low white point
OK
medium white point
OK
high white point
OK
move scans to computer
OK
move scans to USB flash
memory
OK
save settings as default
OK
return to factory default settings
OK
NETWORK
color calibrate
OK
line calibrate
OK
information
OK
update firmware
OK
automatic scanner IP address
OK
fixed IP scanner address
OK
automatic paper size
OK
ISO A4 portrait
OK
ISO A4 landscape
OK
ISO A3 portrait
OK
ISO A3 landscape
OK
ISO A2 portrait
OK
ISO A2 landscape
OK
ISO A1 portrait
OK
ISO A1 landscape
OK
ISO A0 portrait
OK
ANSI A portrait
OK
ANSI A landscape
OK
ANSI B portrait
OK
ANSI B landscape
OK
ANSI C portrait
OK
ANSI C landscape
OK
ANSI D portrait
OK
ANSI D landscape
OK
ANSI E portrait
OK
ARCH A portrait
OK
ARCH A landscape
OK
ARCH B portrait
OK
ARCH B landscape
OK
ARCH C portrait
OK
ARCH C landscape
OK
ARCH D portrait
OK
ARCH D landscape
OK
ARCH E portrait
OK
delete all scans in scanner
OK

6
DOCUMENT NO.88N001D Colortrac Ltd © 2015
SCAN TO SCANNER
STEPS
Check scanner memory is not full (8 scans maximum)
Check / select paper size setting
Check / select file type
Check / select color mode
Load paper in centre of scanner between limit markers
Check mode is ‘download to scanner’ (default)
Press scan button
Document will eject automatically after scan is stored

7
DOCUMENT NO.88N001D Colortrac Ltd © 2015
SCAN TO USB FLASH MEMORY
STEPS
Insert USB flash memory (FAT32, 128GB max)
Check / select paper size setting
Check / select file type
Check / select color mode
Load paper in centre of scanner between limit markers
Change mode to ‘download to USB flash memory’
Press scan button
Document will eject automatically after scan is transferred

8
DOCUMENT NO.88N001D Colortrac Ltd © 2015
SCAN TO COMPUTER (INSTALLATION)
1
2
3
4
5
192.168.001.XXX
255.255.255.000
192.168.002.XXX
255.255.255.000

×

×
STEPS
Download and run installation of netapp (internet)
1,2
Browse to target directory for transferred scans
3
Close program from interface
3
Check taskbar for running netapp called Scan!
4
Only one netapp per subnet
5

9
DOCUMENT NO.88N001D Colortrac Ltd © 2015
SCAN TO COMPUTER (CONFIGURE)
1
3
4
2
STEPS
Start Scan! netapp from Windows program area
1
To configure or exit app first locate icon in taskbar
2
Right-click icon to show Scan! netapp options
3
To change the save directory
4
To convert all incoming grayscale to black and white
4
Use lock to block other scanners using this app after connection
4
Use a shared save location if more than one netapp installation
2

10
DOCUMENT NO.88N001D Colortrac Ltd © 2015
SCAN TO COMPUTER (SCAN)
STEPS
Connect to network, select IP protocol (see notes)
Check / select paper size setting
Check / select file type
Check / select color mode
Load paper in centre of scanner between limit markers
Change mode to ‘download to computer’
Press scan button
Document will eject automatically after scan is transferred

11
DOCUMENT NO.88N001D Colortrac Ltd © 2015
TRANSFER ALL SCANS TO USB FLASH MEMORY
STEPS
Insert USB flash memory (FAT32, 128GB max)
Note number of scans stored inside scanner (top left of display)
Move to settings, more settings, move scans to USB flash memory
Click OK to transfer scans. Wait for process symbol to clear
Note number of scans stored inside scanner will now be zero
Remove USB flash memory

12
DOCUMENT NO.88N001D Colortrac Ltd © 2015
TRANSFER ALL SCANS TO COMPUTER
MEMORY
STEPS
Note number of scans stored inside scanner (top left of display)
Scan! must be connected to a computer –see page ‘ SCAN TO
COMPUTER (SCAN) ‘
Move to settings, more settings, move scans to computer
Click OK to transfer scans. Wait for process symbol to clear
Note number of scans stored inside scanner will now be zero

13
DOCUMENT NO.88N001D Colortrac Ltd © 2015
DELETE ALL SCANS IN SCANNER MEMORY
STEPS
Note number of scans stored inside scanner (top left of
display)
Move to settings, more settings, delete all scans in scanner
memory
Note number of scans stored inside scanner will now be
zero

14
DOCUMENT NO.88N001D Colortrac Ltd © 2015
UPGRADE SCANNER FIRMWARE
MEMORY
STEPS
Check the latest firmware level for Scan! posted at
www.colortrac.com/support.
Switch on Scan! and check fitted firmware level
Obtain an empty USB flash drive of at least 4GB capacity. It
is important the drive contains no folder or files.
Using a Windows computer copy the contents of the
firmware upgrade zip file to the USB stick.
www.colortrac.com/support
Insert the USB drive into scanner USB socket
From the upgrade firmware icon press OK. Upgrading takes
20 seconds. Scan! will restart automatically
Check firmware level has changed to latest level

15
DOCUMENT NO.88N001D Colortrac Ltd © 2015
MAINTENANCE - CLEAN
2
3
5
4
1
STEPS
Power off the scanner and remove all connection cables
1
Fold out rear props, lean scanner back then fold out front
2,3,4,5

16
DOCUMENT NO.88N001D Colortrac Ltd © 2015
MAINTENANCE - CLEAN
5
1
3
4
2
STEPS
Push left and right levers downwards to lower the closed tray section
1
Support tray and fold out lower section
2
Identify white paper pressure plate (sprung)
3
Identify sensor glass
4
Periodically inspect and clean 3 and 4 using non-abrasive, non-solvent, lint-
free cleaning products if required
5
Allow to dry then close tray (check for blue light when powered back up)

17
DOCUMENT NO.88N001D Colortrac Ltd © 2015
MAINTENANCE –CALIBRATE
2
1
3
STEPS
Always ensure sensor glass is clean and dry (previous section)
1
Note: Calibration target is placed between width markers
2
Insert calibration target into scanner face up, black section first
3
Select settings, color calibration
Calibration target is ejected after calibration
Select settings, line calibration
Calibration target is ejected after calibration

18
DOCUMENT NO.88N001D Colortrac Ltd © 2015
Description Explanation
Blue light flashes for 1 second every 5
seconds
Scanner is in sleep mode. Press SCAN button to wake scanner or
insert media
Loaded document suddenly moves
through the scanner and is ejected.
Light flashes 1 second every 5
seconds
Scanner has entered deep power save mode. Place paper on tray
then remove it to re-power the scanner
Orange light shows and will not scan
Paper tray is still open and not properly engaged at one or both
ends. Close paper tray.
Scan! starts to scan but then sends
document through scanner faster
than normal when connected to a
computer
Scan! could not find the computer on the same network. Use
‘information’ in the scanner and ipconfig from the command
prompt at the computer to verify that both devices are identical in
the first three frames of the IP address192.168.001.XXX.
Paper size is not detected properly
Scanner glass may be dirty. Inspect and clean if necessary. Note
if the glass was dirty at the time a color calibration was carried out
a perfectly clean scan glass will not help. Check the scan glass is
still clean then color calibrate and try again.
Document is ejected or does not scan
properly using automatic paper sizing
Document is wider than the scanner maximum scan width.
Rotate document if possible or change to largest manual size (D-
size portrait or E-size portrait).
Scans are not being saved when using
the USB flash memory mode
The USB flash memory may be damaged, worn out of poor quality
or incompatible. Change to a different type
Description Explanation / Tip
Dealing with a document that has
loaded skewed or the document is
not lying flat
Do not press Eject or Scan. Instead slightly lower the paper tray
towards the maintenance position (p16), remove the document,
click the paper tray assembly back up into position and reload
Do not feed a document immediately
behind the document still being
processed (held but not yet ejected)
Always allow the previous document
to be ejected before loading a fresh
document
Failing to allow the scanner to finish and eject a document causes
any following document placed in the scanner to be ejected
without being staged ready to be scanned
I find it difficult sometimes to load
larger documents squarely into the
scanner
Grip the paper at each side 2”/ 50mm in from the leading edge.
With the paper slightly in tension (stretched) rest each hand on
the tray so that the leading edge is parallel and ¼”/ 6mm in front
of the white ruler. Now push the document into the scanner.
Why does the scanner not accept any
more than 8 scans when scanning
internally to its own memory
SmartLF Scan! is limited to holding 8 scans internally.
The processing circle icon seems to
continue beyond 1 minute.
Please restart the scanner and try again. If using a memory stick
try a different one.
OPERATING TIPS
TROUBLESHOOTING GUIDE

19
DOCUMENT NO.88N001D Colortrac Ltd © 2015
Pressing the scan button when using
the USB stick does not start the scan
Wait 3 to 4 seconds after inserting the USB stick into Scan! before
pressing the scan button for the stick to be recognised properly
When using the Scan! netapp no
scans are received into the folder
a) Power cycle the scanner
b) Determine the scanner IP address then ping it from the
computer e.g. ping 192.168.001.xxx
c) Is the netapp running?
d) Is a netapp running on a different computer and directing the
scans somewhere else?
e) If b and c are okay uncheck the Scanner Lock checkbox in c or d
to reset the lock (required after a firmware upgrade)
Straight lines and diagonal lines in the
scan images have very small breaks in
them when inspected at high zoom
If the scanner is subjected to strong physical shock or extremes of
temperature during storage or shipment the internal optical
alignment may be altered very slightly. Use the line calibrate
function from the more settings menu and the calibration target
to electronically re-align the scanner.
The color of the image is suddenly
changing very slightly across the
scanner
If the scanner is being used in a room where the temperature is
more warm or cold than normal or different to the environment
where the scanner was last color calibrated then it may be
necessary to recalibrate. Use the color calibrate function from
the more settings menu and the calibration target to
electronically re-set the color in the scanner.

20
DOCUMENT NO.88N001D Colortrac Ltd © 2015
Declaration of Conformity
COLORTRAC IMAGING SYSTEM (SUZHOU) CO LTD
#39 DONGJING INDUSTRIAL ZONE, #9 DONGFU RD,
SUZHOU INDUSTRIAL PARK, SUZHOU,
JIANGSU, 215123 CHINA
Model name: SmartLF Scan! 24, SmartLF Scan! 36
Function: Large Format Scanner
Rating voltage: 19V
Rating current: 3.42A
Power supply: FSP065-REBXX
(X=0-9, A-Z or Blank)
Approvals applied for: Energy Star, CB, CE, FCC, UL, CuL, VCCI, C-Tick, CCC,
BIS, KCC, EAC, BSMI, RoHS, LVD
Warning:
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
SmartLF Scan! 24
SmartLF Scan! 36
In-the-box
Scan! large format scanner
Tough wheeled carry case
Mains external power supply
Calibration target
RJ45 Ethernet cable
Scan System
Three modes of operation.
TIFF and PDF files are generated inside the scanner. They can be
1 - stored inthe scanner for transfer to a PC later
2 - stored directly on a USB stick
3 - transferred via wired Ethernet,direct toa network or PC.
When connected to a PC, additional black and white binary files are available.
SmartLF Scan! is self-contained and only requires a power supply to operate.
Scan software
Scan formats are viewable using nativeWindows Apps. A small Windows program issupplied to receive live or stored scan files
from the scanner. Thisis not required for scan to USB stick operation.
Optical Resolution
600 dpi
DocLogic
intelligentimage optimisation system
automaticallysets dpi of document or photos accordingto physical size to maximise image qualityand reduce filesize
Max Scan Width
24” (609.6 mm)
36” (914.4 mm)
Max Image Length
50" (1270mm)
Min Media Width / Thickness
6.2” (160mm) / 0.003” (0.07 mm)
6” (150 mm) / 0.003” (0.07 mm)
Max Media Width / Thickness
26” (660mm) / 0.02” (0.5 mm)
38” (965 mm) / 0.02” (0.5 mm)
Paper sizing (image sizes)
ISO DIN / ARCH / ANSI / automatic width and length
Internal memory
approx.6 GBor 8 scans
Scan Accuracy
0.2 % +/-1 pixel
SingleSensor
digital imaging technology
SingleSensor is a full width straight-line contact image sensor (US patent #8,922,849)
Bi-directional long-life LED light system for optimum object illumination and instant-on scanning capability
Operation modes
scan to internal memory / scan to USB stick (not supplied) / scan to networked computer
Color space
24-bit sRGB and grayscale (plus bitonal using the pc connection)
Scan speeds (maximum at 200 dpi)
4.5 inch/sec (114.3mm/sec) grayscale and 3 in/sec (76.2mm/sec) for color.
Paper Path
Centered, face-up, front entry
Data interfaces
Front: USB2 socket for scan to USB memory stick.
Rear: Ethernet RJ45 GBit for scan to computer over network
Power Requirements
External power supply Input: 100~240VAC, 50-60Hz, auto-sensing +/-10%, Output: 3.42A at 19V,
Scanner power consumption: 19.4 W (scanning), 10.2W (standby), 0.05W (sleep). Energy Star qualified
Environment
Operating temperature 10oC –35oC, Relative Humidity 10% –90% (non-condensing)
Weight & Dimensions (WxHxD)
Scanner only 11.5 lbs (5.2 kg) / 34.3 x 6.3 x 5 inches
(870 x 160 x 126 mm)
Scanner incl. case: 22.3 lbs (10.1 kg) / 38.6 x 10.4 x 8.2
inches (980 x 265 x 208 mm)
Scanner only 15.4 lbs (7 kg) / 46.3 x 6.3 x 5 inches (1175 x
160 x 126 mm)
Scanner incl. case: 30.9 lbs (14 kg) / 50.4 x 10.4 x 8.2 inches
(1280 x 265 x 208 mm)
Host Platform
Windows 10, Windows 8, Windows 7, 32-bit and 64-bit architectures
Certifications
ENERGY STAR qualified, CB, CE, CCC, FCC, UL, RoHS compliant
Warranty
12 months or 30,000 linear scan metres
