Combi Baby Keep Slim WA User manual

Parts Included
1 3 4
Screw caps, 2 5 Head pad, 1
Usage instructions sticker, 1
6
Guide stickers, 2 Braille sticker, 1
Users Manual, 3
Installation Manual, 3
2
CAUTION
Do not use male screw
anchor bolts, as it may
not be possible to attach
the head pad.
Concrete/ALC Installation
Please prepare the following before installation:
Baby Keep Slim WA Installation Manual (to a flat surface)
In order to safely install the Baby Keep Slim WA to a flat surface, please make sure you read
this manual and follow the instructions accordingly. This guide explains how to attach
the Baby Keep Slim WA to a wall. To attach the Baby Keep Slim WA in a corner,
please refer to the Installation Manual supplied with the Corner Mounting Kit, sold separately.
Tile
Mortar
Concrete
Anchor
Bolts
Tile
Mortar Concrete
Anchor
Bolts
WARNING
• Make sure that installation hardware such as anchor bolts are firmly placed into the wall.
(Failure to do so may result in fall.)
• Height of Installation Location Prevent
from escaping
300mm
To assist the child promptly, do not install the unit far from
the caregiver.
• Apply foundational reinforcement if the wall surface is other than concrete.
*Make sure that each mounting point can withstand a strength of 1,000 N (100 kgf or more)[fix 8 mounting points]. Failure to do so may result in fall.
• If mounting onto a concrete wall, the tip of the anchor bolts must be embedded at least 40mm into the wall. Failure to do so
may result in fall.
Incorrect Correct 40 mm or greater
Secure the anchor bolts
firmly into concrete,
to a depth of at least 40mm.
Installation Location (Installation Range)
WARNING
If installing the Baby Keep Slim WA in a private
restroom, install the Baby Keep Slim WA in a
location where the child can be seen by the adult
using the restroom at all times.
• Install on a wall at least 600mm away from the toilet, or insure
300mm of space between the Baby Keep Slim WA and toilet.
600mm as standard
Further than 100mm
Not interfere with door
Install the Baby Keep at
least 300mm from the toilet
Types of Screws used for Wall-mounting
φ5 washers
2 small holes
6 large
holes
• Screws for use on concrete
Spring washers
Washers
Bolts
Use M6, M8,
or M10 types
*Use ALC-specific anchors for ALC installation
• Female screw anchor bolts
See back for mounting instructions.
*For information on products, contact the distribution agency.
Manufacturer
Distributor
2-6-7, Motoasakusa, Taito-ku, Tokyo 111-0041 Japan Head Office/2-6-7, Motoasakusa,
Taito-ku, Tokyo 111-0041 Japan
TEL : [phone] FAX : [phone]
www.combiwith.co.jp/
CAUTION
The Baby Keep Slim WA should be installed clearly
from door space. Otherwise it may cause damage.
WARNING
Install the unit where the caregiver can see the child.
WARNING
Below the seating surface, as described in the
diagram on the left, do not place handrails
(including hinged one), trash can, or other objects.
The child may stand up and escape and may fall.
EN CN KR
Screws (φ5)
for concrete
133826050 201225(1)

1 2 3 4
875 6
Remove the two screws from the bottom cover
of the base.
Place the bottom cover on the base.
Confirm points of installation Screw in female type anchor bolts.
Bottom cover
514mm
Please prepare the following before installation:
Make sure 100mm or more of
space is available on either side.
φ5 washers
Spring washers
Washers
Bolts
use M6, M8,
or M10 types
*Use ALC-specific anchors for ALC installation
• Female screw anchor bolts
2 small holes 6 large holes
• Screws for use on concrete
Fix the Baby Keep Slim WA to the wall at four mounting points.
(Refer to “Types of Screws Used for Wall-mounting” on the other side of this instructions)
*Once the screws are in place, make sure the structure
does not shake or wobble.
Screws (φ5)
for concrete
Screws (φ5)
for concrete, 2
φ5 washers, 2
φ6~φ10 Washers, 6
φ6~φ10 Spring washers, 6
φ6~φ10 Bolts, 6
Attach the head pad.
(Make sure the correct side is up.)
Test the guard several times
to make sure it opens and
closes appropriately.
WARNING
Stickers must be placed in highly
visible areas. Dangerous actions
such as indicated on the usage
instructions sticker may lead to
injury or serious accidents.
Affix the guide stickers to the restroom entrance
and to the stall doors.
Restroom entrance Restroom stall
Thoroughly check the Baby Keep Slim WA once it
has been installed. Refer to the Users Manual
“Maintenance Inspection” section. Using the Baby
Keep Slim WA without completely assembling it can
lead to injury or serious accidents.
WARNING
Put stick near the product
Put & stickers on the product.
3
5 6
5Braille sticker
6Routine inspection sticker
970mm
110mm
100mm
346mm
( (
*Anchor bolts must be
placed at least 40mm
into the base.
Installation Instructions * Hole positions are all center pitch (center-to center) dimensions.
Use an M6, M8, or M10
female type anchor bolt.
Female type anchor bolts, 4
Bottom cover
Parts are
included 1
2
Part is included
3
Part is included
Back
Side
Match the 6 tabs with
the corresponding
square holes on the
backside to attach the
head pad.
*The up arrow on the back
indicates which side is up.
Square holes
Square holes
7
Parts are included
CAUTION
The head pad tabs will
make a clicking sound
when correctly attached.
Note that the tabs may
break if incorrectly
inserted.
