Comica CVM-VP2 User manual

CVM-VP2
Condenser Shotgun Microphone for Camera / Camcorder
USER MANUAL

Foreword
Main Features
Thanks for purchasing COMICA CVM-VP2 condenser shotgun microphone.
Comica CVM-VP2 Professional Super cardioid Condenser Shotgun microphone , is
specially designed for video shooting, meeting, and interview for devices like
camera, camcorder ; Meanwhile the Microphone support low noise circuit, two
step high-pass filter (100Hz), 48 phantom power or 1.5V AA battery, full metal
material construction and super shielding , which provides video a broadcast
sound quality.
Please read this manual carefully before using. This product has been precisely
calibrated at the factory, do not assemble and disassemble parts by yourself.
. Low Noise Circuit
. Two Step High-pass Filter
. 48 Phantom Power or 1.5V AA Battery
. Full Metal Material Construction and Super Shielding
. Broadcast Sound Quality
Low-noise Low Cut Filter Support 48V
Phantom Power
Cardioid Pattern Full Metal and
Super Shielding
1

CVM-VP2
CondenserShotgun Microphone for Camera / Camcorder
USER MANUAL
Notice
When putting the batteries in, please notice the “positive and negative poles” to
avoid reversed assembling to cause product damage.
Please do not put the device beside the heat or interference source.
Please avoid falling, collision or pounding during usage.
Don’t expose the device in rain or moist environment .
After usage, please turn it off for storage.
Package Content
Microphone Inteference Tube
XLR-3.5mm Output Cable
XLR-XLR Output Cable
Camera Bracket
Boom Bracket
Windscreen
Black Portable Bag
User Manual
Warranty Card
1
2
3
4
5
6
7
8
9
1
2 3
45 6
78 9
10 11
Standard Parts
Wind Muff
Shock Mount
10
11
Optional parts
2

Components Introduction
Microphone
Audio Receiver End
Low-cut Filter / Normal Audio / Power swtich
Working Status Indicator Light
Audio Output Jack
Battery Holder
1
2
3
4
5
1
2
3
5
4
3

Installation and Operation
1. Installation
1.1 Installation of AA Battery
1.11 Rotate the tube , open the battery holder
1.12 Insert the battery
1.13 Rotate the tube, close the battery holder
4

1.2 Install Mic onto Camera/Camcorder
Connect the Mic and Camera/Camcorder Via Camera Bracket
1.21 Connect the mic onto Camera Bracket
1.22 Connect the mic onto camera/camcorder via Camera Bracket , fasten the
Tightness Adjusting Screw
5

1.23 Connect the 3.5mm output cable / XLR output cable to the Camera/ Camcorder
6

Connect the Mic and Camcorder Via Boom
1.31 Connect the Mic and Boom Bracket
1.32Connect the Boom Bracket and Boom
7

1.33 Connect the 3.5mm / XLR output cable to the Camcorder
8

2. Operation
2.1 Low Cut Filter / Normal Audio / Power Switch
Power on, push the button to , the microphone is in the normal
working status
Low-cut, push the button to , the microphone is in a low-cut filter status
Shut down, push the button to , the microphone is off
2.2 Indicator Light Working Status
Blue light: normal work status
Green light: detected +48V phantom power and switched to phantom power
Red light: low power status, need to replace battery
Low-cut
Power on
Shut down
Indicator Light
The low-cut function can effectively reduce the influence of noise when
recording, but sometimes it may lose some sound details,so it needs to be used
according to demands.
9

Tech Parameters
Polar Pattern
Frequency Range
Low-cut
Sensitivity
Output Impedance
S/N
Maximum SPL
Output Form
Power
Size
Net Weight
Super Cardioid
20Hz-20KHz
100Hz
-38dB ±3dB
200Ω
>65dB
>105dB
3 Pin XLR Balanced Output
1.5V AA Battery/48V Phantom Power
Φ22mm x L 280mm
172g
10
