Commax DP-201LA User manual

DOOR PHONE DP-201LA
User Manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.

2
To prevent fire or shock hazard, do not
This symbol is intended to alert the use to the presence of
“
“dangerous Voltage
”
”within the product s
’
enclose that
risk of electric shock to persons.
1. Warning and caution
CAUTION : To reduce the risk of electric shock, do not remove
refer servicing to qualified service personnel
caution
Risk of electric shock
do not open
expose the unit to rain or moisture.
uninsulated
may be of sufficient magnitude to constitute a
This symbol is intended to alert the use to the presence of
literature accompanying the appliance.
important operating and maintemance(servicing)
instructions in the
cover(or back) no user-serviceable part inside
Controls and functions
ROOM STATION
DOOR STATION
SPEAKER
CALL BUTTON
WALL MOUNTING BRACKET
MICROPHONE
VOLUME SWITCH
HANDSET
DOOR RELEASE BUTTON
HANDSET CORD
POWER CORD
2. Overview

3
3. Operation
1. When the call button( on the door station) is pressed, the chime
2. Adjust the volume switch(on the room station) to control the call
3. Pick up the handset( on the room station) to talk.
4. Press the door release button(on the room station) to open the door.
The door-lock should be instatlled.
5. Place the handset to finish talking.
4. Wiring
ROOM STATION
DOOR
DOOR
STATION
LOCK
5. Specification
①Connect two wires of door
①②of
room station terminal
②Connect electrical door-lock
to the terminal
station to the
⑤ ⑥
as below picture.
③When finished the connection
put in the power cord at AC
outlet.
sounds.
sound.
OUTPUT POWER
POWER SOURCE 220V~, 50Hz High 300mW across 8 ohm
Low 50mW across 8 ohm
DISTANCE 100m(Ø0.65mm), 150m(Ø0.8mm)
DIMENSION 208(D) X 98 (W) X 65(H)mm / Room station.
WEIGHT 700g
DOOR-STATION DR-201D / DR-201H / DR-201A/DR-2R/DR-2L

Printed In Korea / 2016.04.105
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; [phone]~550 Fax.; [phone]
Web site : www.commax.com
