DOOR STATION DP-3HP
User Manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.

2
1. Introduction................................................... 3
2. Important Safeguards ................................... 4
3. Part name and Function ................................5
4. General Function .......................................... 6
5. Installation .....................................................7
6. Wiring Diagram ..............................................8
7. Component Parts .......................................... 9
6. Specification .............................................. 10
Contents

3
Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the
unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided
below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.
Model No. Serial No.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
This symbol is intended to alert the use to the presence of uninsulated
“
“dangerous Voltage” ”
within the product’s enclose that
may be of sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the
literature accompanying the appliance
CAUTION: To reduce the risk of electrix shick, do not remove cover(or back) no user-serviceable
part sinside refer servicing to quaured service personnel
caution
Rosk of electric shock
do not open
1. Introduction

4
▲
DamageRequiringService:This equipment from the power source and source and refer servicing to qualified service personnel under the following
conditions:
ⓐwhenthepowerisdamaged.
ⓑifliquid hasbeenspiled orobjectshavehallen intotheunit
ⓒifthe equipmenthasbeen exposedtorain orwater.
ⓓifthe equipmenthasbeem droppedorotherwise damaged.
ⓔwhenthe equipmentexhibitsa distinctchangeinperformance- thisindicatesa needforservice.
▲ Waterand Moisture:Do not use this productnear water, for example, near abath tub, wash bowl, kitchensink,or laundru tub, in awet basement, or near
aswimming pool,andthe like.
▲ Accessories:The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any mounting of the manufacture’s
insturctions,and shouldusea mountingaccessoryrecommendedby themanufacturer.
▲ Objectand Liquid Entry:Neverpushobjects ofanykindinto thisproductthrough openingsasthey maytouchdangerousvoltage pointsorshort-out parts
thatcould resultina fireorelectricshock. Neverspillliquid ofanykind ontheproduct.
▲ Lightning:For added protection for this product before a lihgtning storm, or when it is left un attached and un used for long periods of time, unplug it from
the wall outlt and disconnect the other system. This will prevent damage to the product due to lightming and power-line surges. If you live in an
ared heavily prone to lightning stoms, it is recommended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge
protectorsto protectyourappliance systemfrompossipledamage
2. Important Safeguards

X
Y
Z
[
\
5
3. Part name and Function
No. Part name
①Volume Controller
②Handset
③Door release button
④S-cord
⑤Power Cord

6
4. General Function
● For installation of DR-3HP, separate power supply should be required to DRC-nAC/nAB
and DR-3Q is available only for individual door.
1. Call of visitor
● CASE 1 : 1 Outdoor unit
- Call a DP
- 3HP from common entrance
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press do or release button to open the door.
d) Leave the handset to end the talk.
● CASE 2 : 2 Outdoor unit
- Call a DP
- 3HP from common entrance (Outdoor unit 1)
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press door release button to open the door.
d) Leave the handset to end the talk.
- Call a DP
- 3HP from common entrance (Outdoor unit 2)
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press door release button to open the door.
d) Leave the handset to end the talk.

7
󱄿Caution
- Please avoid direct ray of sun light to install this unit.
- 1450~1500ᒠis right height from the floor.
- Please avoid the place where being affected by gas,
magnetic source and humid.
5. Installation

8
6. Wiring Diagram
DOOR
RELEASE
POWER
SOURCE
DOOR
RELEASE
POWER
SOURCE
CAMERA
1
2
3
CAMERA
DP-3HP
- Diagram
1
2
3
#1 (RE)
#2 (BL)
#3 (YE)
#1 (RE)
#2 (BL)
#3 (YE)
󱄿Camera connect in polarity
1. RED : VOICE 2. BLUE : GND 3. YELLOW : POWER (+12V)
󱄿Warning
1. In case of installation around the area where pass the high-voltage line, please use
metal tube with coaxial cable.
2. Any malfunction or abnormal aperation shall be caused by scar or peel off the wire.

9
7. Component Parts
BODY
Wall Braket
T4 x18
Screw Connector
User Manual

6. Specification
MODEL DP-3HP
Power Voltage AC220~, 50/60㎐
Power Consumption MAX : 4 W (220V/60㎐)
Transmission To Outdoor unit : 3 wires (Polarity)
Communication Method Handset
Sound From Outdoor unit : Electronic Chime
Time 60 ±20 sec
Distance 28m(Ø0.5) / 50m(Ø0.65) / 70m(Ø0.8)
Operating Temperature 0 ~ +40℃(32℉~ 104℉)
Weight 0.55 ㎏
Dimension 107(W) x195(H) x52(D)㎜
10

Printed In Korea / 2011.07.105
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; [phone]~550 Fax.; [phone]
Web site : www.commax.com
