Installation Guide for Antennas
CMAX-DM20/DM30/DM60-CPUSEi
Page 1
Installation Guide for
CMAX-DM20/DM30/ DM60-CPUSEi Antenna
Note: Please read the complete description before starting the installation! Be
sure that connectors are properly sealed from water if no cables are
connected to them after installation.
1. ASSEMBLY
Fit 3 parts together and fix with screws M8 x 16, washers and spring washers
(M8 torque: 27 Nm)
Tools required:
Wrench
,
width: 13 mm
Washer
Spring washer
Screw

Installation Guide for Antennas
CMAX-DM20/DM30/DM60-CPUSEi
Page 2
2. WALL MOUNTING
1. Mark 4 holes onto the wall as shown in the drawing above.
2. Drill 4 holes into the wall and insert appropriate dowels into holes.
3. Attach the antenna pedestal.
3. POLE MOUNTING
1. Lay proper lashing straps around pole and lead them through mounting
bracket.
2. Adjust bracket in antenna direction and fasten bracket.
Lashing
Straps
Antenna
Pedastal
Pole

Installation Guide for Antennas
CMAX-DM30-CPUSEi / CMAX-DM60-CPUSEi
Page 3
4. ANTENNA MOUNTING
4.1. DM60 ANTENNA MOUNTING
Attach antenna and
tighten it with
washers and M8 nuts
(M8 torque: 27 Nm)
4.2. DM20/DM30 ANTENNA MOUNTING
Depending on space available
and adjusting angel, the
DM/20DM30 antenna can be
mounted onto the pedestal in 3
alternatives (see circle marks in
picture to the left-hand side).
4.3. AZIMUTH ANGLE
1. Loosen the 3 fixing screws
(do NOT unscrew it
completely!)
2. Adjust your desired angle.
The complete antenna
pedestal can be swiveled to
the left / right-hand side by
up to 55°.
3. Tighten the fixing screw.
Spring
Washer
M8 nut
Washer

Installation Guide for Antennas
CMAX-DM20/DM30/DM60-CPUSEi
Page 4
4.4. ELEVATION ANGLE
Loosen 4 fixing screws
at the left and right-
hand side. (do NOT
unscrew it completely!)
2. Adjust your desired
angle.
3. Tighten fixing screws.
4.5. ANTENNA CABLE
Connected antenna cables
can be arranged and fixed
with cable ties as shown.
www.commscope.com
Visit our Web site or contact your local Andrew Wireless Solutions representative for more information.
© 2014 CommScope, Inc. All rights reserved.
Andrew Wireless Solutions is a trademark of CommScope. All trademarks identified by ® or ™ are registered trademarks or
trademarks, respectively, of CommScope.
This document is for planning purposes only and is not intended to modify or supplement any specifications or warranties
relating to AndrewWireless Solutions products or services.
Andrew Wireless Systems GmbH, June-2014
