CommScope CMAX Series User manual

Installation Instruction for CMAX Antennas
Page 1 M0149APB_Installation_CMAX-xxx-Antennas
Installation Guide for CMAX-xxx Antennas
CMAX-DM22S-43-V53, CMAX-DM22S-D-V53, CMAX-DM30-43-V53,
CMAX-DM60-43-V53, CMAX-DMH3030-43V53,
CMAX-DM30-43-UWI53, CMAX-DM60-43-UWI53,
CMAX-3030-43-US, CMAX-30-43-US, CMAX-60-43-US,
CMAX-DMW3030-43I53
Note: Please read the complete description before starting the installation. Be sure that
connectors are properly sealed from water if no cables are connected to them
after installation.
1.Assembly
Fit the 3 parts together and fasten with screws M8 x 16, washers, and spring washers
(M8 torque: 27 Nm).
Tools required:
Wrench, width: 13 mm
Washer
Spring washer
Screw

Installation Instruction for CMAX Antennas
Page 2 M0149APB_Installation_CMAX-xxx-Antennas
2.Wall Mounting
1. Mark 4 holes onto the wall as shown in the drawing above.
2. Drill 4 holes into the wall and insert appropriate dowels into holes.
3. Attach the antenna pedestal.

Installation Instruction for CMAX Antennas
Page 3 M0149APB_Installation_CMAX-xxx-Antennas
3.Pole Mounting (200 mm max. pole diameter)
3.1. Pole Mounting with Lashing Straps (suggestion)
Note: This pole mounting procedure is for reference only. Other than the shown pole
mounting material can be used to mount bracket and antenna to a pole. Make
sure the installation will safely support the combined load of the bracket, antenna,
and connected cables.
1. Lay proper lashing straps around pole and lead them through mounting bracket.
2. Adjust bracket in antenna direction and fasten bracket.
Lashing
Straps
Antenna
Pedastal
Pole
200 mm max.
1
2

Installation Instruction for CMAX Antennas
Page 4 M0149APB_Installation_CMAX-xxx-Antennas
3.2. Optional Pole Mounting Kit
Optionally, a pole-mounting kit can be ordered separately from the supplier (ID 7814722).
The recommended pole diameter for this mounting kit is 60 - 150 mm. To mount an antenna
to a pole using this kit, proceed as follows:
1. Insert the four bolts M8x200 (2) with four of the filet washers (5) into the antenna
mounting bracket (see detailed illustration of bolt head).
2. Insert the pole mounting bracket into these four bolts and place the filet & spring
washers (4 & 5) and the M8 nuts (3) over each bolt (detailed illustration).
3. Tighten the four M8 nuts observing the specified torque of 27 Nm.
4. Hang in the safety wire (6) and attach it to a suitable structure for fall protection.

Installation Instruction for CMAX Antennas
Page 5 M0149APB_Installation_CMAX-xxx-Antennas
4.Antenna Mounting
4.1. DM60 Antenna Mounting
Attach antenna and
fasten it with washers
and M8 nuts (M8
torque: 27 Nm).
4.2. DM22S/DM30 Antenna Mounting
Depending on space available
and adjusting angle, the
DM22S/DM30 antenna can be
mounted onto the pedestal in 3
alternatives (see circle marks in
picture to the left-hand side).
4.3. DMH3030/DMW3030 Antenna Mounting
Attach antenna and
fasten it with washers
and M8 nuts (M8
torque: 27 Nm).
Spring
Washer
M8 nut
Washer

Installation Instruction for CMAX Antennas
Page 6 M0149APB_Installation_CMAX-xxx-Antennas
4.4. CMAX-3030/30/60-43-US Antenna Mounting
4.5. Azimuth Angle
1. Loosen the 3 fixing screws.
(Do NOT unscrew them
completely.)
2.
Adjust your desired angle.
The complete antenna
pedestal can be swiveled to
the left- / right-hand side by
up to 55°.
3. Tighten the fixing screws.
4.6. Elevation Angle
Loosen the 4 fixing
screws at the left- and
right-
hand side. (Do
NOT unscrew them
completely.)
2.
Adjust your desired
angle.
3. Tighten fixing screws.
Attach antenna and
fasten it with washers
and M8 nuts (M8
torque: 27 Nm).

Installation Instruction for CMAX Antennas
Page 7 M0149APB_Installation_CMAX-xxx-Antennas
4.7. Antenna Cable
Connected antenna cables
can be arranged and fixed
with cable ties as shown.
4.8. Outdoor Installation
Note: For outdoor use, we recommend removing the plugs from the drain holes if the
antenna is exposed to high humidity or rainfall.
: Do not remove the plugs if the antenna is mounted other than bottom down,
that means the drain holes showing to the ground. For the top and bottom of the antenna
observe the arrow labeling at the rear side. Otherwise water might penetrate into and
therefore damage the antenna.
Remove the plugs from the drain holes at the bottom of the antenna with a knife or a flat
screwdriver. The below indicates the location of the drain holes, design and/or size of the
antenna may be different.
Bottom
Bottom

Installation Instruction for CMAX Antennas
Page 8 M0149APB_Installation_CMAX-xxx-Antennas
List of Changes
Version
Changes
Release Date
M0149APA
First Release
07-March-2019
M0149APB
List of antenna types added to header
Changed DM22 to DM22S, and DM20 deleted in chapter 4.2
Chapter 4.4 f or US antennas added
04-May-2020
© Copyright 2020 CommScope, Inc.
All rights reserved.
All information contained in this manual has been revised thoroughly. Yet CommScope accepts no liability for any omissions or faults.
CommScope reserves the right to change all hardware and software characteristics without notice.
Names of products mentioned herein are used foridentification purposes only and may be trademarks and / orregistered trademarks of
their respective companies.
No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical,
mechanicalphotocopying, recordingor otherwise, without priorwritten permission of the publisher.
CommScope, 04-May-2020
