CommScope OMX 600 Splice Bay User manual

300100112149 Rev C
www.commscope.com
ADCP-93-090
Rev C, March 2021
SPLICE BAY (STANDARD)
(RAISED FLOOR CABLE CONFIGURATION) SPLICE BAY WITH LOCKABLE SPLICE TRAY DOORS
(RAISED FLOOR CABLE CONFIGURATION) 26051-A
User Manual
OMX 600 Splice Bay
Rev
C

ADCP-93-090 • Rev C • March 2021 • Preface
Page ii
COPYRIGHT
© 2021, CommScope Inc.
All Rights Reserved
REVISION HISTORY
TRADEMARK INFORMATION
CommScope and CommScope (logo) are trademarks.
Telcordia is a registered trademark of Telcordia Technologies, Inc.
GORE is a registered trademark of W. L. Gore & Associates, Inc.
DISCLAIMER OF LIABILITY
Contents herein are current as of the date of publication. CommScope reserves the right to change the contents without prior notice.
In no event shall CommScope be liable for any damages resulting from loss of data, loss of use, or loss of profits and
CommScope further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
This disclaimer of liability applies to all products, publications and services during and after the warranty period. This
publication may be verified at any time by contacting CommScope Support Center at http://www.comscope.com/SupportCenter
ISSUE DATE REASON FOR CHANGE
1 8/2014 Original.
2 8/2015 Revised to add instructions for ribbon cable.
2 July 2016 Updated to CommScope format.
Rev C March 2021 Corrected Figure 41 and updated format.

ADCP-93-090 • Rev C • March 2021 • Preface
Page iii
© 2021, CommScope, Inc.
ABOUT THIS MANUAL
This manual contains OMX Splice Bay component descriptions, installation instructions, and
cable routing procedures (including overhead and raised floor cable routing environments) for
both the standard and lockable splice tray doors versions.This manual contains OMX Splice
Bay component descriptions, installation instructions, and cable routing procedures (including
overhead and raised floor cable routing environments) for both the standard and lockable splice
tray doors versions.
RELATED PUBLICATIONS
Listed below are related manuals and their publication numbers. Copies of these publications
can be ordered by contacting the CommScope Technical Assistance Center at
http://www.commscope.com/SupportCenter
Round Splice Tray Cable Routing Instructions 90-321
ADMONISHMENTS
Important safety admonishments are used throughout this manual to warn of possible hazards to
persons or equipment. An admonishment identifies a possible hazard and then explains what
may happen if the hazard is not avoided. The admonishments — in the form of Dangers,
Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of
the triangular alert icon (seen below) and are listed in descending order of severity of injury or
damage and likelihood of occurrence.
GENERAL SAFETY PRECAUTIONS
Title/Description ADCP Number
Danger: Danger is used to indicate the presence of a hazard that will cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Warning: Warning is used to indicate the presence of a hazard that can cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Caution: Caution is used to indicate the presence of a hazard that will or can cause minor
personal injury or property damage if the hazard is not avoided.
Warning: Never install communication equipment in a wet location or during a lightning
storm. When installing or modifying communication lines, disconnect lines on the network side
before working with uninsulated wires or terminals.

ADCP-93-090 • Rev C • March 2021 • Preface
Page iv
© 2021 CommScope, Inc.
STANDARDS CERTIFICATION
Telco rdia: This equipment complies with the applicable sections of GR-3125-CORE.
LIST OF ACRONYMS AND ABBREVIATIONS
The acronyms and abbreviations used in this manual are detailed in the following list:
AWG American Wire Gauge
CCentigrade
FFahrenheit
FDH Fiber Distribution Hub
FMS Fiberglass Mounting Sleeve
FTTP Fiber To The Premises
IFDH Indoor Fiber Distribution Hub
OSP Outside Plant
PMF Pad Mount Frame
PNP Plug and Play
RBR Reduced Bend Radius
RMA Return Material Authorization
Danger: Do not look into the ends of any optical fiber. Exposure to laser radiation may result.
Do not assume the laser power is turned-off or that the fiber is disconnected at the other end.
Danger: Use adequate lifting equipment when moving or installing Fiber Distribution Hub
cabinets. Verify that the maximum lift weight rating of the equipment is sufficient to handle the
weight of the cabinet.
Danger: Do not stand under a Fiber Distribution Hub cabinet as it is being hoisted into
position for mounting. A failure of the lifting equipment or apparatus could result in serious
personal injury and cause significant damage to the cabinet.
Warning: Before digging, check with all local utilities for the presence of buried cables or
pipes. Contact with underground cables or pipes, especially electric power cables and gas
service lines, could interrupt local utility service and cause serious personal injury and
extensive property damage.

ADCP-93-090 • Rev C • March 2021 • Preface
Page 1
© 2021, CommScope, Inc.
TABLE OF CONTENTS
Content Page
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Admonishments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Standards Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
List of Acronyms and Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1 PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 OMX600 Splice Bay (Equipped with Locking Splice Tray Doors). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 OMX Splice Bay without Locking Splice Tray Doors (Standard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2.1 72- to 96-Fiber IFC Frame Re-Configuration, Raised Floor Cable Environment . . . . . . . . . . . . . . . 2
1.2.2 72-to 96-Fiber IFC Frame Re-Configuration, Overhead Cable Environment . . . . . . . . . . . . . . . . . . 3
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Door Lock Assembly (Lockable Splice Tray Door Configuration, Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.1 Raised Floor Cable Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.2 Overhead Cable Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 CABLE ROUTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 OMX Splice Bay with Locking Splice Tray Doors (Raised Floor Cable Environment) . . . . . . . . . . . . . . . . . . 6
3.2 OMX Splice Bay with Locking Splice Tray Doors (Overhead Cable Environment) . . . . . . . . . . . . . . . . . . . . 10
3.3 OMX Splice Bay without Locking Splice Tray Doors (Raised Floor Cable Environment). . . . . . . . . . . . . . . 14
3.3.1 72-Fiber IFC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3.2 96-Fiber IFC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4 OMX Splice Bay without Locking Splice Tray Doors (Overhead Cable Environment) . . . . . . . . . . . . . . . . . 22
3.4.1 72-Fiber IFC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4.2 96-Fiber IFC Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.5 OMX Splice Cabinet Density Using Ribbon Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4 GROUND INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.1 Ground Front Doors to Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.2 Ground OMX Splice Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3 Ground OSP Cable (with Metallic Sheath Members) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.4 OSP Cable Grounding Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5 TECHNICAL ASSISTANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

ADCP-93-090 • Rev C • March 2021 • Preface
Page 2
© 2021, CommScope, Inc.
TABLE OF CONTENTS
Content Page

ADCP-93-090 • Rev C • March 2021
Page 1
© 2021 CommScope, Inc.
1 PRODUCT DESCRIPTION
1.1 OMX600 Splice Bay (Equipped with Locking Splice Tray Doors)
The OMX600 Splice Bay provides a splicing location for OSP (outside plant) and IFC (intrafacility
cable) cables. The splice bay, equipped with locking splice tray doors, can accommodate up to 84
round splice trays (1008 total splices). Figure 1 shows the main components of the splice bay
equipped with locking splice tray doors.
Figure 1. OMX600 Splice Bay (Raised Floor Cable Environment)
CABLE ENTRANCE
(OVERHEAD CABLE
ENVIRONMENT)
FRONT DOOR
(HINGED)
NOTE: RAISED FLOOR CABLE
ENVIRONMENT SHOWN. SPLICE TRAYS ARE
ORIENTED FOR OVERHEAD
CABLE ENVIRONMENT APPLICATION
26054-A
CABLE
BRACKETS
SPLICE TRAY
DOOR
(LOCKABLE)
CABLE ENTRANCE
(RAISED FLOOR
CABLE ENVIRONMENT)

ADCP-93-090 • Rev C • March 2021
Page 2
© 2021, CommScope, Inc.
1.2 OMX Splice Bay without Locking Splice Tray Doors (Standard)
The OMX600 Splice Bay provides a splicing location for OSP (outside plant) and IFC
(intrafacility cable) cables and can accommodate up to 120 round splice trays (1440 splices). The
standard version’s cable clamp positions also can be custom configured. For IFC counts in
multiples of 72 (as shipped), use the 72-fiber IFC configuration (Figure 2 or Figure 3, depending
on cable origin, left view); for IFC counts in multiples 96, use the 96-fiber IFC configuration
(Figure 2 and 3, depending on cable origin, right view). For IFC counts in multiples of 96,
reposition cable brackets as shown in Figures 2 and 3, depending on cable origin.
1.2.1 72- to 96-Fiber IFC Frame Re-Configuration, Raised Floor Cable Environment
Figure 2. 72- to 96-Fiber IFC Frame Re-Configuration, Raised Floor Cable Environment
(Shown without Front Doors) (Front View)
26055-A
72-FIBER IFC
CABLE CONFIGURATION
96-FIBER IFC
CABLE CONFIGURATION
REPOSITIONED CABLE
TIE-DOWN BRACKETS
MOVE UP
ONE POSITION
MOVE DOWN
ONE POSITION
REMOVE
NO CHANGE
CABLE BRACKET
NO
NO
NO
LEGEND

ADCP-93-090 • Rev C • March 2021
Page 3
© 2021 CommScope, Inc.
1.2.2 72-to 96-Fiber IFC Frame Re-Configuration, Overhead Cable Environment
Figure 3. 72- to 96-Fiber IFC Frame Re-Configuration, Overhead Cable Environment
Shown without Front Doors) (Front View)
26055-A
72-FIBER IFC
CABLE CONFIGURATION
96-FIBER IFC
CABLE CONFIGURATION
REPOSITIONED CABLE
TIE-DOWN BRACKETS
MOVE
UP
ONE
POSITION
MOVE
DOWN
ONE
POSITION
REMOVE
NO
CHANGE
CABLE BRACKET
NO
NO
NO
LEGEND

ADCP-93-090 • Rev C • March 2021
Page 4
© 2021, CommScope, Inc.
2INSTALLATION
2.1 Door Lock Assembly (Lockable Splice Tray Door Configuration, Only)
2.1.1 Raised Floor Cable Environment
Each splice door provides a location for a lock assembly. Figure 4 and Figure 5 show the lock
assembly installation procedure for raised floor and overhead cable environments, respectively.
Figure 4. Door Lock Installation (Raised Floor Cable Environment)
Warning: Never install communication equipment in a wet location or during a lightning
storm. When installing or modifying communication lines, disconnect lines on the network side
before working with uninsulated wires or terminals.
26057-A
STOP
CAM
KEY SET
NOTE: MAKE SURE STRAIGHT CAM IS
ORIENTED UP, AS SHOWN, FOR RAISED
FLOOR CONFIGURATIONS
!
THREADED
CYLINDER
(LOCK)
LOCK
WASHER
STRAIGHT
CAM
(SEE
NOTE)
DOOR
LOCK
NUT
BEZEL
CYLINDER
NUT

ADCP-93-090 • Rev C • March 2021
Page 5
© 2021 CommScope, Inc.
2.1.2 Overhead Cable Environment
Figure 5. Door Lock Assembly (Overhead Cable Environment)
26058-A
STOP
CAM
KEY SET
NOTE: MAKE SURE STRAIGHT CAM IS
ORIENTED UP, AS SHOWN, FOR RAISED
FLOOR CONFIGURATIONS
!
THREADED
CYLINDER
(LOCK)
LOCK
WASHER
STRAIGHT
CAM
(SEE
NOTE)
DOOR
LOCK
NUT
BEZEL
CYLINDER
NUT

ADCP-93-090 • Rev C • March 2021
Page 6
© 2021, CommScope, Inc.
3 CABLE ROUTING
3.1 OMX Splice Bay with Locking Splice Tray Doors (Raised Floor Cable Environment)
Figure 6 shows an example of a fully cabled splice bay (front view).
Figure 6. Fully Cabled Splice Bay (Front View)
26059-A
ROUTE OF IFC CABLES
ON OUTSIDE
OF CABLE BRACKETS
ROUTE OF OSP CABLES
ON INSIDE
OF CABLE BRACKETS
STARTING AT LOWEST CABLE
BRACKET, ROUTE CABLES
CLOSEST TO FRAME, AND
WORK UP AND OUT
ROUTE OSP AND IFC CABLES
TO THEIR RESPECTIVE SPLICE
TRAYS . USING TUBING, SECURE
CABLES TO TIE-DOWN LANCE
ON FRAME
CABLE
BRACKET
OSP
CABLES
IFC
CABLES
123
(7.62 CM)
3 IN.

ADCP-93-090 • Rev C • March 2021
Page 7
© 2021 CommScope, Inc.
Use the following procedure.
1. Route and secure OSP cable to the bay as shown in Figure 7.
Figure 7. OSP Cable Routing (Raised Floor Cable Environment)
26060-A
10-32
SCREW
(2)
OSP CABLE
CLAMP ASSEMBLY
FRONT
VIEW
TOKE (2)
GROMMET
NOTE: FOR OSP CABLE WITH METALLIC
SHEATH MEMBERS, SEE SECTION 4.3
ON PAGE 39
!

ADCP-93-090 • Rev C • March 2021
Page 8
© 2021, CommScope, Inc.
2. Route and secure IFC cable to the bay as shown in Figure 8.
Figure 8. IFC Cable Routing (Raised Floor Cable Environment)
26061-A
TIE-DOWN
LACE
CORRUGATED
TUBING
WIRE
TIE
OSP
CABLE
IFC
CABLE
OSP
CABLE
IFC
CABLE
SECURE
COVER (2)
YOKE (2)
GROMMET
IFC CABLE
CLAMP ASSEMBLY
1
2
3
4
FRONT VIEW

ADCP-93-090 • Rev C • March 2021
Page 9
© 2021 CommScope, Inc.
3. Route second OSP and IFC cable, respectively, as shown in Figure 9.
Figure 9. Second OSP and IFC Cable Routing Procedure

ADCP-93-090 • Rev C • March 2021
Page 10
© 2021, CommScope, Inc.
3.2 OMX Splice Bay with Locking Splice Tray Doors (Overhead Cable Environment)
Figure 10 shows an example of a fully cabled splice bay (front view).
Figure 10. Fully Cabled Splice Bay (Front View)
26053-A
ROUTE OF IFC CABLES ON
OUTSIDE OF CABLE BRACKETS
ROUTE OF OSP CABLES
ON INSIDE
OF CABLE BRACKETS
STARTING AT LOWEST CABLE
BRACKET, ROUTE CABLES
CLOSEST TO FRAME, AND
WORK UP AND OUT
ROUTE OSP AND IFC CABLES
TO THEIR RESPECTIVE SPLICE
TRAYS. USING TUBING, SECURE
CABLES TO TIE-DOWN LANCE
ON FRAME
CABLE
BRACKET
OSP
CABLES
IFC
CABLES
12
3
(7.62 CM)
3 IN.
WIRE TIE
CORRUGATED
TUBING

ADCP-93-090 • Rev C • March 2021
Page 11
© 2021 CommScope, Inc.
Use the following procedure.
1. Route and secure OSP cable to the bay as shown in Figure 11.
Figure 11. OSP Cable Routing (Overhead Cable Environment)
Note: For OSP cable with metallic sheath members, see Section 4.3, “Ground OSP Cable
(with Metallic Sheath Members)” on page 34.
26064-A
10-32
SCREW
(2)
OSP CABLE
CLAMP ASSEMBLY
TOKE (2)
GROMMET

ADCP-93-090 • Rev C • March 2021
Page 12
© 2021, CommScope, Inc.
2. Route and secure IFC cable to the bay as shown in Figure 12.
Figure 12. IFC Cable Routing (Overhead Cable Environment)
26065-A
TIE-DOWN
LACE
CORRUGATED
TUBING
WIRE
TIE
OSP
CABLE
IFC
CABLE
OSP
CABLE
IFC
CABLE
SECURE
COVER (2)
YOKE (2)
GROMMET
IFC CABLE
CLAMP ASSEMBLY
12 3 4
FRONT VIEW

ADCP-93-090 • Rev C • March 2021
Page 13
© 2021 CommScope, Inc.
3. Route second OSP and IFC cable, respectively, as shown in Figure 13.
Figure 13. Second OSP and IFC Cable Routing Procedure
26065-A
OSP
CABLE
IFC
CABLE
FRONT VIEW

ADCP-93-090 • Rev C • March 2021
Page 14
© 2021, CommScope, Inc.
3.3 OMX Splice Bay without Locking Splice Tray Doors (Raised Floor Cable Environment)
3.3.1 72-Fiber IFC Configuration
Figure 14 shows an example of a fully cabled splice bay (front view).
Figure 14. Fully Cabled Bay (Front View, 72-Fiber IFC Configuration)
ROUTE OF IFC CABLES
ON OUTSIDE
OF CABLE BRACKETS
ROUTE OF OSP CABLES
ON INSIDE
OF CABLE BRACKETS
STARTING AT LOWEST CABLE
BRACKET, ROUTE CABLES
CLOSEST TO FRAME, AND
WORK UP AND OUT
ROUTE OSP AND IFC CABLES
TO THEIR RESPECTIVE SPLICE
TRAYS . USING TUBING, SECURE
CABLES TO TIE-DOWN LANCE
ON FRAME
CABLE
BRACKET
OSP
CABLES
IFC
CABLES
123
(7.62 CM)
3 IN.
