Fiber Termination Block With MPO Connectors (FTB w/MPO)
User Manual
Next Generation Frame (NGF)

ADCP-90-372 • Rev B • April 2018 • Preface
Page ii
COPYRIGHT
© 2018, CommScope Inc.
All Rights Reserved
REVISION HISTORY
TRADEMARK INFORMATION
CommScope and CommScope (logo), are trademarks.
Telcordia is a registered trademark of Telcordia Technologies, Inc.
GORE is a registered trademark of W. L. Gore & Associates, Inc.
DISCLAIMER OF LIABILITY
Contents herein are current as of the date of publication. CommScope reserves the right to change the contents without prior notice.
In no event shall CommScope be liable for any damages resulting from loss of data, loss of use, or loss of profits and
CommScope further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
This disclaimer of liability applies to all products, publications and services during and after the warranty period.
This publication may be verified at any time online by contacting CommScope Technical Assistance Center using the following
URL: http://www.commscope.com/SupportCenter
ISSUE DATE REASON FOR CHANGE
2 4/2010 Updated to add MPO connector interface.
Rev B April 2018 Updated to CommScope format.

ADCP-90-372 • Rev B • April 2018 • Preface
Page iii
© 2018, CommScope, Inc.
TABLE OF CONTENTS
Content Page
About This Month . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Admonishments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
General Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
List of Acronyms and Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
1 PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Product Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Main Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 Options That Affect Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6.1 Interconnect Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6.2 Cross-Connect Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.7 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 UNPACKING AND INSPECTING THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 MOUNTING THE FTB ON THE RACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 MPO TRUNK CABLE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 Preparing Cable for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Routing and Securing the Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 12-STRAND MPO CABLE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.1 Routing and Securing the Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 PATCH CORD INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 CUSTOMER INFORMATION AND ASSISTANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

ADCP-90-372 • Rev B • April 2018 • Preface
Page iv
© 2018, CommScope, Inc.
TABLE OF CONTENTS
Content Page
Blank Page

ADCP-90-372 • Rev B • April 2018 • Preface
Page v
© 2018, CommScope, Inc.
ABOUT THIS MONTH
This user manual provides the following information:
• A description of Fiber Termination Block with MPO Connectors (FTB w/MPO).
• Procedures for installing an FTB w/MPO on a Next Generation Frame (NGF);
• Procedures for routing and connecting an MPO trunk cable to the FTB w/MPO;
• Guidelines for connecting patch cords to the FTB w/MPO.
The procedures for installing the various NGF racks and accessories are provided in other
CommScope publications (see “Related Publications,” below).
RELATED PUBLICATIONS
Listed below are related manuals and their publication numbers. Copies of these publications can
be ordered by contacting the CommScope Technical Assistance Center using the URL:
http://www.commscope.com/SupportCenter
NGF Fiber Main Distributing Frame User Manual 90-273
Provides a complete description of the FMDF and procedures for installing the
FMDF rack, the FTB, and the FCB.
NGF Slim Rack Installation Guide 90-274
Provides a complete description of the FMDF and procedures for installing the
FMDF rack, the FTB, and the FCB.
NGF Fiber Optic Terminal Storage Bay User Manual 90-270
Provides instructions for installing the FOTSB with the FMDF rack.
Fiber Main Distribution Frame (FMDF)
Interconnect and Cross-Connect Patch Cord Routing Guide 90-240
Provides instructions for installing and routing patch cords.
MPO Assembly Field Testing and Repair Instructions 90-378
Provides instructions for testing, repairing, and cleaning MPO connectors.
Optical Fiber Connector Wet and Dry Cleaning Instructions 90-159
Provides instructions for cleaning optical connectors.
Multifiber-Push On (MPO) Assembly Connector Cleaning Instructions 90-160
Provides instructions for cleaning MPO assembly connectors.
Title/Description ADCP Number

ADCP-90-372 • Rev B • April 2018 • Preface
Page vi
© 2018, CommScope, Inc..
ADMONISHMENTS
Important safety admonishments are used throughout this manual to warn of possible hazards to
persons or equipment. An admonishment identifies a possible hazard and then explains what
may happen if the hazard is not avoided. The admonishments — in the form of Dangers,
Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of
the triangular alert icon (seen below), and are listed in descending order of severity of injury or
damage and likelihood of occurrence.
GENERAL SAFETY PRECAUTIONS
LIST OF ACRONYMS AND ABBREVIATIONS
The following acronyms are used in this manual:
FMDF Fiber Main Distributing Frame
FTB Fiber Termination Block
FTB w/MPO Fiber Termination Block With MPO Connectors
MPO Multifiber Push-on Connector
NGF Next Generation Frame
Danger: Danger is used to indicate the presence of a hazard that will cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Warning: Warning is used to indicate the presence of a hazard that can cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Caution: Caution is used to indicate the presence of a hazard that will or can cause minor
personal injury or property damage if the hazard is not avoided.
Danger: Infrared radiation is invisible and can seriously damage the retina of the eye. Do not
look into the ends of any optical fiber. Do not look directly into the optical adapters of the
adapter packs. Exposure to invisible laser radiation may result. An optical power meter should
be used to verify active fibers. A protective cap or hood MUST be immediately placed over any
radiating adapter or optical fiber connector to avoid the potential of dangerous amounts of
radiation exposure. This practice also prevents dirt particles from entering the adapter or
connector.

ADCP-90-372 • Rev B • April 2018
Page 1
© 2018, CommScope, Inc.
1 PRODUCT DESCRIPTION
This section describes the CommScope Fiber Termination Block with MPO Connectors (FTB
w/MPO). The FTB w/MPO is available with 96, 144, or 192 terminations per block.
1.1 General Description
The FTB w/MPO is used on a NGF rack to provide a point for terminating MPO trunk cables.
The FTB separates out the multiple circuits within each MPO connector into its component
individual circuits. The circuits are terminated to factory-installed pigtails that are routed within
the FTB to individual connectors in sliding adapter packs. Figure 1 shows the FTB exploded out
from an NGF frame.
MPO trunk cables terminate at the rear of the FTB where the MPO connectors mounted in the
block are accessed. Cross-connect or interconnect patch cords terminate at the front of the FTB
where the sliding adapter packs are accessed. The NGF rack, on which the FTB is mounted,
provides physical support and cable management.
The FTB w/MPO has a left or right orientation for installation on either the left or right side of
the NGF rack (as viewed from the front).
Figure 1. FTB Block With MPO Connectors Exploded Out From a NGF Frame
26631-A

ADCP-90-372 • Rev B • April 2018
Page 2
© 2018, CommScope, Inc.
1.2 Product Function
An MPO trunk cable contains multiple fibers terminated at a single connector. The FTB
separates out the multiple circuits within each MPO connector into its component individual
circuits. The individual circuits are routed through pigtails to individual connectors on sliding
adapter packs. By sliding out an adapter pack and connecting an interconnect or cross-connect
patch cord, a technician easily routes an individual circuit to a local device. In a reverse
direction, the FTB can be used to consolidate 12 individual circuits into a single MPO cable for
routing within a facility or to a network element. Figure 2 is a schematic of product function.
Figure 2. FTB w/MPO Product Function
1.3 Main Components
An FTB w/MPO block consists of a sheet metal chassis with physical features providing for
mounting of MPO connectors on the back of the chassis, mounting of sliding adapter packs on
the front, and placement of factory-installed internal pigtails between the MPO connectors and
sliding adapters. The 96-position chassis accepts sliding adapter packs with four adapters each.
The adapters are arranged in twelve rows, each with two adapter packs (12x2x4). The 144-
position chassis accepts sliding adapter packs with six adapters each (12 rows of 2x6). The 192-
position chassis accepts sliding adapter packs with eight adapters each (12 rows of 2x8). The
adapter packs are available with SC and LC ultra-polish adapters. Figure 3 shows the 144
position chassis.
The FTB chassis has a removable side cover and two hinged front covers. Removing the side
cover provides access to the rear cable management area where the connectors used for
terminating MPO trunk cables are located. The rear cable management area also has an upper
radius limiter and other features designed for securing and routing a MPO trunk cable.
MULTIPLE CIRCUITS
WITHIN ONE CABLE
MPO
CONNECTOR
INDIVIDUAL
CIRCUITS
IN PIGTAILS
ADAPTER
PAC K S INTERCONNECT
OR CROSS-CONNECT
PATCH CORD
INDIVIDUAL
CIRCUIT
INDIVIDUAL
DEVICE
22676-A

ADCP-90-372 • Rev B • April 2018
Page 3
© 2018, CommScope, Inc.
Opening the FTB front covers provides access to the adapter packs (by sliding them out) and to
the front radius limiters which facilitate the routing of interconnect or cross-connect patch
cords. The front covers also include designation labels to identify the optical circuits.
Figure 3. Fiber Termination Block With MPO Connectors
(144-Position Chassis Shown)
1.4 Options That Affect Installation
The following FTB ordering options may affect the installation process:
• The FTB may be ordered with a left or right orientation. The left-orientation FTB installs
on the left side of the frame (when facing the front of the frame); the right-orientation FTB
installs on the right side of the frame.
• The FTB may be ordered any of several different types of internal pigtails. Included are
50/125 um laser optimized to 300 m, 50/125 um. 62.5/125 um, and singlemode.
• The FTB may be ordered any of several different types of connectors. For a complete list,
refer to Table 1 on Page 5.
SLIDING
ADAPTER
PAC K
LOWER
RADIUS
LIMITER
FRONT
RADIUS
LIMITERS
UPPER
RADIUS
LIMITER
23885-A
HINGED
FRONT
COVERS

ADCP-90-372 • Rev B • April 2018
Page 4
© 2018, CommScope, Inc.
1.5 Accessories
The following accessories are available for use with the FTB:
•Patch Cords—Are available with specified connectors in standard lengths of 6.0, 7.0, 8.0,
9.0, 10.0, and 12.0 meters.
•Connector Cleaning Kit—Provides all the materials required to clean fiber optic
connectors and adapters. Two types are required: a ferrule mote kit for the adapter
connectors on front of the block, and an MPO kit for the MPO connectors on back.
1.6 Applications
The FTB may be used to support either interconnect or cross-connect frame applications. Both
are described below.
1.6.1 Interconnect Application
In an interconnect application, only MPO trunk cables are terminated at the rear of the frame.
Network elements are connected directly to the trunk cables using interconnect patch cords. The
excess patch cord slack is stored in the slack storage area on the front of the frame. Figure 4
shows a typical interconnect application using the FMDF. An interconnect application uses the
entire frame for terminating trunk cables. An overhead or underfloor fiber raceway system such
as the FiberGuide system must be used for routing the interconnect patch cords to the frame.
Figure 4. Typical Interconnect Application
1.6.2 Cross-Connect Application
In a cross-connect application, both network elements and MPO trunk cables are terminated at
the rear of the frame. A network element may be connected to a trunk cable, a network element
may be connected to another network element, or a trunk cable may be connected to another
trunk cable, using a cross-connect patch cord.
MPO
TRUNK
CABLE
NETWORK ELEMENT
PATCH CORD
ADAPTER
PIGTAIL
INTERCONNECT WITH MPO TRUNK
CABLE TERMINATED AT FTB
22707-C
FTB
FRONT

ADCP-90-372 • Rev B • April 2018
Page 5
© 2018, CommScope, Inc.
The excess patch cord slack is stored in the slack area on the front of the frame. Figure 5 shows
a typical cross-connect application using the FMDF.
Figure 5. Typical Cross-connect Application
1.7 Specifications
2 UNPACKING AND INSPECTING THE PRODUCT
Use the following procedure to unpack and inspect the FTB w/MPO:
1. Inspect the exterior of the shipping container for evidence of rough handling that may have
damaged the contents of the container.
2. Unpack the FTB and inspect for possible damage.
Table 1. FTB Specifications
PARAMETER SPECIFICATION REMARKS
Number of Terminations 96, 144, or 192
Connector types singlemode SC ultra polish; singlemode SC angled polish;
multimode SC; multimode SC aqua (for 10 Gig applications)
96 or 144 only
singlemode LC ultra polish, singlemode LC angled polish;
multimode LC; multimode LC aqua (for 10 Gig applica-
tions)
144 or 192 only
Operating Temperature –40° C to 65° C (–40° F to149° F)
Storage Temperature –55° C to 85° C (–85° F to185° F)
Relative Humidity
Operating Up to 80% No condensation
Storage Up to 95% No condensation
MPO
TRUNK
CABLE
NETWORK
ELEMENT
PATCH CORD
ADAPTER
CROSS-CONNECT WITH MPO TRUNK CABLE
TERMINATED AT FTB AND NETWORK ELEMENT
PATCH CORDS TERMINATED AT FTB 22708-C
CROSS-CONNECT
PATCH CORD
PIGTAIL
FTB
FTB
FRONT

ADCP-90-372 • Rev B • April 2018
Page 6
© 2018, CommScope, Inc.
3. If damage is detected or if parts are missing, file a claim with the commercial carrier and
then notify CommScope Customer Service (http://www.commscope.com/SupportCenter).
Save damaged carton for inspection by carrier.
4. Even if no damage is evident, save the shipping container in case the equipment requires
shipment at a future date.
3 MOUNTING THE FTB ON THE RACK
Use the following procedure to mount the FTB on the NGF rack (see Figure 6):
1. Unpack the FTB.
Figure 6. FTB Installation on Rack
2. Locate the designated mounting position for the FTB. In a new rack installation, the rack
may be populated by starting at the bottom and working toward the top or by starting at the
top and working toward the bottom. Left-oriented FTBs mount only on the left side of the
rack and right-oriented FTBs mount only on the right side of the rack.
Note: If installing a 144 position FTB with SC or LC adapters on a 30-inch standard frame
(NGFB-MDF7A100-30 or NGF-MDF7A100-30), remove the long brackets on the frame
and replace them with the short brackets provided with the FTB per the installation
instructions provided. If installing a 144 position FTB with SC or LC adapters on a 30-
inch short bracket frame (NGFB-MDF7A144-30), discard the separate short brackets;
they are not needed.
26631-A

ADCP-90-372 • Rev B • April 2018
Page 7
© 2018, CommScope, Inc.
3. Slide the FTB onto the appropriate mounting bracket at the front of the rack as shown in
Figure 6.
4. Secure the FTB to the rack mounting bracket using the two #12-24 screws provided.
5. Repeat steps 1–4 for each FTB.
4 MPO TRUNK CABLE INSTALLATION
This involves first preparing the cable and then routing the cable and securing it on the rack. For
details, refer to the topics below.
4.1 Preparing Cable for Installation
Before being installed, the MPO trunk cable must be broken out using the breakout dimensions
shown in Figure 7.
Figure 7. MTO Trunk Cable Breakout Dimensions
4.2 Routing and Securing the Cable
MPO trunk cables maybe routed into the FTB from either above or below the rack. Use the
following procedure for routing and securing the MPO cable (see Figure 8 and Figure 9).
Caution: Inspect each cable and clean the MPO connectors before connecting the cable. For
instructions, refer to ADCP-90-379.
13.5 IN.
(34.3 CM)
ONE STRAND
(12 CIRCUITS)
MPO TRUNK
(12 STRANDS) FURCATION
22714-A

ADCP-90-372 • Rev B • April 2018
Page 8
© 2018, CommScope, Inc.
1. Route the MPO cable from above or below the rack corresponding to the arrangement
shown in Figure 8 and Figure 9.
2. Locate the cable tying position on the cable tie brackets on the side of the rack. Using
cable lacing, tie down the cable. Position all furcations at the rear of the tie bar as shown.
3. Connect the MPO connectors as shown.
4. Repeat this procedure for each cable being installed.
Figure 8. MPO Trunk Cable Routing Into FTB (Rear View)
Note: For the top FTB in a top entry application, secure the cable to the ladder rack
overhead, as indicated in Figure 10.
FTB
FTB
RACK
TIE OFF ON
TIE NEXT TO
BLOCK
MPO
TRUNK
13.5-INCH
SUB-UNIT
FURCATION
FTB
FTB
RACK
TIE OFF ON
TIE ONE BLOC
K
ABOVE
FURCATION
MPO
TRUNK
13.5-INCH
SUB-UNIT
BOTTOM ENTRY TOP ENTRY
23870-A

ADCP-90-372 • Rev B • April 2018
Page 9
© 2018, CommScope, Inc.
Figure 9. Routing MPO Trunk Cables on NGF Rack (Side View)
1 2 3 4 5 6
BOTTOM ENTRY 22643-A
FOR BOTTOM ENTRY, PLACE
AND SECURE CABLES AS SHOWN.
FRAME MAY BE POPULATED
FROM THE BOTTOM OR TOP.
MPO
12-STRANDS
ALTERNATE
CUT-OUT FOR
CABLE TIE
FTB MOUNTING
BRACKET
CABLE
TIE BAR
USE WAX STRING
OR CABLE TIES
(PER LOCAL PRACTICE)
TO SECURE CABLE TO
CABLE TIE BRACKET
MPO 6
MPO 5
MPO 4
MPO 3
MPO 2
MPO 1
MPO 6
MPO 5
MPO 4
MPO 3
MPO 2
MPO 1
6 5 4 3 2 1
TOP ENTRY
FOR TOP ENTRY, PLACE AND
SECURE CABLES AS SHOWN.
FRAME MAY BE POPULATED
FROM THE BOTTOM OR TOP.
MPO
TRUNK
CABLE
LADDER
RACK
NOTE:
POSITION ALL
FURCATIONS
AT REAR OF
TIE BAR.

ADCP-90-372 • Rev B • April 2018
Page 10
© 2018, CommScope, Inc.
Figure 10. Top Entry MPO Cable, Top FTB
5 12-STRAND MPO CABLE INSTALLATION
Routing and installation of 12-strand MPO cables is similar to routing and installation of MPO
trunk cables except no cable breakout is required.
5.1 Routing and Securing the Cable
MPO 12-strand cables maybe routed into the FTB from either above or below the rack. Use the
following procedure.
1. Measure out a length 13.5 inches (34.3 cm) from the connector and mark a tie-down point
as shown in Figure 11. This is the point at which the cable will be tied to the rack.
2. Route the MPO cable from above or below the rack as shown in Figure 12.
Figure 11. Marking Out Tie-Down Point
Caution: Inspect each cable and clean the MPO connectors before connecting the cable. For
instructions, refer to ADCP-90-378.
SECURE CABLES
TO LADDER RACK
26632-A
MPO
CONNECTOR
TIE-OFF
POINT
13.5 IN.
(34.3 CM)
22721-A

ADCP-90-372 • Rev B • April 2018
Page 11
© 2018, CommScope, Inc.
Figure 12. Routing MPO 12-Strand Cables on NGF Rack (Side View)
1 2 3 4 5 6
BOTTOM ENTRY 22722-A
FOR BOTTOM ENTRY, PLACE
AND SECURE CABLES AS SHOWN.
FRAME MAY BE POPULATED
FROM THE BOTTOM OR TOP.
MPO
12-STRAND
CABLE
ALTERNATE
CUT-OUT FOR
CABLE TIE
FTB MOUNTING
BRACKET
CABLE TIE
BRACKET
USE WAX STRING
OR CABLE TIES
(PER LOCAL PRACTICE)
TO SECURE CABLE TO
CABLE TIE BRACKET
MPO 6
MPO 5
MPO 4
MPO 3
MPO 2
MPO 1
MPO 6
MPO 5
MPO 4
MPO 3
MPO 2
MPO 1
6 5 4 3 2 1
TOP ENTRY
FOR TOP ENTRY, PLACE AND
SECURE CABLES AS SHOWN.
FRAME MAY BE POPULATED
FROM THE BOTTOM OR TOP.
LADDER
RACK
NOTE:
POSITION ALL
TIE DOWNS
AT REAR OF
TIE BAR.

ADCP-90-372 • Rev B • April 2018
Page 12
© 2018, CommScope, Inc.
3. Locate the cable tying position on the cable tie brackets on the side of the rack. Using
cable lacing, tie down the cable at the tie-down point determined in step 1 above. Position
all tie-downs at the rear of the tie bar as shown.
4. Connect the MPO connector as shown.
Figure 13. MPO Trunk Cable Routing Into FTB (Rear View)
Note: In a top entry application, tie off the cable on the tie off one block above the block
where the cable will be connected, as shown in Figure 13. In a bottom entry application,
tie off on the cable on the tie off next to the block where the cable will be connected, as
also show in Figure 13.
Note: For the top FTB in a top entry application, secure the cable to the ladder rack
overhead, as shown in Figure 10 on Page 10.
MPO
12-STRAND
CABLE
MPO
12-STRAND
CABLE
FTB
FTB
RACK
TIE OFF ON
TIE NEXT TO
BLOCK
13.5-INCH
SUB-UNIT
FTB
FTB
RACK
TIE OFF ON
TIE ONE BLOC
K
ABOVE
13.5-INCH
SUB-UNIT
BOTTOM ENTRY TOP ENTRY
23871-A

ADCP-90-372 • Rev B • April 2018
Page 13
© 2018, CommScope, Inc.
6 PATCH CORD INSTALLATION
Patch cords are installed on the front of the rack to route individual circuits from the FTB to
another FTB (cross-connect) or directly to local equipment (interconnect).
1. To ready the FTB for connecting a patch cord, open the door and slide out the desired
adapter pack as shown in Figure 14.
Figure 14. Sliding Out an Adapter Pack
23873-A
DOOR
ADAPTER
PACKS

ADCP-90-372 • Rev B • April 2018
Page 14
© 2018, CommScope, Inc.
2. Remove the dust cap from the desired adapter and connect the patch cord as shown in
Figure 15.
Figure 15. Connecting the Patch Cord
3. Route the patch cord around the radius limiters, into the distribution trough, and in either
of the two directions as shown in Figure 16.
Figure 16. Routing the Patch Cord in the Distribution Trough
Note: For cleaning instructions, refer to ADCP-90-139.
23874-A
DUST
CAP
23875-A
HORIZONTAL
REAR TROUGH
DISTRIBUTION
TROUGH
TO FTB IN
SAME FRAME
TO FTB IN
DIFFERENT
FRAME WITHIN
SAME LINEUP
RADIUS
LIMITERS
