COMPASS HEALTH ProBasics PBBT User manual

The free-standing trapeze is designed to provide
support to the user while changing positions in bed
and stability when transferring out of bed. This is an
assistive tool only and is NOT intended to support the
full body weight of the user.
Free Standing
Bariatric Trapeze
with Base and
Rear Wheels
TRANSPORTING THE TRAPEZE
Within a Single Location or Area
The trapeze can be moved by one or two persons, subject to the strength and
capability of those person(s). The rear, non-locking wheels are designed to make
sliding the trapeze easier. Subject to the area of movement/distance, the
trapeze may be left fully assembled.
ALWAYS secure the hanging triangle grip before moving the trapeze to avoid
injury. To reposition the chain/grip loosen the thumb screw and move the slide
ring closer to the mast where the triangle grip may be secured against the mast.
NEVER tip the trapeze on its wheels when moving to avoid possible injury.
ALWAYS slide the trapeze on the oor to avoid the trapeze falling and
causing personal injury, damage to the trapeze or to property.
Disassembling for Storage or to Move to another Location
The trapeze may be fully disassembled for storage or transport. ALWAYS pack
components with protection materials (e.g., foam pellets) to prevent damage
to the trapeze. Follow the assembly instructions in this guide when
re-assembling the unit. ALWAYS replace any parts that have been damaged
during disassembly, transportation or re-assembly.
LIMITED WARRANTY
The steel frame of this ProBasics product is warranted to be free of defects in
materials and workmanship for ve years.
This device has been manufactured to exacting standards and carefully
inspected prior to shipment. This Limited Warranty is provided based on our
condence in the materials and workmanship of this product and is our
assurance to the consumer of years of dependable service. This warranty is not
transferable and only available to end user owners.
This warranty does not cover failure due to owner misuse or negligence, or
normal wear and tear. This warranty does not include non-durable
components, such as rubber accessories, castors, wheels, chains or grips, which
are subject to normal wear and need periodic replacement.
If you have a question about your ProBasics product or this warranty, please
contact an authorized ProBasics dealer.
6753 Engle Road
Middleburg Heights, Ohio 44130
Tel.: [phone]
www.compasshealthbrands.com
PBBT_USERGUIDE_rev02 ©2020

3
Tools Required:
Drill, rubber mallet and adjustable wrench
Product Dimensions
2
(Boom)(slide ring)
(thumb screw)
(triangle grip)
OPERATION (cont’d)
3. Firmly gripping the triangle, the user should pull with both arms evenly, NEVER
at an angle to help reduce possible injury.
DO NOT use the trapeze to reposition oneself, unless both hands are rmly
gripping the triangle and the user is positioned directly below the boom.
WARNINGS
DO NOT use to support full body weight. This device is intended to assist a user
ONLY while they are positioned on the bed, ALWAYS maintain contact with the bed
when using the trapeze. The maximum weight capacity of this trapeze is 650 lbs/
294 kg. ALWAYS observe the weight limits.
After assembly or transport of the trapeze, ALWAYS check that hardware is
securely tightened BEFORE use.
DO NOT use this device without proper instruction and supervision from a
healthcare professional. It is the responsibility of the patient’s physician and
caregiver to assess the patient and determine which devices and accessories are
needed to support and protect the patient, while limiting risk to the patient. Use of
fall protection, pressure management, and transfer assistance mechanisms should
be considered as appropriate.
DO NOT hang from, stand on, or climb the trapeze stand. DO NOT hang objects from
the trapeze stand. Take care when positioning the trapeze triangle to allow for safe
user head clearance. ONLY use the trapeze for repositioning in bed.
DO NOT modify or replace parts. If replacement parts are needed, contact an
authorized ProBasics dealer.
DO NOT use the trapeze on uneven/rough/sloping ground. Unsuitable surfaces could
cause the device to tip.
DO NOT install or adjust the trapeze while the bed is occupied.
This is not a toy. DO NOT let children play on the trapeze.
ALWAYS check tightness of hardware, if the trapeze is disassembled and
reassembled for transport.
ALWAYS use CAUTION when moving the trapeze, as moving the unit on
uneven surfaces may cause the trapeze to tip.
NEVER use the trapeze except when the boom and handle are aligned with the legs
and the boom is locked in position, NEVER use with a patient when the boom is in
either storage setting (90⁰ left or right from the leg orientation).
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS FURTHER
INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN RISK AND WITH
APPROPRIATE AND SERIOUS ATTENTION TO SAFE OPERATION. USE CAUTION.
MAINTENANCE & CARE
EVERY month, inspect all hardware for tightness, fatigue or rust and rubber tips/
grips for excessive wear. ALWAYS replace the chain, triangle, and/or slide ring/
thumb screw if they show signs of excessive wear.
Clean the trapeze triangle at least once a month AND between patients, clean the
trapeze stand every 6 months, use mild soap and water, DO NOT use
abrasive cleaners, allow the trapeze to dry completely before use.
ASSEMBLY INSTRUCTIONS
1. Connect sections 1 & 3 by sliding section 3 over 1 and depressing the push pins
to secure in place. There should be an audible “click” when the pins are
properly engaged. Repeat for section 2.
2. Connect sections 3 & 4 by sliding section 4 down over section 3. Pull the
locking pin (A) outward to allow section 4 to lock into position.
3. Slide ring (B) over the tube section 4 by depressing push button on section 4
and sliding the into place. Insert the thumb screw ( C) through the ring (B) and
turn clockwise until tight to secure the ring in place. NOTE: thumb screw MUST
be inserted into the side of B without the receptacle nit to be sure it locks into
place correctly.
IMPORTANT
Prior to patient use, be sure to tighten the trapeze clamps onto either the bed or
the Trapeze base. The boom can be positioned at 90⁰ to the left or right, NEVER
use the trapeze for repositioning in these settings. These settings are ONLY for
storage of the trapeze.
OPERATION
Repositioning in Bed
1. Adjust the height of the triangle so the user may fully and rmly grasp the
triangle with both hands without stretching.
2. Position the triangle grip above the middle of the users’ chest by loosening the
thumb screw and moving the slide ring. ALWAYS tighten the thumb screw
before use.
Size 73"h X 43"w
X 48.5"d
Leg Width Legs 37.5" Inner/
43” Outer
Boom Length 36"
Boom Swivel Range 0° - 180°
Product Weight 100 lbs.
Shipping Weight 110 lbs.
Weight Capacity 650 lbs.
!
