COMPX NARC Box User manual

10.41"
9.16"
10.63"
12.81"
NARCOTICS BOX
with CompX cabinet eLock
Thank you for purchasing the CompX NARC Box with
built-in 200/300 Series eLock. The information
contained in these instructions is intended to serve as
a guide so as to allow the NARC Box to be quickly
and easily put into service. CompX’s 300 Series eLock
can be configured to work in conjunction with existing
802.11g or Ethernet networks. For complete set up
instructions for networked and stand-alone eLocks,
please see the “Help” section in CompX’s LockView v5
software.
Narcotics box dimensions with CompX eLock installed
Narcotics box dimensions with CompX eLock — components
NARCOTICS BOX with CompX cabinet eLock — Instructions
Integrated eLatch
control module
Door position
switch
Battery case
Power converter cable

NARCOTICS BOX with CompX cabinet eLock
Part #: 333697-0000-00
Copyright 2017 © CompX Security Products / 847.752.2500 / compx.com / 715 Center St., Grayslake, IL 60030
Any companies and/or products referred to herein are marks or registered trademarks of their respective companies, owners and/or mark holders.
What’s in the box?
w1 - NARCOTICS BOX w/installed 200 or 300 Series eLock
w1 - 12V to 9V power converter
w1 – grommet for use w/converter
w1 – 2-piece magnetic door position switch
w4 – #10 x ¾ Phillips pan head sheet metal screws to hang
NARC box
w1 - warranty card
w1 - serial code sticker set
w1 - in-box instructions
What’s needed?
w6 – AA batteries (optional if 12V to 9V converter is used)
wDrill
w9/64” drill bit (pilot hole for mounting screws)
w1/2” drill bit (if 12V to 9V converter is used)
w#3 Phillips bit or driver
wTape measure
wT15 pin-in Torx (6-lobe) bit
or driver (battery cover)
Care and
Cleaning
To clean the surface of
the eLock, apply non-acid
based cleaner to a clean
cotton cloth; do not spray
cleaner directly on the
eLock.Wipe down keypad
and housing taking care
around the beeper opening
and edges of keypad.
Wipe excess cleaner off of
all surfaces.
Installation
The NARC box can be installed using the 4 predrilled key
holes and supplied #10 x ¾ Phillips pan head screws. Be
sure to mount the box in a location that provides enough
clearance for the door to open.
NOTE: The NARC box may be equipped with a 12V –
9V converter to wire 12V DC power. If the converter is used,
drill a ½” diameter hole in the most convenient area and
install the grommet (included) and feed the cable through
the grommet.
IMPORTANT:
wConnect red wire to positive terminal and
black wire to negative terminal.
wNeglecting to install the grommet may
lead to electrical short circuit / eLock
malfunction and void warranty.
