Conceptronic cm3pvrd Quick start guide

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 1 of 6
Conceptronic CM3PVRD – Tuner Firmware Upgrade Instructions
A. Suita le devices
his tuner firmware upgrade is only suitable for Conceptronic CM3PVRD.
Note: This tuner firmware upgrade is not suitable for the Conceptronic CM3PVR, CM3PVRL and
CM3PVRN

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 2 of 6
B. Upgrade information
A firmware upgrade can improve the performance of your Conceptronic device and can sometimes add new
features.
Periodically firmware upgrades will be available via the official Conceptronic Website.
Conceptronic is not liable for any damages caused by an unofficial, not by Conceptronic approved firmware
for this specific Conceptronic device. Firmware upgrades, even while using official approved firmware, are
always at your own risk.
Installing new firmware without taking the following precautions into account will seriously harm the life
span of your Conceptronic device.
While installing new firmware, make sure the installation procedure is never interrupted.
Interruptions can, amongst others, be caused by:
- turning off the device;
- disconnecting the external USB device or memory card from where the upgrade process was started;
- disconnecting the power supply;
- pressing one or more buttons on the remote control or the device;
- a general power shutdown.
he Conceptronic CM3PVRD can be upgraded in three different ways:
-hrough a USB Storage device (for example: a USB Stick)
-hrough a Memory Card (for example: a SD Card)
-hrough the internal hard disk

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 3 of 6
C. Upgrade procedure from a USB stick or memory card
1. Copying the firmware file to a USB stick or a memory card
1.1 Connect the USB stick or memory card to your computer.
1.2 Copy the file ‘DTVTUNER.BIN’ from the folder ‘Firmware’ to the USB stick or memory card (for
example: ‘F:\DTVTUNER.BIN’ where F:\ is your USB stick or memory card).
Note: Do NOT put the firmware file in a folder on your USB stick or memory card The CM3PVRD must
‘see’ the firmware file directly on the USB stick or memory card
For example: ‘F:\DTVTUNER.BIN’
1.3 Remove the USB stick or memory card from your computer. It is recommended to use the safe
remove/eject/unmount option of your operating system.
1.4 Disconnect the USB stick or memory card from your computer.
2. Upgrading the ‘DTVTUNER.BIN’ firmware
2.1 Select the option ‘Movies’ in the main menu of the CM3PVRD.
he CM3PVRD will show the Movie Browser on your screen, with the ‘RECORDS’ folder opened.
2.2 Press the ‘STORAGE’ button on the remote control to switch to ‘USB MODE’ or ‘CARD MODE’
(depending on what you have inserted, a USB Stick or a memory card).
2.3 Select the file ‘DTVTUNER.BIN’ and press the ‘ENTER’ button on the remote control.
2.4 he CM3PVRD will show a ‘Software Upgrade’ screen and the firmware upgrade will start.
Note: The CM3PVRD must not be turned off during the upgrade process Doing so will result in an
unusable product The same applies for removing the USB stick or memory card
As soon as the upgrade process is completed, the CM3PVRD will show a ‘Data ase empty’ message. urn
the CM3PVRD off with the switch on the back.
Continue to chapter ‘E. Checking the firmware version of the CM3PVRD’.

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 4 of 6
D. Upgrade procedure from the internal hard disk of the CM3PVRD
1. Copying the firmware file to the CM3PVRD
1.1 Connect the CM3PVRD to your computer with the USB cable.
1.2 Copy the file ‘DTVTUNER.BIN’ from the folder ‘Firmware’ to the hard disk (for example:
‘F:\DTVTUNER.BIN’ where F:\ is your CM3PVRD).
1.3 Remove the CM3PVRD from your computer. It is recommended to use the safe
remove/eject/unmount option of your operating system.
1.4 Disconnect the USB cable of the CM3PVRD and turn the CM3PVRD off with the switch on the back
side.
2. Upgrading the ‘DTVTUNER.BIN’ firmware
2.1 Select the option ‘Movies’ in the main menu of the CM3PVRD.
2.2 he CM3PVRD will show the Movie Browser on your screen, with the ‘RECORDS’ folder opened.
2.3 Select ‘C:/’ on top of the Movie Browser.
2.4 Select the file ‘DTVTUNER.BIN’ and press the ‘ENTER’ button on the remote control.
2.5 he CM3PVRD will show a ‘Software Upgrade’ screen and the firmware upgrade will start.
Note: The CM3PVRD must not be turned off during the upgrade process Doing so will result in an
unusable product The same applies for removing the USB stick or memory card
As soon as the upgrade process is completed, the CM3PVRD will show a ‘Data ase empty’ message. urn
the CM3PVRD off with the switch on the back.
3. Removing the firmware file from your hard disk
3.1 urn the CM3PVRD on with the switch on the back.
3.2 Select the option ‘Movies’ in the main menu of the CM3PVRD.
he CM3PVRD will show the Movie Browser on your screen, with the ‘RECORDS’ folder opened.
3.3 Select ‘C:/’ on top of the Movie Browser.
3.4 Select the file ‘DTVTUNER.BIN’ and press the ‘EDIT’ button on the remote control.
3.5 Select ‘DELETE’ in the onscreen menu and press the ‘ENTER’ button on the remote control.
3.6 he CM3PVRD will ask if you are sure to delete the file. Select ‘Yes’ and press the ‘ENTER’ button
on the remote control. he firmware file will now be erased from your hard disk.

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 5 of 6
E. Checking the tuner firmware version of the CM3PVRD
1.1 Connect the CM3PVRD to your V and turn the CM3PVRD on with the switch on the back.
1.2 When the CM3PVRD is in the main menu, press ‘RECORD’ – ‘0’ – ‘0’ – ‘0’ (zero) on the remote
control.
he CM3PVRD will show the Device Information screen where you can see the current tuner firmware
version of the CM3PVRD. his should be:
- DTV TUNER VER: 22
1.3 Press the ‘ENTER’ button on the remote control to return to the CM3PVRD main menu.

Copyright® 2009 by Conceptronic – All rights reserved
www.conceptronic.net
Page 6 of 6
F. Release notes
CM3PVRD tuner firmware – version 022:
Added:
- Replaced “Move” option with “Sort” option. You can now sort your DVB- channels through
Setup->Digital V->Editing-> V Edit. Select the channel you want to move, press the ‘Yellow’ button,
select the destination for the challen and press the ‘SELEC ’ button to move the channel.
CM3PVRD tuner firmware – version 020:
Fixed:
- Loop issue.
- Dual audio issue with DVB- broadcastings.
Added:
- Last watched DVB- channel will now be remembered when turning off the CM3PVRD.
CM3PVRD tuner firmware – version 019:
- Initial release.
