Condair RM Series User manual

Steam humidifier
Condair RM
2598536-0 EN 2002
INSTALLATION MANUAL
Humidication and Evaporative Cooling

Thank you for choosing Condair
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Group AG. Neither this docu-
ment, nor the information contained herein shall be reproduced, used, or disclosed to others without the written
authorisation of Condair Group AG, except to the extent required for installation or maintenance of recipient's
equipment.
Liability Notice
Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due
to the use of parts/components/equipment that are not authorised by Condair Group AG.
Copyright Notice
© Condair Group AG, All rights reserved.
Technical modications reserved

3Contents
Contents
1 Introduction 5
1.1 To the very beginning 5
1.2 Notes on the installation manual 5
2 For your safety 7
3 Product Overview 9
3.1 Models overview 9
3.2 Identication of the unit 10
3.3 Options Condair RM 11
3.4 Accessories Condair RM 11
3.4.1 Details steam distribution pipe DV61-... 12
4 Inspecting the delivery / Storage and Transportation 13
4.1 Delivery 13
4.1.1 Standard delivery 13
4.1.2 Inspecting the delivery 13
4.2 Storage and Transportation 14
5 Mounting and installation work 15
5.1 Safety notes on mounting and installation work 15
5.2 Installation overview 16
5.3 Mounting the unit 17
5.3.1 Notes on locating the unit 17
5.3.2 Wall mounting 19
5.3.3 Floor mounting 21
5.3.4 Inspecting the installed unit 21
5.4 Steam installation 22
5.4.1 Overview steam installation 22
5.4.2 Positioning of the steam distributor 23
5.4.3 Installing the steam distributors 26
5.4.4 Installing the steam and condensate lines 27
5.4.5 Common steam and condensate line errors 31
5.4.6 Inspecting the steam installation 32
5.5 Water installation 33
5.5.1 Overview water installation 33
5.5.2 Notes on water installation 35
5.5.3 Inspecting the water installation 36

4Contents
5.6 Electric installation 37
5.6.1 Notes on electrical installation 37
5.6.2 Wiring diagram Condair RM 38
5.6.3 Installation work external connections 40
5.6.3.1 Connecting the signal cable of a humidity sensor "A1" (operation with internal controller) 40
5.6.3.2 Connecting the signal cable of an external humidity controller "A2" 41
5.6.3.3 Connection of the fault output "Err. Out" 42
5.6.3.4 Connection of external safety chain 42
5.6.3.5 Power supply 43
5.6.4 Performance data / Fuses "F6" power supply 44
5.6.5 Inspecting the electrical installation 44
6 Appendix 45
6.1 Unit dimensions 45
6.1.1 Unit dimensions Condair RM 2...8 45

5Introduction
1 Introduction
1.1 To the very beginning
We thank you for having purchased the Condair RM steam humidier.
The Condair RM steam humidier incorporates the latest technical ad van ces and meets all recognized
safety standards. Nevertheless, improper use of the Condair RM steam humidier may result in danger
to the user or third parties and/or damage to property.
To ensure a safe, proper, and economical operation of the Condair RM steam humidier, please observe
and comply with all information and safety instructions contained in the present documentation as well
as in the separate documentations of the components installed in the humidication system.
If you have questions after reading this documentation, please contact your Condair representative.
They will be glad to assist you.
1.2 Notes on the installation manual
Limitation
The subject of this installation manual is the Condair RM steam humidier in its different versions.
The various options and accessories are only described insofar as is necessary for proper operation
of the equipment. Further information on options and accessories can be obtained in their respective
instructions.
This installation manual is restricted to the installation of the Condair RM steam humidier and is meant
for well trained specialists being sufciently qualied for their respective work.
This installation manual is supplemented by various separate items of documentation (operation manual,
spare parts list, etc.), which are included in the delivery as well. Where necessary, appropriate cross-
references are made to these publications in the installation manual.

6Introduction
Symbols used in this manual
CAUTION!
The catchword "CAUTION" used in conjunction with the caution symbol in the circle designates notes
in this installation manual that, if neglected, may cause damage and/or malfunction of the unit or
damage to property.
WARNING!
The catchword "WARNING" used in conjunction with the general caution symbol designates safety
and danger notes in this installation manual that, if neglected, may cause injury to persons.
DANGER!
The catchword "DANGER" used in conjunction with the general caution symbol designates safety and
danger notes in this installation manual that, if neglected, may lead to severe injury or even death
of persons.
Safekeeping
Please safeguard this installation manual in a safe place, where it can be immediately accessed. If the
equipment changes hands, the documentation must be passed on to the new operator.
If the documentation gets misplaced, please contact your Condair representative.
Language versions
This installation manual is available in other languages. Please contact your Condair representative for
information.

7For your safety
2 For your safety
General
Every person, who is in charge of the installation work on the Condair RM must have read and understood
this installation manual and the Condair RM operation manual before carrying out any work.
Knowing and understanding the contents of the installation manual and the operation manual is a basic
requirement for protecting personnel against any kind of danger, to prevent faulty operation, and to
operate the unit safely and correctly.
All icons, signs and markings applied to the Condair RM must be observed and kept in readable state.
Qualication of personnel
All installation work described in this installation manual may only be carried out by specialists who
are well trained and adequately qualied and are authorised by the customer.
For safety and warranty reasons any action beyond the scope of this manual must be carried out only
by qualied personnel authorised by Condair.
It is assumed that all persons working with the Condair RM are familiar and comply with the appropriate
regulations on work safety and the prevention of accidents.
Intended use
The Condair RM steam humidier is intended exclusively for air humidication in HVAC systems
via a steam distributor approved by Condair within specied operating conditions. Any other type
of application, without the written consent of Condair, is considered as not conforming with the intended
purpose and may lead to the Condair RM becoming dangerous and will void any warranty.
Operation of the equipment in the intended manner requires that all the information contained in this
installation and operation manual are observed (in particular the safety instructions).
Danger that may arise from the Condair RM
DANGER!
Danger of electric shock!
The Condair RM is mains powered. Live parts may be exposed when the unit is open. Touching
live parts may cause severe injury or danger to life.
Prevention: The Condair RM must be connected to the mains only after all mounting and installation
work has been completed, all installations have been checked for correct workmanship and the unit
is closed and properly locked.

8For your safety
Preventing unsafe operation
All persons working with the Condair RM are obliged to report any alterations to the unit that may affect
safety to the owner without delay and to secure the Condair RM against accidental power-up.
Prohibited modications to the unit
No modications must be undertaken on the Condair RM without the express written consent of Condair.
For the replacement of defective components use exclusively original accessories and spare parts
available from your Condair representative.

9Product Overview
3 Product Overview
3.1 Models overview
Steam humidiers Condair RM are available with different heating voltages and steam capacities
ranging from 2 kg/h up to a maximum of 8 kg/h.
Model
Condair RM
Max. steam capacity
in kg/h
PNmax.
in kW
Heating voltage
2 2 2.0
230 V/1~/50...60 Hz
4 4 3.5
6 6 5.0
8 8 6.5
6 6 5.0 400 V/3~/50...60 Hz
8 8 6.5
Key model designation
Example:
Condair RM 8
Product designation
Max. steam capacity in kg/h

10 Product Overview
3.2 Identication of the unit
The identication of the unit is found on the rating plate:
Condair Group AG, Gwattstrasse 17, 8808 Pfäfkon SZ, Switzerland
Type: Condair RM 8 Serial No: XXXXXXX 01.20
Heating voltage: 230 V/1~/50-60 Hz Heating Power: 6.5 kW 28.3 A
Steam capacity: 8 kg/h
Water press.: 100..1000kPa (1..10 bar)
Engineered in Switzerland, Made in Germany
Type designation Serial number (7 digits) Month/Year
Heating voltage
Maximum steam capacity per unit
Admissible water supply pressure
Power consumption heating
Field with certication symbols
Fig. 1: Location of the specication label

11Product Overview
3.3 Options Condair RM
Condair RM
2468
Set of cable glands
Set with cable glands for the control compartment of the Con-
dair RM.
1x CG
Floor brackets
Floor brackets for oor mounting of the Condair RM.
1x FB
3.4 Accessories Condair RM
Condair RM
2468
Steam distribution pipe
Steam distribution pipe for steam distribution inside a air duct
see details in chapter 3.4.1).
1x DV61
Steam hose Meter x DS60
Condensate hose Meter x KS10
Filter valve 1x Z261
Filter cartridge 1x Filter cartridge Size L
Mounting station 1x MS

12 Product Overview
L
B
H
3.4.1 Details steam distribution pipe DV61-...
The steam distribution pipes DV61-... are selected on the basis of the duct width "B" (for horizontal
installation) or the duct height "H" (for vertical installation) and the capacity of the steam humidier.
Important! Always select the longest possible steam distribution pipe (opti mum humidication distance).
Steam distribution pipe DV61-... made of CrNi steel Duct width (B) / Duct height (H)
Type Length in mm (L) * in mm
DV61-200 200 250...400
DV61-350 350 400...600
DV61-500 500 550...750
DV61-650 650 700...900
DV61-800 800 900...1100
* Special length on request
Note: for further information regarding the DV61-... steam distribution pipe please refer to the separate
installation and operating instructions of this product.

13Inspecting the delivery / Storage and Transportation
4 Inspecting the delivery / Storage and Transportation
4.1 Delivery
4.1.1 Standard delivery
The standard delivery includes:
– Steam humidier Condair RM including xing set, installation manual (this document) and operation
manual (this document) and spare parts list, packaged in cardboard box.
Unit type Dimensions packaging (L x W x D) Transport weight
Condair RM 2...8 555 mm x 465 mm x 250 mm 11.8 kg
– Ordered options with operating instructions according chapter 3.3, packed separately.
– Ordered accessories with operating instructions according chapter 3.4, packed separately.
4.1.2 Inspecting the delivery
After receiving:
– Inspect shipping boxes for damage.
Any damages of the shipping boxes must be reported to the shipping company without delay.
– Check packing slip to ensure all parts has been delivered.
All material shortages are to be reported to your Condair supplier within 48 hours after receipt of the
goods. Condair Group AG assumes no responsibility for any material shortages beyond this period.
– Unpack the parts/components and check for any damage.
If parts/components are damaged, notify the shipping company immediately.
– Check whether the components are suitable for installation on your site according to the unit data
stated on the rating plate.

14 Inspecting the delivery / Storage and Transportation
4.2 Storage and Transportation
Storing
Until installation store the Condair RM in its original packaging in a protected area meeting the following
requirements:
– Room temperature: 5 ... 40 °C
– Room humidity: 10 ... 75 %rh
Transportation
For optimum protection always transport the unit and components in their original packaging and use
appropriate lifting/transporting devices.
WARNING!
It is the customer's responsibility to ensure that operators are trained in handling heavy goods and that
the operators comply with the appropriate regulations on work safety and the prevention of accidents.
Packaging
Keep the original packaging of the components for later use.
In case you wish to dispose of the packaging, observe the local regulations on waste disposal. Please
recycle packaging where possible.

15Mounting and installation work
5 Mounting and installation work
5.1 Safety notes on mounting and installation work
Qualication of personnel
All mounting and installation work must be carried out only by well qualied specialists authorised by
the owner. It is the owner’s responsibility to verify proper qualication of the personnel.
General notes
Strictly observe and comply with all information given in the present installation manual regarding the
mounting of the unit and the installation of water, steam and electricity.
Observe and comply with all local regulations dealing with water, steam and electrical installations.
Safety
Some installation work requires removal of the unit covers. Please note the following:
DANGER!
Danger of electric shock!
The Condair RM is mains powered. Live parts may be exposed when the unit is open. Touching
live parts may cause severe injury or danger to life.
Prevention: The Condair RM must be connected to the mains only after all mounting and installation
work has been completed, all installations have been checked for correct workmanship and the unit
is closed and properly locked.
CAUTION!
The electronic components inside the steam humidier are very sensitive to electrostatic
discharge.
Prevention: To protect these components against damage caused by electrostatic discharge (ESD
protection) appropriate measures must be taken when the unit is open for installation work.
VORSICHT!
The Condair RM with SPA control is not splash-proof (IPX4).
Prevention: The Condair RM with SPA control must therefore not be used for prefabricated sauna
cabins.

16 Mounting and installation work
5.2 Installation overview
Fig. 2: Installation overview
Z261
KS10
DS60
DV61
Humidity sensor or
humidity controller
Return duct
Supply duct
Humidity sensor or
humidity controller
Steam line
– As short as possible (max. length 4 m)
– Adequate upslope/downslope min.15 % (8.5°)
– No restrictions
– Condensate trap at the lowest point
– Hose or xed pipe (with same inner diameter
as steam outlet)
Condsensate line
– Min. downslope 15 % (8.5°)
– No restrictions
– Condensate trap ømin 200 mm
Filter valve or
Shut-off valve and
lter 125 µm
Water drain connector ø30 mm
Water supply connector G 3/4"
Water supply pipe
(min. inner diameter 8 mm, supplied by others)
1...10 bar
1...40 °C
Air proving switch
(external safety chain)
Electrical isolator voltage supply
(supplied by others)
ømin: 40 mm
Drain hose (by others)
– internal diameter ø30 mm
– constant downslope (min 15 %/8.5°) to funnel
– if using DI or RO water, use stainless steel
pipe only
– must not touch funnel
Open funnel with trap
(supplied by others)
Filter cartridge
(accessory)
Calculated absorption distance B
N
to any obstruction
or min. 3 m if B
N
is unknown
min. 5x B
N
(B
N
see chapter 5.4.2)
High limit humidistat
(external safety chain)
min. 500 mm
Pmax 800 Pa
Pmin -300 Pa
to drain
to cylinder
ømin: 200 mm
Rmin: 300 mm
Condair RO-A pure water system
(shown scaled down), details see
separate manual

17Mounting and installation work
5.3 Mounting the unit
5.3.1 Notes on locating the unit
Fig. 3: Distances to be observed
Condair RM 2...8
Housing dimensions in mm X470
Y150
Z350
Net weight in kg 10.6
Operation weight in kg 12.9
Y
Z
X
min. 200 mm
min. 1000 mm
min. 200 mm
min. 500 mm
min. 280 mm

18 Mounting and installation work
The installation site of the Condair RM depends largely on the location of the steam distributor. To ensure
proper functioning of the steam humidier and to obtain an optimal efciency, the following points
must be considered and observed when choosing the location for the steam humidier:
– Install the steam humidier so that:
– the length of the steam line is kept as short as possible (max. 4 m),
– the minimum bend radius for steam hoses (R= 300 mm) and for solid steam pipes (5 x
internal diameter) and the minimum upslope/downslope of 15 % (8.5°) of the steam hose is
maintained (see chapter 5.4.4).
– The Condair RM is designed for wall-mounting or oor mounting (with the optional oor supports)
in protected interiors. Make sure that the construction (wall, pillar, oor-mounted console, etc.) to
which or on which the steam humidier is to be mounted, offers a sufciently high load-bearing
capacity (take notice of the weight information found in the dimensions and weights table after Fig.
3), and is suitable for the installation.
– The back panel of the Condair RM retains heat during operation (max. surface temperature of the
metal housing approx. 60 - 70 °C). Make sure, therefore, that the construction (wall, pillar, etc.) to
which or on which the unit is to be mounted, does not consist of heat-sensitive material.
– Install the Condair RM in such a manner that it is freely accessible with sufcient space available
for maintenance purposes. The minimum distances shown in Fig. 3 must be maintained.
– The Condair RM is protected according to IP20. Make sure the unit is installed in a drip-proof loca-
tion and the admissible ambient conditions are complied with.
– Do not mount the Condair RM to hot or very cold walls or near vibrating components.
– The steam humidier Condair RM must only be installed in rooms with a oor drain.
CAUTION!
If for some reason the Condair RM must be installed in a location without oor drain, it is manda-
tory to provide a leakage monitoring device to safely interrupt the water supply in case of leakage.
– When mounting the Condair RM use only the mounting materials supplied with the unit. If mount-
ing with the materials supplied is not possible in your particular case, select a method of mounting
that is of similar stability.
– The Condair RM is designed for installation and operation within buildings (admissible temperature
range 5...40 °C). For outdoor operation the Condair RM must be placed in a weather protective hous-
ing. If ambient temperatures near or below the freezing point have to be expected, the protective
housing must equipped with a thermostat controlled heating of sufcient capacity. The water supply
pipe must be equipped with a trace-heating and must be insulated up to the protective housing.
The installation of a normally open valve inside the building envelope that will drain water in case of
power failure is highly recommended.

19Mounting and installation work
Fig. 4: Mounting the steam humidier to a wall
A
A
A
B
B
B
C
C
C
ab
c
d
e
transport securing device
Dimension Condair RM 2...8
"a" in mm 25.0
"b" in mm 225.0
"c" in mm 65.0
"d" in mm 308.0
"e" in mm 219.5
Weights Condair RM 2...8
Net weight in kg 10.6
Operating weight in kg 12.9
5.3.2 Wall mounting

20 Mounting and installation work
Procedure
1. Mark the attachment points "A" at the desired position with the help of a spirit level. Then, drill holes
diameter: 8 mm, depth: 40 mm.
2. Insert the supplied plastic plugs. Then, screw in the supplied screws 5 x 40 mm into the plastic plug
in such a way that the distance between screw head and unit rear wall is 10 mm.
3. Unlock the retaining screw of the unit cover, then remove the unit cover.
4. Remove transport securing device located on top of the steam tank , disconnect all heating cables
and the connecting cables to the over temperature switch(es). Then, pull steam tank out of the cou-
pling sleeve and remove.
5. Carefully pull the xing clip of the lling cup out of the support, then push lling cup down and pull it
to the front out of the support.
6. Hang the steam humidier onto the screws. Insert the supplied locking plates "B" between screw
head and unit rear wall. Align the steam humidier horizontally using a spirit level, then fasten the
screws.
7. Moisten the O-ring in the steam tank receptacle with water (do not use grease or oil). Then, insert
the stirrup on the backside of the steam tank into the retaining bracket on the back wall of the unit
housing. Insert the connector on the bottom side of the steam tank into steam tank receptacle and
push steam tank downwards until it comes to a stop.
Important: Check whether the steam tank is correctly hooked in the retaining bracket on the back
wall of the unit housing by pulling the steam tank to the front. A correctly mounted steam tank can-
not be moved.
8 Connect heating cable plugs into the corresponding sockets (see Fig. 5).
Important: make sure the cables are not crossed!
Attach connecting cable to the connector of the overtemperature switch.
1
1
2
2
Fig. 5: Connecting the heating cables and the connecting cable of the over temperature switch
9. Insert the hocks of the lling cup into the opening in the lling cup support. Push lling cup upwards
until the xing clip engages.
Important: make sure the drain hose from water cup is inserted into the drain opening on the
bottom of the unit housing.
10. Reattach the unit cover and secure it with the retaining screw.
