Congatec COM Express conga-IT6/COMe User manual
Copyright © 2018 congatec AG T6COm10.indd 2/45
Revision History
Revision Date (yyyy-mm-dd) Author Changes
0.1 2018-01-10 BEU •Preliminary release
0.2 2018-02-12 BEU •Corrected LVDS pinout table in section 5.8 "LVDS Header"
0.3 2018-07-06 BEU •Updated information about electrostatic sensitve devices in the preface section
•Updated sections 5.2.3 "Stereo Speakers Header", 5.2.4 "Digital MIC and S/PDIF Header", 5.2.6
"Surround Sound Header"and 5.3.1 "UART Headers"
•Added possible mating connectors
1.0 2018-10-30 BEU •Updated audio codec to ALC888S in table 4 and section 5.2 "Audio Connectors"
•Corrected pinout description in table 17
•Updated LED status description in table 18
•Added information about feature connector UARTs to section 5.3.1 "UART Headers"
•Changed one power button, one reset button, and a LED to optional in section 7.1 "Power Buttons" and
7.2 "Reset Buttons"
•Corrected and added descriptions to section 7.7 "Feature Connector"
Copyright © 2018 congatec AG T6COm10.indd 3/45
Preface
This user’s guide provides information about the components, features and connectors available on the congatec COM Express™ Type6
based Mini-ITX carrier board.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
congatec AG provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims
any implied warranties of merchantability or fitness for any particular purpose with regard to any of the foregoing. congatec AG assumes
no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for
discrepancies between the product and the user’s guide. In no event shall congatec AG be liable for any incidental, consequential, special, or
exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user’s guide or any other information
contained herein or the use thereof.
Intended Audience
This user’s guide is intended for technically qualified personnel. It is not intended for general audiences.
Lead-Free Designs (RoHS)
All congatec AG designs are created from lead-free components and are completely RoHS compliant.
Electrostatic Sensitive Device
All congatec AG products are electrostatic sensitive devices. They are enclosed in static shielding bags, and shipped enclosed in secondary
packaging (protective packaging). The secondary packaging does not provide electrostatic protection.
Do not remove the device from the static shielding bag or handle it, except at an electrostatic-free workstation. Also, do not ship or store
electronic devices near strong electrostatic, electromagnetic, magnetic, or radioactive fields unless the device is contained within its original
packaging. Be aware that failure to comply with these guidelines will void the congatec AG Limited Warranty
Copyright © 2018 congatec AG T6COm10.indd 4/45
Symbols
The following symbols are used in this user’s guide:
Warning
Warnings indicate conditions that, if not observed, can cause personal injury.
Caution
Cautions warn the user about how to prevent damage to hardware or loss of data.
Note
Notes call attention to important information that should be observed.
Connector Type
Describes the connector on the congatec COM Express™ evaluation carrier board and may also describe a possible mating connector as an
example.
Link to connector layout diagram
This link icon is located in the top left corner of each page. It provides a direct link to the connector layout diagram on page 8 of this document.
Copyright Notice
Copyright © 2018, congatec AG. All rights reserved. All text, pictures and graphics are protected by copyrights. No copying is permitted
without written permission from congatec AG.
congatec AG has made every attempt to ensure that the information in this document is accurate yet the information contained within is
supplied “as-is”.
Copyright © 2018 congatec AG T6COm10.indd 5/45
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this user’s guide, or the congatec website, are the property
of their respective trademark holders. These trademark holders are not affiliated with congatec AG, our products, or our website.
Warranty
congatec AG makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited
warranty (“Limited Warranty”) per the terms and conditions of the congatec entity, which the product is delivered from. These terms and
conditions can be downloaded from www.congatec.com. congatec AG may in its sole discretion modify its Limited Warranty at any time and
from time to time.
The products may include software. Use of the software is subject to the terms and conditions set out in the respective owner’s license
agreements, which are available at www.congatec.com and/or upon request.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, congatec AG represents that the
products are new and warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or
due to non conformance to the agreed upon specifications, will be repaired or exchanged, at congatec’s option and expense.
Customer will obtain a Return Material Authorization (“RMA”) number from congatec AG prior to returning the non conforming product freight
prepaid. congatec AG will pay for transporting the repaired or exchanged product to the customer.
Repaired, replaced or exchanged product will be warranted for the repair warranty period in effect as of the date the repaired, exchanged
or replaced product is shipped by congatec, or the remainder of the original warranty, whichever is longer. This Limited Warranty extends to
congatec’s direct customer only and is not assignable or transferable.
Except as set forth in writing in the Limited Warranty, congatec makes no performance representations, warranties, or guarantees, either
express or implied, oral or written, with respect to the products, including without limitation any implied warranty (a) of merchantability, (b) of
fitness for a particular purpose, or (c) arising from course of performance, course of dealing, or usage of trade.
congatec AG shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be
liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause. The sole and exclusive
remedy against congatec, whether a claim sound in contract, warranty, tort or any other legal theory, shall be repair or replacement of the
product only.
Certification
congatec AG is certified to DIN EN ISO 9001 standard.
C
E
R
T
I
F
I
C
A
T
I
O
N
I
S
O
9
0
0
1
TM
Copyright © 2018 congatec AG T6COm10.indd 6/45
Technical Support
congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products
can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities
and drivers, which have been made available to assist you. If you still require assistance after visiting our website then contact our technical
Terminology
Term Description
Bit Binary Digit
COM Computer On Module
DIP Dual In-line Package
DMIC Digital Microphone
DP DisplayPort
DP++ Dual-mode DisplayPort
eDP Embedded DisplayPort
Gb/s Gigabit per second
GbE Gigabit Ethernet
HDA High Definition Audio
HDMI High-Definition Multimedia Interface
I²C Inter-Integrated Circuit
LPC Low-Pin Count
LVDS Low-Voltage Differential Signaling
M.2 Formerly known as the Next Generation Form Factor (NGFF)
mA Milliampere
Mbyte Megabyte
microSD Micro Secure Digital
Micro-SIM Micro Subscriber Identity Module
N.C Not Connected
PCI Express®Mini Peripheral Component Interface Express®Mini
PEG PCI Express®for Graphics
RS-232 Recommended Standard 232
RS-422 Recommended Standard 422
Copyright © 2018 congatec AG T6COm10.indd 7/45
RS-485 Recommended Standard 485
RTC Real-Time Clock
S/PDIF Sony/Philips Digital Interconnect Format
SATA Serial Advanced Technology Attachment
SATADOM Serial Advanced Technology Attachmen Disc On Module
SBM³ Smart Battery Management
SD Secure Digital
SPI Serial Peripheral Interface
Super I/O Super Input/Output
T.B.D To Be Determined
UART Universal Asynchronous Receiver/Transmitter
USB Universal Serial Bus
VGA Video Graphics Array
Copyright © 2018 congatec AG T6COm10.indd 8/45
