Connect Tech AGX202 User manual

Rogue Carrier for NVIDIA®
Jetson AGX Orin™
CTIM-00086 Revision 0.00 2023-01-24

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 2 of 30
Date: 2023-01-24
TABLE OF CONTENTS
Table of Contents.........................................................................................................................................2
Preface..........................................................................................................................................................4
Disclaimer .......................................................................................................................................................4
Customer Support Overview...........................................................................................................................4
Contact Information ........................................................................................................................................4
Limited Product Warranty...............................................................................................................................5
Copyright Notice.............................................................................................................................................5
Trademark Acknowledgment..........................................................................................................................5
ESD Warning ..................................................................................................................................................6
Revision History...........................................................................................................................................6
Introduction.................................................................................................................................................7
Product Features and Specifications................................................................................................................8
Part Numbers / Ordering Information .............................................................................................................8
Product Overview...................................................................................................................................... 10
Block Diagram ..............................................................................................................................................10
Board (Top Side)...........................................................................................................................................11
Board (Back Side).........................................................................................................................................12
Connector Summary & Locations.................................................................................................................13
Jumper Summary & Locations......................................................................................................................13
LED Summary...............................................................................................................................................13
Detailed Feature Description.....................................................................................................................14
Connector and Switch Locations - Connector Side.......................................................................................14
Connector and Switch Locations - Module Side...........................................................................................15
LED Locations ..............................................................................................................................................15
Jetson AGX Orin™Board-to-Board Carrier Connector ....................................................................16
M.2 M-Key –NVMe..........................................................................................................................16
CAN Bus TERM enable switch..........................................................................................................16
USB UART Debug console –Micro USB-AB...................................................................................17
USB 3.2 Gen2 (10 Gbps) / OTG Type C............................................................................................17
USB 3.2 Gen2 (10Gbps) Type C........................................................................................................18
RTC Battery........................................................................................................................................18
MISC I/O Connector ..........................................................................................................................19
CAN Bus Connector...........................................................................................................................20
CAMERA Expansion Connector........................................................................................................20
M.2 E-Key –WiFi and Bluetooth Expansion port .............................................................................23
Fan Connector (12V)..........................................................................................................................23
External Switch Access Connector.....................................................................................................23
Micro SD Card Expansion port ..........................................................................................................24
HDMI Video Output...........................................................................................................................24
GBE RJ45 Connectors........................................................................................................................24
POWER Connector.............................................................................................................................25
POWER Mode Select Switch .............................................................................................................26
Push Button Switches.........................................................................................................................27
Typical Installation.................................................................................................................................... 27

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 3 of 30
Date: 2023-01-24
Software..................................................................................................................................................... 27
Force Recovery Mode................................................................................................................................28
Power Consumption................................................................................................................................... 28
Cables......................................................................................................................................................... 29
Mechanical Drawings & Models................................................................................................................30
Thermal Options........................................................................................................................................ 30
Passive Heatsink (XHG320) .........................................................................................................................30
Active Heatsink (XHG319)...........................................................................................................................30
Assembly drawings .......................................................................................................................................30

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 4 of 30
Date: 2023-01-24
PREFACE
Disclaimer
The information contained within this user’s guide, including but not limited to any product
specification, is subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the
user’s guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect
Tech reseller from which you purchased the product. In most cases the reseller can help you with
product installation and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff can
assist you. Our support section is available 24 hours a day, 7 days a week on our website at:
https://connecttech.com/support/resource-center/. See the contact information section below for
more information on how to contact us directly. Our technical support is always free.
Contact Information
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
489 Clair Rd. W.
Guelph, Ontario
Canada N1L 0H7
Contact Information
[email protected]om
[email protected]om
www.connecttech.com/
Toll Free: 800-426-8979 (North America only)
Telephone: [phone]
Facsimile: 519-836-4878 (on-line 24 hours)
Support
Please go to the Connect Tech Resource Center for product manuals,
installation guides, device drivers, BSPs and technical tips.
Submit your technical support questions to our support engineers.
Technical Support representatives are available Monday through Friday,
from 8:30 a.m. to 5:00 p.m. Eastern Standard Time.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 5 of 30
Date: 2023-01-24
Limited Product Warranty
Connect Tech Inc. provides a one-year Warranty for this product. Should this product, in Connect Tech
Inc.'s opinion, fail to be in good working order during the warranty period, Connect Tech Inc. will, at its
option, repair or replace this product at no charge, provided that the product has not been subjected to
abuse, misuse, accident, disaster or non-Connect Tech Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc.
must be pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number
marked on the outside of the package and sent prepaid, insured and packaged for safe shipment.
Connect Tech Inc. will return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is
defined as the period during which all components are available. Should the product prove to be
irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if available or to
retract the Warranty if no replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall
not be liable for errors contained herein or for incidental consequential damages in connection with the
furnishing, performance, or use of this material. This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent of Connect Tech, Inc.
Copyright
©
2023 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in
this document as the property of their respective owners. Not listing all possible trademarks or
copyright acknowledgments does not constitute a lack of acknowledgment to the rightful owners of the
trademarks and copyrights mentioned in this document.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 6 of 30
Date: 2023-01-24
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any
circuit board assemblies including Connect Tech
COM Express carrier assemblies, it is recommended
that ESD safety precautions be observed. ESD safe
best practices include, but are not limited to:
•Leaving circuit boards in their antistatic
packaging until they are ready to be installed.
•Using a grounded wrist strap when handling
circuit boards, at a minimum you should touch a
grounded metal object to dissipate any static
charge that may be present on you.
•Only handling circuit boards in ESD safe areas,
which may include ESD floor and table mats,
wrist strap stations and ESD safe lab coats.
•Avoiding handling circuit boards in carpeted
areas.
•Try to handle the board by the edges, avoiding
contact with components.
REVISION HISTORY
Revision
Date
Changes
0.00
2023-01-24
Initial Release

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 7 of 30
Date: 2023-01-24
INTRODUCTION
Connect Tech’s Rogue for AGX Orin™(AGX202) is a full featured NVIDIA® Jetson AGX Orin™module
carrier board. This carrier board for AGX Orin™is specifically designed for commercially deployable
platforms, and has an extremely small footprint of 92mm x 107mm.
Rogue for AGX Orin™provides access to an impressive list of latest generation interfaces on the AGX
Orin™while adding additional interfaces of 3x USB 3.2, 2x 10GbE, 1x HDMI and a locking Mini-Fit Jr.
input power connector.
Rugged camera add-on expansion boards will also be available for use with the Rogue for AGX Orin™to
interface directly with the AGX Orin™high density MIPI CSI interfaces.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 8 of 30
Date: 2023-01-24
Product Features and Specifications
Specifications
NVIDIA® GPU SoC Module
Compatibility
NVIDIA® Jetson AGX Orin™
Networking
2x 10GBase-T Ethernet (RJ45)
Display Output
1x HDMI (Supports up to HDMI 2.0)
Camera Input
6x two lane MIPI CSI-2 or
4x four lane MIPI CSI-2
using a 120 pin (dev kit compatible) QSH expansion connection
USB
3x USB 3.2 5Gbps/10Gbps (Type C –OTG mode 1 port)
(Note only 2 interfaces can be used at 10Gbps simultaneously)
Storage
2x NVMe M.2 Key M Slots
1x Micro SD Slot
UART
2x @3.3V Levels UART0 and UART1
Micro USB Debug UART
I2C/SPI
1x @3.3V I2C
1x @3.3V SPI
CAN Bus
2x CAN 2.0b Port (Non-Isolated)
GPIO
4 bits of 3.3V (level shifted GPIO) (1PWM)
User Expansion
1x M.2 Key E Slot with PCIe & USB (Wifi + BT
Modules)
Input Power
+12VDC Input Only (Positive Locking Molex Mini-Fit Jr Header)
PCB / Electronics Mechanical
Information
92mm x 107mm
Operating Temperature (Carrier
Board Only)
-40°C to +85°C (-40°F to +185°F)
Part Numbers / Ordering Information
Please refer to the Rogue for AGX Orin™product webpage or contact sales for the most up to date
ordering information.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 9 of 30
Date: 2023-01-24
FEATURE COMPARISON
While all attempts to make a drop-in replacement have been made there are notable differences
between AGX101 and AGX202. The table below attempts to clarify these differences
Specifications
Rogue for AGX Orin™(AGX202)
Rogue for AGX Xavier™(AGX101)
NVIDIA® GPU SoC
Module Compatibility
NVIDIA® Jetson AGX Orin™
NVIDIA® Jetson AGX Xavier™
Networking
2x 10GBase-T Ethernet (RJ45)
-Two AQR113 PHYs
2x Gigabit Ethernet (RJ45)
- One port from RGMII PHY (direct
from module)
- One port from a PCIe I210
MAC/PHY
Display Output
1x HDMI (Supports up to HDMI 2.0)
2x HDMI 1.4a (Type A)
Camera Input
6x Two lane MIPI CSI-2 or 4x four lane MIPI CSI-2
using a 120 pin (dev kit compatible) QSH expansion connection
USB
3x USB Type-C (10Gbps)
One port supports OTG mode
Storage
2x NVMe M.2 Key M
1x Micro SD Slot
2x NVMe M.2 Key M
1x Micro SD or UFS slot
UART
2x 3.3V Level UARTs on GPIO Connector
1x Micro USB Debug UART
I2C/SPI
1x 3.3V I2C on GPIO Connector
1x 3.3V SPI on GPIO Connector
CAN Bus
2x CAN 2.0b Port (Non-Isolated)
2x CAN 2.0b Port (Isolated)
GPIO
4x 3.3V GPIOs on GPIO Connector
(1x PWM)
4x 3.3V GPIOs on GPIO Connector
User Expansion
1x M.2 Key E Slot with PCIe & USB2 (Wi-Fi + BT Modules)
Input Power
+12VDC Input Only
(4 pin Mini-fit Jr Connector)
+9-19V DC Wide Input Power
(4 pin Mini-fit Jr Connector)
PCB Mechanical
Information
92mm x 107mm
92mm x 105mm
Weight
143g (Includes PHY heatsink)
103g
Operating Temperature
(Carrier Board Only)
-40°C to +85°C (-40°F to +185°F)

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 10 of 30
Date: 2023-01-24
PRODUCT OVERVIEW
Block Diagram

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 11 of 30
Date: 2023-01-24
Board (Top Side)

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 12 of 30
Date: 2023-01-24
Board (Back Side)

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 13 of 30
Date: 2023-01-24
Connector Summary & Locations
Designator
Description
P9
Jetson AGX Orin™connector
J2A, J2B
M.2 M-Key (NVMe) connector
P4
USB UART Debug Console connector
J3
USB 3.1 device port and OTG programming port connector
J4A, J4B
USB 3.1 device ports
P3
MISC I/O connector
P2
CAN Bus Connector
P1
MIPI Camera Expansion connector
P10
M.2 E-Key connector
P11
12V Fan connector
P12
External Switch Access connector
P13
Micro SD
P5
HDMI Display output connectors
J1A, J1B
RJ45 10GbE connectors
P6
Input Power connector
P7
RTC Battery connector
Jumper Summary & Locations
Designator
Description
S1
Power Option control dip switches
S2
CAN Bus Termination control dip switches
S3
Power ON momentary switch
S5
Force Recovery momentary switch
S6
Reset momentary switch
LED Summary
Designator
Description
D6A
M.2 connector (J2A) activity
D6B
M.2 connector (J2B) activity
D9
Input Power is good
D10
System Power is good and system is powering on (booting up). In manual power on
mode (via dip switch), this light will power on only after the power button has been
pushed. Since the typical default mode is auto power on, the light will come on as
on the system starts to boot.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 14 of 30
Date: 2023-01-24
DETAILED FEATURE DESCRIPTION
Connector and Switch Locations - Connector Side

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 15 of 30
Date: 2023-01-24
Connector and Switch Locations - Module Side
LED Locations

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 16 of 30
Date: 2023-01-24
Jetson AGX Orin™Board-to-Board Carrier Connector
Function
NVIDIA® Jetson AGX Orin™Module
Interface
Location
P9
Type
Molex Mirror Mezz™Connector
Connector
Part Number: 203456-0003
Manufacturer: Molex
Mating
Connector
Same as above.
Pinout
Refer to NVIDIA® Jetson AGX Orin™
System-on-Module datasheet and OEM
design guide for pinout details
M.2 M-Key –NVMe
Function
NVMe Storage (x2 PCIe Gen 4)
Location
J2A, J2B
Type
2280 M.2 M-key 3.2mm mating height
with M3 mounting standoff.
Connector
Part Number: 1-2199119-5
Manufacturer: TE
Mating
Connector
N/A
Pinout
M.2 Specification M-Key pin assignment.
Notes
Interface is x4 PCIe Gen 4. SATA is not supported. PCIe based devices only.
CAN Bus TERM enable switch
Function
Enable CAN Bus termination on CAN1 and CAN2
Location
S2
Type
2 SPST dip switch
Default
Product is shipped with both Terminations DISABLED. Only
add the termination if the unit is an end point of any CAN
Bus connection, otherwise leave disabled.
Pinout
Switch
Description
ON
OFF
S2-1
CAN Bus 1 TERM Enable
120 ohm
No TERM
S2-2
CAN Bus 2 TERM Enable
120 ohm
No TERM

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 17 of 30
Date: 2023-01-24
USB UART Debug console –Micro USB-AB
Function
USB UART Debug console
Location
P4
Type
5 Pin USB Micro AB connector
Connector
Part Number: 47589-0001
Manufacturer: Molex
Mating
Cable
Any standard Micro USB to USB Type A
Notes
This interface utilizes an FTDI USB to Serial device on board to allow access to the Jetson
AGX Orin™Serial debug console using any Micro USB to USB A cable and any PC with a USB
interface and serial terminal program.
USB 3.2 Gen2 (10 Gbps) / OTG Type C
Function
USB 3.2 Gen2 device port,
OTG programming port
Location
J3
Type
24 Pin USB Type C
Connector
Part Number: 632723300011
Manufacturer: Wurth
Mating
Cable
Any Standard Type C interface cable or device
** Note this port only supports USB devices, it
does not include a display interface **
Notes
This interface doubles as both a standard DFP (Downward facing port) USB 3.2 Gen2 port
to support USB 3.2 Gen2 devices and the Jetson AGX Orin™Programming (flashing)
interface port. The port is capable of up to USB 3.2 Gen 2 speeds in normal operation. The
USB 2.0 portion of the interface doubles as the OTG programming port when the FORCE
RECOVERY function is applied at startup. The power to the port is disabled so an external
PC connection is possible in order to reprogram the module using Jetpack.
Maximum power available on this output is 1.5A @5V.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 18 of 30
Date: 2023-01-24
USB 3.2 Gen2 (10Gbps) Type C
Function
USB 3.2 Gen2 device ports
Location
J4A, J4B
Type
24 Pin USB Type C
Connector
Part Number: 632723300011
Manufacturer: Wurth
Mating
Connector
Any Standard Type C interface cable or
device
** Note this port only supports USB
devices, it will not work as a display
interface **
Notes
These interfaces are both standard DFP (Downward facing port) USB 3.2 Gen 2 capable
ports used to support USB peripheral devices. Display devices or devices requiring 20V
power modes are NOT supported.
The power available from either of these ports is 3A @5V.
RTC Battery
Function
RTC Battery Connector
Location
P7
Type
3 pin PicoBlade (vertical)
Connector PN
53047-0310 - Manufacturer: Molex
Mating PN
51021-0300 - Manufacturer: Molex
Pinout
Pin
Signal
Description
1
+3V
RTC Battery Voltage
Input
2
NC
No Connect
3
GND
Ground/Return
Rogue for AGX Orin™allows for an external RTC battery to be connected. This battery should be a 3V
DC battery, and it will hold settings including date and time. For further information about RTC battery
selection and life time estimation, see Application Note 00009: https://connecttech.com/pdf/CTIN-
00009.pdf

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 19 of 30
Date: 2023-01-24
MISC I/O Connector
Function
2x Serial (TTL), 1x I2C, 1x SPI, 4x GPIO
Location
P3
Type
20 Pin
Connector
Part Number: T1M-10-GF-DH
Manufacturer: Samtec
Mating
Cable
S1SD-10-28-GF-xxx
Pinout
Connector Pins
Description
1
UART1 TX
2
UART2 TX
3
UART1 RX
4
UART2 RX
5
I2C SCL
6
UART2 RTS#
7
I2C SDA
8
UART2 CTS#
9,10,11,12
GND
13
GPIO0 (PWM03)
14
SPI CLK
15
GPIO1 (GPIO04)
16
SPI MOSI
17
GPIO2 (GPIO05)
18
SPI MISO
19
GPIO3 (GPIO08)
20
SPI CS#
Notes
This interface provides 3.3V capable generic I/O including:
•UART1 under /dev/ttyTHS0
UART2 under /dev/ttyTHS1
•I2C under i2c-0
•SPI under /dev/spidev0.0
•x4 GPIO under gpiochip2
For more information on I2C usage, please click here.
For more information on GPIO usage, please click here.

Rogue Carrier for NVIDIA® Jetson AGX Orin™
Users Guide
www.connecttech.com
Document: CTIM-00086
Revision: 0.00
Page 20 of 30
Date: 2023-01-24
CAN Bus Connector
Function
2x Non-Isolated CAN Bus
Location
P2
Type
6 Pin
Connector
Part Number: T1M-03-GF-DH
Manufacturer: Samtec
Mating
Cable
S1SD-03-28-GF-xxx
Pinout
Connector Pins
Description
1
CAN0_H
2
CAN1_H
3
CAN0_L
4
CAN1_L
5
GND
6
GND
Notes
This interface provides two Non-Isolated CAN Bus interfaces.
CAMERA Expansion Connector
Function
8 MIPI CSI-2 Camera Interfaces + I2C and GPIO Control
Location
P1
Type
120 Pin QSH with M2.5, 5mm mounting standoffs
Default
Part Number: QSH-060-01-L-D
Manufacturer: Samtec
Mating
Connector
QTH
Pinout
Pin #
Description
Pin #
1
CSI0_D0_P
CSI1_D0_P
2
3
CSI0_D0_N
CSI1_D0_N
4
5
GND
GND
6
7
CSI0_CLK_P
CSI1_CLK_P
8
9
CSI0_CLK_N
CSI1_CLK_N
10
11
GND
GND
12
13
CSI0_D1_P
CSI1_D1_P
14
15
CSI0_D1_N
CSI1_D1_N
16
