Connect-A-Dock myers 1000 Series User manual

Marine Assembly
Instructions
• Floating Docks
• PWC Docking
Make a connection to Life®
Should you have a warranty claim, we may require that you provide a photograph or, in some cases, return the
Connect-A-Dock part to the place of purchase. In order for warranty to be valid, original sales receipt must
accompany warranty claim. NOTE: Shipping costs are not included in warranty.
NOTE: All plastic has an inherent tendency to create static electricity. If you have a concern, contact Connect-A-Dock.
1-877-742-3071 (toll free U.S.A. only) 1-712-243-2430
1501 Owner Avenue, Atlantic, IA 50022 USA
Please call us with your questions and comments
CONNECT-A-DOCK®Warranty — USA & Canada
Connect-A-Dock Inc. warrants to the original owner all polyethylene plastic
components for eight (8) years from date of purchase to be free of defects in
material and workmanship and to perform properly under normal usage and
when *fully assembled according to the instructions provided at the time of
purchase. All other accessories have a one (1) year limited warranty. *Fully
assembled: Install float connectors into all float section sockets where other
float sections will be attached. For a copy of the Connect-A-Dock complete
warranty call Connect-A-Dock.
Connect-A-Dock Inc. warrants to the original owner all polyethylene plastic
components for two (2) years from date of purchase to be free of defects in
material and workmanship and to perform properly under normal usage and
when *fully assembled according to the instructions provided at the time of
purchase. All other accessories have a one (1) year limited warranty. *Fully
assembled: Install float connectors into all float section sockets where other
float sections will be attached. For a copy of the Connect-A-Dock complete
warranty call Connect-A-Dock.
CONNECT-A-PORT®Warranty — USA & Canada
Connect-A-Dock Inc. warrants to the original owner all polyethylene plastic
components for five (5) years from date of purchase to be free of defects in
material and workmanship. For a copy of the Connect-A-Port complete
warranty call Connect-A-Dock.
CONNECT-A-PORT®Warranty — International
Connect-A-Dock Inc. warrants to the original owner all polyethylene plastic
components for two (2) years [one (1) year for commercial use] from date of
purchase to be free of defects in material and workmanship. All other accessories
have a one (1) year limited warranty. For a copy of the Connect-A-Port
complete warranty call Connect-A-Dock.
www.connectaport.com www.connectadock.com
Warranties
180002613 05/23/23
CONNECT-A-DOCK®Warranty — International
Some products in this instruction book are protected by one or more of the following patents. USA
patents: 6,073,572; 5,281,055; 7,481,175; and 6,179,525 B1 Canadian patents: 2,308,617; 2,328,022

1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Preface
Live Load
1000 Series (LP): 35 lbs per square foot
(170 kg per square meter)
2000 Series (HP): 75 lbs per square foot
(365 kg per square meter)
Connect-A-Port: 1500 lbs (680.9 kg)
Dock anchoring methods listed in this
instruction manual are only suggestions.
It is up to you to determine which
method suits your needs.
Anchoring
Connector Sockets
1000 Series (LP): ~15“ (38.1 cm) apart
2000 Series (HP): ~24“ (60.96 cm) apart
A 1000 or 2000 Series dock should not be placed in
areas with constant waves in excess of 12 inches in
total wave height, as measured from crest to trough.
Please note that placing a dock in an unsuitable
location may void any warranty provided by
Connect-A-Dock Inc. or your local distributor or
dealer if you have any questions regarding the
suitability of your particular dock location.
Installation
Storage
When storing the Connect-A-Dock outside,
the walking surface of the dock needs to
face up. If stored upside down, water can
get inside the docks through vent holes
that allow air expansion.
Cleaning
For low maintenance cleaning use a sti
broom or brush with a garden hose. A
pressure washer with no heat can also
be used. When using soap, use an
environmentally safe product.
Stainless Steel
Connect-A-Dock products use marine grade stainless steel for
stainless steel metal components. Stainless steel may stain, discolor or
attain an adhering layer of grime under normal service, and, especially,
when used in salt water conditions. Any contamination of the metal
surface by dirt, or other material, can reduce corrosion protection.
Some corrosion can also occur when stainless steel comes in contact
with dissimilar metals. The removal of dirt, grime and surface stains
that occurs during normal handling and exposure to the elements is
essential for optimum corrosion resistance to prevent surface staining
(corrosion) or pitting.
Dirt, grime and surface stains that occur during normal use and
exposure to the elements should be cleaned with warm water with or
without a gentle detergent, soap or ammonia. (Caution, do not use
ammonia near anodized aluminum). Persistent stains can be removed
with mild non-scratching abrasive powders such as typical household
cleaners used with warm water, bristle brush, sponge or clean cloth
followed by a rinse with clean water and wiped dry. Stubborn stains can
be removed by using a damp cloth and a commercial stainless steel
cleaner and polish, rubbing lightly in the direction of the polish lines on
the stainless steel, then rinsing with clean water and wiping dry.
Connect-A-Port® Product
Installation and Use
Warning Disclaimer
Repairs of a Connect-A-Port should only be performed by an
authorized Connect-A-Port technician. If repair is performed by
unauthorized persons, serious personal injury and/or property
damage could occur.
If unauthorized personnel repair a Connect-A-Port, Connect-A-Dock
hereby disclaims any and all warranties, expressed or implied.
Connect- A-Dock limits its warranty to Connect-A-Dock's published
Connect-A-Port warranty furnished with each product. No other
warranty of any kind either verbal or implied including warranties of
merchantability and fitness for a particular purpose are recognized.
The contents of this manual are subject to change without notice and
should not be construed as a commitment, representation, warranty
or guarantee of any method, product or device by Connect-A-Dock.
Reproduction or translation of any part of this manual, without the
written permission of Connect-A-Dock, is prohibited.
Any inquiries concerning the Connect-A-Port published warranty or
this manual and its contents please contact Connect-A-Dock.
The purpose of the cleat is to provide an area on the PWC Port to
temporarily tie o another PWC, tie down a cover or other similar
light duty tasks. The cleat is not designed to anchor the PWC Port or
to tie two units together. If two units are to be tied/attached together
there is a Side-by-Side Kit designed for that specific purpose. In
addition, there are various anchoring options available so the cleat
should never be used for this purpose.
All specifications provided by Connect-A-Dock are based upon connect-a-dock test data and are provided without representation or
warranty. Actual specifications, weights and dimensions may vary for a variety of reasons, including, without limitation, due to the
rotational molding process. Specifications should be regarded as nominal values only and not as binding actual values. Please
contact Connect-A-Dock if you have specific questions regarding the specifications of any Connect-A-Dock product.
Torque Specs
Tighten all 1000 Series (LP) and 2000 Series (HP)
Connector hardware bolts to 25 lbs/ft (3.46 kg/m)
of torque. Check all bolts every three months or
as needed to insure all connector hardware is
securely fastened.

1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Table of Contents
1000 Series—Low Profile (LP)
Float Sections
Corner Float Section
Extra Flotation
....................................................................................................................................................2
........................................................................................................................................3
...................................................................................................................................................4
2000 Series—High Profile (HP)
Float Sections
Corner Float Section
Heavy Pole Connector
Extra Flotation
Utility Channel
Utility Channel End Cap
Pedestal Lighthouse
...................................................................................................................................................5
.......................................................................................................................................6
.....................................................................................................................................7
...................................................................................................................................................8
.................................................................................................................................................10
.................................................................................................................................11
......................................................................................................................................12
1000 (LP) & 2000 (HP) Series Accessories
Gangway
Gangway Roller Kit
Gangway Hinge (Wood)
Gangway Roller Kit (Wood)
Swim Ladder
Cleat
Kayak Rack
Finishing & Accessory Connectors
Guardrail
Self Wicking Planter
Bench
Flag Pole
Edge Bumper
Dock Box
............................................................................................................................................................13
.........................................................................................................................................15
................................................................................................................................16
..........................................................................................................................17
.....................................................................................................................................................18
....................................................................................................................................................................19
.......................................................................................................................................................21
..........................................................................................................22
...........................................................................................................................................................23
......................................................................................................................................25
................................................................................................................................................................27
...........................................................................................................................................................28
...................................................................................................................................................29
..........................................................................................................................................................30
1000 (LP) & 2000 (HP) Series Anchoring
Pole Pounder
Pole Remover
Pole Auger
Dead Man Collar
Sti Arm Fitting
Deep Water Hardware
Piling Loop
...................................................................................................................................................31
..................................................................................................................................................32
........................................................................................................................................................33
.............................................................................................................................................34
...............................................................................................................................................35
..................................................................................................................................36
.......................................................................................................................................................37
Connect-A-Port XL5 & XL6®
2000 Series Attachment
Fixed Dock Attachment
Floating Dock Attachment
Side by Side Connecting Kit for Connect-A-Port
Bow Stop Connecting Kit for Connect-A-Port XL5 & 6
Connect-A-Port XL5 & 6 Roller Replacement
Winch
...............................................................................................................................38
................................................................................................................................39
...........................................................................................................................40
..................................................................................42
.......................................................................43
.......................................................................................44
..................................................................................................................................................................45

38
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Connect-A-Dock 2000 Series-High Profile Attachment
Instructions for:
2000 Series Attachment Kit
Step 2
Secure with bolts, washers, and
bushings. Tighten all bolts in the XL6
using 25 lbs/ft (3.46 kg/m) of torque.
Step 1
Determine port location (Front or
Side). Insert 2ooo Series XL6
Connectors into float section
connector slots.
Tools Needed
(1) 9/16” Wrench
Step 3
Continue by hooking the XL6 over
the 2000 Series XL6 Connectors,
shift your body weight to the XL6.
Step 4
Secure with bolts, washers, and
bushings. Tighten all bolts in the XL6
using 25 lbs/ft (3.46 kg/m) of torque.
1
1
3
4

39
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL5 & 6
Front or Side Mounting
Connect-A-Port XL5 & 6 Fixed Dock
Step 3
You will need a pipe long enough to
drive into the ground. If you have a
very secure fixed dock you can
mount the pipe to the dock, but if the
dock is not of the best integrity
mounting to the dock is not
recommended because it can work
the dock loose in a high wake area.
It is recommended that you drive the
pipe in the ground and mount it to a
fixed dock if applicable. Note: pipe
size 2” sch 40 pipe or max dia of
2.375”. (50 Dn mm sch 40).
Tools Needed
9/16” Wrench
Pole Pounder
1
2
Step 1
Slip the XL Pole Connectors into each
of the connector slots.
Step 2
Secure each connector with bolt,
diamond washer and spacer. Tighten
all bolts using 25 lbs/ft (3.46 kg/m) of
torque.

40
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL5 & 6
Front or Side Mounting
Connect-A-Port XL5 & 6 Floating Dock
Step 1
Slip the XL Floating Dock Connectors
into each of the connector slots.
Step 2
Secure each connector with bolt,
diamond washer and spacer.
Tighten all bolts using 25 lbs/ft
(3.46 kg/m) of torque.
Step 3
(a) Insert the hinge black bushing into
the XL Hinge Connector. (b) Place the
Metal Dock Channel over the XL Hinge
Connector and align to the hole
needed for your dock height.
(c) Insert the Hitch Pin thru the Metal
Dock Channel and XL Hinge
Connector. (d) Secure with Hairpin
Cotter clip.
Tools Needed
(1) Drill - 1/4” (6.5 mm) & 7/16“
(11 mm) drill bit
(1) 3/4” (18 mm) Wrench
(2) 9/16” Wrench
Not available in metric
1
3
2
(a)
(c)
(b)
(d)

41
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL5 & 6
Front or Side Mounting
Connect-A-Port XL5 & 6 Floating Dock
Step 1
Slip the XL Floating Dock Connectors
into each of the connector slots.
Step 2
Secure each connector with bolt,
diamond washer and spacer.
Tighten all bolts using 25 lbs/ft
(3.46 kg/m) of torque.
Step 3
(a) Insert the hinge black bushing into
the XL Hinge Connector. (b) Place the
Metal Dock Channel over the XL Hinge
Connector and align to the hole
needed for your dock height.
(c) Insert the Hitch Pin thru the Metal
Dock Channel and XL Hinge
Connector. (d) Secure with Hairpin
Cotter clip.
Tools Needed
(1) Drill - 1/4” (6.5 mm) & 7/16“
(11 mm) drill bit
(1) 3/4” (18 mm) Wrench
(2) 9/16” Wrench Not available in metric
1
3
2
(a)
(c)
(b)
(d)
Connect-A-Port XL5 & 6 Floating Dock
Note: If mounting port to wooden floating dock use 3/8” (9 mm) Lag
Bolts (screw based)
4
5
6
Step 4
(a) Determine XL mounting location.
You may want to put your PWC on
the port at this time to see how the
float set in the water. The entrance
end of the port is high with the craft
on it you will want to raise the front
of the port to give is a slight downhill
appearance for easy roll o.
Remember, if it rolls o too hard the
mount is too low. IF it rolls o too
easy it is too high.
(b) Mark the drill holes and remove
Metal Dock Channel for mounting on
the dock. Recommended 4 to 6
mounting holes.
(b) (a)
(b)
Step 5
Hardware to mount the XL Hinge
Connector not included.
Attaching with Lag Bolts:
Mark location for Drilling the (4) 1/4”
Pilot holes. Drill the holes.
Use 9/16” Wrench to install the 3/8”
Lag Bolts.
Attaching with Bolts, Nuts & Washers:
Mark location for Drilling the (4) 9/16”
Pilot holes. Drill the holes.
Use 3/4” Wrench to install the 1/2”
Bolts, Nuts & Washers.
(a) Drill the holes for the Bolts. (b)
Align Metal Dock Channel to the dock
and secure with hardware.
Step 6
Repeat Steps 3 to 5 for the other
anchoring connection.

42
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL5 & 6
Front or Side Mounting
Connect-A-Port XL5 & 6 Side By Side
Step 2
Secure each connector with bolt,
diamond washer and spacer. Tighten
all bolts using 25 lbs/ft (3.46 kg/m) of
torque.
Step 3
Align the next XL6 with the Side By
Side Connectors. Position yourself
carefully on the XL6 with the
connectors. Continue adding the
next XL6 by placing them over the
Side By Side Connectors.Shift your
body weight to the new XL6.
Step 1
Slip the XL6 Side By Side Connectors
into each of the three connector slots.
Step 4
Secure each connector with bolt,
diamond washer and spacer. Tighten
all bolts using 25 lbs/ft (3.46 kg/m) of
torque.
Tools Needed
(1) 9/16” Wrench
1
2
3
4
Note: Check all bolts every three months or as needed to insure all connector
hardware is securely fastened.

43
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL6
Connect-A-Port XL6 Bow Stop
Step 2
(a) Align the Bow Stop’s feet with the
XL6 with the flat side to the outside of
the port. (b) Insert the bolt and washer
into the four connection points. (c)
Secure the Bow Stop with washer and
nut from the underside of the XL6.
Step 1
(a) Insert the bolt into the washer and
cable loop. Then put the bolt in the
hole of the Bow Stop. (b) Secure the
bolt with washer and nut from the
underside of the Bow Stop.
Tools Needed
(2) 9/16” Wrenches
1
2
(a)
(a)
(b)
(b)
(c)

44
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Instructions for:
Connect-A-Port XL5 & 6
Front or Side Mounting
Connect-A-Port XL Move Rollers
Step 2
(a) Align the roller axle assembly to
XL6 roller slot. Secure with a Dead
Blow Hammer by tapping the axial on
both sides of the roller. The axial
should snap into place.
Wheel Parts
(a) Roller
(b) Axle
(c) Spacer
(d) Axial Cap
Step 1
(a) Insert the Pry Bar under the wheel
axial. (b) Pry upward to release the
axial from the XL6.
Tools Needed
(1) Small Pry Bar
(1) Dead Blow Hammer
1
(a) (b)
2
(a)
(a)
(a)
(b)
(c)
(d)

45
1-877-742-3071 www.connectadock.com
1501OwnerAvenue,Atlantic,IA50022USA
Connect-A-Port Winch
Instructions for:
Connect-A-Port XL 5 & 6
Winch (AKW2000)
3
Step 2
(a) Click the Strap Release. (b) Pull
Strap out to be able to add inside nut.
(c) Attach Wench to the bracket with
bolts, washers and lock washers. Note:
Leave o washer on bolt under the
strap for clearance. Tighten all bolts in
the bracket using 25 lbs/ft (3.46 kg/m)
of torque.
Step 1
(a) Releases the Ratchet Handle (b)
Strap Release (c) Direction Ratchet
Handle travels
Tools Needed
(2) 9/16” Wrenches
Not available in metric
Step 3
Attach Winch and bracket to the port
as shown. Use the 3/8” bolts,
washers and lock washers. Tighten
all bolts in the bracket using 25 lbs/ft
(3.46 kg/m) of torque.
Step 4
Engage Ratchet Handle and Strap
Release and retract strap into a
storage position. Note: See Step 3
illustration for proper strap location.
1
(a)
(b)
(c)
2
(a)
Strap
(b)
(c)

Marine Assembly
Instructions
• Floating Docks
• PWC Docking
Make a connection to Life®
Should you have a warranty claim, we may require that you provide a photograph or, in some cases, return the
Connect-A-Dock part to the place of purchase. In order for warranty to be valid, original sales receipt must
accompany warranty claim. NOTE: Shipping costs are not included in warranty.
