INTRODUCTION
Product Features and Specifications
Specifications
Module Compatibility
NVIDIA® Jetson Nano™(PRODUCTION MODULE ONLY)
NVIDIA® Jetson Xavier™NX (PRODUCTION MODULE ONLY)
NVIDIA® Jetson TX2™NX
Mechanical Dimensions
145mm x 64.5mm
USB Camera
1x USB 3.0 (Connector: USB Type-C)
MIPI Cameras
2x 2-lane MIPI CSI-2
Connector: 1-1734248-5 15-pin FPC 1mm Pitch Connector
Please refer to our Jetson Supported Cameras Page for more information
Camera Misc Interface
1x I2C (Can be used for Lens Control)
4x GPIO (Can be used for Additional Camera Control)
1x Power Output (Can be used for IR LEDs)
Internal Debug Ports
1x HDMI Display Output
Storage
1x microSD Card Slot
1x NVMe Slot (M.2 2280 M-KEY PCIe Based)
Wireless Expansion
1x WiFi Module (M.2 2230 E-KEY)
1x LTE Module (M.2 3042 B-KEY) w/ SIM Card Slot
Rear IO –Ethernet
Please refer to this section for
installation instructions for PoE PD
1x 10/100/1000BASE-T Uplink
PoE IEEE 802.3af-2003 (15.4W) Powered Device (PD)
PoE+ IEEE 802.3at-2009 (25.5W) Powered Device (PD)
Capable of operating on either network
Low Cost PoE Bypass Option Available (NGX003)
Rear IO –USB OTG
1x USB 2.0 OTG for Flashing Capability (Micro USB)
Rear IO –USB UART
1x USB FTDI UART (Micro USB)
Rear IO –Power Input
1x 2.1mm DC Barrel Jack (+12V DC +/-5%)
Rear IO –User Feedback
1x RGB LED
Rear IO - Button
Dual RESET + FLASH Enable Functionality
Operating Temperature
-25°C to +85°C (-13°F to +185°F)
Weight
76g (0.167lbs)
Warranty and Support
1 Year Warranty and Free Support

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 7 of 29
Date: 2021-08-20
Connect Tech’s Photon AI Camera Platform brings a low cost deployable Jetson solution to the market.
Its design includes Power over Ethernet (PoE) 802.3at as well as a lower cost variant without it.
Part Numbers / Ordering Information
Part Number
NGX002
Photon AI Camera Platform w/ PoE PD
NGX003
Photon AI Camera Platform w/ No-PoE PD

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 8 of 29
Date: 2021-08-20
PRODUCT OVERVIEW
Block Diagram

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 9 of 29
Date: 2021-08-20
Connector Locations
TOP VIEW
MIPI CSI-2 (P10A)
USB 3.0 TYPE-C (J2)
MIPI CSI-2 (P10B)
FAN (P8)
HDMI (P12)
Power ON LED
RTC (P14)
M.2 B-Key (P3) M.2 E-Key (P4)
Nano/NX Module Connector (P1)
+12V DC 2.1mm
BARREL JACK (P2)
GIGABIT
ETHERNET/ PoE PD (P7)
RGB LED
RESET/RECOVERY PUSHBUTTON
USB 2.0 FTDI DEBUG (P6)

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 10 of 29
Date: 2021-08-20
BOTTOM VIEW
I2C/GPIO/POWER (P9)
M.2 M-Key (P5)
micoSD CARD/SIM CARD (P11)
USB 2.0 OTG (P13)

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 11 of 29
Date: 2021-08-20
Connector Summary
Designator
Connector
Description
P1
2309413-1
Module Board-To-Board Connector
P2
PJ-002A
+12V DC 2.1mm Barrel Jack Connector
P3
SM3ZS067U310ABR1200
M.2 3042 B-Key 2G/3G/LTE Cellular Module Connector
P4
2199119-4
M.2 2230 E-Key WiFi/Bluetooth Module Connector
P5
SM3ZS067U410AMR1000
M.2 2280 M-Key NVMe SSD Connector
P6
1981568-1
USB 2.0 Micro-B FTDI Console Debug Connector
P7
JXK0-0190NL
RJ-45 Gigabit Ethernet Connector
P8
53047-0410
+5V 4-Position Molex 1.25mm PicoBlade Fan Connector
P9
SM09B-NSHSS-TB
I2C/GPIO/LED JST Connector
P10A
52610-1572
MIPI CSI-2 Camera Connector
P10B
52610-1572
MIPI CSI-2 Camera Connector
P11
1042391430
Dual microSD/SIM Connector
P12
0476591000
HDMI Video Connector
P13
47589-0001
USB 2.0 Micro-AB OTG Connector
P14
53047-0310
RTC Battery Connector

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 12 of 29
Date: 2021-08-20
LED, Jumper & Switch Summary
The switches and jumpers should be set correctly before power up. Jumpers J3 and J4 should be
considered when using Micro USB-B connectors P6 and P13 respectively with an external system.
WARNING: With the NGX002, if connecting and powering via Power Over Ethernet PD connection and
connecting the USB2.0 FTDI debug console (P6), GPIO (P9), HDMI (P12), USB 2.0 OTG (P13) –please refer
to this section to avoid damage to product and equipment
Designator
Switch Description
SW1
DIP Switch Select for PCIe Lanes with M.2 2230 E-Key and M.2 2280 M-Key
SW2
Pushbutton for dual function Reset/Recovery
Designator
LED Description
D25
M.2 2280 M-Key Activity LED
D27
PWM RGB LED
D40
Input Power LED
Note: D40 Power Input LED is only available on Revision E and above
Designator
Switch Description
J3**
P6 Micro-B USB UART Ground Configuration
ON = System Frame GND and P6 Micro-B USB Shield Connected
OFF = System Frame GND And P6 Micro-B USB Shield Disconnected
J4**
P13 Micro-B USB OTG Ground Configuration
ON = System Frame GND and Digital Ground Connected
OFF = 10Mohm resistance between System Frame GND and Digital GND
**Note: J3 and J4 Shield GND Jumpers are only available on Revision F and above for NGX002 and NGX003. Also note that the configuration of J3:ON and J4:OFF will
match the NGX002/NGX002 Revision A-E connectivity.
Note: Please refer to our Product Change Notice CTIU-00035(0.00) for more information on the Jumper Ground Configuration

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 13 of 29
Date: 2021-08-20
DETAILED FEATURE DESCRIPTION
Jetson Module Connector
The NVIDIA Jetson NX modules connect to the Photon AI Camera Platform via a TE Connectivity DDR4
SODIMM 260 Pin connector.
Function
Description
Location
P1
Type
TE Connectivity DDR4 SODIMM 260 Pin
Carrier
Connector
Part Number: 2309413-1
Manufacturer: TE Connectivity
Mating
Connector
Jetson NX Module
Pinout
Refer to NVIDIA System-On-Module
datasheet for pinout details for a specific
module
https://developer.nvidia.com/
embedded/downloads
Board-to-
Module
Standoff
Height
M2.5 x 6.57mm standoffs required between
NVIDIA Jetson NX Modules and Photon AI
Camera Platform
(CTI P/N: 155-0746-000.A)

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 14 of 29
Date: 2021-08-20
USB 2.0 OTG/Host Mode Connector
The Photon AI Camera Platform implements a USB2.0 Micro-AB connector to allow host mode access to
the module or OTG flashing of the module. Please refer to the Jumpers section to ensure you are using
the correct ground configuration for your setup. Please ensure DC power is used when connecting any
externally powered device onto the system as mentioned in the following section
Function
Description
Location
P13
Type
Molex Micro-AB USB Connector
Carrier Connector
Part Number: 0475890001
Manufacturer: Molex
Mating Connector
USB 2.0 Micro-B or Micro-AB Cable
Pinout
Refer to USB Standard
Note 1: A USB Micro-B cable is required for OTG Flashing.
Note 2: A USB Micro-A cable is required for Host Mode.
USB 2.0 FTDI Console Connector
The Photon AI Camera Platform implements a USB2.0 Micro-B connector to allow users console access
to the module through an FTDI interface bridge (USB-Serial) to a desktop computer. Please refer to the
Jumpers section to ensure you are using the correct ground configuration for your setup. Please ensure
DC power is used when connecting any externally powered device onto the system as mentioned in the
following section
Function
Description
Location
P6
Type
TE Connectivity Micro-B USB
Connector
Carrier Connector
Part Number: 1981568-1
Manufacturer: TE Connectivity
Mating Connector
USB 2.0 Micro-B Cable
Pinout
Refer to USB Standard

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 15 of 29
Date: 2021-08-20
HDMI Connector
The NVIDIA Jetson NX modules will output video via the Photon AI Camera Platform vertical HDMI
connector. Please ensure DC power is used when connecting any externally powered device onto the
system as mentioned in the following section
Function
Description
Location
P12
Type
Molex HDMI Vertical Connector
Carrier
Connector
Part Number: 0476591000
Manufacturer: Molex
Mating
Connector
HDMI Cable
Pinout
Refer to HDMI Standard
12V Barrel Jack Connector
The Photon AI Camera Platform has a 2.1mm Barrel Jack connector for +12V, 2.1A power supplies.
Please ensure the Photon AI Camera Platform is powered with a DC source when required as mentioned
in the following section
Function
Description
Location
P2
Type
CUI PJ-002A Barrel Jack Connector
Carrier Connector
Part Number: PJ-002A
Manufacturer: CUI

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 16 of 29
Date: 2021-08-20
GBE RJ45 Ethernet & PoE PD Connector
The NVIDIA Jetson NX modules will allow internet communication via the RJ-45 ethernet connector. GbE
connector supports 10Mbps/ 100Mbps/ 1000Mbps.
The Photon AI Camera Platform can support Power over Ethernet delivery through this connector. As in
all Power Over Ethernet implementations, the Photon AI Camera Platform includes power isolation
transformers; therefore, it has an isolated ground from the power sourcing equipment. The Photon AI
Camera Platform PoE PD version is typically used for remote installations where the only outside
connectivity is the PoE PD connection itself.
Function
Description
Location
P7
Type
Pulse Electronics RJ-45
Ethernet Connector
Carrier Connector
Part Number: JXK0-0190NL
Manufacturer: Pulse Electronics
Mating Connector
Ethernet (Cat5, Cat5e, Cat6, etc.)
Cable
Pinout
Refer to Ethernet Standard
Note 1: PoE PD 802.3af / 802.3at supported on PoE PD version of the Photon AI Camera platform (CTI PN: NGX002)
Note 2: PoE PD is not supported on lower cost non-PoE PD of the Photon AI Camera platform (CTI PN: NGX003)
WARNING: If the Photon AI Camera Platform PoE PD version is powered over PoE in a lab setting or field
service scenario, extreme care must be used when connecting externally powered equipment to P6
(USB), P9 (GPIO), P13 (USB) and P12 (HDMI) to avoid creating ground currents from differences in
potential. Please refer to the following section for more information on connectivity.

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 17 of 29
Date: 2021-08-20
MIPI CSI-2 Connectors
The NVIDIA Jetson NX modules will allow 2-Lane MIPI video input via the vertical FPC connectors. Please
refer to our Jetson Supported Cameras Page for more information on our supported cameras.
Function
Description
Location
P10A, P10B
MIPI Lane
usage
P10A –CSI0
P10B –CSI2
Type
MOLEX FPC Vertical Connector
15 Pin
Carrier
Connector
Part Number: 0526101572
Manufacturer: MOLEX
Pinout
Pin
Description
1
GND
2
CAM_DN0
3
CAM_DP0
4
GND
5
CAM_DN1
6
CAM_DP1
7
GND
8
CAM_CLKN
9
CAM_CLKP
10
GND
11
CAM_PWDN
12
CAM_MCLK
13
I2C0_SCL
14
I2C0_SDA
15
3.3V

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 18 of 29
Date: 2021-08-20
M.2 B-Key Connector
The Photon AI Camera Platform implements an M.2 3042 B-Key for a Cellular Module. Please ensure you
certify the wireless cellular module on your home network before using it on that network.
Function
Description
Location
P3
Type
JAE Electronics M.2 B-Key
Connector
Carrier Connector
Part Number:
SM3ZS067U310ABR1200
Manufacturer: JAE Electronics
Mating Connector
M.2 3042 Cellular Module
Pinout
Refer to M.2 NGFF Standard
Note: Only a USB 2.0 based M.2 3042 B-Key Cellular module can be used with this connector. PCIe is not connected to the M.2
3042 B-Key.
M.2 E-Key Connector
The Photon AI Camera Platform implements an M.2 2230 E-Key for a PCIe x1, USB 2.0 WiFi/Bluetooth
Module.
Function
Description
Location
P4
Type
TE Connectivity M.2 E-Key
Connector
Carrier Connector
Part Number: 2199119-4
Manufacturer: TE Connectivity
Mating Connector
M.2 2230 WiFi/Bluetooth Module
Pinout
Refer to M.2 NGFF Standard
Note: Only a M.2 E-Key or M.2 M-Key can be operated at a time. This is a limitation in the amount of available PCIe lanes from
the Jetson Module.

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 19 of 29
Date: 2021-08-20
M.2 M-Key Connector
The Photon AI Camera Platform implements an M.2 2280 M-Key for a PCIe x4 Gen 2 NVMe. Only a M.2
2280 M-Key or M.2 2230 E-Key can be operated at a time. This is a limitation in the amount of available
PCIe lanes from the Jetson NX module.
Function
Description
Location
P5
Type
JAE Electronics M.2 M-Key
Connector
Carrier
Connector
Part Number:
SM3ZS067U410AMR1000
Manufacturer: JAE
Electronics
Mating
Connector
M.2 2280 NVMe Module
Pinout
Refer to M.2 NGFF
Standard
Note 1: Compatibility with PCIe interface NVMe due to Jetson Module limitation
Note 2: PCIe Gen 2 maximum speed due to Jetson Module limitation
Note 3: Only PCIe based NVMe are compatible due to the hardware configuration. SATA based NVMe will not work.
Dual microSD Card/ Module SIM Card Connector
The Photon AI Camera Platform implements a Dual microSD Card/SIM Card connector. Please ensure
the microSD card used with the system is compatible with speed class supported on the Jetson NX
Module used.
Function
Description
Location
P11
Type
Molex Dual microSD/SIM Card
Connector
Carrier Connector
Part Number: 1042391430
Manufacturer: Molex
Mating Connector
microSD Card, SIM Card
Pinout
Refer to SD Card Standard and SIM
Card Standard
Note: microSD card is on the top, SIM card is on the bottom.

Photon AI Camera Platform
Users Guide
www.connecttech.com
Document: CTIM-00080
Revision: 0.06
Page 20 of 29
Date: 2021-08-20
5V Fan Connector
The Photon AI Camera Platform implements a 4 Position Molex PicoBlade connector for active cooling
capability.
Function
Description
Location
P8
Type
Molex 4 Position 1.25mm PicoBlade
Connector
Carrier
Connector
Part Number: 53047-0410
Manufacturer: Molex
Mating
Connector
Molex 0510210400 PicoBlade
Connector
Pinout
Pin
Description
1
GND
2
+5V
3
FAN_TACH
4
FAN_PWM
RTC Battery Connector
The Photon AI Camera Platform implements a 3 Position Molex PicoBlade connector for an RTC Battery.
Function
Description
Location
P14
Type
Molex 3 Position 1.25mm PicoBlade
Connector
Carrier
Connector
Part Number: 53047-0310
Manufacturer: Molex
Mating
Connector
Part Number: 0510210300
Manufacturer: Molex
Pinout
Pin
Description
1
BAT+
2
NC
3
BAT-
