Consort CSL1LST Use and maintenance manual

Installation & Control Guide for
SL Wireless Controlled Low Surface Temperature Fan Heaters
All electrical appliances produced by the Company are guaranteed for one year against
faulty materials or workmanship. This applies only if the appliance has been used for
purposes in accordance with the instructions provided and has not been connected to an
unsuitable electricity supply, or subject to misuse, neglect, damage or modified or repaired
by any person not authorised by us. This guarantee is offered to you as an extra benefit and
does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the
appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of
printing. In the interest of progress the Company reserve the right to vary specifications from
time to time without notice.
QUALITY SPACE HEATERS
Models
62001230 Iss 02
CSL1LST
CSL1MLST

62001230 Iss 02
Overview
Please read this guide carefully and retain
for future use and maintenance.
This appliance has been designed and
manufactured to the highest international
standards, however, care must be taken
for optimal results and safety. This
appliance also meets the requirements of
EU Directive 2004/106/EC for EMC and
2009/125/EC Directive.
Safety & Care
Our Low Surface Temperature heaters
have been designed and built to the NHS
requirement for safe surface temperatures
which is that no surface which can be
touched by the user will be more than 43
degrees C (at a room temperature of 21
degrees C.) This means that our Low
Surface Temperature heaters out-perform
the European Standard by a significant
margin. The appliance is not intended for
use by persons (including children) with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge unless they have been given
supervision or instruction concerning use of
the appliance by a person responsible for
their safety. Children should be supervised
to ensure that they do not play with the
appliance.
Warning
 Do NOT site the appliance in a corner.
 Do NOT handle the appliance with wet
hands.
 Do NOT use the appliance in workshops
or rooms where excessive dust is
generated or present.
 Ensure that nothing is pushed into any
aperture of this appliance.
 Do NOT touch outlet grille when the
appliance is in use.
 Do NOT cover or restrict any aperture of
the appliance when in use.
 Do NOT use the appliance if damaged.
 Do NOT leave the appliance
unattended where young children are
present.
Thermally Operated Cut-Out
The appliance is fitted with a thermally
operated cut-out (TOC). This is a safety device,
which switches the heater off if, for any reason,
the appliance overheats. The TOC can only be
re-set after the appliance has cooled down. In order
to re-set the TOC, proceed as follows:
 Switch off appliance and leave for
approximately 10 minutes.
 Switch appliance back on and TOC will re-
set.
 Ensure that the appliance is functioning
correctly. If the TOC control operates
again, the appliance should be checked
by a competent electrician.
The heater carries a ‘Do Not Cover’ label to warn
the user that if the appliance is covered, there is a
risk of overheating.
Cleaning
Always disconnect the heater from the mains before
cleaning. The heater should not require any
maintenance, but it is strongly advised that it is kept
clean. An occasional wipe over with a soft cloth is
all that should be necessary.
 Do NOT use metal or furniture polish on any part of
the heater.
 Do NOT touch the heater with wet hands or in any
way bring water into contact with it.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
If Your Heater Does Not Work
 Check that power is available to the heater. The
LED light should be illuminated
 Check that the thermal cut-out has not operated.
Follow the reset instructions given under the
section headed ‘Thermal Operated Cut-out’.
 Check that the fuse in the spur unit has not blown.
This can be done by replacing the fuse with
another suitable fuse.
Should none of the above remedies work, then
telephone the helpline number shown in these
instructions (UK ONLY). Do not attempt to repair the
heater.
Connection to the Main Supply
Electrical installation should be carried out by a
competent installer, preferably registered with NICEIC
(National Inspection Council for Electrical Installation
Contracting) in accordance with the 17th edition of the IEE
Wiring Regulations, (BS.7671), and any relevant Local
Authority Bye-Laws. This heater is fitted with a 3-core mains
supply cable and must be permanently connected to the
electricity supply via a double pole switch having 3mm
gap on each pole. There are no exceptions. A switched
Fused Connection unit to BS.1363. Part 4 is a
recommended mains supply connection accessory to
ensure compliance with safety requirements applicable to
fixed-wiring installation.
Note: When switched on for the first time the appliance
may emit a slight smell. This is purely the evaporation of a
fluid used in the manufacturing process.
WARNING: This appliance must be earthed.
2

Wall mounting
3
SLPB
SLTI
SLVT
Please refer to the SL user and operating instructions for
full operational details.
SL wireless controllers
Operation
The heater must not be located immediately below a fixed socket outlet. The Wall Mounting bracket is packed
separately in the carton. Fit the top mounting brackets to the wall at the height and centers shown in the diagram.
Remove the two feet-securing screws from the base of the heater and use these screws to secure the right-angled
bracket to the base of the rear panel of the heater in the correct holes. These are the holes in the two protruding
lugs. Mount your appliance onto the top brackets via the two slots in the rear panel. Secure the bottom bracket to
the wall as shown.
CSL1(M)LST
62001230 Iss 02
This heater can only be used in conjunction with any SL
wireless controller. Each SL controller can control any
number of heaters providing they are in the RF range.
When the appliance is connected to the mains supply,
the LED indicator will light up green, showing that the
power is available to the unit.
When the heat output has been enabled by a
controller, the LED indicator light will turn red. SLVTB
Top brackets

4
62001230 Iss 02
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone] Email: [e-mail] Web:
www.consortepl.com
Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
BS EN ISO 9001 Registered Company No FM12671
