Consort PLSTi100RX Use and maintenance manual

Installation & Control Guide for
Wireless Controlled PLSTi Low Surface Temperature Fan Heaters
With Intellingent Fan Control
All electrical appliances produced for the Company are guaranteed for one year against faulty
material or workmanship. This applies only if the appliance has been used for purposes in accordance
with the instructions provided and has not been connected to an unsuitable electricity supply, or
subject to misuse, neglect, damage or modified or repaired by any person not authorised by us. This
guarantee is offered to you as an extra benefit and does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of printing. In the
interest of progress the Company reserve the right to vary specifications from time to time without
notice.
QUALITY SPACE HEATERS
Models
66000797 Iss 02
PLSTi100RX, PLSTi150RX/PLSTi150SSRX
Please note:
‘SS’ suffix added to model number denotes Stainless Steel derivative.

66000797 Iss 02
2
Overview
Please read this guide carefully and retain for future
use and maintenance.
This appliance has been designed and manufactured
to the highest international standards, however, care
must be taken for optimal results and safety. This
appliance also meets the requirements of EU Directive
2004/106/EC for EMC and 2009/125/EC Directive.
Safety & Care
Our Low Surface Temperature heaters have been
designed and built to the NHS requirement for safe
surface temperatures which is that no surface which
can be touched by the user will be more than 43
degrees C (at a room temperature of 21 degrees C.)
This means that our Low Surface Temperature heaters
out-perform the European Standard by a significant
margin.
The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
Warning
 Do NOT site the appliance into a corner.
 Do NOT handle the appliance with wet hands.
 Do NOT use the appliance in workshops or rooms
where excessive dust is generated or present.
 Ensure that nothing is pushed into the air outlet of
this appliance.
 Do NOT touch outlet grille when the appliance is in
use.
 Do NOT cover or restrict the appliance when in
use.
 Do NOT use the appliance if damaged.
 Do NOT leave the appliance unattended where
young children are present.
Connection to the Main Supply
Electrical installation should be carried out by a competent
installer, preferably registered with NICEIC (National
Inspection Council for Electrical Installation Contracting) in
accordance with the 17 edition of the IEE Wiring Regulations,
(BS.7671), and any relevant Local Authority Bye-Laws. This
heater is fitted with a 3-core mains supply cable and should
be permanently connected to the electricity supply via a
double pole switch having 3mm gap on each pole.
A switched Fused Connection unit to BS.1363. Part 4 is a
recommended mains supply connection accessory to
ensure compliance with safety requirements applicable to
fixed-wiring installation.
Note: When switched on for the first time the appliance may
emit a slight smell. This is purely the evaporation of a fluid
used in the manufacturing process.
WARNING: This appliance must be earthed.
Thermally Operated Cut-Out
The appliance is fitted with a thermally operated cut-out
(TOC). This is a safety device, which switches the heater off
if, for any reason, the appliance overheats. The TOC can
only be re-set after the appliance has cooled down. In
order to re-set the TOC, proceed as follows:
 Switch off appliance and leave for approximately
10 minutes.
 Switch appliance back on and the TOC will re-set.
 Ensure that the appliance is functioning correctly.
If the TOC control operates again, the appliance
should be checked by a competent electrician.
The heater carries a ‘Do Not Cover’ label to warn the user
that if the appliance is covered, there is a risk of
overheating.
Cleaning
Always disconnect the heater from the mains before
cleaning. The heater should not require any maintenance,
but it is strongly advised that it is kept clean. An occasional
wipe over with a soft cloth is all that should be necessary.
 Do NOT use metal or furniture polish on any part of the
heater.
 Do NOT touch the heater with wet hands or in any way
bring water into contact with it.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.

66000797 Iss 02
Installation
MILLIMETRES
WATTS A B C D/E
PLSTi100RX 1000 640 430 364 138
PLSTi150RX/SSRX 1500 892 430 616 138
3

66000797 Iss 02
Controls
When the appliance is connected to the mains
supply and the wall socket is switched ‘ON’ the
mains neon indicator will light, showing that the
power is available to the unit.
4
Intelligent Fan Control
The intelligent fan control incorporates one of the
latest low energy consumption EC motors. This allows
the heater to operate quietly, whilst still providing the
best possible levels of comfort.
The intelligent fan control is only activated when the
heat is switched on. If the heater is running in fan/
boost mode only (heat switched off), then the fan
will operate at a fixed speed.
When activated, the intelligent fan control detects
the temperature of the room. Depending on which
heat mode is activated, it will calculate the best
possible airflow temperature and will adjust the fan
speed accordingly.
NOTE: When turning the heater on, or changing heat
mode or fan speed mode, the fan will respond
accordingly after a small time delay.
Mounting
This unit is for wall mounting only. It is designed to be very
quiet in operation if mounted correctly. It must be fitted using
the wall bracket supplied which has been specially designed
to minimise noise levels. Care must be taken when handling
the bracket not to bend or distort it.
When fitting more than one heater into a room we would
recommend that they are sited on the same wall to optimise
airflow and ensure quiet operation.
MOUNTING ON APLASTERBOARD WALL
•Ensure at least one of the wall brackets is secured
to the timber frame of the studded wall by using
standard wood screws.
•Where the bracket is fitted onto plasterboard only,
ensure plasterboard fixings are used. Standard wall
plugs will not be suitable.
•Where possible mount the heater(s) on an outside
wall to inhibit transfer of sound within the building.
NB: Failure to follow the instructions and recommendations
provided could result in increased noise levels.
Operation
This heater can only be used when connected
to a CRX2 wireless programmable controller.
Each CRX2 can control any number of heaters.
CRX2
wireless
controller
Please refer to the CRX2 installation and con-
trol guide for full operational details.
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort product please contact our Helpline:
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone] Email: [email protected] Web: www.consortepl.com
Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
BS EN ISO 9001 Registered Company No FM12671
