Consort WMH3RX Manual

58000361 Iss 02
MAINTENANCE
ALWAYS ENSURE THAT THE MAIN EXTERNAL ELECTRICAL SUPPLY IS SWITCHED OFF BEFORE ANY
MAINTENANCE IS CARRIED OUT.
To obtain the best results from the heater, it is necessary to avoid any accumulation of dust or dirt
within the unit or on the air inlet grille. The unit should be cleaned regularly.
SAFETY
This equipment has been designed and manufactured to the highest international standards but, like
all electrical appliances which are operated by mains voltage, care must be taken if you are to obtain the
best results and safety is to be assured.
NOTE: The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do NOT use this appliance in bathrooms or where similar conditions of excessive moisture are
present.
No NOT handle the appliance with wet hands.
Do NOT use the appliance in an enclosed room so small that the heater will generate ambient
temperatures in excess of 300C.
Do NOT use the appliance with young children unattended.
Do NOT use the appliance in rooms where excessive dust is generated or present.
Do NOT touch THE outlet grille when appliance is in use.
Do NOT cover or restrict any aperture of the appliance when in use.
Do NOT use the appliance if damaged.
If the appliance has been kept in freezing conditions, run at cold/fan setting for 5 minutes before
using heat settings.
This appliance meets the requirements of EU Directive 98/336/EEC for EMC.
GUARANTEE
This guarantee is offered to you as an extra benefit and does not affect your legal rights.
All electrical appliances produced for the Company are guaranteed for one year against faulty
material or workmanship. This applies only if the appliance has been used for purposes in accordance
with the instructions provided and has not been connected to an unsuitable electricity supply, or subject
to misuse, neglect, damage or modified or repaired by any person not authorised by us.
The correct electricity supply voltage is shown on the rating label attached to the appliance.
Please retain your receipt as proof of purchase.
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort product, or should you require service or
repair, please contact our Helpline:
Operating hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone]
Email: technic[email protected] Web: www.consortepl.com
Quality Space Heaters
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS FOR
CHELSEA WALL MOUNTED FAN HEATER
FOR WIRELESS ELECTRONIC CONTROLS
Catalogue Numbers: WMH3RX (brushed aluminium fascia)
PLEASE RETAIN THIS LEAFLET FOR FUTURE MAINTENANCE

58000361 Iss 2
INSTALLATION
Ensure the electricity supply is disconnected from any relevant fixed wiring before
commencing the installation. The supply circuit must be adequate for the input of the
appliance and must be protected by a 13 Amp fuse.
The heater must not be located immediately below a fixed socket outlet.
There must be a minimum clearance of 600mm above the heater.
CONNECTION TO THE MAIN SUPPLY
Electrical installation should be carried out by a competent installer, preferably
registered with NICEIC (National Inspection Council for Electrical Installation Contracting) in
accordance with the 16 edition of the IEE Wiring Regulations, (BS.7671: 1992), and any
relevant Local Authority Bye-Laws.
This heater is fitted with a 3-core mains supply cable and should be permanently
connected to the electricity supply via a double pole switch having 3mm gap on each pole.
A switched fused connection unit to BS.1363 Part 4 is a recommended mains supply
connection accessory to ensure compliance with safety requirements applicable to a fixed-
wiring installation.
PROCEDURE
1. Remove the front cover (2 screws on the side and 2 screws on the bottom).
2. Mark top 2 screw fixing positions ‘A’ in accordance with the dimension shown on the
diagram. The unit must be screwed to the wall with 3 screws through the holes provided
in the case. Drill 2 holes in the wall to suit No 10 wood screws (round Head) and insert
wall plugs. At the top 2 screw positions ‘A’ screws can now be screwed in until the
heads are approximately 5mm from the wall. The unit can now be hung on these two
screws and the position of the third bottom fixing marked on the wall. Remove the unit
from the wall and drill a third fixing hole in the position marked and insert a wall plug.
The unit can now be hung on the wall and the third screw screwed in. Before tightening
all three screws ensure the unit is horizontal.
3. Refit front cover. Ensure grille bars internal/external are spaced equally.
OPERATION
This heater can only be used when connected to a CRX2 wireless programmable timer.
Each CRX2 can control any number of heaters. The heater has an indicator light positioned
behind the fascia panel on the top right side. The light may be:
Green -when no heat is needed
Yellow -when some heat is needed to maintain the room temperature
Red -when the heater is on full power
Fast Flashing Red - when the heater has overheated and the Electronic Safety Control
has switched the heater off.
Please refer to the CRX2 user and operating instructions for full operational details.
ELECTRONIC SAFETY CONTROL
The appliance is fitted with an Electronic Safety Control (ES). This is a safety device,
which switches the heater off if, for any reason, the appliance overheats. Overheating is
indicated by a fast flashing red light. The ES control can only be re-set after the appliance
has cooled down. In order to re-set the ES control, proceed as follows:
Switch the appliance off at the mains by using the isolator switch and leave to cool
down for approximately 5 minutes.
Switch appliance back on and the ES control will re-set.
Ensure that the appliance is functioning correctly. If the ES control operates again,
the appliance should be checked by a competent electrician.
