Consort CN2FSLT Use and maintenance manual

Installation & Control Guide for
SL Wireless Controlled Fan Convector Heaters
All electrical appliances produced by the Company are guaranteed for one year against
faulty materials or workmanship. This applies only if the appliance has been used for
purposes in accordance with the instructions provided and has not been connected to an
unsuitable electricity supply, or subject to misuse, neglect, damage or modified or repaired
by any person not authorised by us. This guarantee is offered to you as an extra benefit and
does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the
appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of
printing. In the interest of progress the Company reserve the right to vary specifications from
time to time without notice.
QUALITY SPACE HEATERS
Model
62001251 Iss 02
CN2FSLT
CN2FSL

62001251 Iss 02
Overview
Please read this guide carefully and retain
for future use and maintenance.
This appliance has been designed and
manufactured to the highest international
standards, however, care must be taken
for optimal results and safety. This
appliance also meets the requirements of
EU Directive 2004/106/EC for EMC and
2009/125/EC Directive.
Safety & Care
The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for their
safety. Children should be supervised to
ensure that they do not play with the
appliance.
Warning
 Do NOT site the appliance in a corner.
 Do NOT handle the appliance with wet
hands.
 Do NOT use the appliance in workshops
or rooms where excessive dust is
generated or present.
 Ensure that nothing is pushed into any
aperture of this appliance.
 Do NOT touch outlet grille when the
appliance is in use.
 Do NOT cover or restrict any aperture of
the appliance when in use.
 Do NOT use the appliance if damaged.
 Do NOT leave the appliance
unattended where young children are
present.
Thermally Operated Cut-Out
The appliance is fitted with a thermally
operated cut-out (TOC). This is a safety device,
which switches the heater off if, for any reason,
the appliance overheats. The TOC can only be
re-set after the appliance has cooled down. In
order to re-set the TOC, proceed as follows:
 Switch off appliance and leave for
approximately 10 minutes.
 Switch appliance back on and TOC
will re-set.
 Ensure that the appliance is functioning
correctly. If the TOC control operates
again, the appliance should be checked
by a competent electrician.
The heater carries a ‘Do Not Cover’ label to warn
the user that if the appliance is covered, there is a
risk of overheating.
Cleaning
Always disconnect the heater from the mains before
cleaning. The heater should not require any
maintenance, but it is strongly advised that it is kept
clean. An occasional wipe over with a soft cloth is
all that should be necessary.
 Do NOT use metal or furniture polish on any part of
the heater.
 Do NOT touch the heater with wet hands or in any
way bring water into contact with it.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
If Your Heater Does Not Work
 Check that power is available to the heater. The
LED light should be illuminated
 Check that the thermal cut-out has not operated.
Follow the reset instructions given under the
section headed ‘Thermally Operated Cut-out’.
 Check that the fuse in the spur unit has not blown.
This can be done by replacing the fuse with
another suitable fuse.
Should none of the above remedies work, then
telephone the helpline number shown in these
instructions (UK ONLY). Do not attempt to repair the
heater.
Connection to the Main Supply
Electrical installation should be carried out by a
competent installer, preferably registered with
NICEIC (National Inspection Council for Electrical
Installation Contracting) in accordance with the 17th
edition of the IEE Wiring Regulations, (BS.7671), and
any relevant Local Authority Bye-Laws. This heater is
fitted with a 3-core mains supply cable and must be
permanently connected to the electricity supply via
a double pole switch having 3mm gap on each
pole. There are no exceptions. A switched Fused
Connection unit to BS.1363. Part 4 is a recommended
mains supply connection accessory to ensure
compliance with safety requirements applicable to
fixed-wiring installation.
Note: When switched on for the first time the
appliance may emit a slight smell. This is purely the
evaporation of a fluid used in the manufacturing
process.
WARNING: This appliance must be earthed.
2

3
SLPB SLTI
SLVT
Please refer to the SL user and operating instructions for full operational details.
SL wireless controllers
62001251 Iss 02
This heater can only be used in conjunction with any SL wireless controller. Each SL controller can
control any number of heaters providing they are in the RF range.
Operation
When the appliance is connected to the mains supply, the LED indicator will light up green, showing
that the power is available to the unit.
When the heat output has been enabled by a controller, the LED indicator light will turn red.
Variable Thermostat ( only for CN2FSLT model )
The heater is fitted with a variable thermostat which works in conjunction with the SL controllers. This
allows the comfort room temperature set by the SL controller to be lowered - it can not increase the
comfort temperature. The adjusted comfort temperature is only applied to an individual heater not to
any other heater controlled by the SL controller.
If the comfort temperature has not been enabled on the SLPB controller the variable thermostat can set
the operating temperature between 5°C and 31°C when the button on the SLPB controller has been
pressed.
The variable thermostat is located on the right hand end side of the heater, behind a cover. The
thermostat knob is numbered. The lower the number set the cooler the operating set back temperature
becomes.
Note frost protection is enabled through the SL controller only, and not by the variable thermostat. By
setting the variable thermostat to the frost symbol you have set the comfort temperature to 5°C, this
would also lower the operating set back temperature should the SL controller set back temperature be
set at a higher temperature.
SLVTB

4
62001251 Iss 02
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort product please contact our Helpline:
Consort Equipment Products Limited
Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT
Tel: [phone] Fax: [phone] Email: [e-mail] Web: www.consortepl.com
Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm
BS EN ISO 9001 Registered Company No FM12671
The heater must not be located immediately below a fixed socket outlet. The Wall
Mounting bracket is packed separately in the carton. Fit the top mounting brackets
to the wall at the height and centers shown in the diagram.
Remove the two feet-securing screws from the base of the heater and use these
screws to secure the right-angled bracket to the base of the rear panel of the heater
in the correct holes. These are the holes in the two protruding lugs. Mount your appli-
ance onto the top brackets via the two slots in the rear panel. Secure the bottom
brackets to the wall as shown.
Wall mounting
